Introduction to Apache Flink @ Current 2022

Transcript

1. Introduction to
   Apache Flink
   Robert Metzger, Staff Engineer @ decodable
   Apache Flink Committer and PMC Chair


   View Slide

2. What is Apache Flink?
   ● Data processing engine for low latency, high throughput stream processing
   ● Open source at the Apache Software Foundation, one of the biggest projects there
   ● Wide industry adoption, various hosted services available
   https://flink.apache.org/poweredby.html


   View Slide

3. Common use-cases for Apache Flink
   Categories:
   ● Real-time reporting / dashboards
   ● Low-latency alerting, notifications, promotions etc.
   ● Materialized view maintenance, caches
   ● Real-time cross-database sync, lookup joins, windowed joins, aggregations
   ● Machine learning: model serving, feature engineering
   ● Change data capture, data integration
   Examples:
   ● Stripe: CDC use-cases such as Stripe Dashboard, Stripe Search, Financial Reporting
   ● Uber: Ads on Uber Eats
   ● Netflix: Real-time product metrics (viewing session duration, clickpaths, …)
   https://flink.apache.org/poweredby.html


   View Slide

4. Properties of Apache Flink
   Low Cost
   Low Latency
   High throughput
   Efficient
   real-time
   Easy to build
   Applications
   Declarative APIs
   SQL
   Debuggability
   Observability
   Python
   Integrations and
   Connectors
   Kafka
   Kubernetes
   AWS Kinesis
   AWS S3
   Pulsar
   Change data capture
   Joins
   Aggregations
   Avro
   JSON Parquet
   Easy to operate
   Community &
   Documentation


   View Slide

5. Focus of the upcoming slides:
   Properties of Apache Flink
   Low Cost
   Low Latency
   High throughput
   Efficiency
   In real-time
   Easy to build
   Applications
   Declarative APIs
   SQL
   Debuggability
   Observability
   Python
   Integrations and
   Connectors
   Kafka
   Kubernetes
   AWS Kinesis
   AWS S3
   Pulsar
   Change data capture
   Joins
   Aggregations
   Avro
   JSON Parquet
   Easy to operate
   Community &
   Documentation


   View Slide

6. Flink Application Development
   ● Flink offers 3 underlying primitives: events, state, time
   ● Events in a dataflow:
   ● Flink takes care of efficient, parallel execution in a cluster
   Easy to build
   Applications
   Declarative APIs
   SQL
   Python
   Joins
   Aggregations
   Community &
   Documentation
   Data Source
   Data
   Aggregation
   Data Sink
   partition
   by key


   View Slide

7. Flink Application Development
   ● Flink offers 3 underlying primitives: events, state, time
   Easy to build
   Applications
   Declarative APIs
   SQL
   Python
   Joins
   Aggregations
   Community &
   Documentation
   Data
   Source
   Data
   Aggreg
   ation
   Data
   Sink
   partition
   by key
   Src
   Src
   Agg
   Agg
   Sink


   View Slide

8. Flink Application Development
   ● Flink offers 3 underlying primitives: events, state, time
   ● State:
   ● Flink guarantees that state is always available, by backing it up to cheap
   storage
   ● Flink guarantees exactly-once semantics for state
   Easy to build
   Applications
   Declarative APIs
   SQL
   Python
   Joins
   Aggregations
   Community &
   Documentation
   Data Source
   Current
   Kafka reader
   offsets
   Data
   Aggregation
   Current
   aggregates
   (e.g. count
   by key)
   Data Sink
   Pending
   Kafka
   transaction
   data
   partition
   by key
   Cheap,
   durable
   storage
   (S3)
   Checkpointing


   View Slide

9. Flink Application Development
   ● Flink offers 3 underlying primitives: events, state, time
   ● Time: event time and watermarks
   Easy to build
   Applications
   Declarative APIs
   SQL
   Python
   Joins
   Aggregations
   Community &
   Documentation
   9am
   10am
   11am
   {id: 15, op: logout, time: “9:33”}
   {id: 299, op: add, time: “10:01”}
   {id: 2, op: logout, time: “10:29”}
   {id: 2, op: update, time: “9:48”}
   {id: 74, op: login, time: “10:36”}
   {id: 81, op: login, time: “11:15”}
   Stream of Events: Window Operator:
   → Events are arriving out of order


   View Slide

10. Flink Application Development
    ● Flink offers 3 underlying primitives: events, state, time
    ● Time: event time and watermarks
    Easy to build
    Applications
    Declarative APIs
    SQL
    Python
    Joins
    Aggregations
    Community &
    Documentation
    9am
    10am
    11am
    {id: 15, op: logout, time: “9:33”}
    {id: 299, op: add, time: “10:01”}
    {id: 2, op: update, time: “9:48”}
    {id: 74, op: login, time: “10:36”}
    {id: 81, op: login, time: “11:15”}
    {id: 2, op: logout, time: “10:29”}
    Window Operator
    with event-state:
    When has an
    hourly window
    seen all events?
    → Out-of-order events: buffer them in the window operator


    View Slide

11. Flink Application Development
    ● Flink offers 3 underlying primitives: events, state, time
    ● Time: event time and watermarks
    Easy to build
    Applications
    Declarative APIs
    SQL
    Python
    Joins
    Aggregations
    Community &
    Documentation
    9am
    10am
    11am
    {id: 15, op: logout, time: “9:33”}
    {id: 299, op: add, time: “10:01”}
    {id: 2, op: logout, time: “10:29”}
    {id: 2, op: update, time: “9:48”}
    Stream of Events: Window Operator:
    When has an
    hourly window
    seen all events?
    → Watermarks
    Watermark time: “10:11”}
    {id: 74, op: login, time: “10:36”}
    {id: 81, op: login, time: “11:15”}
    Triggers Window
    Processing
    Watermark = virtual
    clock for event time


    View Slide

12. Application Development: APIs
    Easy to build
    Applications
    Declarative APIs
    SQL
    Python
    Joins
    Aggregations
    Community &
    Documentation
    This slide is copied from “Change Data Capture with Flink SQL and Debezium” a presentation at DataEngBytes by Marta Paes
    https://noti.st/morsapaes/liQzgs/change-data-capture-with-flink-sql-and-debezium


    View Slide

13. Flink SQL example
    Easy to build
    Applications
    Declarative APIs
    SQL
    Python
    Joins
    Aggregations
    Community &
    Documentation
    Defining an input:
    SELECT window_start,
    window_end,
    COUNT(*)
    FROM TABLE(
    TUMBLE(TABLE kafka_example,
    DESCRIPTOR(`timestamp`),
    INTERVAL '1' SECOND))
    GROUP BY window_start, window_end
    CREATE TABLE kafka_example (
    `user_id` BIGINT,
    `item_id` BIGINT,
    `behavior` STRING,
    `timestamp` TIMESTAMP(3)
    ) WITH (
    'connector' = 'kafka',
    'topic' = 'user_behavior',
    'bootstrap.servers' = 'host:9092',
    'group.id' = 'testGroup',
    'format' = 'csv'
    )
    Running a tumbling-window
    streaming pipeline:


    View Slide

14. Process Function
    Easy to build
    Applications
    Declarative APIs
    SQL
    Python
    Joins
    Aggregations
    Community &
    Documentation
    public class MyFunction extends KeyedProcessFunction> {
    /** The state that is maintained by this process function */
    private ValueState state;
    @Override
    public void processElement(String value, Context ctx, Collector> out) throws Exception {
    // set the state's timestamp to the record's assigned event time timestamp
    current.lastModified = ctx.timestamp();
    // write the state back
    state.update(current);
    // schedule the next timer 60 seconds from the current event time
    ctx.timerService().registerEventTimeTimer(current.lastModified + 60000);
    }
    @Override
    public void onTimer(long timestamp, OnTimerContext ctx, Collector> out) throws Exception {
    // do stuff with time
    }
    }


    View Slide

15. Next slide:
    Properties of Apache Flink
    Low Cost
    Low Latency
    High throughput
    Efficiently
    In real-time
    Easy to build
    Applications
    Declarative APIs
    SQL
    Debuggability
    Observability
    Python
    Integrations and
    Connectors
    Kafka
    Kubernetes
    AWS Kinesis
    AWS S3
    Pulsar
    Change data capture
    Joins
    Aggregations
    Avro
    JSON Parquet
    Easy to operate
    Community &
    Documentation


    View Slide

16. Efficiency & Performance
    ● Highly-optimized engine, battle tested: Pinterest runs Flink at 300M messages per
    second (150TB/s)
    ● Examples
    ○ State and checkpointing
    ■ Scale state beyond memory using build-in RocksDB statebackend
    ■ Fast, incremental, asynchronous checkpoints
    ○ Network stack (Netty)
    ■ Native backpressure support, optimized for both latency and throughput
    ○ SQL
    ■ Optimized using Apache Calcite, micro-batched aggregations, skew handling,
    efficient internal data format
    Low Cost
    Low Latency
    High throughput
    Efficiency
    In real-time
    Source: https://www.slideshare.net/FlinkForward/flink-powered-stream-processing-platform-at-pinterest


    View Slide

17. Next slide:
    Properties of Apache Flink
    Low Cost
    Low Latency
    High throughput
    Efficiently
    In real-time
    Easy to build
    Applications
    Declarative APIs
    SQL
    Debuggability
    Observability
    Python
    Integrations and
    Connectors
    Kafka
    Kubernetes
    AWS Kinesis
    AWS S3
    Pulsar
    Change data capture
    Joins
    Aggregations
    Avro
    JSON Parquet
    Easy to operate
    Community &
    Documentation


    View Slide

18. Integrations and Connectors
    Deployment
    Formats
    Data Connectors
    Observability
    Various Kubernetes
    deployment options:
    ● Operator
    ● Native integration
    ● DIY
    DIY Deployments:
    Bash scripts,
    library-style,
    MiniCluster, etc.
    Hadoop YARN is still
    around


    View Slide

19. Operations
    ● Autoscaling Flink via Kubernetes Operator, Flink Reactive Mode
    ● Persist in-flight state via Savepoints, then upgrade Flink version, Flink application,
    investigate/rewrite state
    ● Observability: Latency-tracking, RocksDB metrics, operator/task/JVM-level performance
    metrics, Flame Graph UI, Backpressure monitoring
    ● Local Debugging/Profiling: run the cluster code from your IDE or Unit tests
    ● High Availability with Zookeeper or K8s etcd


    View Slide

20. Flink Q&A
    Low Cost
    Low Latency
    High throughput
    Efficiency
    In real-time
    Easy to build
    Applications
    Declarative APIs
    SQL
    Debuggability
    Observability
    Python
    Integrations and
    Connectors
    Kafka
    Kubernetes
    AWS Kinesis
    AWS S3
    Pulsar
    Change data capture
    Joins
    Aggregations
    Avro
    JSON Parquet
    Easy to operate
    Community &
    Documentation
    Follow me on Twitter: @rmetzger_
    Visit the decodable booth (G5) to
    discuss Flink and Stream Processing


    View Slide
