Uncoiling the COIL Vol 2 - Droidcon Italy

Image loading is hard but luckily this problem has already been addressed on Android. There are many libraries out there that handle image loading seamlessly. COIL is the new kid to the club and you may be wondering why do we need another image loading library?

COIL is Kotlin first library backed by Kotlin Coroutines. It gives you an easy and concise API to deal with image loading. Oh and also it takes less space! In a nutshell, it's an easy to use, fast, lightweight, and modern library.

This talk will address
- Why you should consider this library for image loading?
- Understanding its API.
- How it works? by covering its entire image loading pipeline.

By the end, you'll walk away with the advantages of using COIL and its image loading pipeline.

Transcript

1. Uncoiling the COIL - Vol 2
   @viradiya_sagar
   Understanding modern image loading on Android
   Android at


   View Slide

2. We are hiring!
   https://careers.deliveryhero.com/global/en


   View Slide

3. COIL 2.0
   Alpha02


   View Slide

4. Agenda
   ● What is COIL?
   ● Why COIL?
   ● How COIL?
   ● Image loading pipeline
   ● Caching


   View Slide

5. What is COIL?


   View Slide

6. What is COIL?
   ● COroutine Image Loader


   View Slide

7. What is COIL?
   ● COroutine Image Loader
   ● An image loading library for android (Another? 🤔)


   View Slide

8. Why COIL?
   ● Modern


   View Slide

9. Why COIL?
   ● Modern
   ● Easy to use


   View Slide

10. Why COIL?
    ● Modern
    ● Easy to use
    ● Lightweight


    View Slide

11. Why COIL?
    ● Modern
    ● Easy to use
    ● Lightweight
    ● Fast


    View Slide

12. API
    val imageRequest = ImageRequest.Builder(context)
    .data("https://www.example.com/image.jpg")
    .crossfade(true)
    .target(imageView)
    .build()


    View Slide

13. API
    val imageLoader = context.imageLoader
    OR
    val imageLoader = ImageLoader.Builder(context)
    .availableMemoryPercentage(0.25)
    .crossfade(true)
    .build()


    View Slide

14. API
    val disposable = imageLoader.enqueue(imageRequest)


    View Slide

15. Kotlin syntactic sugar
    // URL
    imageView.load("https://www.example.com/image.jpg")
    // Resource
    imageView.load(R.drawable.image)
    // File
    imageView.load(File("/path/to/image.jpg"))
    // And more...


    View Slide

16. Kotlin syntactic sugar
    imageView.load("https://www.example.com/image.jpg")


    View Slide

17. Kotlin syntactic sugar
    imageView.load("https://www.example.com/image.jpg") {
    crossfade(true)
    placeholder(R.drawable.image)
    transformations(CircleCropTransformation())
    }


    View Slide

18. Imperative style
    // Coroutine scope
    val request = ImageRequest.Builder(context)
    .data("https://www.example.com/image.jpg")
    .build()
    val result = imageLoader.execute(request) // Suspends the execution
    val drawable = result.drawable


    View Slide

19. Jetpack Compose Support
    Image(
    painter = rememberImagePainter("https://www.example.com/image.jpg"),
    contentDescription = null,
    modifier = Modifier.size(128.dp)
    )


    View Slide

20. Jetpack Compose Support
    Image(
    painter = rememberImagePainter(
    data = "https://www.example.com/image.jpg",
    builder = {
    transformations(CircleCropTransformation())
    crossfade(true)
    }
    ),
    contentDescription = null,
    modifier = Modifier.size(128.dp)
    )


    View Slide

21. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult


    View Slide

22. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult


    View Slide

23. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult
    data: T


    View Slide

24. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult
    data: T data: T


    View Slide

25. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult
    data: T data: T data: M


    View Slide

26. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult
    data: T data: T data: M
    FetchResult


    View Slide

27. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult
    data: T data: T data: M
    FetchResult
    DecodeResult


    View Slide

28. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult
    data: T data: T data: M
    FetchResult
    DecodeResult
    ErrorResult


    View Slide

29. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult
    data: T data: T data: M
    FetchResult
    DecodeResult
    ErrorResult


    View Slide

30. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult
    data: T data: T data: M
    FetchResult
    DecodeResult
    ErrorResult


    View Slide

31. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult


    View Slide

32. ImageLoader
    ● A service class responsible for executing and managing
    entire pipeline.


    View Slide

33. ImageLoader
    ● A service class responsible for executing and managing
    entire pipeline.
    ● Takes ImageRequest.


    View Slide

34. ImageLoader
    ● A service class responsible for executing and managing
    entire pipeline.
    ● Takes ImageRequest.
    ● COIL provides singleton (Recommended)


    View Slide

35. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult
    data: T


    View Slide

36. Interceptor


    View Slide

37. Interceptor
    ● Allows you to observe, transform, short circuit or retry
    request


    View Slide

38. Interceptor
    ● Allows you to observe, transform, short circuit or retry
    request
    ● You can wrap the pipeline with your custom logic


    View Slide

39. Interceptor
    ● Allows you to observe, transform, short circuit or retry
    request
    ● You can wrap the pipeline with your custom logic
    ● Inspired from OKHttp’s interceptor


    View Slide

40. class CustomCacheInterceptor(
    private val context: Context,
    private val cache: LruCache
    ) : Interceptor {
    override suspend fun intercept(chain: Interceptor.Chain): ImageResult {
    val value = cache.get(chain.request.data.toString())
    if (value != null) {
    return SuccessResult(
    drawable = value.bitmap.toDrawable(context),
    request = chain.request,
    metadata = TODO()
    )
    }
    return chain.proceed(chain.request)
    }
    }


    View Slide

41. class CustomCacheInterceptor(
    private val context: Context,
    private val cache: LruCache
    ) : Interceptor {
    override suspend fun intercept(chain: Interceptor.Chain): ImageResult {
    val value = cache.get(chain.request.data.toString())
    if (value != null) {
    return SuccessResult(
    drawable = value.bitmap.toDrawable(context),
    request = chain.request,
    metadata = TODO()
    )
    }
    return chain.proceed(chain.request)
    }
    }


    View Slide

42. class CustomCacheInterceptor(
    private val context: Context,
    private val cache: LruCache
    ) : Interceptor {
    override suspend fun intercept(chain: Interceptor.Chain): ImageResult {
    val value = cache.get(chain.request.data.toString())
    if (value != null) {
    return SuccessResult(
    drawable = value.bitmap.toDrawable(context),
    request = chain.request,
    metadata = TODO()
    )
    }
    return chain.proceed(chain.request)
    }
    }


    View Slide

43. class CustomCacheInterceptor(
    private val context: Context,
    private val cache: LruCache
    ) : Interceptor {
    override suspend fun intercept(chain: Interceptor.Chain): ImageResult {
    val value = cache.get(chain.request.data.toString())
    if (value != null) {
    return SuccessResult(
    drawable = value.bitmap.toDrawable(context),
    request = chain.request,
    metadata = TODO()
    )
    }
    return chain.proceed(chain.request)
    }
    }


    View Slide

44. class CustomCacheInterceptor(
    private val context: Context,
    private val cache: LruCache
    ) : Interceptor {
    override suspend fun intercept(chain: Interceptor.Chain): ImageResult {
    val value = cache.get(chain.request.data.toString())
    if (value != null) {
    return SuccessResult(
    drawable = value.bitmap.toDrawable(context),
    request = chain.request,
    metadata = TODO()
    )
    }
    return chain.proceed(chain.request)
    }
    }


    View Slide

45. Plugin custom interceptor
    val imageLoader = ImageLoader.Builder(context)
    .components {
    add(CustomCacheInterceptor())
    }
    .build()


    View Slide

46. EngineInterceptor
    ● The last interceptor in the chain


    View Slide

47. EngineInterceptor
    ● The last interceptor in the chain
    ● Responsible for checking in memory cache


    View Slide

48. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult
    data: T data: T


    View Slide

49. Mapper
    ● Allows you to add support for custom data types


    View Slide

50. Mapper - Example
    data class Item(
    val id: Int,
    val imageUrl: String,
    val price: Int,
    val weight: Double
    )
    class ItemMapper : Mapper {
    override fun map(data: Item, options: Options) = data.imageUrl
    }


    View Slide

51. Mapper - Example
    data class Item(
    val id: Int,
    val imageUrl: String,
    val price: Int,
    val weight: Double
    )
    class ItemMapper : Mapper {
    override fun map(data: Item, options: Options) = data.imageUrl
    }


    View Slide

52. Mapper - Example
    imageView.load(item)


    View Slide

53. Plugin custom mapper
    val imageLoader = ImageLoader.Builder(context)
    .components {
    add(ItemMapper())
    }
    .build()


    View Slide

54. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult
    data: T data: T data: M


    View Slide

55. Fetcher
    ● Translates data into either ImageSource or Drawable


    View Slide

56. Fetcher
    ● Translates data into either ImageSource or Drawable
    ● Built-in fetchers
    ○ AssetUriFetcher
    ○ ContentUriFetcher
    ○ FileFetcher
    ○ HttpFetcher


    View Slide

57. Custom Fetcher
    interface Fetcher {
    suspend fun fetch(): FetchResult?
    fun interface Factory {
    fun create(data: T, options: Options, imageLoader: ImageLoader): Fetcher?
    }
    }


    View Slide

58. Plugin custom fetcher
    val imageLoader = ImageLoader.Builder(context)
    .components {
    add(MyFetcher.Factory())
    }
    .build()


    View Slide

59. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult
    data: T data: T data: M
    FetchResult


    View Slide

60. Decoder
    ● Converts ImageSource to Drawable


    View Slide

61. Decoder
    ● Converts ImageSource to Drawable
    ● Built-in format support
    ○ JPEG
    ○ PNG
    ○ WebPs


    View Slide

62. Decoder
    ● Converts ImageSource to Drawable
    ● Built-in format support
    ○ JPEG
    ○ PNG
    ○ WebPs
    ● Extensions
    ○ SVG
    ○ GIFs/HEIFs
    ○ Video frame


    View Slide

63. Custom Decoder
    interface Decoder {
    suspend fun decode(): DecodeResult?
    fun interface Factory {
    fun create(
    result: SourceResult,
    options: Options,
    imageLoader: ImageLoader
    ): Decoder?
    }
    }


    View Slide

64. Plugin custom decoder
    val imageLoader = ImageLoader.Builder(context)
    .components {
    add(MyDecoder.Factory())
    }
    .build()


    View Slide

65. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult
    data: T data: T data: M
    FetchResult
    DecodeResult


    View Slide

66. Transformation
    ● Allows you to change the pixel data.


    View Slide

67. Transformation
    ● Allows you to change the pixel data.
    ● Built-in transformations
    ○ Circle crop
    ○ Rounded corner


    View Slide

68. Custom Transformation
    interface Transformation {
    val cacheKey: String
    suspend fun transform(input: Bitmap, size: Size): Bitmap
    }


    View Slide

69. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult
    data: T data: T data: M
    FetchResult
    DecodeResult


    View Slide

70. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult
    data: T data: T data: M
    FetchResult
    DecodeResult


    View Slide

71. The pipeline
    ImageLoader Interceptor
    ImageRequest
    Mapper Fetcher
    Decoder
    Transformation
    ImageResult
    SuccessResult ErrorResult
    data: T data: T data: M
    FetchResult
    DecodeResult


    View Slide

72. Thread
    Interceptor
    Mapper
    Fetcher
    Decoder
    Transformation
    Transition
    Main Thread
    Default - I/O Thread
    OR
    Based on custom
    dispatchers
    Main Thread


    View Slide

73. Caching


    View Slide

74. Caching
    ● Disk cache


    View Slide

75. Caching
    ● Disk cache
    ● In memory cache


    View Slide

76. Disk cache


    View Slide

77. Disk cache
    ● Coil 2.0 has its own disk cache


    View Slide

78. Disk cache
    ● Coil 2.0 has its own disk cache
    ● Prior versions relies on OkHttp disk cache


    View Slide

79. HttpUriFetcher


    View Slide

80. HttpUriFetcher
    URL
    Disk Cache


    View Slide

81. HttpUriFetcher
    URL
    Disk Cache
    Snapshot?


    View Slide

82. HttpUriFetcher
    URL
    Disk Cache
    Snapshot?
    Snapshot !=
    null


    View Slide

83. HttpUriFetcher
    URL
    Disk Cache
    Snapshot?
    Snapshot !=
    null
    Pass result to
    decoder
    Yes


    View Slide

84. HttpUriFetcher
    URL
    Disk Cache
    Snapshot?
    Snapshot !=
    null
    Pass result to
    decoder
    No
    Yes
    Fetch image
    from source


    View Slide

85. HttpUriFetcher
    URL
    Disk Cache
    Snapshot?
    Snapshot !=
    null
    Pass result to
    decoder
    No
    Yes
    Fetch image
    from source
    N/W


    View Slide

86. HttpUriFetcher
    URL
    Disk Cache
    Snapshot?
    Snapshot !=
    null
    Pass result to
    decoder
    No
    Yes
    Fetch image
    from source
    N/W
    data


    View Slide

87. HttpUriFetcher
    URL
    Disk Cache
    Snapshot?
    Snapshot !=
    null
    Pass result to
    decoder
    No
    Yes
    Fetch image
    from source
    N/W
    Write
    data


    View Slide

88. HttpUriFetcher
    URL
    Disk Cache
    Snapshot?
    Snapshot !=
    null
    Pass result to
    decoder
    No
    Yes
    Fetch image
    from source
    N/W
    Write
    data
    Read


    View Slide

89. HttpUriFetcher
    URL
    Disk Cache
    Snapshot?
    Snapshot !=
    null
    Pass result to
    decoder
    No
    Yes
    Fetch image
    from source
    N/W
    Write
    data
    Pass result to
    decoder
    Read


    View Slide

90. HttpUriFetcher
    URL
    Disk Cache
    Snapshot?
    Snapshot !=
    null
    Pass result to
    decoder
    No
    Yes
    Fetch image
    from source
    N/W
    Write
    data
    Pass result to
    decoder
    Read


    View Slide

91. Disk Cache
    interface DiskCache {
    operator fun get(key: String): Snapshot?
    fun edit(key: String): Editor?
    fun remove(key: String): Boolean
    fun clear()
    interface Snapshot : Closeable
    interface Editor
    }


    View Slide

92. Disk Cache
    interface DiskCache {
    operator fun get(key: String): Snapshot?
    fun edit(key: String): Editor?
    fun remove(key: String): Boolean
    fun clear()
    interface Snapshot : Closeable
    interface Editor
    }


    View Slide

93. Disk Cache
    interface DiskCache {
    operator fun get(key: String): Snapshot?
    fun edit(key: String): Editor?
    fun remove(key: String): Boolean
    fun clear()
    interface Snapshot : Closeable
    interface Editor
    }


    View Slide

94. Disk Cache
    interface DiskCache {
    operator fun get(key: String): Snapshot?
    fun edit(key: String): Editor?
    fun remove(key: String): Boolean
    fun clear()
    interface Snapshot : Closeable
    interface Editor
    }


    View Slide

95. Disk Cache
    interface DiskCache {
    operator fun get(key: String): Snapshot?
    fun edit(key: String): Editor?
    fun remove(key: String): Boolean
    fun clear()
    interface Snapshot : Closeable
    interface Editor
    }


    View Slide

96. LRU Disk Cache
    ● Snapshot


    View Slide

97. Snapshot
    ● Result of the cache read operation


    View Slide

98. Snapshot
    ● Result of the cache read operation
    ● Encapsulates cache entry


    View Slide

99. Snapshot
    ● Result of the cache read operation
    ● Encapsulates cache entry
    ● Gives access to the cache file object


    View Slide

100. LRU Disk Cache
     ● Snapshot
     ● Editor


     View Slide

101. Editor
     ● Allows disk writing


     View Slide

102. Editor
     ● Allows disk writing
     ● Gives access to the cache file (Dirty file)


     View Slide

103. LRU Disk Cache
     ● Snapshot
     ● Editor
     ● LinkedHashMap


     View Slide

104. LinkedHashMap
     ● In memory representation of a disk cache


     View Slide

105. LinkedHashMap
     ● In memory representation of a disk cache
     ● Entry is an object holding cache entry files
     ○ Clean file
     ○ Dirty file


     View Slide

106. LinkedHashMap
     ● In memory representation of a disk cache
     ● Entry is an object holding cache entry files
     ○ Clean file
     ○ Dirty file
     ● Keeps track of cache entry status


     View Slide

107. File System
     Journal File
     Image files


     View Slide

108. libcore.io.DiskLruCache
     1
     100
     2
     CLEAN 3400330d1dfc7f3f7f4b8d4d803dfcf6 832 21054
     DIRTY 335c4c6028171cfddfbaae1a9c313c52
     CLEAN 335c4c6028171cfddfbaae1a9c313c52 3934 2342
     REMOVE 335c4c6028171cfddfbaae1a9c313c52
     DIRTY 1ab96a171faeeee38496d8b330771a7a
     CLEAN 1ab96a171faeeee38496d8b330771a7a 1600 234
     READ 335c4c6028171cfddfbaae1a9c313c52
     READ 3400330d1dfc7f3f7f4b8d4d803dfcf6
     Journal file


     View Slide

109. libcore.io.DiskLruCache
     1
     100
     2
     CLEAN 3400330d1dfc7f3f7f4b8d4d803dfcf6 832 21054
     DIRTY 335c4c6028171cfddfbaae1a9c313c52
     CLEAN 335c4c6028171cfddfbaae1a9c313c52 3934 2342
     REMOVE 335c4c6028171cfddfbaae1a9c313c52
     DIRTY 1ab96a171faeeee38496d8b330771a7a
     CLEAN 1ab96a171faeeee38496d8b330771a7a 1600 234
     READ 335c4c6028171cfddfbaae1a9c313c52
     READ 3400330d1dfc7f3f7f4b8d4d803dfcf6
     Journal file


     View Slide

110. libcore.io.DiskLruCache
     1
     100
     2
     CLEAN 3400330d1dfc7f3f7f4b8d4d803dfcf6 832 21054
     DIRTY 335c4c6028171cfddfbaae1a9c313c52
     CLEAN 335c4c6028171cfddfbaae1a9c313c52 3934 2342
     REMOVE 335c4c6028171cfddfbaae1a9c313c52
     DIRTY 1ab96a171faeeee38496d8b330771a7a
     CLEAN 1ab96a171faeeee38496d8b330771a7a 1600 234
     READ 335c4c6028171cfddfbaae1a9c313c52
     READ 3400330d1dfc7f3f7f4b8d4d803dfcf6
     Journal file


     View Slide

111. libcore.io.DiskLruCache
     1
     100
     2
     CLEAN 3400330d1dfc7f3f7f4b8d4d803dfcf6 832 21054
     DIRTY 335c4c6028171cfddfbaae1a9c313c52
     CLEAN 335c4c6028171cfddfbaae1a9c313c52 3934 2342
     REMOVE 335c4c6028171cfddfbaae1a9c313c52
     DIRTY 1ab96a171faeeee38496d8b330771a7a
     CLEAN 1ab96a171faeeee38496d8b330771a7a 1600 234
     READ 335c4c6028171cfddfbaae1a9c313c52
     READ 3400330d1dfc7f3f7f4b8d4d803dfcf6
     Journal file


     View Slide

112. Key
     Get
     Cache read flow


     View Slide

113. Key
     Get
     Initialised
     ?
     Cache read flow


     View Slide

114. Key
     Get
     Initialised
     ?
     No
     Initialisation
     Cache read flow


     View Slide

115. Key
     Get
     Initialised
     ?
     No
     Journal File
     Initialisation
     Cache read flow


     View Slide

116. Key
     Get
     Initialised
     ?
     No
     Journal File
     Initialisation
     LinkedHashMap
     Entry>
     Cache read flow


     View Slide

117. Key
     Get
     Initialised
     ?
     Yes
     No
     Journal File
     Initialisation
     Get the Entry
     from cache
     LinkedHashMap
     Entry>
     Cache read flow


     View Slide

118. Key
     Get
     Initialised
     ?
     Yes
     No
     Journal File
     Initialisation
     Get the Entry
     from cache
     LinkedHashMap
     Entry>
     Key
     Cache read flow


     View Slide

119. Key
     Get
     Initialised
     ?
     Yes
     No
     Journal File
     Initialisation
     Get the Entry
     from cache
     LinkedHashMap
     Entry>
     Entry?
     Key
     Cache read flow


     View Slide

120. Key
     Get
     Initialised
     ?
     Yes
     No
     Journal File
     Initialisation
     Get the Entry
     from cache
     LinkedHashMap
     Entry>
     Entry?
     Key
     Cache read flow


     View Slide

121. Key
     Get
     Initialised
     ?
     Yes
     No
     Journal File
     Initialisation
     Get the Entry
     from cache
     LinkedHashMap
     Entry>
     Entry?
     Journal
     cleanup
     req?
     Key
     Cache read flow


     View Slide

122. Key
     Get
     Initialised
     ?
     Yes
     No
     Journal File
     Initialisation
     Get the Entry
     from cache
     LinkedHashMap
     Entry>
     Entry?
     Journal
     cleanup
     req?
     No
     Return Snapshot?
     Key
     Cache read flow


     View Slide

123. Key
     Get
     Initialised
     ?
     Yes
     No
     Journal File
     Initialisation
     Get the Entry
     from cache
     LinkedHashMap
     Entry>
     Entry?
     Journal
     cleanup
     req?
     Yes Run cleanup
     task
     No
     Return Snapshot?
     Key
     Cache read flow


     View Slide

124. Key
     Get
     Initialised
     ?
     Yes
     No
     Journal File
     Initialisation
     Get the Entry
     from cache
     LinkedHashMap
     Entry>
     Entry?
     Journal
     cleanup
     req?
     Yes Run cleanup
     task
     No
     Return Snapshot?
     Key
     Cache read flow


     View Slide

125. Commit
     Editor
     Cache write flow


     View Slide

126. Initialised
     ?
     Commit
     Editor
     Cache write flow


     View Slide

127. Initialised
     ?
     No
     Initialisation
     Commit
     Editor
     Cache write flow


     View Slide

128. Initialised
     ?
     No
     Journal File
     Initialisation
     Commit
     Editor
     Cache write flow


     View Slide

129. Initialised
     ?
     No
     Journal File
     Initialisation
     LinkedHashMap
     Entry>
     Commit
     Editor
     Cache write flow


     View Slide

130. Initialised
     ?
     Yes
     No
     Journal File
     Initialisation
     Copy dirty
     file to clean
     file
     LinkedHashMap
     Entry>
     Commit
     Editor
     Cache write flow


     View Slide

131. Initialised
     ?
     Yes
     No
     Journal File
     Initialisation
     Copy dirty
     file to clean
     file
     LinkedHashMap
     Entry>
     Commit
     Editor
     Cache write flow
     Key


     View Slide

132. Initialised
     ?
     Yes
     No
     Journal File
     Initialisation
     Copy dirty
     file to clean
     file
     LinkedHashMap
     Entry>
     Commit
     Editor
     Cache write flow
     Key
     Entry


     View Slide

133. Initialised
     ?
     Yes
     No
     Journal File
     Initialisation
     LinkedHashMap
     Entry>
     Copy dirty
     file to clean
     file
     Commit
     Editor
     Cache write flow
     Key
     Entry


     View Slide

134. Cache
     full?
     Initialised
     ?
     Yes
     No
     Journal File
     Initialisation
     LinkedHashMap
     Entry>
     Copy dirty
     file to clean
     file
     Commit
     Editor
     Cache write flow
     Key
     Entry


     View Slide

135. Cache
     full?
     Initialised
     ?
     Yes
     No
     Journal File
     Initialisation
     LinkedHashMap
     Entry>
     Copy dirty
     file to clean
     file
     Commit
     Editor
     Yes Run cleanup
     task
     Cache write flow
     Key
     Entry


     View Slide

136. In memory caching


     View Slide

137. In memory caching
     ● Strong Memory Cache


     View Slide

138. In memory caching
     ● Strong Memory Cache
     ● Weak Memory Cache


     View Slide

139. Engine
     Interceptor


     View Slide

140. Engine
     Interceptor
     Is in strong
     memory?
     Key


     View Slide

141. Engine
     Interceptor
     Is in strong
     memory?
     Key
     Yes
     Return Bitmap
     and short
     circuit image
     loading pipeline


     View Slide

142. Engine
     Interceptor
     Is in strong
     memory?
     Key
     Yes
     Return Bitmap
     and short
     circuit image
     loading pipeline
     No
     Is in
     weak
     memory?


     View Slide

143. Engine
     Interceptor
     Is in strong
     memory?
     Key
     Yes
     Return Bitmap
     and short
     circuit image
     loading pipeline
     No
     Is in
     weak
     memory?
     Yes
     Return Bitmap
     and short
     circuit image
     loading pipeline


     View Slide

144. Engine
     Interceptor
     Is in strong
     memory?
     Key
     Yes
     Return Bitmap
     and short
     circuit image
     loading pipeline
     No
     Is in
     weak
     memory?
     No
     Execute Image
     loading
     pipeline
     Yes
     Return Bitmap
     and short
     circuit image
     loading pipeline


     View Slide

145. Strong Memory Cache
     ● Backed by LRU cache


     View Slide

146. Strong Memory Cache
     ● Backed by LRU cache
     ● Size of the cache is computed dynamically


     View Slide

147. Weak Memory Cache
     ● Backed by HashMap


     View Slide

148. Weak Memory Cache
     ● Backed by HashMap
     ● Periodically do cleanups after 10 read or write
     operations


     View Slide

149. Summary
     ● COIL - Coroutine Image Loader
     ● Modern, Easy, Lightweight and Fast
     ● API
     ● Image loading pipeline
     ● Caching


     View Slide

150. Resources
     ● Library documentation
     https://coil-kt.github.io/coil/
     ● Github
     https://github.com/coil-kt/coil


     View Slide

151. Thank you!


     View Slide

152. Questions?


     View Slide
