  1. Android Apps
    with
    Mortar and Flow
    Edward Dale
    @scompt

    View full-size slide

  2. Agenda
    • Motivation
    • Flow
    • Mortar
    http://knowyourmeme.com/memes/business-cat

    View full-size slide

  3. Motivation
    • Lots of activities (old)
    • Lots of fragments (new)
    • Loaders
    • Lifecycle fun hell
    • Fragment transitions
    • Back stack
    The Android Way

    View full-size slide

  4. Motivation
    • Lots of activities (old)
    • Lots of fragments (new)
    • Loaders
    • Lifecycle fun hell
    • Fragment transitions
    • Back stack
    The Android Way
    • Few activities
    • No fragments
    • Fatter views
    • Dependency injection
    • RxJava
    The Square Way

    View full-size slide

  5. Sample
    App
    https://github.com/square/flow

    View full-size slide

  6. Sample
    App
    https://github.com/square/flow

    View full-size slide

  7. Flow
    A small library that helps with describing an app
    as a collection of moderately independent
    screens.

    View full-size slide

  8. Flow
    • A screen in a POJO with the
    @Screen annotation saying
    which view or layout should
    be used to display it.
    • The Backstack is a stack of
    these objects.
    • The Flow is the interface for
    navigating the history of your
    app.
    http://www.rluxemburg.com/2013/09/01/kitten-flow-chart/

    View full-size slide

  9. The conversation list screen
    @Screen(ConversationListView.class)
    public class ConversationList {
    }

    View full-size slide

  10. The conversation view
    screen
    @Screen(ConversationView.class)
    public static class Conversation
    implements HasParent {
    public final int conversationIndex;
    !
    public Conversation(int conversationIndex) {
    this.conversationIndex = conversationIndex;
    }
    !
    @Override public ConversationList getParent() {
    return new ConversationList();
    }
    }

    View full-size slide

  11. App start
    Object firstScreen = new ConversationList();
    Backstack backstack = Backstack.single(firstScreen);
    Flow flow = new Flow(backstack, this);
    go(flow.getBackstack(), Flow.Direction.FORWARD);

    View full-size slide

  12. On conversation tap
    Flow flow = ...;
    int position = ;
    flow.goTo(new Conversation(position));

    View full-size slide

  13. • Controller layer is a bit

    too ad-hoc
    But not quite enough
    This is nice
    • No fragments
    • Unified interface for
    navigating in the app
    • Power over the back stack
    http://www.catster.com/molz/happy-cat-is-happy

    View full-size slide

  14. • Controller layer is a bit

    too ad-hoc
    But not quite enough
    This is nice
    • No fragments
    • Unified interface for
    navigating in the app
    • Power over the back stack

    View full-size slide

  15. Mortar
    Mortar eases the use of Dagger to divide Android
    apps into composable modules.

    View full-size slide

  16. Mortar
    • View and controller destroyed in traditional
    android MVC
    • Only view destroyed with MVP under mortar.
    Presenter stays around.
    MVC MVP

    View full-size slide

  17. Mortar
    • Every Screen has an
    associated Dagger Module
    • Every View has an associated
    ViewPresenter
    Implementation
    http://animals.desktopnexus.com/wallpaper/1386356/

    View full-size slide

  18. Blueprint
    @Screen(ChatListView.class)
    public class ChatListScreen implements Blueprint {
    @Override public String getMortarScopeName() {
    return getClass().getName();
    }
    @Override public Object getDaggerModule() {
    return new Module();
    }
    }

    View full-size slide

  19. ViewPresenter
    public class ChatListView extends ListView
    implements ChatListScreen.View {
    @Inject ChatListScreen.Presenter presenter;
    !
    public ChatListView(Context context, AttributeSet attrs) {
    super(context, attrs);
    Mortar.inject(context, this);
    }
    !
    @Override protected void onAttachedToWindow() {
    super.onAttachedToWindow();
    presenter.takeView(this);
    }
    }

    View full-size slide

  20. http://www.catster.com/molz/happy-cat-is-happy
    This is nice
    • Screens are self-contained
    and injected, facilitating
    testing
    • Insulated from lifecycle events
    • Memory efficient

    View full-size slide

  21. Mortar
    Flow
    A small library that helps with describing an app as a
    collection of moderately independent screens.
    Mortar eases the use of Dagger to divide
    Android apps into composable modules.
    Questions?
    Edward Dale
    @scompt

    View full-size slide
