Taming your browser with Geb

Talk at ApacheCon 2020

Transcript

1. Taming your browser
   with Geb introduction


   View Slide

2. Sergio del Amo


   OCI Grails Team


   https://sergiodelamo.com


   View Slide

3. Geb Introduction


   View Slide

4. 䡦 A Groovy layer on top of WebDriver


   䡦 WebDriver instance management


   䡦 Built-in configuration mechanism


   䡦 Page Object Pattern as first class citizen


   䡦 jQuery-like Navigator API


   䡦 Integrates with various test frameworks
   What is Geb?


   View Slide

5. Geb is a Browser automation solution


   You can use it for:


   䡦 Acceptance Testing Web Applications


   䡦 Automating Web Sites


   䡦 Screen Scraping
   Totally Groovy Browser
   Automation


   View Slide

6. 䡦 Cross browser automation capabilities of
   WebDriver


   䡦 Elegance of jQuery content selection


   䡦 Expressiveness of the Groovy language


   䡦 Robustness of Page Object modelling
   It brings together the…


   View Slide

7. 䡦 Free Open Source, Apache License, v2.0.


   䡦 Home Page http://www.gebish.org


   䡦 The Book of Geb http://www.gebish.org/
   manual/current


   䡦 Source Code https://github.com/geb/geb


   䡦 User Mailing List http://xircles.codehaus.org/
   projects/geb/lists


   䡦 In Maven Central http://mvnrepository.com/
   artifact/org.codehaus.geb
   About the Project


   View Slide

8. Marcin Erdmann


   Geb project Lead


   http://blog.proxerd.pl


   View Slide

9. The heart is the geb-core component which is all
   you really need (plus Web Driver).


   For testing, you probably also want one of these
   as well:


   䡦 geb-spock


   䡦 geb-junit3


   䡦 geb-junit4


   䡦 geb-testng


   䡦 geb-easyb
   Project Components


   View Slide

10. 䡦 http://seleniumhq.org/projects/webdriver/


    䡦 Successor to the Selenium project


    䡦 Also known as “Selenium 2”.


    䡦 Sponsored and driven by Google.


    䡦 Becoming a standard.


    䡦 https://www.w3.org/TR/webdriver/
    WebDriver


    View Slide

11. Java based, with many language bindings.
    Cross-browser automation


    View Slide

12. 䡦 Geb sits on top of WebDriver so you rarely deal
    with its API, though it’s accessible if you need
    it.


    䡦 Geb never talks to the actual browser.


    䡦 That’s what WebDriver does.
    WebDriver API


    View Slide

13. You need to pull in a specific driver
    implementation for each browser you want to
    work with.
    Driver dependency


    View Slide

14. http://jquery.com jQuery - write more do less


    jQuery provides an incredibly powerful ApI for
    navigating and selecting content.


    CSS based, a whole lot better than XPath.
    jQuery


    View Slide

15. Geb features a Navigator API that it is inspired by
    jQuery.


    API is not identical
    Geb’s inspiration


    View Slide

16. 䡦 Compiled, never interpreted


    䡦 Dynamically, optionally typed


    䡦 99% Java syntax compatible


    䡦 Concise, clear and pragmattic


    䡦 Great for DSLs


    䡦 A comfortable Java alternative for most
    Groovy


    View Slide

17. 䡦 http://groovy-lang.org


    䡦 You don’t need to be a Groovy ninja to use
    Geb.


    䡦 Groovy knowledge can defenitely help when
    things go wrong though.
    Required Apache Groovy
    Knowledge


    View Slide

18. Geb uses Groovy’s dynamism to remove
    boilerplate.
    Geb & Groovy


    View Slide

19. 䡦 The key to not pulling your hair out when
    dealing with web tests.


    䡦 In a phrase: Domain Modelling


    䡦 By modelling and creating abstractions, we
    can isolate implementation detail.
    Page Objects


    View Slide

20. is more fragile than this…
    Page Objects


    View Slide

21. 䡦 It's the application of trusted principles;
    encapsulation and reuse.


    䡦 Not new at all, but new to the world of web
    testing/automation.


    䡦 Not just about modelling “pages”. It's about
    modelling all kinds of things in the domain of a
    user's actions online.


    䡦 Just giving symbolic names to page content is
    a great start.


    䡦
    Just Good Programming


    View Slide

22. The to() and click() methods are changing the
    underlying page.


    You can refer to the current page’s content and
    methods just by name.
    Browser has-a Page


    View Slide

23. The Page Object Pattern allows us to apply the same principles of
    modularity, reuse and encapsulation that we use in other aspects of
    programming to avoid such issues in browser automation code
    Geb Pages


    View Slide

24. View Slide

25. View Slide

26. View Slide

27. View Slide

28. Geb Pages


    View Slide

29. Geb Modules


    View Slide

30. View Slide

31. View Slide

32. Modules can be used for repeating content


    View Slide

33. Modules
    Modules have a base, from which all content
    lookups are relative.


    View Slide

34. We now have a model for a row in our table.


    Can be used for any reused/repeating content.


    Note: talking about domain objects, not HTML
    tables and rows.
    Modules


    View Slide

35. Example - Pagination Module
    .PAGINATION
    .NAV-NEXT


    View Slide

36. Example - Pagination Module


    View Slide

37. Example - Pagination Module


    View Slide

38. Example - Pagination Module


    View Slide

39. Inheritance
    Pages (and modules) can be arranged in
    inheritance hierarchies.


    View Slide

40. Geb's testing adapters. Geb can be used with…


    䡦 Spock


    䡦 Junit ( 3 & 4)


    䡦 TestNG


    䡦 EasyB


    䡦 Cucumber (Cuke4Duke)
    Testing


    View Slide

41. Geb can dump HTML and screenshots for each
    “test” to help in debugging.


    Reports


    View Slide

42. 䡦 jQuery inspired content selection/navigation


    䡦 The $() method


    䡦 Returns a Navigator Object


    䡦 General Format
    Navigator API


    View Slide

43. 䡦 Returned from invocations of $() function


    䡦 Wrapper around DOM elements


    䡦 jQuery-like API


    䡦 Used for finding, filtering and interacting with
    DOM elements
    Navigator


    View Slide

44. Examples


    View Slide

45. Full CSS3 if the target browser supports it.


    CSS Lookups are fast
    CSS Selector


    View Slide

46. Can match on attribute values:
    Attribute/Text matching


    View Slide

47. The “text” attribute is special
    Attribute/Text matching


    View Slide

48. Can use Regular Expressions:
    Attribute/Text matching


    View Slide

49. Geb supplies some handy predicates:


    There are more of these.


    Predicates


    View Slide

50. $() returns a Navigator that allows you to find
    relative content.


    Relative content


    View Slide

51. Most of these methods take selectors, indexes
    and attribute text/matchers too.
    Relative Content
    $("p").nextAll(".listing")




    View Slide

52. Content definitions can build upon each other.


    Content definitions are actually templates.


    Content DSL
    class GoogleResultsPage extends Page {


    static content = {


    results { $("li.g") }


    result { i -> results[i] }


    resultLink { i -> result(i).find("a.l", 0) }


    firstResultLink { resultLink(0) }


    }


    }


    View Slide

53. By default, Geb will error if the content you select
    doesn't exist.


    The “`required`” option disables this check.


    Content definitions are actually templates.


    Optional Content
    class OptionalPage extends Page {


    static content = {


    errorMsg(required: false) { $("p.errorMsg") }


    }


    }


    View Slide

54. Geb will wait for some time for this content to
    appear.


    Same semantics as the waitFor {} method that
    can be used anywhere.


    Content definitions are actually templates.


    Dynamic Content
    class DynamicPage extends Page {


    static content = {


    errorMsg(wait: true) { $("p.errorMsg") }


    }


    }


    View Slide

55. Getting around. The to() method


    Pages can define a url that defines the page
    location.


    Navigation
    class MicronautHomePage extends Page {


    static url = “http://micronaut.io/index.html”


    }


    View Slide

56. The to() method sends the browser there and sets
    that as the current page object.


    to MicronautHomePage


    The page url can be relative (will be resolved
    against a config driven base).


    There are advanced parameterisation options too.
    Navigation


    View Slide

57. When this content is clicked, the underlying page
    will be changed implicitly.
    Content based navigation
    class FrontPage {


    static content = {


    aboutUsLink(to: AboutUsPage) {


    $("div#nav ul li a", text:
    iStartsWith("About Us"))


    }


    }


    }


    to FrontPage


    aboutUsLink.click()


    page instanceof AboutUsPage


    View Slide

58. url = baseUrl + url + covertToPath
    Dynamic Url
    browser.baseUrl = 'http://localhost:8080'


    browser.to EditRoomPage, 1
    class EditRoomPage extends Page {


    static at = { title == 'Edit Room' }


    static url = '/room/edit'


    String convertToPath(Object[] args) {


    args ? "/${args[0]}" : ""


    }




    View Slide

59. UI Interaction - Keyboard


    View Slide

60. UI Interaction - Sliders


    View Slide

61. 䡦 JavaScript interface


    䡦 jQuery interface


    䡦 Direct Downloading


    䡦 Multi Window support


    䡦 Frame support


    䡦 Page Change Listening


    䡦 Actions (e.g. Drag & Drop)


    䡦 alert()/confirm() handling
    䡦 Caching expensive
    content lookups


    䡦 Scripting style (sans
    Page Objects)


    䡦 Configuration &
    Environments
    WebDriver instance
    management
    More


    View Slide

62. Example


    Hidden Content
    and Mouse over
    events


    View Slide

63. View Slide

64. View Slide

65. Fails: Hidden Content


    View Slide

66. Call a JS Method


    View Slide

67. Move to Element


    View Slide

68. Include Library


    View Slide

69. geb-spock
    GebSpec
    Contains Specification subclasses which
    setup a Browser instance that all method
    calls and property accesses/references
    resolve against via Groovy’s methodMissing
    and propertyMissing mechanism.
    GebReportingSpec


    View Slide

70. 䡦 BrowserStack


    䡦 Sauce Labs


    䡦 Xvfb
    Headless browser alternatives


    View Slide

71. Sample App
    https://github.com/grails-samples/geb-example-grails


    View Slide

72. Website testing
    https://github.com/micronaut-projects/static-website-test


    View Slide

73. Q & A
