Breaking the Monolith: best practices to containerize your app

Following simple patterns of good application design can allow you to scale your application for your customers easily. We'll dive into the 12 factor application design and demo how this applies to containers and deployments on Amazon ECS and Fargate. We'll take a look at tooling that can be used to simplify your work flow and help you adopt the principles of the 12 factor application.

Transcript

1. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. P U B L I C S E C T O R S U M M I T Breaking the Monolith - Best Practices to Run Your Containers in the Cloud Sébastien Stormacq Technical Evangelist, AWS @sebsto
2. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. P U B L I C S E C T O R S U M M I T
3. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. The 12 factor application I. Codebase One codebase w/ revision control, many deploys II. Dependencies Explicitly declare and isolate dependencies III. Config Store config in the environment IV. Backing services Treat backing services as attached resources V. Build, release, run Strictly separate build and run stages VI. Processes Execute the app as one or more stateless processes VII. Port binding Export services via port binding VIII. Concurrency Scale out via the process model IX. Disposability Fast startup and graceful shutdown X. Dev/prod parity Keep environments as similar as possible XI. Logs Treat logs as event streams XII. Admin processes Run admin/management tasks as one-off processes
4. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. You know what’s great for a 12 factor app?
5. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. P U B L I C S E C T O R S U M M I T
6. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. RUNNING A SINGLE CONTAINER
7. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. EC2 Instance Task Task Task Task EC2 Instance Task Task Task Task EC2 Instance Task Task Task Task EC2 Instance Task Task Task Task EC2 Instance Task Task Task Task RUNNING CONTAINERS
8. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. RUNNING CONTAINERS AT SCALE WITH ECS Availability Zone #1 Availability Zone #2 Availability Zone #3 Scheduling and Orchestration Cluster Manager Placement Engine
9. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. ECS AMI Docker agent ECS agent ECSTask ECSTask ECSTask ECSTask EC2 Instance
10. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. ECS AMI Docker agent ECS agent EC2 Instance ECS AMI Docker agent ECS agent EC2 Instance ECS AMI Docker agent ECS agent EC2 Instance Scheduling and Orchestration Cluster Manager Placement Engine
11. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. “Just launch 10 copies of my container distributed across three availability zones and connect them to this load balancer” X 10
12. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. P U B L I C S E C T O R S U M M I T One codebase tracked in revision control, many deploys
13. Deployed Version Code Version Control
14. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Staging / QA Production Dev #1 Dev #2
15. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. P U B L I C S E C T O R S U M M I T Explicitly declare and isolate dependencies
16. Dependencies Binaries Code Application Bundle
17. Dependency Declaration: Node.js package.json npm install # - or - yarn install
18. Dependency Declaration: Python requirements.txt pip install
19. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Dependencies Dependencies Binaries Code
20. Dependency Declaration & Isolation: Docker Dockerfile docker build
21. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. P U B L I C S E C T O R S U M M I T Store config in the environment
22. Development Configuration Production Configuration Development Production
23. Development Production Same container deployed to both environments. Configuration is part of the environment on the host.
24. At runtime the container gets config from the environment.
25. Application code pulls from the environment Environment is customized when docker runs a container
26. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. AWS Secrets Manager & Task Definitions "containerDefinitions": [ { "secrets": [ { "name": "environment_variable_name", "valueFrom": ”arn_of_your_secret" } ] } ]
27. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. P U B L I C S E C T O R S U M M I T Treat backing services as attached resources
28. PostgreSQL app1 Host app2 3rd party service Treat local services just like remote third party ones
29. PostgreSQL app1 app2 Load balancer Use CNAMES for maximum flexibility and easy reconfiguration postgres.mycompany.com app2.mycompany.com
30. Easily create and maintain custom maps of your applications Before Version 2 After Version 2
31. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. P U B L I C S E C T O R S U M M I T Strictly separate build and run stages
32. Build Dependencies Binaries Code
33. Release Config Release Build Artifact + = Tagged image stored in ECR
34. Amazon Elastic Container Service Config
35. Run Task Definition Release v1 Task Definition Release v2
36. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. CodeDeploy-ECS appspec version: 1.0 Resources: - TargetService: Type: AWS::ECS::Service Properties: - TaskDefinition: "my_task_definition:8" LoadBalancerInfos: - ContainerName: "SampleApp" ContainerPort: 80 Hooks: - BeforeInstall: "LambdaFunctionToExecuteAnythingBeforeNewRevisionInstalltion" - AfterInstall: "LambdaFunctionToExecuteAnythingAfterNewRevisionInstallation" - AfterAllowTestTraffic: "LambdaFunctionToValidateAfterTestTrafficShift" - BeforeAllowTraffic: "LambdaFunctionToValidateBeforeTrafficShift" - AfterAllowTraffic: "LambdaFunctionToValidateAfterTrafficShift"
37. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. CodeDeploy-ECS blue-green deployment 100% Prod traffic
38. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. CodeDeploy-ECS blue-green deployment Target group 2 100% Prod traffic Test traffic listener (port 9000)
39. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. CodeDeploy-ECS blue-green deployment Green tasks: v2 code 100% Prod traffic Provision green tasks
40. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. CodeDeploy-ECS blue-green deployment 100% Test traffic 100% Prod traffic Run hook against test endpoint before green tasks receive prod traffic
41. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. CodeDeploy-ECS blue-green deployment 100% Prod traffic Flip traffic to green tasks, rollback in case of alarm 0% Prod traffic
42. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. CodeDeploy-ECS blue-green deployment 100% Prod traffic Drain blue tasks
43. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Container image tagging for deployments • Docker tags are resolved when each container starts, not just during deployments • Deploying “latest” or “prod” can result in untested code in production after a scale-out event • Use unique “immutable” tags for deployments
44. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Container image tagging for deployments
45. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Container image tagging for deployments Build pushes new “latest” image Image: sha256@22222... (“latest”)
46. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Container image tagging for deployments Service scales up, launching new tasks Image: sha256@22222... (“latest”)
47. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Container image tagging for deployments Deploy using immutable tags { "name": "sample-app", "image": "amazon/amazon-ecs- sample@sha256:3e39d933b1d948c92309bb583b5a1f3d28f0119e1551ca1fe538ba414a41af48d" } { "name": "sample-app", "image": "amazon/amazon-ecs-sample:build-b2085490-359f-4eaf-8970-6d1e26c354f0" } SHA256 Digest Build ID
48. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Container image tagging for deployments Compute immutable tags during build SHA256 Digest export IMAGE_URI=`docker inspect --format='{{index .RepoDigests 0}}' my_image:$IMAGE_TAG Example Result: amazon/amazon-ecs-sample@sha256:3e39d933b... Build ID export IMAGE_TAG=build-`echo $CODEBUILD_BUILD_ID | awk –F":" ‘{print $2}'` Example Result: build-b2085490-359f-4eaf-8970-6d1e26c354f0
49. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Container image tagging for deployments
50. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Container image tagging for deployments Build pushes new image tagged with new build ID Image: sha256@22222... (“build-22222”)
51. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Container image tagging for deployments Service scales up, launching new tasks Image: sha256@22222... (“build-22222”)
52. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Container image tagging for deployments Image: “build-22222” tag Deployment updates service’s task definition, replacing tasks Image: sha256@22222... (“build-22222”)
53. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. P U B L I C S E C T O R S U M M I T Execute the app as one or more stateless processes
54. Stateful container stores state in local disk or local memory. Workload ends up tied to a specific host that has state data. eu-west-1b Container 1 Disk eu-west-1c eu-west-1a
55. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Stateful data Use services: • Amazon RDS • Amazon DynamoDB • Amazon ElasticCache • Amazon ElasticSearch • Amazon S3 • ……
56. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. P U B L I C S E C T O R S U M M I T Export services via port binding
57. Port 32456 Port 32457 Port 32458
58. Port 32768 Port 33487 Port 32192 Port 32794 Port 32781 Match: /api/users* Match: /api/auth*
59. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. P U B L I C S E C T O R S U M M I T Keep development, staging, and production as similar as possible
60. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Dev #1 Dev #2 Staging / QA Production
61. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Staging / QA Production Dev #1 Dev #2 Local Application Remote
62. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. Model container environments with AWS Cloud Development Kit (CDK) Developer Preview • Open source framework to define cloud infrastructure in TypeScript, Java, C#, … • Provides library of higher-level resource types (“construct” classes) that have AWS best practices built in by default, packaged as npm modules • Provisions resources with CloudFormation • Supports all CloudFormation resource types AWS CDK https://awslabs.github.io/aws-cdk
63. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. CDK template import ec2 = require('@aws-cdk/aws-ec2'); import ecs = require('@aws-cdk/aws-ecs'); import cdk = require('@aws-cdk/cdk'); class BonjourFargate extends cdk.Stack { constructor(parent: cdk.App, name: string, props?: cdk.StackProps) { super(parent, name, props); const vpc = new ec2.VpcNetwork(this, 'MyVpc', { maxAZs: 2 }); const cluster = new ecs.Cluster(this, 'Cluster', { vpc }); new ecs.LoadBalancedFargateService( this, "FargateService", { cluster, image: ecs.DockerHub.image("amazon/amazon-ecs-sample"), }); } } const app = new cdk.App(); new BonjourFargate(app, 'Bonjour'); app.run();
64. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. import ec2 = require('@aws-cdk/aws-ec2'); import ecs = require('@aws-cdk/aws-ecs'); import cdk = require('@aws-cdk/cdk'); class BonjourFargate extends cdk.Stack { constructor(parent: cdk.App, name: string, props?: cdk.StackProps) { super(parent, name, props); const vpc = new ec2.VpcNetwork(this, 'MyVpc', { maxAZs: 2 }); const cluster = new ecs.Cluster(this, 'Cluster', { vpc }); new ecs.LoadBalancedFargateService( this, "FargateService", { cluster, image: ecs.DockerHub.image("amazon/amazon-ecs-sample"), }); } } const app = new cdk.App(); new BonjourFargate(app, 'Bonjour'); app.run(); CDK template
65. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. CDK template import ec2 = require('@aws-cdk/aws-ec2'); import ecs = require('@aws-cdk/aws-ecs'); import cdk = require('@aws-cdk/cdk'); class BonjourFargate extends cdk.Stack { constructor(parent: cdk.App, name: string, props?: cdk.StackProps) { super(parent, name, props); const vpc = new ec2.VpcNetwork(this, 'MyVpc', { maxAZs: 2 }); const cluster = new ecs.Cluster(this, 'Cluster', { vpc }); new ecs.LoadBalancedFargateService( this, "FargateService", { cluster, image: ecs.DockerHub.image("amazon/amazon-ecs-sample"), }); } } const app = new cdk.App(); new BonjourFargate(app, 'Bonjour'); app.run();
66. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. P U B L I C S E C T O R S U M M I T Treat logs as event streams
67. Docker connects container’s stdout to a log driver Containerized code writes to stdout
68. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. CLOUDWATCH LOGS CONFIGURATION { "containerDefinitions": [ { "name":“scorekeep-api", ... "logConfiguration": { "logDriver": "awslogs", "options": { "awslogs-group": "scorekeep", "awslogs-region": “us-east-1", "awslogs-stream-prefix": "scorekeep/api"}} } ]}
69. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. CLOUDWATCH LOGS Logs Tab in the Task Detail Page View logs in the ECS or Cloudwatch Console
70. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. P U B L I C S E C T O R S U M M I T
71. Thank you! © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. P U B L I C S E C T O R S U M M I T Sébastien Stormacq Technical Evangelist, AWS @sebsto
72. © 2019, Amazon Web Services, Inc. or its affiliates. All rights reserved. P U B L I C S E C T O R S U M M I T
