Serverless IdP for Small Team: Himari

Lightning Talk given at RubyKaigi 2023,
https://rubykaigi.org/2023/presentations/lt/

https://github.com/sorah/himari

Transcript

1. Serverless IdP for Small Team
   Sorah Fukumori https://sorah.jp/


   View Slide

2. Whoami
   Sorah Fukumori (ͦΒ͸)
   • https://sorah.jp

   • https://github.com/sorah

   • RubyKaigi Organizer: Sponsor Relations, Wi-Fi, Virtual Venue

   • Sta
   ff
   Software Engineer at Cookpad SRE and IT

   • My recent working hours spent for RubyKaigi as a part of Wi-Fi sponsorship

   • Infrastructure for the Drink Fridge is built by me~

   • Please Remember: When I appear in the hallway, I’m not busy and happy to chat
   with Rubyists even I face against my laptop!


   View Slide

3. RubyKaigi 2023 Wi-Fi so far
   • approx. 1,200 clients

   • Inbound around 300Mbps

   • 1/3 of DNS queries use DNS over HTTP/2

   • I believe it’s pretty stable this year

   • Kudos for my Network Ops team members!

   • https://rubykaigi.org/2023/about/

   • We’re running NOC team trivia quiz at Cookpad
   booth, come visit us!


   View Slide

4. Agenda
   • Introduction of https://github.com/sorah/himari

   • Motivation

   • Solution

   • Application in RubyKaigi

   • How it works

   • Demo


   View Slide

5. Himari: Omniauth to OpenID Connect (OIDC)
   • https://github.com/sorah/himari - Rack app (using Sinatra)

   • Federate Omniauth result to OIDC

   • Authenticate users using Omniauth as a upstream provider

   • Provide authentication for downstream OIDC relying parties

   • We can apply a lot of omniauth strategies for OIDC world!

   • https://dexidp.io/ alternative
   omniauth-google-oauth2

   omniauth-github

   omniauth-…
   himari OIDC apps
   Authorize and generate claims data
   Provide user authentication


   View Slide

6. Motivation
   • For single-sign on thingy, most organisations like companies can utilise a full-
   suite IdPs like Azure AD, Google Workspace, and Okta

   • But what about small team or personal groups?

   • Sometimes we want to deploy apps and authorise users using their existing
   social logins

   • But some apps don’t support our preferred way or can’t authorise users
   based on users role easily


   View Slide

7. Motivation: RubyKaigi
   • I created this tool for RubyKaigi

   • RubyKaigi organising team is formed by individuals and we prefer not to have
   additional credentials for the project like using Google Workspace.

   • But it’s not easy to authorise individual @gmail.com accounts…

   • Plus, we’d like to keep subscriptions minimum!


   View Slide

8. Motivation: RubyKaigi
   • Some RubyKaigi tools have started to use Himari and our Himari deployment
   uses GitHub strategy and GitHub org/team membership to determine role for
   access control

   • There’s less convenient and common way to implement access control using
   individual account, so we need something acts as IdP, but relying on other
   login method

   • Not all apps support ACL by Google Groups membership or GitHub Team
   membership…


   View Slide

9. Solution
   • What I need is: Use individual-owned accounts, and do some authorization
   with ID token claims manipulation

   • So,

   • Use Omniauth to allow arbitrary strategy for upstream identity

   • Some simple rule processor for authn/authz - write as a Ruby code

   • OIDC for downstream apps.

   • Thanks to nov/openid_connect gem for low-level protocol
   implementation


   View Slide

10. How it works
    1. A downstream app initiates OIDC
    fl
    ow against Himari

    2. Himari redirects user to Omniauth strategy (/auth/…)

    3. Generate ID token claims based on Omniauth auth hash and Claims Rule
    4. Authenticate a user by evaluating Authn Rule with the generated claims

    5. Authorize a downstream app with the claims and Authz Rule
    6. A downstream app receives the ID token and voila!


    View Slide

11. Rule evaluation
    • So Himari has: Claims Rule, Authentication Rule, and Authorization Rule

    • Claims Rule determines ID token claims from Omniauth auth hash

    • Authn Rule determines whether a incoming user can use Himari or not

    • Authz Rule determines whether the authenticated user a downstream app or
    not

    • All rule types use the same evaluation engine.

    Each rule can decide incoming claims/request to allow, explicit deny, skip, or
    continue. Claims Rule and Authz Rule can update the ID token claims for later use.

    • Let’s take a look of actual deployment…


    View Slide

12. Example at RubyKaigi
    • https://github.com/ruby-no-kai/rubykaigi-nw/tree/master/tf/himari

    • Con
    fi
    guration is entirely done using Rack middlewares.

    • We authenticate team members using GitHub and org/team membership.


    View Slide

13. Example at RubyKaigi
    • https://github.com/ruby-no-kai/rubykaigi-nw/tree/master/tf/himari

    • Con
    fi
    guration is entirely done using Rack middlewares.
    use(Himari::Middlewares::Client,
    name: 'grafana',
    id: '88445b54-09dd-6790-ecf0-1e7bbfd5e12d',
    secret_hash: …, # sha384.hexdigest
    redirect_uris: %w(
    https://grafana.rubykaigi.net/login/generic_oauth
    ),
    )


    View Slide

14. Example at RubyKaigi
    • https://github.com/ruby-no-kai/rubykaigi-nw/tree/master/tf/himari

    • There’s a provider API so some con
    fi
    g items can be dynamically generated
    from other sources (e.g. AWS Secrets Manager for signing key)
    use(Himari::Aws::SecretsmanagerSigningKeyProvider,
    secret_id: ENV.fetch('HIMARI_SIGNING_KEY_ARN'),
    group: nil,
    kid_prefix: 'asm1',
    )


    View Slide

15. Example at RubyKaigi
    • https://github.com/ruby-no-kai/rubykaigi-nw/tree/master/tf/himari

    • Claims rule to initialize claims from github auth hash:
    use(Himari::Middlewares::ClaimsRule, name: 'github-initialize') do |context, decision|
    next decision.skip!("provider not in scope") unless context.provider == 'github'
    decision.initialize_claims!(
    sub: "github_#{context.auth[:uid]}",
    name: context.auth[:info][:nickname],
    preferred_username: context.auth[:info][:nickname],
    email: context.auth[:info][:email],
    )
    decision.user_data[:provider] = 'github'
    decision.continue!
    end


    View Slide

16. Example at RubyKaigi
    • https://github.com/ruby-no-kai/rubykaigi-nw/tree/master/tf/himari

    • Store user’s GitHub team memberships in claims:
    use(Himari::Middlewares::ClaimsRule, name: 'github-oauth-teams') do |context, decision|
    # (snip)
    teams_in_scope = [‘ruby-no-kai/rko-infra’, …]
    teams = user_teams_resp
    .map { |team| "#{team.fetch('organization').fetch('login')}/#{team.fetch('slug')}" }
    .select { |login_slug| teams_in_scope.any? { |s| s === login_slug } }
    next decision.skip!("no teams in scope") if teams.empty?
    # claims
    decision.claims[:groups] ||= []
    decision.claims[:groups].concat(teams)
    decision.claims[:groups].uniq!
    decision.continue!
    End


    View Slide

17. Example at RubyKaigi
    • https://github.com/ruby-no-kai/rubykaigi-nw/tree/master/tf/himari

    • Authenticate user if user belongs to a known GitHub team:
    use(Himari::Middlewares::AuthenticationRule, name: 'allow-github-with-teams') do |context, decision|
    next decision.skip!("provider not in scope") unless context.provider == 'github'
    if context.claims[:groups] && !context.claims[:groups].empty?
    next decision.allow!
    end
    decision.skip!("no available groups")
    end


    View Slide

18. Example at RubyKaigi
    • https://github.com/ruby-no-kai/rubykaigi-nw/tree/master/tf/himari

    • Authorize a downstream app based on groups claims and customize
    outbound ID token:
    use(Himari::Middlewares::AuthorizationRule, name: 'grafana') do |context, decision|
    # …snip…
    if groups.include?('ruby-no-kai/rk-noc')
    roles.push('admin')
    else
    roles.push('viewer')
    end
    decision.claims[:roles] = roles
    decision.allowed_claims.push(:roles)
    unless roles.empty?
    next decision.allow!
    end
    decision.skip!
    end


    View Slide

19. sorah/himari2amc: Access to AWS
    • https://github.com/sorah/himari2amc

    • RubyKaigi also uses the above app to access AWS console and API

    • Himari2amc utilises sts:AssumeRoleWithWebIdentity for federation

    • But to modify and re-sign ID claims upon role selection, Himari2amc also
    posses a signing key and openid-con
    fi
    guration…

    • Himari generates a claim for allowed role ARNs using Authz Rule


    View Slide

20. Demo


    View Slide

21. Serverless Support
    • As explained earlier, RubyKaigi wants to keep subscriptions minimum

    • So Himari supports Serverless deployment using AWS Lambda

    • And provides Terraform module for quick deployment

    • https://github.com/sorah/apigatewayv2_rack for connecting API Gateway to
    Rack app

    • There are some alternatives though…

    • You can utilize this small gem for your own Rack app~


    View Slide

22. Conclusion
    • https://github.com/sorah/himari is a Swiss Army Knife OIDC provider

    • Omniauth → do something → Downstream Apps
