1. REST Services: HTTP caching
2. “A distributed system is one in which the failure of a computer you didn’t even know existed can render your own computer unusable.” - Leslie Lamport
3. • REST stands for REpresentational State Transfer • Representation is just a very simple rendering of the object • Has benefits when leverages existing HTTP protocol What is REST?
4. • Up-to-date • Fresh • Stale States of Resource Representation
5. Up-to-Date state means the Representation is current according to the origin server Representation is being sent back with no expiry and no caching instructions means the client is allowed to cache for however long or not cache at all Up-to-Date State
6. Fresh State considered as long as the Representation hasn’t expired at client side, proxy or browser Fresh State
7. • Sending must-revalidate means the client must revalidate once the representation is Stale • Stale means it’s gone over it’s expiration date Stale State
8. • Doesn’t actually mean do not cache • Means the client must revalidate both Fresh and Stale entries and then may use the cached copy if it’s up to date No-Cache Directive
9. • In plain English text format • Starting line: Method URI HTTP/version • Headers • Body HTTP Message
10. Request: GET /wiki HTTP/1.1 Host: wikipedia.org Accept: text/html Connection: close Response: HTTP/1.1 200 OK Content-Type: text/html; charset=utf-8 Content-Language: en Content-Length: 1234 Sample HTTP Request/Response
11. • Get • Post • Put • Delete • Options • Head • Patch • Trace • Link • Unlink • Connect Cache-enabled methods are in Red HTTP Methods
12. Response: HTTP/1.1 200 OK Content-Type: text/html Content-Length: 1234 Expires: Fri, 27 Jan 2012 02:33:12 GMT • Allows only HTTP date • Good for static resources • Limited control HTTP Expires header
13. • Enough for static content • For things that rarely change • Or don’t change at all like Calculator /Calculator/Multiply?x=2&y=2 Client Expires is Enough?
14. • public • private • no-cache • no-store • max-age=[seconds] • s-maxage=[seconds] • must-revalidate • proxy-revalidate • no-transform HTTP Cache-Control directives
15. Response: HTTP/1.1 200 OK Content-Type: text/html Content-Length: 1234 Cache-Control: max-age=3600, must-revalidate HTTP Cache-Control Sample
16. What if we need to update data? Cache-Control is Enough for REST
17. • Optimistic is when we version our data • And do not have any transactions • Make use of ETag, If-Match and If-None-Match headers Optimistic Locking: ETag
18. /Orders Client GET /Orders HTTP/1.1 HTTP/1.1 200 OK Etag: 1 [content goes in body] GET /Orders HTTP/1.1 If-None-Match: 1 HTTP/1.1 304 Not Modified [no ETag] [no content returned!] ETag: GET Not Modified Resource
19. /Orders Client GET /Orders HTTP/1.1 HTTP/1.1 200 OK Etag: 1 [content goes in body] GET /Orders HTTP/1.1 If-None-Match: 1 HTTP/1.1 200 OK Etag: 2 [new content goes in body!] ETag: GET modified resource
20. /Orders Client HTTP/1.1 200 OK Etag: 1 [content goes in body] PUT /Orders HTTP/1.1 If-Match: 1 [new content goes in body] HTTP/1.1 100 Continue [no ETag] [no content!] GET /Orders HTTP/1.1 ETag: Modify Resource (PUT)
21. /Orders Client HTTP/1.1 200 OK Etag: 1 [content goes in body] PUT /Orders HTTP/1.1 If-Match: 1 [new content goes in body] HTTP/1.1 412 Precondition Failed [no ETag] [no content!] GET /Orders HTTP/1.1 ETag: Modify Changed Resource (PUT)
22. God damned HTTP! What we gonna do? • Override changes! • Yeah! It’s possible! • Download the latest version using GET method • We will know the new Etag then Etag: mismatch when PUT
23. /Orders Client HTTP/1.1 412 Precondition Failed [no ETag] [no content!] PUT /Orders HTTP/1.1 If-None-Match: 1 [new content goes in body] HTTP/1.1 100 Continue [no ETag] [no content!] PUT /Orders HTTP/1.1 If-Match: 1 [new content goes in body] Etag: Override Changes When PUT
24. • ETag and If-* headers came with HTTP 1.1 • In HTTP 1.0 there are another set of headers: Last-Modified: Sat, 29 Oct 2011 19:43:31 GMT If-Modified-Since: Sat, 29 Oct 2011 19:43:31 GMT Additional HTTP Headers
25. int Multiply(int x, int y) HTTP IPC (Named Pipes) TCP Client TCP SOAP UDP Web Services: Protocols
26. POST /search HTTP/1.1 Host: www.domain.com Content-Type: application/x-www-form- urlencoded term=something HTTP/1.1 303 See Other Location: /search/something/1 POST-Redirect-GET pattern
