The Theory of Relational Databases

Sperasoft workshop presentation: The Theory of Relational Databases

Transcript

1. Relational database
2. Relational Model The main highlights of this model • Data is stored in tables called relations. • Relations can be normalized. • In normalized relations, values saved are atomic values. • Each row in a relation contains a unique value. • Each column in a relation contains values from a same domain.
3. Concepts Concepts Tables − In relational data model, relations are saved in the format of Tables. This format stores the relation among entities. A table has rows and columns, where rows represents records and columns represent the attributes. Tuple − A single row of a table, which contains a single record for that relation is called a tuple. Relation instance − A finite set of tuples in the relational database system represents relation instance. Relation instances do not have duplicate tuples. Relation schema − A relation schema describes the relation name (table name), attributes, and their names. Relation key − Each row has one or more attributes, known as relation key, which can identify the row in the relation (table) uniquely. Attribute domain − Every attribute has some pre-defined value scope, known as attribute domain.
4. Normalization Database Normalization is a technique of organizing the data in the database. Normalization is a systematic approach of decomposing tables to eliminate data redundancy. It is a multi-step process that puts data into tabular form by removing duplicated data from the relation tables. Normalization is a method to remove all anomalies and bring the database to a consistent state.
5. First Normal Form First Normal Form is defined in the definition of relations (tables) itself. This rule defines that all the attributes in a relation must have atomic domains. The values in an atomic domain are indivisible units.
6. Second Normal Form As per the Second Normal Form there must not be any partial dependency of any column on primary key. It means that for a table that has concatenated primary key, each column in the table that is not part of the primary key must depend upon the entire concatenated key for its existence.
7. Third Normal Form For a relation to be in Third Normal Form, it must be in Second Normal form and should not be non-prime attribute is transitively dependent on prime key attribute.
8. SQL Overview SQL is a programming language for Relational Databases. It is designed over relational algebra and tuple relational calculus. SQL comes as a package with all major distributions of RDBMS.
9. SQL Joins Join is a combination of a Cartesian product followed by a selection process. A Join operation pairs two tuples from different relations, if and only if a given join condition is satisfied.
10. Transactions A transaction can be defined as a group of tasks. A single task is the minimum processing unit which cannot be divided further.
11. Indexing Indexing is a data structure technique to efficiently retrieve records from the database files based on some attributes on which the indexing has been done.
12. Hashing Hashing uses hash functions with search keys as parameters to generate the address of a data record.
