  1. P4 新手初探 2018/05/26, Taiwan, SDN x Cloud Native Meetup Presenter:

    Shan-Jung Fu (Samina) 1 Slides: http://bit.ly/p4cntug
  2. Hello! I am Shan-Jung Fu (Samina). • A master student

    in computer science at NCTU • Was a Information Technology Service Center Network & System Engineer at NCTU before • You can find me at ◦ GitHub: @sufuf3 ◦ Twitter: @sufuf3149 2
  3. Outline • What is P4 • Why P4 • P4.org

    Membership • The concept of Packet processing w/ P4 • Key Components of P4 • P4 16 Language • Example of P4 pipeline • P4 Compiler • Environments • Try P4 • What can you do with P4? • Conclusion 3
  4. • What is P4 • Why P4 • P4.org Membership

    • The concept of Packet processing w/ P4 • Key Components of P4 • P4 16 Language • Example of P4 pipeline • P4 Compiler • Environments • Try P4 • What can you do with P4? • Conclusion Outline 4
  5. • Programming Protocol-Independent Packet Processors ◦ processors: eg. switches, smart

    NIC, etc • Web site: https://p4.org • GitHub: https://github.com/p4lang • White Paper(July 2014) What is P4 5
  6. What is P4 (Cont’d) • A high-level language • Can

    program the network data plane Ref: https://www.slideshare.net/Docker/docker-networking-control-plane-and-data-plane 6
  7. • What is P4 • Why P4 ◦ Motivation ◦

    Benefits • P4.org Membership • The concept of Packet processing w/ P4 • Key Components of P4 • P4 16 Language • Example of P4 pipeline • P4 Compiler • Environments • Try P4 • What can you do with P4? • Conclusion Outline 7
  8. • Network changes Motivation 2014 P4: Programming Protocol-Independent Packet Processors

    2008 Software Defined Networking (SDN) with OpenFlow Before 2008 Traditional Network • Motivation • Benefits 8
  9. Software-Defined Networking(SDN) • Physical separation of the network control plane

    from the forwarding plane (data plane) • Control plane controls several devices • The network control to become directly programmable • Motivation • Benefits Ref: https://www.sdxcentral.com/sdn/definitions/inside-sdn-architecture/ 9
  10. Using P4 to solve OpenFlow problems • OpenFlow explicitly specifies

    protocol headers on which it operates. This set has grown from 12 to 41 fields in a few years, increasing the complexity of the specification while still not providing the flexibility to add new headers. • Motivation • Benefits Versio n Date Header Fields OF 1.0 Dec 2009 12 fields (Ethernet, TCP/IPv4) OF 1.1 Feb 2011 15 fields (MPLS, inter-table metadata) OF 1.2 Dec 2011 36 fields (ARP, ICMP, IPv6, etc.) OF 1.3 Jun 2012 40 fields OF 1.4 Oct 2013 41 fields Ref: https://www.sigcomm.org/sites/default/files/ccr/papers/2014/July/0000000-0000004.pdf 11
  11. The goals of P4 • Reconfigurability in the field •

    Protocol independence ◦ Switches should not be tied to any specific network protocols. ◦ Controller should be able to specify ▪ A packet parser for extracting header fields with particular names and types ▪ A collection of typed match + action tables that process these headers • Target independence ◦ Programmers should be able to describe packet-processing functionality independently of the specifics of the underlying hardware. • Motivation • Benefits Ref: https://www.sigcomm.org/sites/default/files/ccr/papers/2014/July/0000000-0000004.pdf 12
  12. Benefits of P4 Benefits of Data Plane Programmability • New

    Features - Add new protocols • Reduce complexity - Remove unused protocols • Efficient use of resources - flexible use of tables • Greater visibility - New diagnostic techniques, telemetry, etc. • Software style development - rapid design cycle, fast innovation, fix data plane bugs in the field • You keep your own ideas Think programming rather than protocols... • Motivation • Benefits Ref: https://p4.org/p4-spec/docs/P4-16-v1.0.0-spec.html#sec-benefits-of-p4 && https://p4.org/assets/P4_tutorial_01_basics.gslide.pdf 13
  13. • What is P4 • Why P4 • P4.org Membership

    • The concept of Packet processing w/ P4 • Key Components of P4 • P4 16 Language • Example of P4 pipeline • P4 Compiler • Environments • Try P4 • What can you do with P4? • Conclusion Outline 14
  14. • What is P4 • Why P4 • P4.org Membership

    • The concept of Packet processing w/ P4 • Key Components of P4 • P4 16 Language • Example of P4 pipeline • P4 Compiler • Environments • Try P4 • What can you do with P4? • Conclusion Outline 16
  15. The concept of Packet processing w/ P4 • Headers ◦

    Describes the sequence & structure of a series of fields typedef bit<48> macAddr_t; typedef bit<32> ip4Addr_t; header ethernet_t { macAddr_t dstAddr; macAddr_t srcAddr; bit<16> etherType; } 17
  16. • Parsers ◦ Specifies how to identify headers & valid

    header sequences within packets The concept of Packet processing w/ P4 (Cont’d) MAC Header IP Header TCP header data 18
  17. The concept of Packet processing w/ P4 (Cont’d) • Parsers

    ◦ Specifies how to identify headers & valid header sequences within packets header ethernet_t { macAddr_t dstAddr; macAddr_t srcAddr; bit<16> etherType; } dstAddr = 8000207A3F3E srcAddr = 800020203AAE etherType = 0x800 19
  18. • After the switch parse headers’ value, the switch needs

    to process the packet. • How does the switch process the headers’ value? 1. Write some logical program to deal with them ▪ Actions 2. Invoke the actions according to the rules which are sent from the SDN controller ▪ Tables • Control Program ◦ Determines the order of tables that are applied to a packet. A simple imperative program describe the flow of control between match + action tables The concept of Packet processing w/ P4 (Cont’d) 20
  19. The concept of Packet processing w/ P4 (Cont’d) SDN controller

    table_add ipv4_lpm ipv4_forward 10.0.1.1/32 => 00:00:00:00:01:01 1 Table name Action name Key table ipv4_lpm { key = { hdr.ipv4.dstAddr: lpm; } action = { ipv4_forward; drop; NoAction; } ...} 21
  20. • Match-Action Processing The concept of Packet processing w/ P4

    (Cont’d) Ref: https://p4.org/assets/P4_tutorial_01_basics.gslide.pdf 22
  21. • What is P4 • Why P4 • P4.org Membership

    • The concept of Packet processing w/ P4 • Key Components of P4 • P4 16 Language • Example of P4 pipeline • P4 Compiler • Environments • Try P4 • What can you do with P4? • Conclusion Outline 23
  22. • Headers ◦ Describes the sequence & structure of a

    series of fields • Parsers ◦ Specifies how to identify headers & valid header sequences within packets • Tables (match + action tables) ◦ The mechanism for performing packet processing • Actions ◦ P4 supports construction of complex actions from simpler protocol-independent primitives. These complex actions are available within match + action tables. • Control Program ◦ Determines the order of tables that are applied to a packet. A simple imperative program describe the flow of control between match + action tables Key Components of P4 24
  23. • What is P4 • Why P4 • P4.org Membership

    • The concept of Packet processing w/ P4 • Key Components of P4 • P4 16 Language ◦ Program Template ◦ Approach ▪ Target ▪ Architecture • Example of P4 pipeline • P4 Compiler • Environments • Try P4 • What can you do with P4? • Conclusion Outline 25
  24. P4 16 Program Template • • Program Template • Approach

    ◦ Target ◦ Architecture Ref: https://p4.org/assets/P4_tutorial_01_basics.gslide.pdf Learn P4 lang like SQL 26
  25. P4 16 Approach • Program Template • Approach ◦ Target

    ◦ Architecture Ref: https://p4.org/assets/P4_tutorial_01_basics.gslide.pdf 27 Term P4 Architecture P4 Target
  26. P4 Target • Program Template • Approach ◦ Target ◦

    Architecture Ref: https://p4.org/assets/P4_tutorial_01_basics.gslide.pdf 28 • An embodiment of a specific hardware implementation
  27. P4 16 Architecture • Program Template • Approach ◦ Target

    ◦ Architecture • Provides an interface to program a target via some set of P4-programmable components, externs, fixed components 29 Ref: https://p4.org/assets/P4_tutorial_01_basics.gslide.pdf
  28. • What is P4 • Why P4 • P4.org Membership

    • The concept of Packet processing w/ P4 • Key Components of P4 • P4 16 Language • Example of P4 pipeline ◦ Topology ◦ Source code ◦ Architecture ◦ Explain • P4 Compiler • Environments • Try P4 • What can you do with P4? Outline 30
  29. Basic Forwarding: Topology • For every packet, the L3 switch

    must perform: ◦ Update the source and destination MAC addresses ◦ Decrement the time-to-live (TTL) in the IP header ◦ Forward the packet out the appropriate port • Topology • Source code • Architecture • Explain 31 • Have a single table: the control plane will populate with static rules • Each rule will map an IP address to the MAC address and output port for the next hop • Already defined the control plane rules
  30. • Topology • Source code • Architecture • Explain Basic

    Forwarding: Source code • Code: https://github.com/p4lang/tutorials/blob/master/P4D2_2018 _East/exercises/basic/solution/basic.p4 • Ref: https://p4.org/assets/P4_tutorial_01_basics.gslide.pdf 32
  31. Architecture • Ingress Pipeline • Egress Pipeline • Traffic Manager

    ◦ N:1 Relationships: Package Queueing, Congestion Control ◦ 1:N Relationships: Replication ◦ Scheduling Ref: https://p4.org/assets/P4_tutorial_01_basics.gslide.pdf https://github.com/NetFPGA/P4-NetFPGA-public/blob/master/slides/FPGA-2018/FPGA%202018%20P4%20tut orial.pdf 33 • Topology • Source code • Architecture • Explain
  32. Explain • Preprocessor and contant • Headers • Parser •

    Controls ◦ Checksum Verification ◦ Ingress Processing ◦ Egress Processing ◦ Checksum Computation ◦ Deparser • Switch • Topology • Source code • Architecture • Explain 34
  33. • Preprocessor and contant • Headers • Parser • Controls

    ◦ Checksum Verification ◦ Ingress Processing ◦ Egress Processing ◦ Checksum Computation ◦ Deparser • Switch Explain • Topology • Source code • Explain 35 • Topology • Source code • Architecture • Explain
  34. • Include P4 core library ◦ Defines some standard data-types

    and error codes ◦ https://p4.org/p4-spec/docs/P4-16-v1.0.0-spec.html#sec -p4-core-lib • Ref: https://en.wikipedia.org/wiki/EtherType Preprocessor and contant 36 2 3 4 5 #include <core.p4> #include <v1model.p4> const bit<16> TYPE_IPV4 = 0x800;
  35. • Preprocessor and contant • Headers • Parser • Controls

    ◦ Checksum Verification ◦ Ingress Processing ◦ Egress Processing ◦ Checksum Computation ◦ Deparser • Switch Explain • Topology • Source code • Explain 37 • Topology • Source code • Architecture • Explain
  36. Headers • Typedef ◦ Alternative name for a type •

    Basic Types ◦ bit<n> ◦ bit == bit<1> ◦ int<n> ◦ varbit<n> • Header Types ◦ Ordered collection of members 38 11 12 13 14 15 16 17 18 19 typedef bit<9> egressSpec_t; typedef bit<48> macAddr_t; typedef bit<32> ip4Addr_t; header ethernet_t { macAddr_t dstAddr; macAddr_t srcAddr; bit<16> etherType; }
  37. Headers (Cont’d) 39 21 22 23 24 25 26 27

    28 29 30 31 32 33 34 header ipv4_t { bit<4> version; bit<4> ihl; bit<8> diffserv; bit<16> totalLen; bit<16> identification; bit<3> flags; bit<13> fragOffset; bit<8> ttl; bit<8> protocol; bit<16> hdrChecksum; ip4Addr_t srcAddr; ip4Addr_t dstAddr; }
  38. • Other useful types • Struct ◦ Unordered collection of

    members (with no alignment restrictions) • Header Stack ◦ array of headers • Header Union ◦ one of several headers Headers (Cont’d) 40 36 37 38 39 40 41 42 43 struct metadata { /* empty */ } struct headers { ethernet_t ethernet; ipv4_t ipv4; }
  39. • Preprocessor and contant • Headers • Parser • Controls

    ◦ Checksum Verification ◦ Ingress Processing ◦ Egress Processing ◦ Checksum Computation ◦ Deparser • Switch Explain • Topology • Source code • Explain 41 • Topology • Source code • Architecture • Explain
  40. 49 . . . 71 parser MyParser(packet_in packet, out headers

    hdr, inout metadata meta, inout standard_metadata_t standard_metadata) { state start { transition parse_ethernet; } state parse_ethernet { packet.extract(hdr.ethernet); transition select(hdr.ethernet.etherType) { TYPE_IPV4: parse_ipv4; default: accept; } } state parse_ipv4 { packet.extract(hdr.ipv4); transition accept; } } Parser 42
  41. parser MyParser(packet_in packet, out headers hdr, inout metadata meta, inout

    standard_metadata_t standard_metadata) { state start { transition parse_ethernet; } state parse_ethernet { packet.extract(hdr.ethernet); transition select(hdr.ethernet.etherType) { TYPE_IPV4: parse_ipv4; default: accept; } } state parse_ipv4 { packet.extract(hdr.ipv4); transition accept; Parser (Cont’d) Parsers are functions that map packets into headers and metadata, written in a state machine style • packet_in: reads its input from a packet_in • in: read-only • out: are treated as a storage • inout: both in & out 43
  42. parser MyParser(packet_in packet, out headers hdr, inout metadata meta, inout

    standard_metadata_t standard_metadata) { state start { transition parse_ethernet; } state parse_ethernet { packet.extract(hdr.ethernet); transition select(hdr.ethernet.etherType) { TYPE_IPV4: parse_ipv4; default: accept; } } state parse_ipv4 { packet.extract(hdr.ipv4); transition accept; } Every parser has three predefined states • start • accept • reject Parser (Cont’d) 44
  43. is_default parser MyParser(packet_in packet, out headers hdr, inout metadata meta,

    inout standard_metadata_t standard_metadata) { state start { transition parse_ethernet; } state parse_ethernet { packet.extract(hdr.ethernet); transition select(hdr.ethernet.etherType) { TYPE_IPV4: parse_ipv4; default: accept; } } state parse_ipv4 { packet.extract(hdr.ipv4); transition accept; } Every parser has three predefined states • start • accept • reject Parser (Cont’d) packet.extract is from include file: core.p4 select statement that can be used to branch in a parser 45 start parse_ethernet Ethernet header extract is_IPv4: parse_ipv4 IPv4 header extract Accept Accept
  44. Explain • Topology • Source code • Explain 46 •

    Preprocessor and contant • Headers • Parser • Controls ◦ Checksum Verification ◦ Ingress Processing ◦ Egress Processing ◦ Checksum Computation ◦ Deparser • Switch • Topology • Source code • Architecture • Explain
  45. • Similar to C functions (without loops) • Can declare

    variables, create tables, instantiate externs, etc. • Functionality specified by code in apply statement • Represent all kinds of processing that are expressible as DAG(Directed Acyclic Graph): ◦ Additional forms of packet processing (updating checksums) ◦ Match-Action Pipelines ◦ Deparsers Controls control MyVerifyChecksum(inout headers hdr, inout metadata meta) { apply { } } Evaluating a program that has several instantiations of the same component. parameters of control • Controls ◦ CV ◦ Ingress ◦ Egress ◦ CC ◦ Deparser 47
  46. Controls (Cont’d) • The control instances enclose controllable entities: ◦

    actions, tables, keys, extern instances • Control flow control MyIngress(inout headers hdr, inout metadata meta, inout standard_metadata_t standard_metadata) { action drop() { ... } action ipv4_forward(macAddr_t dstAddr, egressSpec_t port) { standard_metadata.egress_spec = port; hdr.ethernet.srcAddr = hdr.ethernet.dstAddr; hdr.ethernet.dstAddr = dstAddr; hdr.ipv4.ttl = hdr.ipv4.ttl - 1; } table ipv4_lpm { ... } apply { //body of the pipeline if (hdr.ipv4.isValid()) { ipv4_lpm.apply(); } } } • Controls ◦ CV ◦ Ingress ◦ Egress ◦ CC ◦ Deparser 48
  47. • Actions ◦ Very similar to C functions ◦ Reside

    in tables; invoked automatically on table match. ◦ Can be declared inside a control or globally ◦ Parameters have type and direction ◦ Variables can be instantiated inside ◦ Many standard arithmetic and logical operations are supported Controls (Cont’d) • Controls ◦ CV ◦ Ingress ◦ Egress ◦ CC ◦ Deparser 49
  48. Data Plane (P4) Program • Defines the format of table

    ◦ Key Fields ◦ Actions ◦ Action Data • Performs the lookup • Executes the chosen action Control Plane (IP stack, Routing protocols) • Populates table entries with specific information ◦ Based on the configuration, automatic discovery, protocol calculations table ipv4_lpm { key = { hdr.ipv4.dstAddr: lpm; } action = { ipv4_forward; drop; NoAction; } size = 1024; default_action = NoAction(); } Controls (Cont’d) Tables(Cont’d) • Controls ◦ CV ◦ Ingress ◦ Egress ◦ CC ◦ Deparser 50 table_add ipv4_lpm ipv4_forward 10.0.1.1/32 => 00:00:00:00:01:01 1 Longest prefix match
  49. Checksum Verification • No built-in constructs in P416 for manipulating

    packet checksums • You can write your checksum verification • Ref: https://p4.org/p4-spec/docs/P4-16-v1.0.0-spec.html#sec-ch ecksums • Controls ◦ CV ◦ Ingress ◦ Egress ◦ CC ◦ Deparser 51 77 78 79 control MyVerifyChecksum(inout headers hdr, inout metadata meta) { apply { } }
  50. 86 . . . 118 control MyIngress(inout headers hdr, inout

    metadata meta, inout standard_metadata_t standard_metadata) { action drop() { mark_to_drop(); } action ipv4_forward(macAddr_t dstAddr, egressSpec_t port) { standard_metadata.egress_spec = port; hdr.ethernet.srcAddr = hdr.ethernet.dstAddr; hdr.ethernet.dstAddr = dstAddr; hdr.ipv4.ttl = hdr.ipv4.ttl - 1; } table ipv4_lpm { key = { hdr.ipv4.dstAddr: lpm; } action = { ipv4_forward; drop; NoAction; } size = 1024; default_action = NoAction(); } apply { if (hdr.ipv4.isValid()) { ipv4_lpm.apply(); }}} Ingress Processing • Controls ◦ CV ◦ Ingress ◦ Egress ◦ CC ◦ Deparser 52
  51. Egress Processing • Egress processing • Controls ◦ CV ◦

    Ingress ◦ Egress ◦ CC ◦ Deparser 53 124 125 126 127 128 control MyEgress(inout headers hdr, inout metadata meta, inout standard_metadata_t standard_metadata){ apply { } }
  52. 134 135 136 137 138 139 140 141 142 143

    144 145 146 147 148 149 150 151 152 control MyComputeChecksum(inout headers hdr, inout metadata meta) { apply { update_checksum( hdr.ipv4.isValid(), { hdr.ipv4.version, hdr.ipv4.ihl, hdr.ipv4.diffserv, hdr.ipv4.totalLen, hdr.ipv4.identification, hdr.ipv4.flags, hdr.ipv4.fragOffset, hdr.ipv4.ttl, hdr.ipv4.protocol, hdr.ipv4.srcAddr, hdr.ipv4.dstAddr }, hdr.ipv4.hdrChecksum, HashAlgorithm.csum16); } } Checksum Computation Computes the checksum of the supplied data • Controls ◦ CV ◦ Ingress ◦ Egress ◦ CC ◦ Deparser 54
  53. 158 159 160 161 162 163 control MyDeparser(packet_out packet, in

    headers hdr){ apply { packet.emit(hdr.ethernet); packet.emit(hdr.ipv4); } } Deparser • Assembles the headers back into a well-formed packet • P416 does not provide a separate language for packet deparsing • Deparsing is done in a control block that has at least one parameter of type packet_out • packet_out extern is defined in core.p4: emit(hdr): serializes header if it is valid • Advantages: ◦ Makes deparsing explicit...but decouples from parsing • Controls ◦ CV ◦ Ingress ◦ Egress ◦ CC ◦ Deparser 55
  54. Explain • Topology • Source code • Explain 56 •

    Preprocessor and contant • Headers • Parser • Controls ◦ Checksum Verification ◦ Ingress Processing ◦ Egress Processing ◦ Checksum Computation ◦ Deparser • Switch • Topology • Source code • Architecture • Explain
  55. 169 170 171 172 173 174 175 176 V1Switch( MyParser(),

    MyVerifyChecksum(), MyIngress(), MyEgress(), MyComputeChecksum(), MyDeparser() ) main; • Instantiate the top-level V1Switch package • All the arguments of the V1Switch package constructor have been evaluated (instances of MyParser, MyVerifyChecksum ...). • Their signatures are matched w/ the V1Switch declaration • The result of the program evaluation is the value of the main variable Switch 57
  56. • What is P4 • Why P4 • P4.org Membership

    • The concept of Packet processing w/ P4 • Key Components of P4 • P4 16 Language • Example of P4 pipeline • P4 Compiler • Environments • Try P4 • What can you do with P4? • Conclusion Outline 58
  57. • p4c • A new, alpha-quality reference compiler • Supports

    P4 16 • Provides a standard frontend and midend which can be combined with a target-specific backend to create a complete P4 compiler • The compiler supports several backends: • p4c-bmv2 – targets the behavioral model • p4c-ebpf, p4c-graphs, p4test … etc. • Repository: https://github.com/p4lang/p4c • Eg. P4 Compiler $ p4c -b bmv2-ss-p4org program.p4 -o program.bmv2.json 59
  58. • What is P4 • Why P4 • P4.org Membership

    • The concept of Packet processing w/ P4 • Key Components of P4 • P4 16 Language • Example of P4 pipeline • P4 Compiler • Environments • Try P4 • What can you do with P4? • Conclusion Outline 60
  59. Environments BMv2 (Behavioral Model) • The second version of the

    P4 software switch (aka behavioral model) • nicknamed BMv2 • A simulation environment to run the P4 software switch, standalone or in Mininet • Allows you to easily simulate new architectures by implementing new externs • Enabling you to organize the forwarding elements as needed • Repository: https://github.com/p4lang/behavioral-model 62
  60. Environments Programmable Network Devices • Protocol-Independent Switch Architecture (PISA): Flexible

    Match+Action ASICs ◦ Intel Flexpipe, Cisco Doppler, Cavium (Xpliant), Barefoot Tofino, ... • Network Processor Unit (NPU) ◦ EZchip, Netronome, ... • CPU ◦ Open Vswitch, eBPF, DPDK, VPP... • Field-Programmable Gate Array (FPGA) ◦ Xilinx, Altera, ... Ref: https://p4.org/assets/P4_tutorial_01_basics.gslide.pdf 63
  61. • What is P4 • Why P4 • P4.org Membership

    • The concept of Packet processing w/ P4 • Key Components of P4 • P4 16 Language • Example of P4 pipeline • P4 Compiler • Environments • Try P4 • What can you do with P4? • Conclusion Outline 64
  62. Try P4 • P4 tutorials: https://github.com/p4lang/tutorials • Before Hands-on, you

    need to setup the environment ◦ OS & HW requirement ▪ OS: Ubuntu 16.04 64-bits ▪ CPU: at least 2 cores ▪ RAM: at least 2G ▪ Disk: at least 25G ◦ Run command by yourself (not root), after finish OS installation $ wget -O setup.sh https://goo.gl/EHgk4v && sudo bash setup.sh && wget -O - https://goo.gl/NKaau7 | bash 65
  63. • What is P4 • Why P4 • P4.org Membership

    • The concept of Packet processing w/ P4 • Key Components of P4 • P4 16 Language • Example of P4 pipeline • P4 Compiler • Environments • Try P4 • What can you do with P4? • Conclusion Outline 66
  64. Applications of P4 • Layer 4 Load Balancer – SilkRoad[1]

    • Low Latency Congestion Control – NDP[2] • Fast In-Network cache for key-value stores – NetCache[3] • In-band Network Telemetry – INT[4] • Consensus at network speed – NetPaxos[5] • ... and much more [1] Miao, Rui, et al. "SilkRoad: Making Stateful Layer-4 Load Balancing Fast and Cheap Using Switching ASICs." SIGCOMM, 2017. [2] Handley, Mark, et al. "Re-architecting datacenter networks and stacks for low latency and high performance.” SIGCOMM, 2017. [3] Xin Jin et al. “NetCache: Balancing Key-Value Stores with Fast In-Network Caching.” To appear at SOSP 2017 [4] Kim, Changhoon, et al. "In-band network telemetry via programmable dataplanes.” SIGCOMM. 2015. [5] Dang, Huynh Tu, et al. "NetPaxos: Consensus at network speed.” SIGCOMM, 2015 What can you do with P4? 67
  65. Outline • What is P4 • Why P4 • P4.org

    Membership • The concept of Packet processing w/ P4 • Key Components of P4 • P4 16 Language • Example of P4 pipeline • P4 Compiler • Environments • Try P4 • What can you do with P4? • Conclusion 68
  66. Conclusion • Introduce P4, its concepts, languages & some applications

    • With P4, SDN programmers can design these goals ◦ Can keep the new ideas secret ▪ Don’t have to let switch chip vendor know ◦ Unique features in every network 69
  67. Thanks! Any questions? You can find me at: @sufuf3 (GitHub)

    @sufuf3149 (Twitter) More: https://p4tw.org/ 70
