1. Writing testable Android apps Tomáš Kypta @TomasKypta
2. What does it mean testable?
3. What does it mean testable? • Test it quickly during development • Test units in isolation • There’s a way to provide mocks
4. How Google imagined unit testing?
5. Instrumentation tests
6. What “standard” Android app code looks like?
7. “Standard” Android app • check Android SDK samples & documentation • or Google’s iosched app • business logic in Activities, Fragments, Services, … • view and presenter effectively mixed together
8. This is actually the structure recommended by Google!
9. How to make it testable?
10. Abstract away from Android APIs
11. Android APIs • difficult to test and mock • we don’t have creation of Android components under control
12. Abstracting Android APIs • we need some boilerplate to get away • remove all business logic from Android component classes • isolate business logic into presenters, managers, POJOs, … • when possible use MVP pattern
13. Abstracting Android APIs • further improvements • avoid or wrap Android API
14. Clean code • try to write clean code • avoid methods having hundreds of lines • avoid Activities/Fragments having thousands of lines
15. And how to test it? • our presenters, POJOs, managers, providers, etc. are simple to test • Android components are stripped off of business logic • nothing important to test remains there
16. Bonus Advantages • better readability • better maintainability
17. Android Unit Tests
18. Android Unit Tests • Added rather recently • You need some work to make them really useful. • Dependency injection • Mocking
19. Dependency Injection
20. Dependency Injection • the main ingredient • avoid “new” keyword • Dagger 2 FTW
21. Dagger 2 • by Google • evolution of Dagger 1 (by Square) • no reflection • generated code in compile time • constructor and field injection
22. Dagger 2 • Constructor injection private ProviderC mProviderC;
 private ProviderD mProviderD;

 @Inject
 public ProviderA(ProviderC providerC, ProviderD providerD) {
 mProviderC = providerC;
 mProviderD = providerD;
 }
23. Dagger 2 • Field injection public class MainActivity extends AppCompatActivity {
 @Inject ProviderA mProviderA;
 @Inject ProviderB mProviderB; @Override
 protected void onCreate(Bundle savedInstanceState) {
 super.onCreate(savedInstanceState);
 ((MyApp) getApplication()).getAppComponent() .injectMainActivity(this); } }
24. Dagger 2 • prefer constructor injection wherever possible • you can test the unit in isolation • providing mocks is a piece of cake
25. Dagger 2 • Some catches when using field injection • Construct the whole component • Implicit provisions doesn’t support overrides!! public class ProviderA { … @Inject
 public ProviderA(ProviderC providerC) {
 mProviderC = providerC;
 } }
26. Dagger 2 • Some catches when using field injection • Make explicit provisions @Module
 public class AppModule {

 @Provides @Singleton
 ProviderB provideProvider2(ProviderC providerC) {
 return new ProviderB(providerC);
 }

 @Provides
 ProviderD provideProvider4() {
 return new ProviderD();
 }
 } • Beware marking constructors with @Inject when providing explicitly • may create unwanted double provision
27. Mocking
28. Mocking • Android framework has some historical things • package android.test.mock • for instrumentation tests
29. Android APIs & Unit Test • historically • java.lang.RuntimeException: Stub! • now • mockable android.jar • Method ... not mocked.
30. Mocking • it’s important to “program to an interface” • avoid final and static
31. Mocking
32. @RunWith(JUnit4.class)
 public class ProviderATest {

 @Mock ProviderC mProviderC;

 @Mock ProviderD mProviderD;

 ProviderA mProviderA;

 @Before
 public void setUp() throws Exception {
 MockitoAnnotations.initMocks(this);
 Mockito.when(mProviderC.getString()).thenReturn("hello");
 Mockito.when(mProviderD.getString()).thenReturn("world");
 mProviderA = new ProviderA(mProviderC, mProviderD);
 } … }
33. Mocking static methods
34. Static methods • avoid it as much as possible • things like TextUtils.isEmpty() can be painful • alternatives, e.g. Apache commons StringUtils.isEmpty() • PowerMock to the rescue • still better to avoid static
35. Negatives of testable apps?
36. Negatives? • increase the number of methods and classes • duplication of Android interfaces/classes • bloated constructors with lots of dependencies
37. Dev App Builds
38. Dev App Builds • How to use dev overrides in dev buils? • utilize Android’s Gradle build • Product Flavors can be used for that
39. Recommended Libraries
40. Recommended Libraries • Dagger 2 • Retrofit • RxJava / RxAndroid • Mortar
41. Recommended Libraries - for testing
42. Q&A
43. Thank You
