Guide to the jungle of testing frameworks

There are many tools, libraries and frameworks available for Android developers to test their applications. The jungle is huge and it's not easy to find the right ones. Some frameworks are good for unit testing, some are good for instrumentation testing, and some can be used for both. Some have great capabilities but annoying weaknesses. Some are good for testing UI, other allow you to make good mocks. We will look at many frameworks, the popular ones like Mockito, Robolectric, Espresso, and some other.
Presented at GDG DevFest Minsk 2016.

Transcript

1. Guide to the jungle of testing frameworks Tomáš Kypta @TomasKypta
3. Unit Testing Experience on Android
5. Android apps are difficult to test
6. Android apps were difficult to test
7. Types of Android tests
8. Types of Android tests Instrumentation tests Local unit tests
9. Android test code • project sources • ${module}/src/main/java • instrumentation tests • ${module}/src/androidTest/java • unit tests • ${module}/src/test/java • full Gradle and Android Studio support
11. • the essential piece of both instrumentation and unit tests • alone can be used only for pure Java code • doesn’t provide any mocks or Android APIs
12. Instrumentation Tests
13. Instrumentation Tests • running on physical device or emulator • gradle connectedAndroidTest • ${module}/build/reports/androidTests/connected/ index.html
15. Instrumentation Tests Legacy instrumentation tests or Testing Support Library
16. Legacy Instrumentation Tests • JUnit3 • Tests extend from TestCase • AndroidTestCase • ActivityInstrumentationTestCase2 • ServiceTestCase • … deprecated since API level 24
17. Testing Support Library • JUnit4 compatible • AndroidJUnitRunner android { defaultConfig { testInstrumentationRunner "android.support.test.runner.AndroidJUnitRunner" } } dependencies { androidTestCompile 'com.android.support.test:runner:0.5' }
18. Testing Support Library • JUnit test rules • AndroidTestRule • ServiceTestRule • DisableOnAndroidDebug • LogLogcatRule • … androidTestCompile 'com.android.support.test:rules:0.5'
20. • framework for functional UI tests • part of Android Testing Support Library androidTestCompile 'com.android.support.test.espresso:espresso-core:2.2.2'
21. @Test public void sayHello() { onView(withId(R.id.edit_text)) .perform(typeText(STRING_TO_BE_TYPED), closeSoftKeyboard()); onView(withText("Say hello!")) .perform(click()); String expectedText = "Hello, " + STRING_TO_BE_TYPED + "!"; onView(withId(R.id.textView)) .check(matches(withText(expectedText))); }
22. Problems • testing on device is not isolated • device state affects the result • e.g. screen on/off might affect test result onView(withId(R.id.my_view)) .check(matches(isDisplayed()));
23. Some annoyances android.support.test.espresso.NoActivityResumedException: No activities in stage RESUMED. Did you forget to launch the activity. (test.getActivity() or similar)?
24. UI Automator
25. UI Automator • APIs for building UI tests • interaction with both your apps and system apps • Android 4.3+ androidTestCompile 'com.android.support.test.uiautomator:uiautomator-v18:2.1.2'
26. UI Automator • several parts • API for information retrieval and performing operations • API for cross-app testing • uiautomatorviewer tool
27. UI Automator @RunWith(AndroidJUnit4.class) public class AnActivityTest { private static final String MY_PACKAGE = "com.example.helloworld"; private static final int LAUNCH_TIMEOUT = 5000; UiDevice mDevice; @Before public void setUP() { mDevice = UiDevice.getInstance(InstrumentationRegistry.getInstrumentation()); mDevice.pressHome(); Context context = InstrumentationRegistry.getContext(); Intent intent = context.getPackageManager().getLaunchIntentForPackage(MY_PACKAGE); intent.addFlags(Intent.FLAG_ACTIVITY_CLEAR_TASK); context.startActivity(intent); // Wait for the app to appear mDevice.wait(Until.hasObject(By.pkg(MY_PACKAGE).depth(0)), LAUNCH_TIMEOUT); } // do the testing }
28. UI Automator @RunWith(AndroidJUnit4.class) public class AnActivityTest { // a setup @Test public void testText() throws Exception { UiObject textLabel = mDevice.findObject( new UiSelector().packageName(MY_PACKAGE).text("Hello World!")); UiObject button = mDevice.findObject( new UiSelector().packageName(MY_PACKAGE).text("Change text")); button.click(); UiObject2 textResult = mDevice.findObject(By.res(MY_PACKAGE, "txt_label")); Assert.assertEquals("Hello Minsk!", textResult.getText()); } }
29. Java API
30. • use with UI Automator • direct manipulation with sensor values on Genymotion devices • allows to omit mocking sensor values androidTestCompile 'com.genymotion.api:genymotion-api:1.0.2'
31. if (!GenymotionManager.isGenymotionDevice()) { return; //don't execute this test }
32. if (!GenymotionManager.isGenymotionDevice()) { return; //don't execute this test } GenymotionManager genymotion = Genymotion.getGenymotionManager( getInstrumentation().getContext());
33. if (!GenymotionManager.isGenymotionDevice()) { return; //don't execute this test } GenymotionManager genymotion = Genymotion.getGenymotionManager( getInstrumentation().getContext()); genymotion .getRadio().call("555123456");
34. if (!GenymotionManager.isGenymotionDevice()) { return; //don't execute this test } GenymotionManager genymotion = Genymotion.getGenymotionManager( getInstrumentation().getContext()); genymotion .getRadio().call("555123456"); genymotion .getNetwork().setProfile(Network.Profile.EDGE);
36. • for iOS, Android, Windows apps • based on WebDriver protocol • alternative to UI Automator • aims to automate apps from any language and any test framework • …with access to back-end APIs and DBs • Android 4.1+
37. Instrumentation tests are kinda SLOOOOOW
38. Unit Tests
39. Unit Tests • run on JVM • mockable android.jar • gradle test • ${module}/build/reports/tests/${variant}/index.html
40. ...
42. • Helps rarely • returns 0, false, null, … Method ... not mocked. android {
 testOptions {
 unitTests.returnDefaultValues = true }
 }
44. • mocking framework • easy to use • compatible with Android unit testing testCompile 'org.mockito:mockito-core:2.2.11'
45. • can be used also in instrumentation tests • needs dexmaker androidTestCompile 'org.mockito:mockito-core:2.2.11' androidTestCompile 'com.google.dexmaker:dexmaker:1.2' androidTestCompile 'com.google.dexmaker:dexmaker-mockito:1.2'
46. @RunWith(JUnit4.class) public class ContextManagerTest { @Mock Context mAppContext; }
47. @RunWith(JUnit4.class) public class ContextManagerTest { @Mock Context mAppContext; @Before public void setUp() { MockitoAnnotations.initMocks(this); } }
48. @RunWith(JUnit4.class) public class ContextManagerTest { @Mock Context mAppContext; @Before public void setUp() { MockitoAnnotations.initMocks(this); } @Test public void testWithContext() { … } }
49. @RunWith(MockitoJUnitRunner.class) public class ContextManagerTest { @Mock Context mAppContext; @Test public void testWithContext() { … } }
50. @RunWith(JUnit4.class) public class ContextManagerTest { @Test public void testWithContext() { Context appContext = mock(Context.class); } }
51. @RunWith(JUnit4.class) public class ContextManagerTest { @Test public void testWithContext() { Context appContext = mock(Context.class); Mockito.when(appContext.getPackageName()) .thenReturn(“com.example.app”); … } }
52. • Mockito.spy() • wrapping a real object • Mockito.verify() • verify that special condition are met • e.g. method called, method called twice, …
53. Limitations • final classes • opt-in incubating support in Mockito 2 • anonymous classes • primitive types • static methods
55. • Can mock static methods • Can be used together with Mockito
56. @RunWith(PowerMockRunner.class) @PrepareForTest(Static.class); PowerMockito.mockStatic(Static.class); Mockito.when(Static.staticMethod()) .thenReturn(value); PowerMockito.verifyStatic(Static.class);
58. • functional testing framework • runs on JVM • at first, might be difficult to use • the ultimate mock of Android APIs • provides mocks of system managers • allows custom shadows
59. • possible to use for UI testing • better to use for business logic @RunWith(RobolectricTestRunner.class) public class MyTest { … }
60. • Robolectric • RuntimeEnvironment • Shadows • ShadowApplication • ShadowLooper
61. Potential problems • difficult to search for solutions • long history of bigger API changes • many obsolete posts
63. • cross-platform BDD framework • human-like test definitions testCompile ‘junit:junit:4.12' testCompile ‘info.cukes:cucumber-java:1.2.5' testCompile 'info.cukes:cucumber-junit:1.2.5'
64. • describe the desired behaviour Feature: CoffeeMaker

 Scenario: a few coffees
 Given I previously had 3 coffees
 When I add one coffee
 Then I had 4 coffees
65. • create the mapping public class CoffeeMakerDefs {
 CoffeeMaker mCoffeeMaker = new CoffeeMaker();




 }
66. • create the mapping public class CoffeeMakerDefs {
 CoffeeMaker mCoffeeMaker = new CoffeeMaker();

 @Given("^I previously had (\\d+) coffees$")
 public void hadCoffeesPreviously(int coffees) {
 mCoffeeMaker.setCoffeeCount(coffees);
 }


 }
67. • create the mapping public class CoffeeMakerDefs {
 CoffeeMaker mCoffeeMaker = new CoffeeMaker();

 @Given("^I previously had (\\d+) coffees$")
 public void hadCoffeesPreviously(int coffees) {
 mCoffeeMaker.setCoffeeCount(coffees);
 }

 @When("^I add one coffee$")
 public void addCoffee() {
 mCoffeeMaker.addCoffee();
 }


 }
68. • create the mapping public class CoffeeMakerDefs {
 CoffeeMaker mCoffeeMaker = new CoffeeMaker();

 @Given("^I previously had (\\d+) coffees$")
 public void hadCoffeesPreviously(int coffees) {
 mCoffeeMaker.setCoffeeCount(coffees);
 }

 @When("^I add one coffee$")
 public void addCoffee() {
 mCoffeeMaker.addCoffee();
 }

 @Then("^I had (\\d+) coffees$")
 public void hadCoffees(int coffees) {
 Assert.assertEquals(coffees, mCoffeeMaker.getCoffeeCount());
 }
 }
69. • place definition and mapping at the same paths! • ${module}/src/test/java/com/example/MyMapping.java • ${module}/src/test/resources/com/example/ MyDefinition.feature @RunWith(Cucumber.class)
 public class RunCucumberTest {
 }
70. Code Coverage
71. Code Coverage • instrumentation tests • JaCoCo • EMMA • obsolete • unit tests • JaCoCo
72. Instrumentation Tests & Code Coverage • has to be explicitly enabled • gradle createDebugCoverageReport • ${module}/build/reports/coverage/debug/index.html • ${module}/build/outputs/code-coverage/connected/$ {deviceName}-coverage.ec • doesn’t work on some devices!!! buildTypes {
 debug {
 testCoverageEnabled true
 } }
73. JaCoCo
74. JaCoCo • enabled by default for unit tests • gradle test • generates binary report in build/jacoco • ${module}/build/jacoco/testDebugUnitTest.exec • it’s necessary to create a JacocoReport task to obtain a readable report
77. Good tests • run in any order • run in isolation • run consistently • run fast • are orthogonal
78. Rules of thumb • prefer pure Java • abstract away from Android APIs • separate business logic and UI • don’t write business logic into activities and fragments • MVP, MVVM is a way to go • try avoid static and final • use dependency injection
79. Questions?
