OpenShiftのクラスターバックアップリストア / OpenShift Cluster Backup Restore

OpenShiftのクラスターバックアップリストア / OpenShift Cluster Backup Restore

OpenShift.RUN 2022で話した内容です。

Takuya Utsunomiya

January 21, 2022
Tweet

More Decks by Takuya Utsunomiya

Other Decks in Technology

Transcript

  1. OpenShiftの
    クラスターバックアップ/リストア
    Red Hat K.K.
    Solution Architect
    宇都宮卓也
    あけおめ OpenShift.Run 2022

    View Slide

  2. kind: HumanBeings
    metadata:
    name: 宇都宮 卓也
    spec:
    group: レッドハット株式会社
    title: ソリューションアーキテクト
    born: 大阪
    age: 40歳
    favorites:
    technology: ストレージ
    hobby: [“プロレス観戦”,“将棋観戦”]
    drink: [“ビール”, “ワイン”]
    annoyance: [“最近目が霞む”, “肩が痛い”]
    うつぼ
    @japan_rook
    Japan Rook
    https://rook.connpass.com/
    Cloud Native Data
    Community
    https://cndata.connpass.com/
    https://www.redhat.com/ja/resource
    s/openshift-4-first-step-guide-step-t
    o-enterprise-kubernetes-ebook
    https://www.shoeisha.co.jp/
    book/detail/9784798175027
    $ whoami
    OpenShiftのクラスターバックアップ/リストア
    2

    View Slide

  3. 3
    バックアップ/リストアの基本
    OpenShiftのクラスターバックアップ/リストア
    様々なリストアが必要となる原因
    ● 物理障害
    ○ 機器故障、NW断、...
    ● 論理障害
    ○ オペミス、ファイルシステム破損、
    ...
    ● (広域)災害
    ○ 火災、地震、...
    ● セキュリティ事故
    ○ 攻撃、ランサムウェア、…
    サービスへの影響に直結
    ● RTO (Recovery Time Objective)
    ○ 復旧するまでの時間
    ● RPO (Recovery Point Objective)
    ○ 復旧すべき過去の地点
    想定するリストアを実施する状況 いつまでに、どの地点まで戻したいか
    状況ごとに、サービスレベルを守れるバックアップ方法を採用すべき

    View Slide

  4. 4
    サービスレベルに合わせたデータ保護の方法
    OpenShiftのクラスターバックアップ/リストア
    ● データセンター障害からの保護:
    ○ 電力網/空調設備の故障
    ○ 火災など人的災害
    ○ 洪水、地震など地理的規模の自然災害
    ● 非同期ミラーリングによるリモートの
    Standby/HotSiteへのFailover
    WAN DR Metro HA-DR
    ● システム全体障害からの保護:
    ○ ハードウェアコンポーネント、システム、ま
    たはラックレベルの障害
    ○ 電源系統/空調設備の故障
    ● 同期ミラーリングによるアベイラビリ
    ティゾーン間の自動Failover
    ローカルバックアップ
    ● 次の事象からの保護:
    ○ 論理障害とアプリケーションのバグ
    ○ 誤った削除などユーザーエラー
    ○ 悪意ある人/ソフト
    ● 過去の一時点へのリストア
    ● ローカルのSnapshot

    View Slide

  5. 5
    方法ごとのサービスレベル
    OpenShiftのクラスターバックアップ/リストア
    Days
    Days Hours Minutes
    リカバリーポイント (RPO)
    Hours Minutes
    ダウンタイム (RTO)
    コスト
    WAN DR
    Metro HA-DR
    ローカルバックアップ

    View Slide

  6. 6
    [参考]バックアップとミラーリングは別物
    OpenShiftのクラスターバックアップ/リストア
    バックアップ (リモート)ミラーリング
    意義
    本番のある一時点の断面を別の領域に保管する
    こと
    本番と全く同じ状態をリアルタイムで
    (離れた)別
    の領域で動かすこと
    リカバリーポイント バックアップした時点 直前に戻せる
    世代 複数持てる 最新一世代だけ
    災害の耐性 耐えられない (リモートミラーなら)耐えられる
    データの上書き されない される
    論理障害の耐性 耐えられる 耐えられない
    同期/非同期 非同期 同期、非同期両方できる

    View Slide

  7. 7
    OpenShiftのバックアップの難しさ
    OpenShiftのクラスターバックアップ/リストア
    ● アプリケーションやデータの整合性を考慮すると、バックアップ対象 (スコープ)が多い。
    ● バックアップの手法は色々あるが、それぞれ対応するスコープが異なり、プラットフォームや構成によって実施できる手法が
    限られる。
    ● 一つで全部完璧にバックアップするのは難しいため、複数組み合わせて実施すべき。
    アプリ/ミドルウェア
    のバックアップ
    Etcd
    バックアップ
    基盤ストレージ
    のバックアップ
    バックアップツール
    対象 アプリ/ミドルウェア層 ○ - △ ○
    OpenShift ユーザ構成
    (Kubernetes Namespace)
    - ○ △ ○
    OpenShift クラスタ構成
    (Kubernetes Namespace)
    - ○ △ ○
    OpenShift 永続ボリューム - - ○ ○
    ホストのディスク - - ○ -

    View Slide

  8. 8
    インフラチームとユーザの責任分界点
    OpenShiftのクラスターバックアップ/リストア
    ユースケースの例 対応方針の例 (インフラ側) 対応方針の例 (ユーザ側)
    ユーザが誤って Deployment などのオブジェクト
    (マニフェスト) を削除した場合の復旧プロセスや
    責任範囲をどう扱うか
    ユーザが管理するマニフェストはクラスタ管
    理者が対応する範囲でないため、ユーザの
    責任で対応する
    GitOpsを前提にあらゆるマニフェストを Git リ
    ポジトリで管理する
    ユーザが誤って PV 上のファイルなどを削除した
    場合の復旧プロセスや責任範囲をどう扱うか
    ストレージ基盤障害に対する復旧を前提と
    するため、ユーザの責任で対応する
    一定の RPO を前提に CSI Driver が提供する
    スナップショットを利用する
    外部の Object Storage に PV のバックアップ
    を取得する
    ストレージ基盤の障害によってユーザが使用する
    PVが失われてしまった場合の復旧プロセスや責
    任範囲をどう扱うか
    インフラ側で取得する最新のバックアップか
    らリストアする
    外部の Object Storage に取得していた最新
    のバックアップからリストアする
    ╳ インフラ側でユーザのリソースを含めてバックアップ /リストアを面倒見る
    ⃝ ユーザが独自にバックアップ /リストアするようにしておく
    ● どこまでインフラ側でリストアし、どこからユーザ側でリストアする、の責任分界点は明確に計画しておくこと

    View Slide

  9. 9
    Etcdのクラスターバックアップ/リストア
    OpenShiftのクラスターバックアップ/リストア
    ● OpenShiftが提供しているスクリプトを実行
    ○ CoreOSにスクリプトが仕込んである。
    ○ master nodeに入って実行するだけ。
    ● クラスター全体のバックアップ/リストア
    ○ リストア時はクラスター全体のリソースが復元される。
    ○ 1台でもmasterが生きていればリストアできる。
    ● 注意点
    ○ ストレージ(PV)のデータはバックアップされないた
    め、リストアできない。
    ○ 特定のNamespaceだけ、など部分的なリストアはで
    きない。
    ○ 別のクラスタにリストアはできない。
    [[email protected] ~]# oc debug node/master0
    Starting pod/master0-debug ...
    To use host binaries, run `chroot /host`
    Pod IP: 172.16.0.10
    If you don't see a command prompt, try pressing enter.
    sh-4.4# chroot /host
    sh-4.4# /usr/local/bin/cluster-backup.sh /home/core/backup/
    found latest kube-apiserver: /etc/kubernetes/static-pod-resources/kube-apiserver-pod-20
    found latest kube-controller-manager:
    /etc/kubernetes/static-pod-resources/kube-controller-manager-pod-8
    found latest kube-scheduler: /etc/kubernetes/static-pod-resources/kube-scheduler-pod-9
    found latest etcd: /etc/kubernetes/static-pod-resources/etcd-pod-4
    etcdctl is already installed
    {"level":"info","ts":1642661012.619663,"caller":"snapshot/v3_snapshot.go:68","msg":"created
    temporary db file","path":"/home/core/backup//snapshot_2022-01-20_064332.db.part"}
    {"level":"info","ts":1642661012.6269116,"logger":"client","caller":"v3/maintenance.go:211",
    "msg":"opened snapshot stream; downloading"}
    {"level":"info","ts":1642661012.6271513,"caller":"snapshot/v3_snapshot.go:76","msg":"fetchi
    ng snapshot","endpoint":"https://172.16.0.10:2379"}
    {"level":"info","ts":1642661013.1581688,"logger":"client","caller":"v3/maintenance.go:219",
    "msg":"completed snapshot read; closing"}
    {"level":"info","ts":1642661013.4697661,"caller":"snapshot/v3_snapshot.go:91","msg":"fetche
    d snapshot","endpoint":"https://172.16.0.10:2379","size":"81 MB","took":"now"}
    {"level":"info","ts":1642661013.4698682,"caller":"snapshot/v3_snapshot.go:100","msg":"saved
    ","path":"/home/core/backup//snapshot_2022-01-20_064332.db"}
    Snapshot saved at /home/core/backup//snapshot_2022-01-20_064332.db
    Deprecated: Use `etcdutl snapshot status` instead.
    {"hash":678588886,"revision":36324472,"totalKey":11757,"totalSize":81399808}
    snapshot db and kube resources are successfully saved to /home/core/backup/
    sh-4.4# ls -l /home/core/backup/
    total 79576
    -rw-------. 1 root root 81399840 Jan 20 06:43 snapshot_2022-01-20_064332.db
    -rw-------. 1 root root 78742 Jan 20 06:43static_kuberesources_2022-01-20_064332.tar.gz

    View Slide

  10. 10
    OpenShiftのバックアップ/リストアのキーポイント
    Etcdバックアップだけしていればよいわけではない!
    OpenShiftのクラスターバックアップ/リストア
    PVのバックアップ/リストア
    部分的なリストア
    別クラスタへのリストア
    ● ファイルコピー
    ● VolumeSnapshot
    ● Namespace単位
    ● Appとの連携
    ● クラスタリソース
    ● マイグレーション
    バックアップツール
    を使いましょう

    View Slide

  11. 11
    OpenShift API for Data Protection (OADP)
    OpenShiftのクラスターバックアップ/リストア
    ● Veleroベースのバックアップ/リストアのFramework&API。
    ● クラスターリソースとユーザーアプリケーションのマニフェストと
    PVをバックアップ/リストアできる。
    ● OperatorHubからインストールできる。
    ● 他のツールから連携して使われることがメイン。
    Velero Plugin Interface
    Backup ISV Product
    Policy, Scheduling, Governance, Compliance, Reporting, etc
    OADP Focus
    Velero API
    As defined by upstream community
    k8s CSI
    Snapshot API
    velero-csi
    Plugin
    Data Mover
    Plugin by
    Backup ISV
    Backup ISV / 3rd
    Party
    Community /
    Upstream
    Backup Storage
    Location
    Plugins
    S3, Azure Blob, Google
    Cloud, etc
    Backup Storage
    Location
    Plugins
    S3, Azure Blob, Google
    Cloud, etc
    Backup Storage
    Location
    Plugins
    S3, Azure Blob, Google
    Cloud, etc
    Backup
    Restore
    Backup Storage
    Location
    Volume Snapshot
    Location
    Application
    Defined by
    Namespace
    and/or
    Label Selector
    Velero Custom Resources
    k8s Resource
    Plugins
    per Kind
    Backup/Restore
    k8s Resource
    Plugins
    per Kind
    Backup/Restore
    k8s Resource
    Plugins
    per Kind
    Backup/Restore
    Volume
    Snapshot
    Location
    Plugins
    Volume
    Snapshot
    Location
    Plugins
    Volume
    Snapshot
    Location
    Plugins
    Data Mover
    Controller

    View Slide

  12. IBM Spectrum Protect Plus for OpenShift
    Market leading backup and recovery for Kubernetes and Red Hat OpenShift
    Value proposition
    ● Simplified data access: Rapid access to
    revenue producing data
    ● Native Kubernetes integration: kubectl
    CLI, intuitive developer familiarity &
    simplicity, faster adoption
    ● Consistent experience: Self-service—
    developers protect & reuse their own data
    with compliant SLAs
    ● Dynamic scale: Uses OpenShift API for
    data resilience, integrated with OADP &
    OpenShift CSI snapshots
    ● Certified technology: Available through
    Red Hat OpenShift Operator Hub and
    Marketplace
    Benefits
    ● Drive operational efficiency: Unify and
    automate data protection processes
    across physical, virtual machines, and
    containerized infrastructure
    ● Maximize developer productivity:
    familiar Kubernetes CLI & SLA policies for
    persistent volume backup & recovery
    ● Lower storage costs: CSI snapshot
    support spans both container native and
    container ready storage
    ● Ensure data security: Container data
    can be replicated and security stored in
    immutable IBM Cloud Object Storage or
    IBM Tape
    Key differentiators
    ● Enterprise backup and recovery for
    critical workloads now extended to
    Kubernetes
    ● Resilience for your data in context of
    applications and container infrastructure
    ● Integrated with OpenShift tools like
    OpenShift API for Data Protection and
    OpenShift CSI snapshots
    ● Extended support through IBM data
    platforms and CloudPaks
    Proof points
    ● Solution Brief
    ● Demo
    ● IBM Solution Brief
    ● Blog post
    ● Deployment Tech Note
    ● SpectrumCast (video)
    OpenShiftのクラスターバックアップ/リストア
    12

    View Slide

  13. Kasten K10 Data Protection for OpenShift
    Clear market leader for Kubernetes backup and DR for OpenShift
    Value proposition
    ● Application-centric: Multi-layered
    backup with granular restores
    ● Integrated: OpenShift integrations
    including OpenShift Container Storage
    ● Operator Hub: Certified to work with
    Red Hat OpenShift
    ● Freedom of Choice: Deploy on-premise
    and/or clouds
    Use cases
    ● Kubernetes Backup and DR: Storage
    and database integration
    Cross-Region/Cluster/Account
    ● Kubernetes App Mobility: Complete
    application (storage, K8s & data services)
    Cross-Region/DC/Cloud, and Kubernetes
    distribution
    Benefits
    ● More secure and resilient: Policy-based
    automation for backup and DR. Flexible
    consistency options including storage,
    logical, etc.
    ● DevOps speed and scale: More secure
    self-service protection and recovery.
    Extensible workflows in shift-left
    environments.
    Key differentiators
    ● Easy installation and Certified
    Operator: Built and tested to exacting
    standards and ready to deploy with
    OpenShift
    ● Deep K10 and OCS 4 integration for
    resilience and durability: Perform
    durable backups of OCS storage classes,
    metadata, and local persistence of the
    backup to minimize restore time
    ● Diverse workloads and freedom of
    choice: Global application portability and
    protection policies without development or
    application code changes
    ● Security and automation for scale:
    Wide choice of authentication tools, secure
    access to the K10 dashboard and APIs,
    flexible permissions model
    Proof points
    ● Website
    ● Solution Brief
    ● Demos: Local recovery | Disaster recovery
    ● Kasten Blog post
    ● Solution Guide
    OpenShiftのクラスターバックアップ/リストア
    13

    View Slide

  14. TrilioVault Data Protection for OpenShift
    Protect your entire kubernetes applications with enterprise-grade backup
    and recovery
    Value proposition
    ● Application-centric: Protects data,
    metadata, and Kubernetes objects
    ● Infrastructure compatibility & cloud
    agnostic: Compatible with any storage (CSI,
    NFS, S3), or any cloud (private, AWS, GCP,
    Azure, IBM)
    ● Native to Kubernetes & OpenShift:
    Packaged as an operator, deployed as a CRD,
    and API with all facilities (CSI)
    ● Application deployment & ecosystem
    tooling: Helm, Operators, Labels,
    Prometheus, Fluentd, Grafana
    ● Certified technology: Red Hat OpenShift
    Operator certification & IBM Cloud Pak
    certified for data, multicloud management,
    and applications
    Benefits
    ● Nondisruptive: Lightweight
    Kubernetes API and CSI Snapshots
    to backup/capture entire
    application
    ● Efficient: Use Snapshots that are
    incrementally updated forever
    ● Robust restoration/recovery: To
    any Kubernetes or OpenShift
    Cluster running in public, private, or
    hybrid cloud
    ● Use cases: Support for
    backup/restore, migrations, DR, and
    application mobility
    Key differentiators
    ● Horizontal scale: Deployed within any
    Kubernetes cluster or namespace
    ● Deployment: Operator or Helm-based
    ● Open backup format: Nonproprietary
    Open Universal Schema (QCOW2)
    Proof points
    ● Website
    ● Solution Brief
    ● Demos: Local recovery | Disaster recovery
    ● Product: OperatorHub | Marketplace
    ● Deployment Guide
    ● Blog post
    ● Webinar
    ● OpenShift Commons Briefing (video)
    OpenShiftのクラスターバックアップ/リストア
    14

    View Slide

  15. 15
    [参考] Red Hat Advanced Cluster Management for Kubernetesを使ったDR
    OpenShiftのクラスターバックアップ/リストア
    Data Center 2
    ManagedCluster 2
    PASSIVE
    NAMESPACE
    PVs
    RESOURCES
    RESOURCES
    RESOURCES
    PVs
    PVs
    Volsync - Asynchronous
    Data Replication
    Data Center 1
    ManagedCluster 1
    NAMESPACE
    ACTIVE
    PVs
    RESOURCES
    RESOURCES
    RESOURCES
    PVs
    PVs
    RPO/RTOを極力短くできるDRソリューション
    ● ACMの管理下のクラスタ間で、リソースと
    PV
    をレプリケーション
    ● 自動的なクラスタFailover-Failback
    ● Red Hat OpenShift Data Foundation(ODF)
    のミラーリング機能によるデータ転送
    ○ ODFを使わない場合は、 Volsyncを使用
    Tech Preview

    View Slide

  16. linkedin.com/company/red-hat
    youtube.com/user/RedHatVideos
    facebook.com/redhatinc
    twitter.com/RedHat
    Red Hat is the world’s leading provider of enterprise
    open source software solutions. Award-winning
    support, training, and consulting services make
    Red Hat a trusted adviser to the Fortune 500.
    Thank you

    View Slide
