Code indexing: How language servers understand our code

Language servers are a way of providing IDE features to any editor. Specialized functionality for navigating and understanding our Ruby code can greatly improve the developer experience and is highly aligned with the goal of making the developer happy.

In the context of the Ruby LSP, let’s dive into how language servers can build up knowledge about codebases using indexing and how it is used to implement features such as go to definition.

Transcript

1. Vinicius Stock
   Code indexing
   How language servers understand our code


   View Slide

2. Vinicius Stock
   Senior dev @ Ruby DX team


   Shopify
   Twitter: @vinistock


   GitHub: @vinistock


   https://vinistock.com


   View Slide

3. What is a language server?


   View Slide

4. Source: https://microsoft.github.io/language-server-protocol/specification


   View Slide

5. Editor


   (Client)
   Language
   server
   STDIN
   STDOUT
   User
   Go to def
   Definition
   Location
   Jumps to def


   View Slide

6. Language servers can
   connect to any editor


   View Slide

7. We can collaborate in
   improving the experience


   View Slide

8. Improving the development
   experience with language
   servers


   RubyConf 2022


   View Slide

9. Shopify/vscode-ruby-lsp


   Shopify/ruby-lsp
   Ruby LSP


   View Slide

10. Semantic highlighting
    Document symbol
    Document link
    Hover
    Folding range
    Selection range
    Formatting
    On type formatting
    Diagnostic
    Code actions
    Document highlight
    Inlay hints
    Path completion
    Code Lens


    View Slide

11. Document symbol


    View Slide

12. Semantic highlighting
    Document symbol
    Document link
    Hover
    Folding range
    Selection range
    Formatting
    On type formatting
    Diagnostic
    Code actions
    Document highlight
    Inlay hints
    Path completion
    Code Lens


    View Slide

13. Diagnostic Code actions


    View Slide

14. Code actions


    View Slide

15. Semantic highlighting
    Document symbol
    Document link
    Hover
    Folding range
    Selection range
    Formatting
    On type formatting
    Diagnostic
    Code actions
    Document highlight
    Inlay hints
    Path completion
    Code Lens


    View Slide

16. Code Lens


    View Slide

17. To explore code indexing,
    we’ll think about


    go to definition


    View Slide

18. class Foo


    def process


    Bar.baz


    end


    end


    View Slide

19. {


    "params": {


    "textDocument": {


    "uri": "file:
    /
    /
    /
    foo.rb"


    },


    "position": {


    "line": 2,


    "character": 5


    }


    }


    }


    View Slide

20. {


    "uri": "file:
    /
    /
    /
    bar.rb"


    "range": {


    "start": { "line": 0, "character": 0 }


    "end": { "line": 5, "character": 2 }


    }


    }


    View Slide

21. The request and
    response are just file
    locations


    View Slide

22. What’s happening in
    between?


    View Slide

23. class Foo


    def process


    Bar.baz


    end


    end
    How do we determine what’s
    under the cursor?
    How do we find the definition?


    View Slide

24. Locating targets
    Part 1


    View Slide

25. We want to search an
    AST to find the node at
    the requested position


    View Slide

26. We must parse the file
    and then search the AST


    View Slide

27. 0 class Foo


    1 def process


    2 Bar.baz


    3 end


    4 end
    CLASS
    CONST (Foo)
    BODY
    DEF
    IDENT (process)
    BODY
    CALL
    CONST (Bar) IDENT (baz)


    View Slide

28. More than one node
    covers the requested
    position


    View Slide

29. We’re looking for the
    most specific one


    View Slide

30. Converting position into string
    index
    Step 1


    View Slide

31. "position": { "line": 2,"character": 5 }




    View Slide

32. "position": { "line": 2,"character": 5 }


    source = "class Foo\n def process\n Bar.baz…"




    View Slide

33. "position": { "line": 2,"character": 5 }


    source = "class Foo\n def process\n Bar.baz…"


    line + character
    =
    >
    string index




    View Slide

34. "position": { "line": 2,"character": 5 }


    source = "class Foo\n def process\n Bar.baz…"


    line + character
    =
    >
    string index


    { "line": 2,"character": 5 }
    =
    >
    28


    View Slide

35. Locating the AST node
    Step 2


    View Slide

36. 1. Go through AST


    2. Use target and candidate
    pointers


    3. Compare proximity to
    requested index


    View Slide

37. 0 class Foo


    1 def process


    2 Bar.baz


    3 end


    4 end
    CLASS
    CONST (Foo)
    BODY
    DEF
    IDENT
    (process)
    BODY
    CALL
    CONST (Bar) IDENT (baz)


    View Slide

38. def locate(node, index)




    end


    View Slide

39. def locate(node, index)


    queue = node.child_nodes


    target = node


    end


    View Slide

40. def locate(node, index)


    queue = node.child_nodes


    target = node


    until queue.empty?


    end


    target


    end


    View Slide

41. until queue.empty?


    candidate = queue.shift


    end


    View Slide

42. until queue.empty?


    candidate = queue.shift


    queue.concat(candidate.child_nodes)


    end


    View Slide

43. until queue.empty?


    candidate = queue.shift


    queue.concat(candidate.child_nodes)


    loc = candidate.location


    next unless loc.cover?(index)


    end


    View Slide

44. until queue.empty?


    candidate = queue.shift


    queue.concat(candidate.child_nodes)


    loc = candidate.location


    next unless loc.cover?(index)


    break if index < loc.start_char


    end


    View Slide

45. until queue.empty?


    # …


    break if index < loc.start_char


    tloc = target.location


    if loc.end_char - loc.start_char
    <
    =


    tloc.end_char - tloc.start_char


    target = candidate


    end


    end


    View Slide

46. We discovered the target 🎉


    View Slide

47. But where’s the definition?


    View Slide

48. Code indexing
    Part 2


    View Slide

49. We have to know what’s
    available in the codebase


    View Slide

50. Index


    Classes


    Modules


    Methods


    Constants
    Does this thing exist?
    Where is it?


    View Slide

51. We can’t populate the index
    on every definition request


    View Slide

52. We need to initialize the
    index on boot


    View Slide

53. And we have to keep it
    synchronized if files are
    modified


    View Slide

54. Let’s start by the initial
    indexing


    View Slide

55. We’ll focus implementing
    classes in 4 steps


    View Slide

56. Ruby
    code
    Parser
    AST
    Visitor
    Index
    AST Classes
    For all Ruby files


    View Slide

57. Collecting class declarations
    in an AST
    Step 1


    View Slide

58. class IndexVisitor < SyntaxTree
    :
    :
    Visitor


    end


    View Slide

59. class IndexVisitor < SyntaxTree
    :
    :
    Visitor


    attr_reader :constants


    def initialize


    @constants = []


    end


    end


    View Slide

60. class IndexVisitor < SyntaxTree
    :
    :
    Visitor


    attr_reader :constants


    def initialize


    @constants = []


    end


    def visit_class(node)


    @constants
    <
    <
    node


    super


    end


    end


    View Slide

61. visitor = IndexVisitor.new


    visitor.visit(ast)


    visitor.constants


    #
    =
    >
    [


    # #,


    # #


    # ]




    View Slide

62. Creating the Index class
    Step 2


    View Slide

63. class Index


    include Singleton


    def initialize


    @knowledge = {}


    end


    def add(path, constants)


    constants.each do |const|


    end


    end


    end


    View Slide

64. class Index


    include Singleton


    def initialize


    @knowledge = {}


    end


    def add(path, constants)


    constants.each do |const|


    @knowledge[const.name] = {


    }


    end


    end


    end


    View Slide

65. class Index


    include Singleton


    def initialize


    @knowledge = {}


    end


    def add(path, constants)


    constants.each do |const|


    @knowledge[const.name] = {


    file: path, location: const.location


    }


    end


    end


    end


    View Slide

66. {


    "Foo"
    =
    >
    {


    path: "/foo.rb",


    location: #

    end_line=2,


    start_column=4,


    end_column=6,


    >


    }


    }


    View Slide

67. Populating the Index
    Step 3


    View Slide

68. index = Index.instance


    all_files_in_load_path.each |path|


    index.process("file
    :
    /
    /
    #
    {
    path}")


    end


    View Slide

69. class Index


    def process(uri)


    path = URI(uri).path












    end


    end




    View Slide

70. class Index


    def process(uri)


    path = URI(uri).path




    content = File.read(path)










    end


    end




    View Slide

71. class Index


    def process(uri)


    path = URI(uri).path




    content = File.read(path)


    ast = SyntaxTree.parse(content)








    end


    end




    View Slide

72. class Index


    def process(uri)


    path = URI(uri).path




    content = File.read(path)


    ast = SyntaxTree.parse(content)


    visitor = IndexVisitor.new


    visitor.visit(ast)




    end


    end




    View Slide

73. class Index


    def process(uri)


    path = URI(uri).path




    content = File.read(path)


    ast = SyntaxTree.parse(content)


    visitor = IndexVisitor.new


    visitor.visit(ast)


    add(path, visitor.constants)


    end


    end




    View Slide

74. The initial indexing is
    done


    View Slide

75. Synchronizing file
    modifications
    Step 4


    View Slide

76. If a file is modified, the
    existing classes might
    change


    View Slide

77. LSPs can request file
    watching


    View Slide

78. Remove
    related
    entries
    Index
    the new
    file
    Ruby file
    modified
    Deleted Added
    Remove
    and
    index
    Changed


    View Slide

79. def execute(req)


    case req[:method]


    when "workspace/didChangeWatchedFiles"


    changes = req.dig(:params, :changes)


    Index.instance.synchronize(changes)


    end


    end


    View Slide

80. class Index


    def synchronize(changes)


    changes.each do |change|


    case change[:type]


    end


    end


    end


    end


    View Slide

81. class Index


    def synchronize(changes)


    changes.each do |change|


    case change[:type]


    when "deleted"


    remove_entries_for(change[:uri])


    end


    end


    end


    end


    View Slide

82. class Index


    def synchronize(changes)


    changes.each do |change|


    case change[:type]


    when "deleted"


    remove_entries_for(change[:uri])


    when "created"


    process(change[:uri])


    end


    end


    end


    end


    View Slide

83. class Index


    def synchronize(changes)


    changes.each do |change|


    case change[:type]


    when "deleted"


    remove_entries_for(change[:uri])


    when "created"


    process(change[:uri])


    when "changed"


    remove_entries_for(change[:uri])


    process(change[:uri])


    end


    end


    end


    end


    View Slide

84. class Index


    def remove_entries_for(uri)


    path = URI(uri).path




    @knowledge.each do |const, loc|


    if loc[:file]
    =
    =
    path


    @knowledge.delete(const)


    end


    end


    end


    end


    View Slide

85. We can now perform


    initial indexing and
    synchronization 🎉


    View Slide

86. We’re ready to implement
    go to definition


    View Slide

87. Implementing go to definition
    Part 3


    View Slide

88. 1. Locate the target


    2. Find target in index


    3. Return declaration
    location


    View Slide

89. class Definition < BaseRequest


    def initialize(document, position)


    @document = document


    @position = position


    end


    end


    View Slide

90. class Definition < BaseRequest


    def run


    target = @document.locate_node(@position)


    file, location = case target


    end


    # …


    end


    end


    View Slide

91. class Definition < BaseRequest


    def run


    target = @document.locate_node(@position)


    file, location = case target


    when SyntaxTree
    :
    :
    Const


    Index.instance.fetch(target.value)


    end


    # …


    end


    end


    View Slide

92. class Definition < BaseRequest


    def run


    # …


    { uri: "file
    :
    /
    /
    #
    {
    file}"


    range: {


    start: {


    line: location.start_line,


    character: location.start_column


    },


    end: {


    line: location.end_line,


    character: location.end_column


    }


    }


    }


    end


    end


    View Slide

93. Go to definition for
    classes is done 🎉


    View Slide

94. This is not yet released
    in the Ruby LSP


    View Slide

95. But I have a demo!


    View Slide

96. View Slide

97. Other features also
    depend on an index


    View Slide

98. Signature help
    Workspace
    symbols
    Hover
    Autocomplete


    View Slide

99. Signature help


    View Slide

100. Signature help
     Workspace
     symbols
     Hover
     Autocomplete


     View Slide

101. Workspace
     symbols


     View Slide

102. Signature help
     Workspace
     symbols
     Hover
     Autocomplete


     View Slide

103. Hover


     View Slide

104. Signature help
     Workspace
     symbols
     Hover
     Autocomplete


     View Slide

105. Autocomplete


     View Slide

106. This approach is similar
     to what a typechecker does


     View Slide

107. And there are still many
     improvements we can make


     View Slide

108. • Use parallelism to build index
     • Cache the index
     • Include the missing parts (modules,
     constants, methods…)
     • Add the option to control what is
     indexed


     View Slide

109. > lib
     > my_gem
     foo.rb
     > .ruby-lsp
     > lib
     > my_gem
     foo.indexed
     Last modified: 3 days ago
     Last modified: 1 minute ago


     View Slide

110. # Gemfile


     gem "ruby_index"


     View Slide

111. Multiple gems could reuse
     the index


     View Slide

112. "ruby-lsp"
     "steep"
     "typeprof"
     "rdoc"
     "irb"


     View Slide

113. Shopify/vscode-ruby-lsp


     Shopify/ruby-lsp
     Ruby LSP


     View Slide

114. Developer experience is a
     part of making developers
     happy


     View Slide

115. Let’s collaborate on
     improving it


     View Slide

116. Thank you


     View Slide

117. • https://github.com/Shopify/vscode-ruby-lsp


     • https://github.com/Shopify/ruby-lsp


     • https://microsoft.github.io/language-server-
     protocol/specification


     • Code font: Cascadia Code


     • Screenshots made with VS Code
     References


     View Slide
