  1. 2021: CI for Mobile - State of the Art -

    1
  2. Plan 1. The role of the CI 2. Key principles

    3. Simple Workflow 4. On-Premise 5. IaaS 6. SaaS 7. Best Practices 8. Static Analysis 9. Metrics 2
  3. 3

  4. The role of the CI 1. Lints and performs static

    analysis 2. Tests (Unit, Integration) 3. Calculates and publishes metrics 4. Interacts with the repository (publishes status, ...) 5. Interacts with the team (Slack, mail, ...) 6. Builds 7. Prepares and/or sends artifacts for the CD 4
  5. Key principles for a good CI — Automated — Idempotent

    — Isolation — Fast — Secure — Observable 5
  6. Why automating? 1. Avoid human errors 2. Enforces the workflow

    steps (tests, linting, etc) 3. Frozen configuration 4. Security: avoids sharing admin credentials 5. Time saving: CI runs while we perform other tasks 6
  7. 7

  8. 8

  9. 9

  10. 10

  11. 11

  12. 2 Categories 1. On Premise (Self Hosted) 2. Cloud (IaaS

    or SaaS) 3. (Mix of the two above) 12
  13. On Premise - (Self Hosted) - 13

  14. 14

  15. Configuration — Main Only — Main + Agent / Runner

    15
  16. Configuration — Main Only — Main + Agent / Runner

    16
  17. Configuration — Jobs described via scripting (Groovy in Jenkins /

    YML + Bash in GitLab CI) — Environment variables managed in the Jenkins / GitLab CI console — Secrets managed in the Jenkins console or other tools 17
  18. Jenkinsfile node { def server = Artifactory.server "SERVER_ID" def buildInfo

    stage('Clone sources') { git url: 'https://github.com/jfrogdev/project-examples.git' } stage('Gradle build') { buildInfo = rtGradle.run rootDir: "gradle-examples/4/gradle-example-ci-server/", buildFile: 'build.gradle', tasks: 'clean artifactoryPublish' } stage('Publish build info') { server.publishBuildInfo buildInfo } } 18
  19. .gitlab-ci.yml build-job: stage: build script: - echo "Hello, $GITLAB_USER_LOGIN!" test-job1:

    stage: test script: - echo "This job tests something" test-job2: stage: test script: - echo "This job tests something, but takes more time than test-job1." - sleep 20 deploy-prod: stage: deploy script: - echo "This job deploys something from the $CI_COMMIT_BRANCH branch." 19
  20. Main Advantages 1. Fast 2. Machines are in an internal

    & protected network 3. Fully configurable (supports custom Swift toolchains, special tooling such as mitm-proxy, ...) 20
  21. Main Disadvantages 1. Manual management of project configuration (certificates, keystore,

    secrets, ...) 2. Manual management of the machine (hardware, OS versions, tool versions, security patches, ...) 3. Parallel execution is hard 4. Isolation is hard 21
  22. Some solutions — Android: Docker — iOS: Fastlane Match (Certificate

    management) — iOS: xcversion for easily install Xcode versions — iOS: macOS Virtualization (e.g. VMware ESXi, Orka, Veertu) 22
  23. + New Anka "Develop" Free version 23

  24. Cloud 24

  25. 2 Solutions: IaaS OR SaaS 25

  26. IaaS 26

  27. IaaS — AWS EC2 — iOS: MacStadium 27

  28. Key Concepts — Physical or virtual machines managed by providers

    — Choose between a range of available OSs — Tooling not pre-installed — Access remotely for configuration — Pay per hour/day/month of usage — Pricing may vary (from 5$/month (EC2) to ∞€) 28
  29. Advantages — Easy OS provisioning — Generally fast (bare metal)

    Disadvantages — Manual management of project configuration (certificates, keystore, secrets, ...) — Less hardware choice than On-Premise 29
  30. Focus on macOS on EC2 — Dedicated instance: Mac Mini

    bare metal — Core i7 3.2Ghz - 32GB RAM — minimum period of 24 hours — $1.083 per hour => 779$ / month — Fully integrated with AWS infrastructure (VPC, AZ, etc) — macOS 10.14 and 10.15, M1 coming soon 30
  31. SaaS 31

  32. SaaS — Bitrise — Circle CI — Visual Studio App

    Center — GitHub Actions 32
  33. Key Concepts 1. Mobile-Oriented 2. Almost anything is pre-installed 3.

    Perfect isolation & good security: One job = one VM Virtual machines are spawned for every new job and killed when the job ends 4. Project configuration can be administered via dashboards / API / code 5. (In some cases) workflow can be edited from within the solution 33
  34. 34

  35. .github/workflows/main.yml name: CI on: pull_request: branches: [ master ] jobs:

    build: runs-on: macos-11.0 steps: - uses: actions/checkout@v2 - name: Run a one-line script run: echo Hello, world! 35
  36. Advantages — Fully managed — Quite easy to setup —

    Easy to switch between configurations 36
  37. Disadvantages — Usually Slow — Risk of Vendor lock-in —

    Harder to debug the build process (kind of a black box) 37
  38. Configuration Best Practices 38

  39. Best Practices Keep your CI code readable 39

  40. Best Practices Rely on standalone automation tools rather than on

    proprietary CI steps (e.g. use fastlane or Gradle) 40
  41. Rely on standalone automation tools rather than on proprietary CI

    steps — Reduces risk of vendor lock-in — Allows local debugging of the CI steps — Does not require specific CI knowledge 41
  42. 42

  43. Best Practices Commit the dependency versions you're using 43

  44. Commit the dependency version you're using Use dependency managers when

    possible and commit the version files. — For Ruby, use rbenv (or rvm) + Bundler and don't forget to commit — .ruby-version — Gemfile and Gemfile.lock — With JavaScript, use npm (or yarn) and commit the node_modules folder (or at least package-lock.json) 44
  45. Commit the dependency version you're using — On Android, commit

    — gradlew — gradle-wrapper.properties — gradle-wrapper.jar — On iOS, commit — Podfile AND Podfile.lock (or, better, the whole Pods directory) — Package.resolved 45
  46. Best Practices Commit the CI steps and configuration alongside your

    project 46
  47. Commit the CI steps and configuration alongside your project —

    Commit Jenkinsfile, bitrise.yml, etc in your project repo — allows for coherence between CI and project structure — reduces risk of breaking changes 47
  48. Best Practices Retrieve secrets from a secondary repo or service

    (vault), accessible from the CI only 48
  49. Best Practices No "one size fits all". If you're dealing

    with a huge project use the appropriate tools. 49
  50. If you're dealing with a huge project use the appropriate

    tools If building a huge multi-module project, favor: — monorepo configurations (when possible) — distributed building tools such as: — Bazel — Buck 50
  51. Focus on Static Analysis 51

  52. Static Analysis Performs automated static checks on your code, such

    as: — Linting — via SwiftLint (or Taylor) — gradle lint — Changelog verification — Commit message checks — Suspicious file modifications — ... 52
  53. Static Analysis A good practice involves publishing the static analysis

    result to the Pull Request page. A number of off-the-shelf solutions exist: — GitLab Push Rules (GitLab only) — Hound — Danger 53
  54. Hound (Based on SwiftLint) 54

  55. Danger 55

  56. Danger Examples # Ensure a clean commits history if git.commits.any?

    { |c| c.message =~ /^Merge branch/ } fail('Please rebase to get rid of the merge commits in this PR') end # Don't let testing shortcuts get into master by accident fail("fit left in tests") if `grep -r "fit" Demo/Tests/`.length > 1 56
  57. Danger Examples # Did you make analytics changes? # Please

    also include a change to our analytics spec made_analytics_changes = modified_files.include?("AppDelegate+Analytics.swift") made_analytics_specs_changes = modified_files.include?("AppAnalyticsSpec.swift") if made_analytics_changes && !made_analytics_specs_changes fail("Analytics changes should have reflected specs changes") end 57
  58. Bonus: SwiftInfo 58

  59. Focus on Metrics 59

  60. Which metrics? — Lines of Code — Coverage — Cyclomatic

    complexity — Duplication — Documentation (when needed) — Code smells (cf Static Analysis) 60
  61. How to track them? — SonarQube — Codecov — Code

    Climate 61
  62. 62

  63. The key to a successful DevOps practice on mobile projects

    63
  64. The keys to a successful practice on mobile projects —

    No CI-people — Shared knowledge — You build it, you run it — CI as readable code — We are developers — Code is documentation — Don't underestimate the time spent on CI: — time is $$: a simple yet expensive setup can be much cheaper than a complex one 64
  65. Thank you! 65

  66. Credits — https://about.gitlab.com/stages-devops-lifecycle/ continuous-integration/ — https://www.ingloriousmind.com/blog/continuous- integration-using-bitrise/ 66
