Data is a new security boundary

Data is a new security boundary

@vixentael

View Slide

@vixentael
Head of customer solutions,

Security software engineer at Cossack Labs.
I’m focused on data security and applied cryptography,
building e2ee protocols, and security controls around
crypto. Core maintainer of Themis cryptolib.
cossacklabs.com

View Slide

@vixentael
Things we won’t talk about
Exact ciphers, symmetric vs asymmetric encryption.
TLS.
Typical cryptographic mistakes developers do.
Privacy, and evil corporations.
Recent data incidents and breaches. FUD.
What library / tool to use to encrypt your data the best way.

View Slide

@vixentael
What we will talk about
Data security 101: encryption, OWASP, regulations.
Cases: observations of real apps that combine encryption with
supporting security controls.
Encryption ways: ALE, FLE, E2EE, ZKA/ZT.

View Slide

Data security 101

View Slide

@vixentael
Your app’s data is everywhere.

(apps, public clouds, databases, backups, 3rd APIs, analytics, etc).
No perimeters, no trusted zones anymore.

View Slide

@vixentael

View Slide

@vixentael
Your app’s data is everywhere.

(apps, public clouds, databases, backups, 3rd APIs, analytics, etc).
No perimeters, no trusted zones anymore.
Data security measures become
security boundary for data.
It's not about "protect the data where it's stored".

It’s “protect the data whenever it exists”.

View Slide

@vixentael
Data security depends on a data
fl
ow
gathering
secure
processing
secure storage
and backups
secure
disclosure
data removal
data migration
Gathering Processing Output
logging,
analytics

View Slide

@vixentael
Data security depends on a data
fl
ow
gathering
secure
processing
secure storage
and backups
secure
disclosure
data removal
data migration
Gathering Processing Output
logging,
analytics
leakage, loss,
disclosure
never removed,
disclosure, loss
gathering
without consent

View Slide

@vixentael
Data security 101
1. Identify sensitive data, understand sensitive data lifecycle, classify data.

2. Identify risks to data.

3. Build trust models, understand risk impact.

4. Prioritize threat vectors.

5. Select and implement proper security controls for exploitable high risk
vectors (to prevent risks and to identify leaks).

View Slide

Encryption

View Slide

@vixentael
Encryption is an ultimate

data security measure
1. When data is properly encrypted, it can’t be suddenly,
unnoticeably decrypted.
2. Even if leaked, data is encrypted. Encryption is the best access control.
3. Protections against insiders & outsiders.
4. Properly con
fi
gured encryption allows mistakes in other
security controls.
5. Regulations, compliance.

View Slide

@vixentael
Regulations, compliance
media.defense.gov/2018/Apr/22/2001906836/-1/-1/0/
DEFENSEINNOVATIONBOARD_TEN_COMMANDMENTS_OF_SOFTWARE_2018.04.20.PDF

View Slide

@vixentael
gdpr-info.eu/issues/encryption/
GDPR art 32/35: responsibly store and process data according to risks.

GDPR art 33/34: detecting data leakage and alert users & controller.

View Slide

@vixentael
cossacklabs.com/blog/what-we-need-to-encrypt-cheatsheet.html
also, HIPAA, FISMA, FIPS, FedRAMP, CCPA, PCI DSS, FERPA, and many more

View Slide

@vixentael
OWASP Top10 2021
A01:2021-Broken Access Control.
A02:2021-Cryptographic Failures.
A03:2021-Injection.
A04:2021-Insecure Design.
A05:2021-Security Miscon
fi
guration.
A06:2021-Vulnerable and Outdated Components.
A07:2021-Identi
fi
cation and Authentication Failures.
A08:2021-Software and Data Integrity Failures.
A09:2021-Security Logging and Monitoring Failures.
A10:2021-Server-Side Request Forgery.
owasp.org/Top10/

View Slide

@vixentael
A02:2021-Cryptographic Failures.
owasp.org/Top10/A02_2021-Cryptographic_Failures/
Focused mostly on crypto usage and implementation.
Bad ciphers: old and insecure? Wrong AES modes? AES-CBC instead
of AES-GCM? Asymmetric encr where symmetric should be used?
Bad keys: short, low entropy keys? Math.random? User password used
as encryption keys without a proper KDF? Bad KDF choice / params?
Unsuitable crypto-primitives choice: MD5 instead of Argon2DI, AES-
OFB instead of GCM. SHA-256 instead of HMAC-SHA256.
Home-brewed crypto.

View Slide

@vixentael
A04:2021-Insecure Design.
owasp.org/Top10/A04_2021-Insecure_Design/
Focused on design, missing or wrong security controls.
Bad key management: storing encryption keys in plaintext together
with data. Lack of rotation, revocation, expiration? Components are
trusted when they shouldn’t be? One encryption key for everything?
Lack of PKI?
Lack of encryption for sensitive assets.
Home-brewed encryption protocols.
Encryption is not supported by authN, access control, logging & monitoring.

View Slide

@vixentael
OWASP ASVS
github.com/OWASP/ASVS
V6: Stored Cryptography, V8: Data Protection, V9: Communications

View Slide

@vixentael
OWASP MASVS
github.com/OWASP/owasp-masvs/
V3: Cryptography, V2: Data Storage, V5: Network Communication

View Slide

@vixentael
*ASVS

View Slide

Encryption models and ways

View Slide

@vixentael
Encryption
Data stored encrypted locally – data-at-rest
encryption; also FS/OS encryption,
database encryption.
host OS /
server app
host OS /
server app
Transport layer encryption – data-in-transit
encryption (TLS, IPSec, SSH).
host OS /
server app

View Slide

@vixentael
Application-level encryption (ALE)
Encryption process happening within application context,
triggered by an application.
ALE could work together with data-at-rest encryption and data-
in-transit encryption.
ALE could be client-side, server-side, end-to-end, etc.
infoq.com/articles/ale-software-architects/
Encryption is easy, key management is hard.

View Slide

@vixentael
TLS (in transit)
application-level encryption
server 1 server 2 server 3
Alice Carol Bob
server 1 server 2 server 3
Alice Carol Bob
encrypted
encrypted

View Slide

@vixentael
Application-level encryption
data encrypted by any app – application-
level encryption (ALE)
app
ALE happens on a client side – client-side
encryption
client
ALE happens on a server side – server-side
encryption
server
proxy … proxy-side encryption

View Slide

@vixentael
Field-level encryption
Only some data
fi
elds are encrypted –
fi
eld-level encryption (FLE).
{

"name": base64_str(encrypted_name),
 
"phone": base64_str(encrypted_phone),
 
"passport": base64_str(encrypted_passport),

"ID": user_ID,

"last_activity_date": timestamp,

...

}

View Slide

@vixentael
End-to-end encryption
Alice
App-side encryption when no keys/
secrets/data is available to the
intermediate infrastructure – end-to-end
encryption.
Bob
speakerdeck.com/vixentael/e2ee-equals-security-equals-privacy
Encryption should work on all selected platforms. Key management is tricky
– backend should work only as key discovery service without access to
private/secret keys. Complicated to design, easy to maintain, hard to debug.

View Slide

@vixentael
TLS and ALE have different threat models, it’s
unfair to compare them, but we will :)

View Slide

@vixentael
encryption
controls / events
transit (TLS) disk / FS
TDE / DB
encryption
ALE E2EE
physical access
to servers
⛔ ✅ ✅ ✅ ✅
MitM
✅ ⛔ ⛔ ✅ ✅
privileged DB
access
⛔ ⛔ Depends
✅ ✅
privileged
system access
⛔ ⛔ ⛔ Depends
✅
backups, logs,
snapshots
⛔ ⛔ Depends
✅ ✅

View Slide

@vixentael
If E2EE is so great, why we don’t use it everywhere?
TLS
FS/OS
encr,
TDE
custom data-at-
rest encryption
ALE
E2EE
security
efforts,
tradeoffs
key storage,

key rotation, key
revocation,

data re-encryption,

consistency, backups,

tying keys w/ identity,

search in encrypted data,

logging monitoring,

and all the NIST SP
800-57, 800-53.

View Slide

@vixentael
Zero Trust / Zero Trust Architecture
– assumes there is no implicit trust granted to assets or user
accounts based solely on their physical or network location.
No asset is inherently trusted.
nist.gov/publications/zero-trust-architecture
ZT is more about access control and authN than encryption.

View Slide

@vixentael
Zero Knowledge Architecture (ZKA)
– system where no one has access to unencrypted data,
except the user (node, service, person). Also known as “No
Knowledge” Systems.
Typically built on E2EE + strong authN + privacy-respectful design.
See also: ZKP, SMP, PAKE, OPAQUE; FHE, searchable encryption.
cossacklabs.com/solutions/e2ee-zero-trust/

View Slide

@vixentael
Searchable encryption
Perform queries on encrypted data without decryption.
Different schemes are
possible: SSE, PEKS, blind
index, (F)HE, etc.
cossacklabs.com/blog/secure-search-over-encrypted-data-acra-se/
eprint.iacr.org/2019/806.pdf
Most realistic: keyword search
(blind index).

View Slide

@vixentael
*ASVS
ALE, E2EE

View Slide

@vixentael
Other exciting crypto terms
Privacy-enhancing cryptography: SMPC, PSI, PIR, FHE, PAKE, OPAQUE.
ZK: ZKP, zk-SNARKs, zk-STARKs, zk-SNORKs :)
nist.gov/blogs/cybersecurity-insights/privacy-enhancing-cryptography-complement-differential-privacy
Crypto reinforced guarantees in data structures: blockchain, Merkle-tree.
PQC.
hackernoon.com/eli5-zero-knowledge-proof-78a276db9eff
cossacklabs.com/blog/crypto-signed-audit-logs.html
aumasson.jp/data/talks/quantum-poc-2021.pdf
blog.cloud
fl
are.com/opaque-oblivious-passwords/
blog.cloud
fl
are.com/the-tls-post-quantum-experiment/

View Slide

@vixentael
SMPC, PIR, zk-
SNARKs, PQC

View Slide

Crypto is more useful when
integrated with traditional
security controls.

View Slide

@vixentael
data
encryption
access control,

authN
transport encryption
access logging
honeypots, SIEMs

View Slide

@vixentael

View Slide

AAA
WAF
honey pots
IDS
infra mngmt
compartmentalization
access logging
jailbans
monitoring
data
fi
rewall
SIEM
HIDS
DAST
SAST
HSM
PKI
TPM
honey tokens
dependency
mngmt
UEBA
IAM
TLS
TDE
@vixentael
API protection
obfuscation
anti-RE
csrc.nist.gov/publications/detail/sp/800-53/rev-5/
fi
nal
RTFM

View Slide

@vixentael
Security controls to support crypto
1. Use encryption to protect sensitive data globally during
the whole data
fl
ow.

2. Whatever is the attack vector, there is a defense layer.

3. For most popular attack vectors, set up as many
independent and overlapping defenses as possible.
✅
✅
✅

View Slide

@vixentael
*ASVS
ALE, E2EE
crypto + security
controls

View Slide

Let’s see some
real-world cases

View Slide

Field-level data encryption
for SaaS platforms

View Slide

@vixentael
Who we are and what we want
Huge B2B SaaS platforms.

Protect from insiders, provide transparency, detect malicious users.

Encrypt data per customer, using different keys, BYOK.

Minimize lifecycle of plaintext data – use encryption as early as
possible to the data generation point.

View Slide

application
@vixentael
Client-side
fi
eld-level encryption MongoDB
MongoDB
SDK
MongoDB
stores records with
encrypted
fi
elds
encryption /
decryption
TLS
writes records with encrypted
fi
elds
reads records with encrypted
fi
elds
TLS
docs.mongodb.com/drivers/security/client-side-
fi
eld-level-encryption-guide
key vault,

KMS

View Slide

@vixentael
Key hierarchy
fi
MongoDB
fi
eld, encrypted by DEK
Key Vault
DEK,

encrypted by CMK
KMS
CMK
millions dozens 1

View Slide

@vixentael
Pros & Cons
fi
Extremely useful when you have MongoDB.

Client apps shares responsibility for en/decryption and key
management due to exposure to key material.

Deterministic & non-deterministic encryptions available.

Support for different encryption keys (DEK).

View Slide

application
@vixentael
Proxy-side
fi
eld-level encryption Acra
github.com/cossacklabs/acra
Database
stores records with
encrypted
fi
elds
writes records with encrypted
fi
elds
reads records with encrypted
fi
elds
Acra proxy
encryption /
decryption
TLS
TLS
TLS key vault,

KMS

View Slide

@vixentael
Key hierarchy
Database
fi
eld encrypted by DEK,

DEK encrypted by KEK
Key Vault
KEK,

encrypted by CMK
KMS
CMK
millions dozens 1

View Slide

@vixentael
Pros & Cons
Neither database, not application doesn’t know that the data is encrypted.

Proxy app is responsible for en/decryption.

Easy to scale and build DAO-based architectures.

Non-deterministic and searchable encryptions available.

Support for different encryption keys, BYOK, key rotation, revocation, etc.

Easy-to-armor a single encryption layer with speci
fi
c controls: DLP, anomaly
detection,
fi
rewaling, anonymisation, etc.

View Slide

@vixentael
ALE for NoCode platform
API
frontend database
DAO
encryption
integration
API
frontend database
DAO
encryption
integration
customer’s

pod
NoCode
platform
tech logs, analytics
...
...

View Slide

@vixentael
ALE for NoCode platform
MongoDB
key vault,

KMS
DAO + ALE
encryption
module
API
frontend
fi
elds are encrypted
+ TLS
fi
elds are plaintext

+ TLS

View Slide

@vixentael
Crypto + supporting controls
1. Key management, separate key per customer (BYOK).

2. Full compartmentalization: customer’s data is located in different DBs,
encrypted by different key, each app uses its own DAO.

3. Full transparency — the platform doesn’t have access to customer’s
data.
1. Logging, monitoring.

2. Alerting on suspicious activity,
fi
rewaling.

3. ASVS: API protection, anti throttling, anti-fraud, access control …

View Slide

@vixentael
ALE for
fi
ntech platform
Service1 PostgreSQL
encryption /
decryption layer
Service2
BI
Analytics
ServiceN
...
DAO1
DAON
load balancing
...
MySQL
key vault,

KMS
...
fi
elds are encrypted

+ TLS
fi
elds are plaintext

+ TLS

View Slide

@vixentael
Crypto + supporting controls
1. Key management, separate keys per domain.

2. Decryption & anonymisation of data for BI software.

3. Isolation of sensitive data from non-sensitive.
1. Logging, monitoring.

2. PCI DSS audit logging + crypto-veri
fi
able logging.

3. Alerting on suspicious activity.

4. AppSec measures for DAO.

View Slide

Crypto-based ML models
protection

View Slide

@vixentael
AI/ML-driven product with unique IP. Paid feature.
Server-side generates ML models, mobile-side executes them.
ML models are unique per user, per app, per request (IML). Protecting
them is crucial.
leakage of IP
loss of IP, competitor advantage,

investments into updating ML model.

Losing 1 IML is not a problem, losing many IML is.
broken apps, clones
apps,

API fraud
abuse of infrastructure, revenue loss, abuse of IP,

competitor advantage, reputation risks

View Slide

API
@vixentael
IML data
fl
ow
user
data
GCE
worker,

TF
native

iOS app
native

Android app
GCP,

storing
IMLs
training
servers
main ML infra
generating

IMLs

View Slide

@vixentael
Encryption layer
API
GCE
worker,

TF
native

iOS app
native

Android app
GCP,

storing
IMLs
encrypts

each IML
stores encrypted
decrypts IML
decrypts IML

View Slide

@vixentael
Encryption scheme
GCE
worker,

TF
IML
encryptedIML
generation
encryption
storage
transfer

+ TLS
transfer

+ TLS
decryption
re-encryption

& storage
execution
encryptedIML
encryptedIML IML
IML encryptedIML
IMLs are encrypted after generation using ALE, unique keys per each
encryption. Transmitted using TLS. Then re-encrypted on device.
github.com/cossacklabs/themis

View Slide

@vixentael
IML encryption & decryption
GCE
worker,

TF
1. Generate keypair. Send app.publicKey
to backend.
2. Generate keypair. Use server.privateKey and app.publicKey to
derive sharedKey (ECDH).
3. Generate random DEK.
4. Encrypt IML using DEK, AES-256-GCM.
5. Encrypt DEK using sharedKey, AES-256-GCM.
6. Send { encryptedIML, encryptedDEK, server.publicKey }.
7. Receive. Use app.privateKey and server.publicKey to derive
sharedKey.
8. Decrypt DEK, decrypt IML.

View Slide

@vixentael
IML format
{

"data": base64_str(encrypted_IML),

"key": base64_str(encrypted_DEK),

"public_key": server_ephemeral_public_key,

"version": MODEL_VERSION,

"layers": {

// additional ML layers encryption

}

}
speakerdeck.com/vixentael/cryptographic-protection-of-ml-models

View Slide

@vixentael
Hybrid Public Key Encryption (HPKE)
datatracker.ietf.org/doc/draft-irtf-cfrg-hpke/
encrypt data with symmetric key using AEAD;

encapsulate symmetric key with public key scheme
RFC describes approach
used before and implies
standardization.

View Slide

@vixentael
Supporting security controls
API
native

iOS app
native

Android app
GCP,

storing
IMLs
AuthN
AuthN
TTL
crypto
anti-
RE
AppSec
crypto
anti-
RE
AppSec
API sec
anti-
fraud
crypto
crypto
ACL
logging
monitoring
AppSec
GCE
worker,

TF

View Slide

@vixentael
Cloud storage security 101
1. IMLs are stored min time – apps are expected
to grab their IML quickly.

2. URL TTL (expire after mins).

3. URL authentication & access control.

4. Clean up IML
fi
les (every hour).

5. Do not backup IMLs.

6. URLs are not logged.

7. Monitoring of access errors.
(also see OWASP WSTG-CONF-11)
AuthN
TTL
ACL

View Slide

@vixentael
API protection 101
1. User authN, IMLs are available only after
successful authN.

2. API limits, requests throttling,
fi
rewalling.

3. IML request limits – after N model requests,
server returns error.
(also see OWASP ASVS :) )
API
AuthN
AppSec
API sec

View Slide

@vixentael
Anti-fraud system 201
1. Limit access to IML based on user behaviour.

2. Gather events from mobile apps and from
server side.

3. Calculate user scoring based on events (“stop-
factors”, rules).

4. User scoring: OK, suspicious, malicious.

5. Block malicious, limit suspicious.
anti-
fraud
API

View Slide

@vixentael
Anti-fraud system 201
JB detected
same public key, different device
invalid app signature
remote device attestation failed 🛑 stop factors
}
URL download failure
app reinstall
too many requests
keychain not accessible
🤨 implicative
rules
}
wrong API version …
honey token deviceID …
malicious
suspicious
OK

View Slide

@vixentael
Remote device attestation
developer.apple.com/
documentation/devicecheck
Apple DeviceCheck
developer.android.com/training/
safetynet/attestation
Android SafetyNet
1. Use as part of user authN.

2. Use as source for anti-fraud system.

3. Block apps installed not from stores.

View Slide

@vixentael
Read the full story!
speakerdeck.com/vixentael/cryptographic-protection-of-ml-models
Cryptographic protection of ML models

View Slide

CRDT & E2EE

View Slide

@vixentael
CRDT-based mobile-
fi
rst product.
Users create shared spaces and collaborate on visuals and texts together.
Encrypt users’ data but allow them to collaborate.
speakerdeck.com/ept/adapting-secure-group-messaging-for-encrypted-crdts
Martin Kleppmann discussed other approaches
1 2 3 4
1 2 5
1 2 3 4 5

View Slide

@vixentael
CRDT log encryption strategy
1. The main problem – how to reduce problem to a typical one.

2. We selected document-based encryption, not chat-based.

3. Encrypt payload or action + payload. Trade-off: the more server knows the
faster are merges; the less server knows – the better security.

4. Use the same encryption key for all entries of the document.

5. Tricky part: “invite” and “revoke” users:

• give users access to the Document Key (“invite”) by encrypting it for
each user.

• de
fi
ne key rotation period.

• pre-keying, double ratchet – overkill.

View Slide

log entries
protection

(e2ee)
@vixentael

View Slide

passphrase
encryption
hint

encryption
zeroing

secrets
secure key
sharing

auto-locking

timer
failed attempts
counter
encrypted user
settings
log entries
protection

(e2ee) obfuscation

anti-RE &

anti-debugging

good TLS

@vixentael
authZ / authN

View Slide

@vixentael
*ASVS
ALE, E2EE
crypto + security
controls

View Slide

Encryption is not that hard.

Key management is a bit harder.

View Slide

Encryption is not that hard.

Key management is a bit harder.
Crypto + key management + data
fl
ow control

+ security controls…

Welcome to the real world :)

View Slide

@vixentael
Don’t hesitate to talk to me if you have questions
about data security and cryptography. Esp E2EE.
vixentael.dev
cossacklabs.com

View Slide

Data is a new security boundary

Data is a new security boundary

vixentael

More Decks by vixentael

Other Decks in Programming

Featured

Transcript
