1. Low level APIs

   using three.js
   Presented by Akihiro Oyamada (@yomotsu)
   Jul 6, 2015


   View Slide

2. Frontend Engineer
   at PixelGrid, Inc.
   @yomotsu
   recent works
   • http://yomotsu.github.io/walkthrough/
   • http://yomotsu.github.io/xmas2014/
   Akihiro Oyamada


   View Slide

3. three.js makes
   WebGL easier


   View Slide

4. • Too lengthy initialization of WebGL
   • Shaders in GLSL
   • Math: Linear algebra, physics, etc
   and others.
   *USFEVDFT


   View Slide

5. You may think
   that’s all?


   View Slide

6. You can also use

   low level APIs,

   like pure WebGL.


   View Slide

7. THREE.BufferGeometry

   for attributes


   View Slide

8. THREE.ShaderMaterial and

   THREE.RawShaderMaterial

   for uniforms

   and shaders in GLSL


   View Slide

9. sorry for a CHEAP figure, ive been having a cold…


   View Slide

10. var width = window.innerWidth;
    var height = window.innerHeight;
    var clock = new THREE.Clock();
    var scene = new THREE.Scene();
    var camera = new THREE.PerspectiveCamera( 60, width / height, .1, 100 );
    camera.position.set( 0, 0, 2 );
    var renderer = new THREE.WebGLRenderer();
    renderer.setSize( width, height );
    document.body.appendChild( renderer.domElement );
    !
    !
    var indices = new Uint16Array( [
    0, 1, 2,
    3, 4, 5
    ] );
    !
    var vertices = new Float32Array( [
    -1, -1, 0,
    1, -1, 0,
    -1, 1, 0,
    !


    View Slide

11. !
    !
    var indices = new Uint16Array( [
    0, 1, 2,
    3, 4, 5
    ] );
    !
    var vertices = new Float32Array( [
    -1, -1, 0,
    1, -1, 0,
    -1, 1, 0,
    !
    -1, 1, 0,
    1, -1, 0,
    1, 1, 0
    ] );
    !
    var uvs = new Float32Array( [
    0, 1,
    1, 1,
    0, 0,
    !
    0, 0,


    View Slide

12. !
    !
    var indexBuffer = new THREE.BufferAttribute( indices, 1 );
    var vertexBuffer = new THREE.BufferAttribute( vertices, 3 );
    var uvBuffer = new THREE.BufferAttribute( uvs, 2 );
    !
    !
    var geometry = new THREE.BufferGeometry();
    geometry.addAttribute( 'index', indexBuffer );
    geometry.addAttribute( 'position', vertexBuffer );
    geometry.addAttribute( 'uv', uvBuffer );
    !
    !
    //
    // You don't need to put following uniforms.
    // modelMatrix is automatically linked to `mesh.matrixWorld`
    // viewMatrix is automatically linked to `camera.matrixWorldInverse`
    // projectionMatrix is automatically linked to `camera.projectionMatrix`
    //
    var uniforms = {
    // modelMatrix : { type: 'm4', value: new THREE.Matrix4() },
    // viewMatrix : { type: 'm4', value: new THREE.Matrix4() },
    // projectionMatrix : { type: 'm4', value: new THREE.Matrix4() },


    View Slide

13. !
    //
    // You don't need to put following uniforms.
    // modelMatrix is automatically linked to `mesh.matrixWorld`
    // viewMatrix is automatically linked to `camera.matrixWorldInverse`
    // projectionMatrix is automatically linked to `camera.projectionMatrix`
    //
    var uniforms = {
    // modelMatrix : { type: 'm4', value: new THREE.Matrix4() },
    // viewMatrix : { type: 'm4', value: new THREE.Matrix4() },
    // projectionMatrix : { type: 'm4', value: new THREE.Matrix4() },
    diffuse : { type: "t", value: THREE.ImageUtils.loadTexture( 'uv.png' ) }
    };
    !
    var vertexShader = [
    !
    'attribute vec3 position;',
    'attribute vec2 uv;',
    !
    'uniform mat4 projectionMatrix;',
    'uniform mat4 viewMatrix;',
    'uniform mat4 modelMatrix;',
    !


    View Slide

14. !
    var vertexShader = [
    !
    'attribute vec3 position;',
    'attribute vec2 uv;',
    !
    'uniform mat4 projectionMatrix;',
    'uniform mat4 viewMatrix;',
    'uniform mat4 modelMatrix;',
    !
    'varying vec2 vUv;',
    !
    'void main() {',
    !
    ' gl_Position = projectionMatrix * viewMatrix * modelMatrix * vec4( position, 1.0
    );',
    ' vUv = uv;',
    !
    '}'
    !
    ].join( "\n" );
    !
    !


    View Slide

15. !
    !
    var fragmentShader = [
    !
    'precision mediump float;',
    !
    'uniform sampler2D diffuse;',
    !
    'varying vec2 vUv;',
    !
    'void main() {',
    !
    'vec4 diffuseColor = texture2D( diffuse, vUv );',
    'gl_FragColor = diffuseColor;',
    // 'gl_FragColor = vec4( 1 );',
    !
    '}',
    !
    ].join( "\n" );
    !
    !
    var material = new THREE.RawShaderMaterial( {
    vertexShader : vertexShader,
    fragmentShader : fragmentShader,


    View Slide

16. !
    !
    var material = new THREE.RawShaderMaterial( {
    vertexShader : vertexShader,
    fragmentShader : fragmentShader,
    attributes : {
    // if you put custom attributes except
    // positions, indices, normals, colors and UVs
    // you need to declare those like
    //
    // vertexOpacity: { type: 'f', value: [] }
    },
    uniforms : uniforms,
    defines : {}
    } );
    !
    var mesh = new THREE.Mesh( geometry, material );
    scene.add( mesh );
    !
    !
    ( function animate () {
    !
    requestAnimationFrame( animate );
    !


    View Slide

17. !
    var mesh = new THREE.Mesh( geometry, material );
    scene.add( mesh );
    !
    !
    ( function animate () {
    !
    requestAnimationFrame( animate );
    !
    var theta = clock.getElapsedTime();
    mesh.rotation.set( 0, theta, 0 );
    !
    renderer.render( scene, camera );
    !
    } )();


    View Slide

18. View Slide

19. View Slide

20. A gas-ish fluid object
    in a MMO game


    View Slide

21. 21
    https://github.com/yomotsu/VolumetricFire
    Fire in three.js using

    THREE.BufferGeometry and
    THREE.RawShaderMaterial


    View Slide

22. Extended build-in shades


    View Slide

23. View Slide

24. In a MMO game what I play…
    Similar to THREE.MeshPhongMaterial,
    but edge of the model is different.
    It seems, normal directions make it…


    View Slide

25. 25
    https://github.com/mrdoob/three.js/blob/master/src/renderers/shaders/ShaderLib.js


    View Slide

26. You can use
    THREE.ShaderChank

    in your custom shader


    View Slide

27. var uniforms = THREE.UniformsUtils.merge( [
    !
    THREE.UniformsLib[ "common" ],
    THREE.UniformsLib[ "bump" ],
    THREE.UniformsLib[ "normalmap" ],
    THREE.UniformsLib[ "fog" ],
    THREE.UniformsLib[ "lights" ],
    THREE.UniformsLib[ "shadowmap" ],
    !
    {
    "emissive" : { type: "c", value: new THREE.Color( 0x000000 ) },
    "specular" : { type: "c", value: new THREE.Color( 0x111111 ) },
    "shininess": { type: "f", value: 30 },
    "wrapRGB" : { type: "v3", value: new THREE.Vector3( 1, 1, 1 ) }
    },
    !
    {
    // ADDED UNIFROMS
    The same as actual code of

    build-in PhongMaterial


    View Slide

28. "shininess": { type: "f", value: 30 },
    "wrapRGB" : { type: "v3", value: new THREE.Vector3( 1, 1, 1 ) }
    },
    !
    {
    // ADDED UNIFROMS
    glowColor : { type: "c", value: new THREE.Color( 0x84ccff ) },
    viewVector: { type: "v3", value: new THREE.Vector3() },
    viewMatrixInverse : { type: 'm4', value: new THREE.Matrix4() }
    },
    !
    ] );
    !
    var vertexShader = [
    !
    "#define PHONG",
    !
    "varying vec3 vViewPosition;",
    !
    "#ifndef FLAT_SHADED",
    The same as actual code of

    build-in PhongMaterial


    View Slide

29. !
    var vertexShader = [
    !
    "#define PHONG",
    !
    "varying vec3 vViewPosition;",
    !
    "#ifndef FLAT_SHADED",
    !
    " varying vec3 vNormal;",
    !
    "#endif",
    !
    THREE.ShaderChunk[ "common" ],
    THREE.ShaderChunk[ "map_pars_vertex" ],
    THREE.ShaderChunk[ "lightmap_pars_vertex" ],
    THREE.ShaderChunk[ "envmap_pars_vertex" ],
    THREE.ShaderChunk[ "lights_phong_pars_vertex" ],
    THREE.ShaderChunk[ "color_pars_vertex" ],
    THREE.ShaderChunk[ "morphtarget_pars_vertex" ],
    The same as actual code of

    build-in PhongMaterial


    View Slide

30. THREE.ShaderChunk[ "skinning_pars_vertex" ],
    THREE.ShaderChunk[ "shadowmap_pars_vertex" ],
    THREE.ShaderChunk[ "logdepthbuf_pars_vertex" ],
    !
    !
    'uniform mat4 viewMatrixInverse;', //ADDED
    'uniform vec3 viewVector;', //ADDED
    'varying float vIntensity;', //ADDED
    !
    "void main() {",
    !
    THREE.ShaderChunk[ "map_vertex" ],
    THREE.ShaderChunk[ "lightmap_vertex" ],
    THREE.ShaderChunk[ "color_vertex" ],
    !
    THREE.ShaderChunk[ "morphnormal_vertex" ],
    THREE.ShaderChunk[ "skinbase_vertex" ],
    THREE.ShaderChunk[ "skinnormal_vertex" ],
    THREE.ShaderChunk[ "defaultnormal_vertex" ],
    !
    The same as actual code of

    build-in PhongMaterial


    View Slide

31. !
    !
    var fragmentShader = [
    !
    "#define PHONG",
    !
    "uniform vec3 diffuse;",
    "uniform vec3 emissive;",
    "uniform vec3 specular;",
    "uniform float shininess;",
    "uniform float opacity;",
    !
    "uniform vec3 glowColor;", //ADDED
    'varying float vIntensity;', //ADDED
    !
    THREE.ShaderChunk[ "common" ],
    THREE.ShaderChunk[ "color_pars_fragment" ],
    THREE.ShaderChunk[ "map_pars_fragment" ],
    THREE.ShaderChunk[ "alphamap_pars_fragment" ],
    THREE.ShaderChunk[ "lightmap_pars_fragment" ],
    The same as actual code of

    build-in PhongMaterial


    View Slide

32. this should be pre-multiplied to allow for bright highlights on very
    transparent objects
    // 'gl_FragColor = vec4( outgoingLight, diffuseColor.a );', //
    REMOVED
    !
    'vec3 glow = glowColor * vIntensity;',
    'gl_FragColor = vec4(',
    // 'glow,',
    'outgoingLight + glow,',
    'diffuseColor.a',
    ');',
    !
    "}"
    !
    ].join( "\n" );
    !
    !
    !
    var material = new THREE.ShaderMaterial( {
    vertexShader : vertexShader,


    View Slide

33. !
    !
    var material = new THREE.ShaderMaterial( {
    vertexShader : vertexShader,
    fragmentShader: fragmentShader,
    attributes: {},
    uniforms: uniforms,
    defines: {},
    !
    fog: true,
    lights: true,
    // side: THREE.FrontSide,
    // blending: THREE.AdditiveBlending,
    skinning: true,
    transparent: true,
    // depthWrite: false
    // wireframe: true
    } );
    !
    material.uniforms.map = { type: 't', value: texture }


    View Slide

34. // side: THREE.FrontSide,
    // blending: THREE.AdditiveBlending,
    skinning: true,
    transparent: true,
    // depthWrite: false
    // wireframe: true
    } );
    !
    material.uniforms.map = { type: 't', value: texture }
    material.defines.USE_MAP = '';


    View Slide

35. build in shader custom shader


    View Slide

36. Conclusion


    View Slide

37. Three.js is not only high level APIs,

    but also it provides low level APIs


    View Slide

38. • THREE.BufferAttribute
    • THREE.BufferGeometry
    • THREE.ShaderMaterial
    • THREE.RawShaderMaterial
    "WBJMBCMFGFBUVSFTJOUISFFKT


    View Slide

39. Three.js is a

    flexible and extensible library


    View Slide

40. gl.finish();
    @yomotsu
