Add Reality to your App with ARCore

AR is a buzzword we hear everywhere. But is it really possible to build enhanced AR experiences quickly? There were quite a few attempts to bring AR to Android, but they were not easy to implement or required special hardware. ARCore solves both of the problems. It is a fast and performant SDK providing great API to build AR focused apps using just a phone’s camera. The slides cover AR main concepts, geometry detection, object rendering and potential problems. Lessons learnt are also shared from the experience of building e-commerce AR experience at Jet.com.

Transcript

1. @YuliyaKaleda Add Reality to App with ARCore
2. Jet.com AR experience
3. Tango several cameras sensors high cost $ few devices (Lenovo Phab 2 Pro, Asus Zenfone) D E P R E C A T E D
4. ARCore several cameras sensors devices cost $ low more (Pixel, Samsung, LG V30, Asus)
5. Augmented Reality geometry detection view rendering +
6. ARCore geometry detection view rendering
7. ARCore OpenGL geometry detection view rendering +
8. ARCore Concepts motion tracking environmental understanding light estimation
9. Motion Tracking feature points camera position and orientation sensors
10. Environmental understanding planes surfaces with no texture !!! vertical planes
11. Light estimation average intensity
12. Support Pixel, Samsung Galaxy, OnePlus, LG V30, Asus API 24 ~ 45MB
13. Building AR experience 1. ARCore compatibility and installation 3. Geometry detection 4. Object rendering 2. UI components
14. AR Apps AR optional AR required AR Stickers Jet.com
15. <manifest xmlns:android="http://schemas.android.com/apk/res/android" android:targetSandboxVersion="2" package=“com.jet.baselib"> <uses-feature android:name="android.hardware.camera.ar" android:required="true"/> <application android:name=“JetApp"> . . . <activity android:name=“.activities.SplashScreenActivity" /> <meta-data android:name="com.google.ar.core" android:value=“required" /> </application> </manifest> AR Required
16. <manifest xmlns:android="http://schemas.android.com/apk/res/android" android:targetSandboxVersion="2" package="com.jet.baselib"> <application android:name=“JetApp"> . . . <activity android:name=“.activities.SplashScreenActivity" /> <meta-data android:name="com.google.ar.core" android:value="optional" /> </application> </manifest> AR Optional
17. private void showArBanner() { ArCoreApk.Availability availability = ArCoreApk.getInstance() .checkAvailability(arCard.getContext()); if (availability.isTransient()) { new Handler().postDelayed(() -> showArBanner(), 200); } HelperViews.setVisibleOrGone(arCard, availability.isSupported()); } AR Optional
18. private void showArBanner() { ArCoreApk.Availability availability = ArCoreApk.getInstance() .checkAvailability(arCard.getContext().getApplicationContext()); if (availability.isTransient()) { new Handler().postDelayed(() -> showArBanner(), 200); } HelperViews.setVisibleOrGone(arCard, availability.isSupported()); } AR Optional
19. private boolean requestedARCoreInstall = true; public void onResume() { try { switch (ArCoreApk.getInstance() .requestInstall(activity, requestedARCoreInstall)) { case INSTALLED: //Success break; case INSTALL_REQUESTED: //Request installation requestedARCoreInstall = false; return; } } catch (UnavailableUserDeclinedInstallationException e) { message = "Please install or update ARCore"; } catch (Exception e) { message = "This device does not support AR"; } if (message != null) { showSnackbarMessage(message, true); return; } } ARCore installation
20. private boolean requestedARCoreInstall = true; public void onResume() { try { switch (ArCoreApk.getInstance() .requestInstall(activity, requestedARCoreInstall)) { case INSTALLED: //Success break; case INSTALL_REQUESTED: //Request installation requestedARCoreInstall = false; return; } } catch (UnavailableUserDeclinedInstallationException e) { message = "Please install or update ARCore"; } catch (Exception e) { message = "This device does not support AR"; } if (message != null) { showSnackbarMessage(message, true); return; } } ARCore installation
21. AR installation
22. Building AR experience 1. ARCore compatibility and installation 3. Geometry detection 4. Object rendering 2. UI components
23. <RelativeLayout xmlns:android="http://schemas.android.com/apk/res/android" xmlns:app="http://schemas.android.com/apk/res-auto" xmlns:tools="http://schemas.android.com/tools" android:layout_width="match_parent" android:layout_height="match_parent" tools:context="com.jet.arlib.activities.ArActivity"> <android.opengl.GLSurfaceView android:id=“@+id/surface_view" android:layout_width="match_parent" android:layout_height="match_parent"/> </RelativeLayout> UI Components
24. public class ArCoreRenderer implements GLSurfaceView.Renderer { @Override public void onSurfaceCreated(GL10 gl, EGLConfig config) { } @Override public void onSurfaceChanged(GL10 gl, int width, int height) { } @Override public void onDrawFrame(GL10 gl) { } } UI Rendering GL thread
25. public class ArActivity extends JetActivity { @Override protected void onCreate(Bundle savedInstanceState) { super.onCreate(savedInstanceState); setContentView(R.layout.activity_ar); GLSurfaceView surfaceView = findViewById(R.id.surfaceview); ArCoreRenderer coreRenderer = new ArCoreRenderer(this); surfaceView.setPreserveEGLContextOnPause(true); surfaceView.setEGLContextClientVersion(2); surfaceView.setEGLConfigChooser(8, 8, 8, 8, 16, 0); surfaceView.setRenderer(coreRenderer); surfaceView.setRenderMode(GLSurfaceView.RENDERMODE_CONTINUOUSLY); } } UI Rendering
26. Building AR experience 1. ARCore compatibility and installation 3. Geometry detection 4. Object rendering 2. UI components
27. ARCore building blocks session
28. public void onResume() { if (session == null) { try { switch (ArCoreApk.getInstance() .requestInstall(activity, requestedARCoreInstall)) { case INSTALLED: session = new Session(activity); break; case INSTALL_REQUESTED: requestedARCoreInstall = false; return; } } catch (UnavailableUserDeclinedInstallationException e) { ... } Config config = new Config(session); session.configure(config); } session.resume(); } Session
29. public void onPause() { if (session != null) { session.pause(); } } Session * no guarantees that objects are trackable
30. ARCore building blocks session
31. Session Config light estimation mode (AMBIENT_INTENSITY, DISABLED) plane finding mode (DISABLED, HORIZONTAL) update mode (BLOCKING, LATEST_CAMERA_IMAGE)
32. public void onResume() { if (session == null) { try { switch (ArCoreApk.getInstance() .requestInstall(activity, requestedARCoreInstall)) { case INSTALLED: session = new Session(activity); break; case INSTALL_REQUESTED: requestedARCoreInstall = false; return; } } catch (UnavailableUserDeclinedInstallationException e) { ... } // Create default config Config config = new Config(session); session.configure(config); } session.resume(); } Session Config
33. ARCore building blocks session frames
34. @Override public void onDrawFrame(GL10 gl) { if (session == null) { return; } Frame frame = session.update(); } Frame
35. ARCore building blocks session frames camera
36. @Override public void onDrawFrame(GL10 gl) { if (session == null) { return; } Frame frame = session.update(); Camera camera = frame.getCamera(); } Frame
37. ARCore building blocks session frames camera light light
38. @Override public void onDrawFrame(GL10 gl) { if (session == null) { return; } Frame frame = session.update(); Camera camera = frame.getCamera(); float lightIntensity = frame.getLightEstimate().getPixelIntensity(); } Frame
39. ARCore building blocks session frames camera light hitResult
40. HitResult feature points planes
41. @Override public void onDrawFrame(GL10 gl) { if (session == null) { return; } Frame frame = session.update(); Camera camera = frame.getCamera(); float lightIntensity = frame.getLightEstimate().getPixelIntensity(); List<HitResult> hitResults = frame.hitTest(position.x, position.y); //List<HitResult> hitResults = frame.hitTest(motionEvent); } Frame
42. @Override public void onDrawFrame(GL10 gl) { if (session == null) { return; } Frame frame = session.update(); Camera camera = frame.getCamera(); float lightIntensity = frame.getLightEstimate().getPixelIntensity(); //List<HitResult> hitResults = frame.hitTest(position.x, position.y); List<HitResult> hitResults = frame.hitTest(motionEvent); } Frame
43. @Override public void onDrawFrame(GL10 gl) { . . . List<HitResult> hitResults = frame.hitTest(position.x, position.y); if (hitResults.size() > 0) { HitResult hit = getClosestHit(hitResults); } } private HitResult getClosestHit(List<HitResult> hitResults) { for (HitResult hitResult : hitResults) { if (hitResult.getTrackable() instanceof Plane) { return hitResult; } } return hitResults.get(0); } HitResult
44. ARCore building blocks session frames camera light HitResult anchors
45. @Override public void onDrawFrame(GL10 gl) { . . . List<HitResult> hitResults = frame.hitTest(position.x, position.y); if (hitResults.size() > 0) { HitResult hit = getClosestHit(hitResults); Anchor anchor = hit.createAnchor(); } } Anchor
46. Building AR experience 1. ARCore compatibility and installation 3. Geometry detection 4. Object rendering 2. UI components
47. Object rendering geometry texture + .obj | .collada | .fbx .png | .webP
48. Object rendering geometry texture o GoogleHome_GEO v 9.16292e-006 0.00498037 -0.0290344 v -0.00769833 0.00176132 -0.0292111 v -0.0148647 0.00176132 -0.0261927 v -0.0210186 0.00176132 -0.0213912 v -0.0257407 0.00176132 -0.0151337 v -0.0287091 0.00176132 -0.00784677 v -0.0297216 0.00176132 -2.6893e-005 v -0.0287091 0.00176132 0.00779299 v -0.0257407 0.00176132 0.01508 v -0.0210186 0.00176132 0.0213374 v -0.0148647 0.00176132 0.0261389 v -0.00769833 0.00176132 0.0291573 v -7.85162e-006 0.00176132 0.0301868 v 0.00768262 0.00176132 0.0291573 v 0.014849 0.00176132 0.0261389 v 0.0210029 0.00176132 0.0213374 v 0.025725 0.00176132 0.01508 v 0.0286934 0.00176132 0.00779299 … .obj .webP
49. public void createOnGlThread(Context context, String objAssetName, String diffuseTextureAssetName) throws IOException { // Read texture. Bitmap textureBitmap = BitmapFactory.decodeStream(context.getAssets() .open(diffuseTextureAssetName)); GLES20.glActiveTexture(GLES20.GL_TEXTURE0); GLES20.glGenTextures(textures.length, textures, 0); GLES20.glBindTexture(GLES20.GL_TEXTURE_2D, textures[0]); GLES20.glTexParameteri(GLES20.GL_TEXTURE_2D, GLES20.GL_TEXTURE_MIN_FILTER, GLES20.GL_LINEAR_MIPMAP_LINEAR); GLES20.glTexParameteri(GLES20.GL_TEXTURE_2D, GLES20.GL_TEXTURE_MAG_FILTER, GLES20.GL_LINEAR); GLUtils.texImage2D(GLES20.GL_TEXTURE_2D, 0, textureBitmap, 0); GLES20.glGenerateMipmap(GLES20.GL_TEXTURE_2D); GLES20.glBindTexture(GLES20.GL_TEXTURE_2D, 0); textureBitmap.recycle(); } Texture
50. public void createOnGlThread(Context context, String objAssetName, String diffuseTextureAssetName) throws IOException { // Read texture. Bitmap textureBitmap = BitmapFactory.decodeStream(context.getAssets() .open(diffuseTextureAssetName)); GLES20.glActiveTexture(GLES20.GL_TEXTURE0); GLES20.glGenTextures(textures.length, textures, 0); GLES20.glBindTexture(GLES20.GL_TEXTURE_2D, textures[0]); GLES20.glTexParameteri(GLES20.GL_TEXTURE_2D, GLES20.GL_TEXTURE_MIN_FILTER, GLES20.GL_LINEAR_MIPMAP_LINEAR); GLES20.glTexParameteri(GLES20.GL_TEXTURE_2D, GLES20.GL_TEXTURE_MAG_FILTER, GLES20.GL_LINEAR); GLUtils.texImage2D(GLES20.GL_TEXTURE_2D, 0, textureBitmap, 0); GLES20.glGenerateMipmap(GLES20.GL_TEXTURE_2D); GLES20.glBindTexture(GLES20.GL_TEXTURE_2D, 0); textureBitmap.recycle(); } Texture
51. public void createOnGlThread(Context context, String objAssetName, String diffuseTextureAssetName) throws IOException { // Read texture. Bitmap textureBitmap = BitmapFactory.decodeStream(context.getAssets() .open(diffuseTextureAssetName)); GLES20.glActiveTexture(GLES20.GL_TEXTURE0); GLES20.glGenTextures(textures.length, textures, 0); GLES20.glBindTexture(GLES20.GL_TEXTURE_2D, textures[0]); GLES20.glTexParameteri(GLES20.GL_TEXTURE_2D, GLES20.GL_TEXTURE_MIN_FILTER, GLES20.GL_LINEAR_MIPMAP_LINEAR); GLES20.glTexParameteri(GLES20.GL_TEXTURE_2D, GLES20.GL_TEXTURE_MAG_FILTER, GLES20.GL_LINEAR); GLUtils.texImage2D(GLES20.GL_TEXTURE_2D, 0, textureBitmap, 0); GLES20.glGenerateMipmap(GLES20.GL_TEXTURE_2D); GLES20.glBindTexture(GLES20.GL_TEXTURE_2D, 0); textureBitmap.recycle(); } Texture
52. public void createOnGlThread(Context context, String objAssetName, String diffuseTextureAssetName) throws IOException { . . . // Read the obj file. InputStream objInputStream = context.getAssets().open(objAssetName); Obj obj = ObjReader.read(objInputStream); obj = ObjUtils.convertToRenderable(obj); IntBuffer wideIndices = ObjData.getFaceVertexIndices(obj, 3); FloatBuffer vertices = ObjData.getVertices(obj); FloatBuffer texCoords = ObjData.getTexCoords(obj, 2); FloatBuffer normals = ObjData.getNormals(obj); . . . // Load vertex buffer verticesBaseAddress = 0; texCoordsBaseAddress = verticesBaseAddress + 4 * vertices.limit(); normalsBaseAddress = texCoordsBaseAddress + 4 * texCoords.limit(); final int totalBytes = normalsBaseAddress + 4 * normals.limit(); GLES20.glBindBuffer(GLES20.GL_ARRAY_BUFFER, vertexBufferId); GLES20.glBufferData(GLES20.GL_ARRAY_BUFFER, totalBytes, null, GLES20.GL_STATIC_DRAW); GLES20.glBufferSubData(GLES20.GL_ARRAY_BUFFER, verticesBaseAddress, 4 * vertices.limit(), vertices); GLES20.glBufferSubData(GLES20.GL_ARRAY_BUFFER, texCoordsBaseAddress, 4 * texCoords.limit(), texCoords); GLES20.glBufferSubData(GLES20.GL_ARRAY_BUFFER, normalsBaseAddress, 4 * normals.limit(), normals); GLES20.glBindBuffer(GLES20.GL_ARRAY_BUFFER, 0); . . . } Read .obj
53. public void createOnGlThread(Context context, String objAssetName, String diffuseTextureAssetName) throws IOException { . . . // Read the obj file. InputStream objInputStream = context.getAssets().open(objAssetName); Obj obj = ObjReader.read(objInputStream); obj = ObjUtils.convertToRenderable(obj); IntBuffer wideIndices = ObjData.getFaceVertexIndices(obj, 3); FloatBuffer vertices = ObjData.getVertices(obj); FloatBuffer texCoords = ObjData.getTexCoords(obj, 2); FloatBuffer normals = ObjData.getNormals(obj); . . . // Load vertex buffer verticesBaseAddress = 0; texCoordsBaseAddress = verticesBaseAddress + 4 * vertices.limit(); normalsBaseAddress = texCoordsBaseAddress + 4 * texCoords.limit(); final int totalBytes = normalsBaseAddress + 4 * normals.limit(); GLES20.glBindBuffer(GLES20.GL_ARRAY_BUFFER, vertexBufferId); GLES20.glBufferData(GLES20.GL_ARRAY_BUFFER, totalBytes, null, GLES20.GL_STATIC_DRAW); GLES20.glBufferSubData(GLES20.GL_ARRAY_BUFFER, verticesBaseAddress, 4 * vertices.limit(), vertices); GLES20.glBufferSubData(GLES20.GL_ARRAY_BUFFER, texCoordsBaseAddress, 4 * texCoords.limit(), texCoords); GLES20.glBufferSubData(GLES20.GL_ARRAY_BUFFER, normalsBaseAddress, 4 * normals.limit(), normals); GLES20.glBindBuffer(GLES20.GL_ARRAY_BUFFER, 0); . . . } Read .obj
54. public void createOnGlThread(Context context, String objAssetName, String diffuseTextureAssetName) throws IOException { . . . // Read the obj file. InputStream objInputStream = context.getAssets().open(objAssetName); Obj obj = ObjReader.read(objInputStream); obj = ObjUtils.convertToRenderable(obj); IntBuffer wideIndices = ObjData.getFaceVertexIndices(obj, 3); FloatBuffer vertices = ObjData.getVertices(obj); FloatBuffer texCoords = ObjData.getTexCoords(obj, 2); FloatBuffer normals = ObjData.getNormals(obj); . . . // Load vertex buffer verticesBaseAddress = 0; texCoordsBaseAddress = verticesBaseAddress + 4 * vertices.limit(); normalsBaseAddress = texCoordsBaseAddress + 4 * texCoords.limit(); final int totalBytes = normalsBaseAddress + 4 * normals.limit(); GLES20.glBindBuffer(GLES20.GL_ARRAY_BUFFER, vertexBufferId); GLES20.glBufferData(GLES20.GL_ARRAY_BUFFER, totalBytes, null, GLES20.GL_STATIC_DRAW); GLES20.glBufferSubData(GLES20.GL_ARRAY_BUFFER, verticesBaseAddress, 4 * vertices.limit(), vertices); GLES20.glBufferSubData(GLES20.GL_ARRAY_BUFFER, texCoordsBaseAddress, 4 * texCoords.limit(), texCoords); GLES20.glBufferSubData(GLES20.GL_ARRAY_BUFFER, normalsBaseAddress, 4 * normals.limit(), normals); GLES20.glBindBuffer(GLES20.GL_ARRAY_BUFFER, 0); . . . } Read .obj
55. public void createOnGlThread(Context context, String objAssetName, String diffuseTextureAssetName) throws IOException { . . . // Read the obj file. InputStream objInputStream = context.getAssets().open(objAssetName); Obj obj = ObjReader.read(objInputStream); obj = ObjUtils.convertToRenderable(obj); IntBuffer wideIndices = ObjData.getFaceVertexIndices(obj, 3); FloatBuffer vertices = ObjData.getVertices(obj); FloatBuffer texCoords = ObjData.getTexCoords(obj, 2); FloatBuffer normals = ObjData.getNormals(obj); . . . // Load vertex buffer verticesBaseAddress = 0; texCoordsBaseAddress = verticesBaseAddress + 4 * vertices.limit(); normalsBaseAddress = texCoordsBaseAddress + 4 * texCoords.limit(); final int totalBytes = normalsBaseAddress + 4 * normals.limit(); GLES20.glBindBuffer(GLES20.GL_ARRAY_BUFFER, vertexBufferId); GLES20.glBufferData(GLES20.GL_ARRAY_BUFFER, totalBytes, null, GLES20.GL_STATIC_DRAW); GLES20.glBufferSubData(GLES20.GL_ARRAY_BUFFER, verticesBaseAddress, 4 * vertices.limit(), vertices); GLES20.glBufferSubData(GLES20.GL_ARRAY_BUFFER, texCoordsBaseAddress, 4 * texCoords.limit(), texCoords); GLES20.glBufferSubData(GLES20.GL_ARRAY_BUFFER, normalsBaseAddress, 4 * normals.limit(), normals); GLES20.glBindBuffer(GLES20.GL_ARRAY_BUFFER, 0); . . . } Read .obj
56. public void createOnGlThread(Context context, String objAssetName, String diffuseTextureAssetName) throws IOException { . . . // Load shaders final int vertexShader = ShaderUtil.loadGLShader(TAG, context, GLES20.GL_VERTEX_SHADER, R.raw.object_vertex); final int fragmentShader = ShaderUtil.loadGLShader(TAG, context, GLES20.GL_FRAGMENT_SHADER, R.raw.object_fragment); program = GLES20.glCreateProgram(); GLES20.glAttachShader(program, vertexShader); GLES20.glAttachShader(program, fragmentShader); GLES20.glLinkProgram(program); GLES20.glUseProgram(program); GLES20.glDetachShader(program, vertexShader); GLES20.glDetachShader(program, fragmentShader); GLES20.glDeleteShader(vertexShader); GLES20.glDeleteShader(fragmentShader); textureUniform = GLES20.glGetUniformLocation(program, "u_Texture"); lightingParametersUniform = GLES20.glGetUniformLocation(program, "u_LightingParameters"); materialParametersUniform = GLES20.glGetUniformLocation(program, "u_MaterialParameters"); . . . Matrix.setIdentityM(modelMatrix, 0); } Load shaders
57. public void createOnGlThread(Context context, String objAssetName, String diffuseTextureAssetName) throws IOException { . . . // Load shaders final int vertexShader = ShaderUtil.loadGLShader(TAG, context, GLES20.GL_VERTEX_SHADER, R.raw.object_vertex); final int fragmentShader = ShaderUtil.loadGLShader(TAG, context, GLES20.GL_FRAGMENT_SHADER, R.raw.object_fragment); program = GLES20.glCreateProgram(); GLES20.glAttachShader(program, vertexShader); GLES20.glAttachShader(program, fragmentShader); GLES20.glLinkProgram(program); GLES20.glUseProgram(program); GLES20.glDetachShader(program, vertexShader); GLES20.glDetachShader(program, fragmentShader); GLES20.glDeleteShader(vertexShader); GLES20.glDeleteShader(fragmentShader); textureUniform = GLES20.glGetUniformLocation(program, "u_Texture"); lightingParametersUniform = GLES20.glGetUniformLocation(program, "u_LightingParameters"); materialParametersUniform = GLES20.glGetUniformLocation(program, "u_MaterialParameters"); . . . Matrix.setIdentityM(modelMatrix, 0); } Load shaders
58. public void draw(float[] cameraView, float[] cameraPerspective, float lightIntensity, float deltaTime) { // Build the ModelView and ModelViewProjection matrices to calculate object position Matrix.multiplyMM(modelViewMatrix, 0, cameraView, 0, modelMatrix, 0); Matrix.multiplyMM(modelViewProjectionMatrix, 0, cameraPerspective, 0, modelViewMatrix, 0); GLES20.glUseProgram(program); // Configure light Matrix.multiplyMV(viewLightDirection, 0, cameraView, 0, LIGHT_DIRECTION, 0); normalize(viewLightDirection); GLES20.glUniform4f(lightingParametersUniform,viewLightDirection[0], viewLightDirection[1], viewLightDirection[2], lightIntensity); // Set object material properties GLES20.glUniform4f(materialParametersUniform, ambient, diffuse, specular, specularPower); // Attach the object texture. GLES20.glActiveTexture(GLES20.GL_TEXTURE0); GLES20.glBindTexture(GLES20.GL_TEXTURE_2D, textures[0]); GLES20.glUniform1i(textureUniform, 0); . . . } Finally draw
59. public void draw(float[] cameraView, float[] cameraPerspective, float lightIntensity, float deltaTime) { // Build the ModelView and ModelViewProjection matrices to calculate object position Matrix.multiplyMM(modelViewMatrix, 0, cameraView, 0, modelMatrix, 0); Matrix.multiplyMM(modelViewProjectionMatrix, 0, cameraPerspective, 0, modelViewMatrix, 0); GLES20.glUseProgram(program); // Configure light Matrix.multiplyMV(viewLightDirection, 0, cameraView, 0, LIGHT_DIRECTION, 0); normalize(viewLightDirection); GLES20.glUniform4f(lightingParametersUniform,viewLightDirection[0], viewLightDirection[1], viewLightDirection[2], lightIntensity); // Set object material properties GLES20.glUniform4f(materialParametersUniform, ambient, diffuse, specular, specularPower); // Attach the object texture. GLES20.glActiveTexture(GLES20.GL_TEXTURE0); GLES20.glBindTexture(GLES20.GL_TEXTURE_2D, textures[0]); GLES20.glUniform1i(textureUniform, 0); . . . } Finally draw
60. public void draw(float[] cameraView, float[] cameraPerspective, float lightIntensity, float deltaTime) { // Build the ModelView and ModelViewProjection matrices to calculate object position Matrix.multiplyMM(modelViewMatrix, 0, cameraView, 0, modelMatrix, 0); Matrix.multiplyMM(modelViewProjectionMatrix, 0, cameraPerspective, 0, modelViewMatrix, 0); GLES20.glUseProgram(program); // Configure light Matrix.multiplyMV(viewLightDirection, 0, cameraView, 0, LIGHT_DIRECTION, 0); normalize(viewLightDirection); GLES20.glUniform4f(lightingParametersUniform, viewLightDirection[0], viewLightDirection[1], viewLightDirection[2], lightIntensity); // Set object material properties. GLES20.glUniform4f(materialParametersUniform, ambient, diffuse, specular, specularPower); // Attach the object texture. GLES20.glActiveTexture(GLES20.GL_TEXTURE0); GLES20.glBindTexture(GLES20.GL_TEXTURE_2D, textures[0]); GLES20.glUniform1i(textureUniform, 0); . . . } Finally draw
61. public void draw(float[] cameraView, float[] cameraPerspective, float lightIntensity, float deltaTime) { // Build the ModelView and ModelViewProjection matrices for calculating object position Matrix.multiplyMM(modelViewMatrix, 0, cameraView, 0, modelMatrix, 0); Matrix.multiplyMM(modelViewProjectionMatrix, 0, cameraPerspective, 0, modelViewMatrix, 0); GLES20.glUseProgram(program); // Configure light Matrix.multiplyMV(viewLightDirection, 0, cameraView, 0, LIGHT_DIRECTION, 0); normalize(viewLightDirection); GLES20.glUniform4f(lightingParametersUniform, viewLightDirection[0], viewLightDirection[1], viewLightDirection[2], lightIntensity); // Set object material properties GLES20.glUniform4f(materialParametersUniform, ambient, diffuse, specular, specularPower); // Attach the object texture. GLES20.glActiveTexture(GLES20.GL_TEXTURE0); GLES20.glBindTexture(GLES20.GL_TEXTURE_2D, textures[0]); GLES20.glUniform1i(textureUniform, 0); . . . } Finally draw
62. Attention!!!
63. UI guidance
64. Performance don’t rely on world coordinates, use anchors > 12 anchors don’t use vibration detect a plane if available, else closest feature point 30 fps or higher lock orientation
65. private void moveActiveObject(Session session, Frame frame, MotionEvent event) { List<HitResult> hitResults = frame.hitTest(event); Anchor newAnchor = null; if (hitResults.size() > 0) { HitResult hit = hitResults.get(0); newAnchor = hit.createAnchor(); } if (newAnchor != null) { Pose cameraPose = frame.getCamera().getPose(); Pose anchorPose = newAnchor.getPose(); float distance = getDistanceBetweenPoses(cameraPose, anchorPose); if (distance > OBJ_MAX_DISTANCE) return; activeArObject.getAnchor().detach(); activeArObject.setAnchor(newAnchor); } } Distance
66. if (anchor.getTrackingState() != TrackingState.TRACKING) { //Do not draw objects } if (camera.getTrackingState() == TrackingState.PAUSED) { return; } Tracking State TRACKING PAUSED STOPPED
67. Thank you! @YuliyaKaleda
