The Object Oriented Paradigm in Perspective

Since Alan Key pioneered the object oriented paradigm in the 70s, there has been a clear evolution in how we do programming and technology . Still, the OOP is one of the most misunderstood and badly applied paradigms when it comes to real programing and computing.. Also it has been subject of controversy and multiple different explanations. Does everybody understand polymorphism in the same way?
The purpose of this talk is to understand the object oriented paradigm from another perspective and getting to the essences of what is needed to understand about OOP to properly apply the paradigm when create software.

Transcript

1. The  Object  Oriented  Paradigm  in  perspec2ve  :


   From  Plato  and  Aristotle  to  Alan  Kay..  and  beyond
   Ruben  Gonzalez  Blanco
   Nov  2013


   View Slide

2. Modeling  and  Understanding  the  World
   Philosopher     Computer  Scien2st


   View Slide

3. The  School  of  Athens  (by  Raphael)


   View Slide

4. Ideas
   Things
   Plato   Aristotle


   View Slide

5. The  Theory  of  Ideas  from  Plato
   Sensi4ve  World
   Intelligible  World
   Horse
   Idea
   Mammal
   Idea
   Instan4a4on


   View Slide

6. First  are  the  Ideas,  then  the  Things


   View Slide

7. Most  of  our  OOP  soPware  is  “Platonic”
   CLASS
   Object1   Object2   Object3
   Create  Object
   INTERFACE
   Run4me  World
   Design&Coding  World


   View Slide

8. First  the  Code,  then  the  Objects
   Interface    Shape  {
                draw(Canvas  c);
                move(int  x,  int  y);
   }
   class  Circle  implements  Shape  {
            //  a:ributes
              int  cx;
              int  cy;
              int  radius;

              //  implementa>on
              draw(Canvas  c)  {
                            c.drawEllipse(cx,cy,  r);
              }
              move(int  x,  int  y)  {
                            cx  =  cx+x;
                            cy  =cy+y
              }
              setC(int  x,  int  y)  {
                              cx=x;
                              cy=y;
              }

            setR(int  radious)  {
                              r=radious;
          }
   }
   Main()  {
          Circle  s1  =  new  Circle();
          s1.setC(100,50)
          s1.setR(20);
          Canvas  c  =  new  DefaultCanvas();
          c.addShape(s1);  //  registered  as  Shape
          c.show();
   }
   $

   a"rributes*
   memory&
   '
   '
   '
   $! # #
   draw()*implementa3on*
   %
   &



   #
   !!
   !"



   opera3ons*table*
   '
   "

   Design&  Coding  World   Run4me  World


   View Slide

9. The  Forms  Theory  from  Aristotle
   Only  1  World  =  Sensi4ve  World
   Concepts  or  Forms  =  Abstrac4ons
   Horse
   Form
   Mammal
   Form
   Abstrac4on
   (extract  the  general  from  the  par2cular)
   (in  our  minds)


   View Slide

10. First  are  the  Things,  then  the  Forms


    View Slide

11. The  Forms  are  not  separated  from  the  Things
    Horse
    Form
    Horse
    Form   Horse
    Form


    View Slide

12. Form  Theory  from  Aristotle
    Substance
    Form   Physical  Ma`er
    Accidents
    (Thing)
    (Idea)
    (thing  proper4es  varia4ons)
    •  Forms  can  have  different  levels  of  abstrac2ons
    •  Ma`er  can  disappear,  Forms  persist


    View Slide

13. OOP  and  Form  Theory
    Substance
    Form   Physical  Ma`er
    Accidents
    (Thing)
    (Idea)
    Object
    Class   “Electronic”  Ma`er
    (Object  in  the  Computer
    Memory,  processed
    by  the  CPU)
    State
    (Object  aKributes=status  varia4ons)
    Interface
    (thing  proper4es  varia4ons)
    code
    code
    (Abstrac4on)   (Abstrac4on)
    (Abstrac4on)
    Sensible  World   Run4me  World


    View Slide

14. “Aristotelic”  view  of  OOP:  What  it  really  ma`ers
    are  the  Objects
    Interface Shape {
    draw(Canvas c);
    move(int x, int y);
    }
    class Circle implements Shape {
    // a$ributes
    int cx;
    int cy;
    int radius;
    // implementa0on
    draw(Canvas c) {
    c.drawEllipse(cx,cy, r);
    }
    move(int x, int y) {
    cx = cx+x;
    cy =cy+y
    }
    setC(int x, int y) {
    cx=x;
    cy=y;
    }
    setR(int radious) {
    r=radious;
    }
    }
    draw()
    move()
    _Line_draw()
    _Line_move()
    X1=100
    Y1=100
    X2=100
    Y2=200
    draw()
    move()
    _Circle_draw()
    _Circle_move()
    Cx=80
    Cy=90
    R=50
    show()
    addShape()
    removeShape()
    _DefaultCanvas_show()
    …
    shapes=[s1]
    c1:DefaultCanvas
    onMousePressed()
    onMouseMoved()
    onMouseReleased()
    _CircleTool_onMouseReleased()
    …
    canvas=c1
    ..
    :CircleTool
    draw()
    move()
    _Circle_draw()
    _Circle_move()
    Cx=80
    Cy=90
    R=50
    draw()
    move()
    _Circle_draw()
    _Circle_move()
    Cx=80
    Cy=90
    R=50
    onMouseReleased(MouseEvent mevent) {
    //..get radious from mevent posi3on
    r = ….
    Circle circle = new Circle();
    circle.setC(x,y);
    circle.setR(r);
    // registered as Shape
    canvas.addShape(circle);
    }
    App=Run4me  World
    Design  &  Coding  World


    View Slide

15. The  OOP  concept  revisited  40  years  later
    Dr.  Alan  Kay


    View Slide

16. OOP  by  Alan  Kay
    "OOP  to  me  means  only  messaging,  local  reten4on  and  protec4on  and  hiding
    of  state-­‐process,  and  extreme  late-­‐binding  of  all  things.  It  can  be  done  in
    Smalltalk  and  in  LISP.  There  are  possibly  other  systems  in  which  this  is  possible,
    but  I'm  not  aware  of  them."  -­‐  Dr.  Alan  Kay


    View Slide

17. Objects  in  OOP  are  “like”  Cells
    I  thought  of  objects  being  like  biological  cells  and/or  individual  computers
    on  a  network,  only  able  to  communicate  with  messages  (so  messaging
    came  at  the  very  beginning  -­‐-­‐  it  took  a  while  to  see  how  to  do  messaging  in  a
    programming  language  efficiently  enough  to  be  useful).

    h`p://www.purl.org/stefan_ram/pub/doc_kay_oop_en




    View Slide

18. A  “primi2ve”  form  of  object
    h`p://www.smalltalk.org/smalltalk/TheEarlyHistoryOfSmalltalk_Abstract.html



    View Slide

19. Dr.  Alan  Kay  OOP  realiza2on  :  Smalltalk
    Smalltalk  is  a  founda2onal  programming  language  that  is  based  on  pervasive
    message  passing,  pervasive  dynamic  and  strong  typing,  pervasive  reflec4on  and
    pervasive  object  orienta4on.
    h`p://www.smalltalk.org/ar2cles/ar2cle_20100320_a3_Gekng_The_Message.html

    Smalltalk  is  one  of  the  first  object-­‐oriented  programming  languages.  Its  design  was  influenced  by  Lisp,  Logo,
    Sketchpad,  Flex  and  Simula.  Smalltalk  was  developed  as  a  research  project  at  Xerox  PARC  in  the  1970s  by  a
    team  whose  members  included  Dr.  Alan  Kay,  Dan  Ingalls,  Adele  Goldberg,  Ted  Kaehler,  [Dianna  Merry-­‐
    Shipiro],  Sco`  Wallace  and  others.


    View Slide

20. Understanding  OOP


    View Slide

21. An  Object  is  a  run4me  en4ty  that  processes
    messages  using  dynamic  binding
    Message
    Dynamic  Binding  =  Late  Binding
    Binding
    mechanism
    Message
    Object
    Message  processor  Implementa2on
    Data  A`ributes=State
    Opera2ons
    Realiza2on
    A`ributes
    Interface
    Opera2ons
    Specifica2on
    Class
    Data


    View Slide

22. Dynamic  Binding
    Message
    At  run-­‐2me
    1


    View Slide

23. Dynamic  Binding
    Message
    Binding
    mechanism
    At  run-­‐2me
    1
    2


    View Slide

24. Dynamic  Binding
    Message
    Binding
    mechanism
    Binding
    mechanism
    Message  processor  Implementa4on
    Data  A`ributes=State
    Data
    At  run-­‐2me
    1
    2
    3


    View Slide

25. Dynamic  Binding  =  Late  Binding
    Binding
    mechanism
    Message  processor  Implementa4on
    Data  A`ributes=State
    Data
    Not  Bound
    1


    View Slide

26. Dynamic  Binding  =  Late  Binding
    Binding
    mechanism
    Message  processor  Implementa4on
    Data  A`ributes=State
    Data
    Binding
    mechanism
    Message  processor  Implementa4on
    Data  A`ributes=State
    Data
    Message
    Not  Bound
    Linked  when  the  message  is  received
    1
    2
    •  Implementa2on  is  bound  in  the  last  moment
    •  (when  a  message  is  received)


    View Slide

27. The  same  object  can  change  its  implementa2on
    between  messages  recep2on
    Binding
    mechanism
    Object2
    Message  processor  Implementa2on
    Data  A`ributes=State
    Data
    Object1
    1


    View Slide

28. The  same  object  can  change  its  implementa2on
    between  messages  recep2on
    Binding
    mechanism
    Object2
    Message  processor  Implementa2on
    Data  A`ributes=State
    Data
    Binding
    mechanism
    Object2
    Message  processor  Implementa2on
    Data  A`ributes=State
    Data
    Object1
    Object1
    1
    2


    View Slide

29. An  object  can  interact  with  different
    Implementa2ons  of  the  same  interface
    Binding
    mechanism
    Object2
    Message  processor  Implementa2on
    Data  A`ributes=State
    Binding
    mechanism
    Object3
    Message  processor  Implementa2on
    Data  A`ributes=State
    Data
    Data
    Object1
    •  Same  “Interface”  and  different  implementa2on
    •  Implementa2on  can  vary  at  run2me
    •  Flexibility  =  easily  recombine  exis2ng  objects  into  new  configura2ons
    •  Extensibility  =  easily  add  new    behaviours


    View Slide

30. Polymorphism  and  Encapsula2on
    Binding
    mechanism
    Message  processor  Implementa4on
    Data  A`ributes=State
    Data
    INTERFACE  (specifica2on)
    Mul2ple  muta2ons  of  the  same  “Thing”

    Same  object  instance  with  varia2ons  in  its  implementa2on

    Same  specifica2on  (interface)  with  different  instances  realiza2ons
    IMPLEMENTATION1  (realiza2on)
    Binding
    mechanism
    Message  processor  Implementa4on
    Data  A`ributes=State
    Data
    IMPLEMENTATION2  (realiza2on)
    Hidden


    View Slide

31. The  “P”  in  OOP  is  misleading


    OOP  is    a  Computa4onal  Model  Not  a  Programming  Model
    Can  be  implemented  in  different  programming  languages


    View Slide

32. An  object  is  like  a  “virtual”  server
    OOP  should  be  equals  to    Object  Oriented  Processing


    View Slide

33. Most  of  the  “modern”  so  called  OO  languages  (C++,  Java,  …)  are
    more  focused  on  the  Programming  part  than  the  Computa2onal
    part  (the  run2me  objects)
    Interface

    Class

    Inheritance
    Messages

    Object

    Late  Binding
    Design  &  Coding  Time   Run4me  Processing
    Plato   Aristotle


    View Slide

34. How  SoPware  Objects  Would  be  like  in  our
    physical  World?
    (  just  for  adding  clarifica>on  )


    View Slide

35. How  SoPware  Objects  Would  be  like  in  our
    physical  World?    The  Post-­‐World
    a  PostBox  Object


    View Slide

36. The  Post-­‐World
    aPostboxObject
    Ann
    aPostBoxObject
    Teacher  Postbox
    (abstract  or  representa>on  box)
    slot  Interface
    How  it  is  seen  by  other  postBoxObjects
    (only  the  interface  is  seen,  not  the  implementa>on)

    As  a  Teacher  implementa>on
    Abstract  Form
    slot
    teachLesson
    Dynamic  binding


    View Slide

37. Teacher
    Student
    Robert
    Marie
    Student
    Ann   Dynamic  binding


    View Slide

38. Teacher
    Student
    Robert
    Marie
    Student
    Robert   Dynamic  binding


    View Slide

39. Teacher
    Student
    Robert
    Marie
    Student
    aTapeRecorder
    Dynamic  binding


    View Slide

40. A  C++,Java  like  “Typed”  Post-­‐World  would  be  also  possible,  but
    would  be  “less”  OO  (less  polymorphic)    and  more  complicated  to
    deal  with
    Teacher
    answerQues2on
    teachLesson
    Teacher
    aTapeRecorder  exposed/referenced
    as  a  Teacher
    TapeRecorderTeacher
    teachLesson
    answerQues2on
    play
    stop
    forward
    rewind
    aTapeRecorder  exposed/referenced    as
    TapeRecoderTeacher
    teachLesson
    answerQues2on
    play
    stop
    forward
    rewind
    concrete  slots  are  hidden
    Referenced  as  Teacher
    Teacher
    •  Type=“slots  Interface”  is  hardcoded.
    •  Different  slots  are  presented  in  different  situa2ons  (type  cas2ng)
    •  To  be  “more”  OO  polymorphic,  objects  always  try  to  present  themselves  as  the  most  abstract  type  possib


    View Slide

41. Analysis  of  the  OOP  idea  and  how  we  have
    implemented  it  during  the  past  40  years


    View Slide

42. Dynamic  Binding  is  present  in  many  places

    •  func2on  pointers  in  C  and  C++
    •  DLLs  and  Shared  Objects
    •  “CGI”  like  mechanism  in  HTTP  servers
    •  GUIs
    For  origins  of  dynamic  binding:
    “Fundamental  Concepts  in  Programming  Languages”.  CHRISTOPHER  STRACHEY  -­‐  1967


    View Slide

43. Dynamic  Binding  is  present  in  many  places
    a  basic  example  in  C

    typedef int (*foo)(int i);!
    int fooImp1(int i ) {!
    return 2*i;!
    }!
    !
    int fooImp2(int i ) {!
    return i/2;!
    }!
    !
    void doFoo(int i,foo afoo) {!
    !
    int r = afoo(i);!
    !
    printf (“result=%d\n”,r);!
    !!
    }!
    !
    int main (int argc, char** argv){!
    !
    foo myfoo = &fooImp1;!
    !
    doFoo (4, myfoo); !
    }!
    //foo  is  polymorphic
    2A10F
    memory
    …
    …
    _fooImp2(int i)
    fooImp2()  implementa2on
    …
    afoo 1A001
    1A001 _fooImp1(int i)
    fooImp1()  implementa2on
    i 4
    //sets  the  concrete  “instance”


    View Slide

44. OOP  applica2ons  are  executed  as  a  set  of
    collabora2ng  objects
    :User
    object
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp


    View Slide

45. DrawingTool+
    Selec/onTool+
    Rectangle+
    Line+
    Circle+
    Canvas+
    The  so  typical  OOP  Applica2on  example…


    View Slide

46. Anatomy  of  an  object  in  C,  C++,  Java…
    draw()
    move()
    _Circle_draw()
    _Circle_move()
    cx=100
    cy=50
    r=0
    s1:Shape
    s1:Circle
    Opera>ons
    specifica>on
    Opera>ons
    realiza>on
    a:ributes
    draw()
    move()
    s1:Shape
    How  it  is  seen  by  other  objects
    s1  referenced  as  a  Shape
    Dynamic  Binding
    s1  is  a  Circle  class  instance
    that  implements  the  Shape  interface


    View Slide

47. Anatomy  of  an  object  in  C,  C++,  Java…
    draw()
    move()
    _Circle_draw()
    _Circle_move()
    …
    cx=100
    cy=50
    r=20
    s1:Shape
    s1:Circle
    Dynamic  binding
    Interface
    Implementa>on
    data
    Opera>ons
    specifica>on
    Opera>ons
    realiza>on
    a:ributes
    Interface    Shape  {
                 draw(Canvas  c);
                 move(int  x,  int  y);
    }
    class  Circle  implements  Shape  {
             //  a:ributes
               int  cx;
               int  cy;
               int  radius;

               //  implementa>on
               draw(Canvas  c)  {
                             c.drawEllipse(cx,cy,  r);
               }
               move(int  x,  int  y)  {
                             cx  =  cx+x;
                             cy  =cy+y
               }
               setC(int  x,  int  y)  {
                               cx=x;
                               cy=y;
               }

             setR(int  radious)  {
                               r=radious;
           }
    }
    s1  Instan>a>on
    (new)
    Main()  {
           Circle  s1  =  new  Circle();
           s1.setC(100,50)
           s1.setR(20);
           Canvas  c  =  new  DefaultCanvas();
           c.addShape(s1);  //  registered  as  Shape
           c.show();
    }
    Object  s1  shown  as  “Shape”  interface  while  its
    implementa>on  is  class  “Circle”
    Instan&a&on  Code
    Defini&on  Code


    View Slide

48. A  basic  implementa2on  in  C  (not  C++)
    $

    a"rributes*
    Shape*

    memory&
    '
    '
    '
    $! # #
    draw()*implementa5on*
    %
    &



    #
    !!
    !"



    opera5ons*table*
    '
    typedef struct tShape Shape;!
    typedef struct tCanvas Canvas;!
    !
    // SHAPE INTERFACE DECLARATION!
    struct tShape {!
    void (*draw) (Shape * this, Canvas * canvas);!
    void (*move) (Shape * this , int x, int y);!
    !!
    };!
    !
    !
    // CIRCLE CLASS DECLARATION!
    !
    typedef struct tCircle Circle;!
    !
    struct tCircle {!
    void (*draw) (Circle * this, Canvas * canvas);!
    void (*move) (Circle * this, int x, int y);!
    !
    double (*circunference) (Circle * this );!
    !!
    int cx;!
    int cy;!
    int r;!
    !
    };!
    !
    // CIRCLE CLASS OPERATIONS!
    !
    void _Circle_draw(Circle * this, Canvas* canvas) {!
    // code for drawing a circle!
    }!
    !
    double _Circle_circunference(Circle * this) {!
    return 2*M_PI*this->r;!
    }!
    !
    // code for allocating a Circle in memory!
    !
    Circle * newCircle (int cx, int cy, int r) {!
    Circle * circle = malloc(sizeof(Circle));!
    !
    circle->cx = cx;!
    circle->cy = cy;!
    circle-> r= r;!
    !
    // filling function pointer members!
    !
    circle->draw = &_Circle_draw;!
    circle->move = &_Circle_move;!
    circle->circunference = &_Circle_circunference;!
    !
    return circle;!
    !
    }!
    "

    Shape**shape*
    Circle**shape*


    View Slide

49. draw()'
    move()'
    _Circle_draw()'
    _Circle_move()'
    …'
    cx=100'
    cy=50'
    r=20'
    s1:Shape'
    s1:Circle'
    show()'
    s1,s2'referenced'as'a'Shape.'
    Implementa9on'is'bound'dynamically'at'run9me.''
    Line'and'Circle'implementa9on'is'not'known'by'Canvas'object'
    show()'
    _DefaultCanvas_show()'
    …'
    shapes=
    [s1,s2]'
    c1:DefaultCanvas'
    GUI'
    OS'
    c1:Canvas'
    draw()'
    draw()'
    move()'
    _Line_draw()'
    _Line_move()'
    …'
    x0=0'
    y0=0'
    x1=20'
    y1=20'
    s2:Shape'
    s2:Line'
    draw()'
    Dynamic'binding'
    Dynamic'binding'
    Dynamic'binding'
    class%DefaultCanvas()'{'
    ''''''Shape[]'shapes;'
    '
    '''''addShape(Shape's)'{'
    ''''''''shapes.add(s);'
    ''''}'
    ''''show(){'
    '''''''for's'in'shapes'{'
    ''''''''''''s.draw(this);'
    '''''''}'
    '''}'
    }'
    Dynamic  binding  in  ac2on


    View Slide

50. Fine…But….
    Messages  are  synchronous  (like  “func2on  calls”)

    Classes  are  defined  at  coding  2me,  can  not  be
    changed  at  run2me.

    Too  much  focus  on  coding  the  Hierarchies  (aaarg..)

    No  Reflec2on  (yes  in  Java)

    Late  binding  limited  to  message  processing


    In  Java,  C++  like  languages  ,  inheritance  is  a  coding  mechanism,  for  reusing  both
    specifica2on  (interface)  and    realiza2on  (implementa2on)


    View Slide

51. Making  OOP  “survive”  in  C++,Java  like  languages


    View Slide

52. Basic  Advise  for  java,c++  like  programmers
    •  Programing  to  an  interface  not  an  Implementa4on
    •  Composi4on  and  Delega4on  over  inheritance


    View Slide

53. Basic  Advise  for  java,c++  like  programmers  I
    Interface!!Shape!{!
    !!!!!!!draw(Canvas!c);!
    !!!!!!!move(int!x,!int!y);!
    }!
    class!Circle!implements!Shape!{!
    !!!!!//!a$ributes!
    !!!!!!int!cx;!
    !!!!!!int!cy;!
    !!!!!!int!radius;!
    !!!!!!!!!!!
    !!!!!!//!implementa0on!
    !!!!!!draw(Canvas!c)!{!
    !!!!!!!!!!!!!c.drawEllipse(cx,cy,!r);!
    !!!!!!}!
    !!!!!!move(int!x,!int!y)!{!
    !!!!!!!!!!!!!cx!=!cx+x;!
    !!!!!!!!!!!!!cy!=cy+y!
    !!!!!!}!
    !!!!!!setC(int!x,!int!y)!{!
    !!!!!!!!!!!!!!cx=x;!
    !!!!!!!!!!!!!!cy=y;!
    !!!!!!}!
    !
    !!!!!setR(int!radious)!{!
    !!!!!!!!!!!!!!r=radious;!
    !!!!}!
    }!
    draw()!
    move()!
    setC()!
    setR()!
    _Circle_draw()!
    _Circle_move()!
    _Circle_setC()!
    _Circle_setR()!
    cx=100!
    cy=50!
    r=20!
    s1:Circle!
    Shape!instanceShape()!{!
    !!!!Circle!s1!=!new!Circle();!
    !!!!s1.setC(100,50)!
    !!!!s1.setR(20);!
    !!!!return!s1;!
    }!
    draw()!
    move()!
    setC()!
    setR()!
    _Circle_draw()!
    _Circle_move()!
    _Circle_setC()!
    _Circle_setR()!
    cx=100!
    cy=50!
    r=20!
    s1:Shape!
    draw()!
    move()!
    s1:Shape!
    draw()!
    How!it!is!seen!by!other!objects!
    s1!referenced!as!a!Shape!
    s1!referenced!as!a!Circle!
    Instan0a0on!
    Object!allocated!and!running!in!memory!
    Programmed!code!
    Reference  an  Object  (class  Circle)  as  its  most  abstract  form  possible  (Shape)


    View Slide

54. Basic  Advise  for  java,c++  like  programmers  II
    •  new  operator  is  hardcode
    –  Instan2a2on  should  be  encapsulated  and  done  via  scrip2ng  or  declara2ve  like    mechanisms  (xml,
    proper2es  file,  json…)
    •  Never  instan2ate  a  concrete  object  from  other  object  methods
    –  (inject  dependencies  via  abstract  refs)
    class CircleDrawingTool extends DrawingTool {
    DefaultCanvas canvas;
    CircleDrawingTool(){
    this.canvas = new DefaultCanvas();
    }
    ….
    }
    class CircleDrawingTool extends DrawingTool {
    Canvas canvas;
    CircleDrawingTool(Canvas c){
    this.canvas = c;
    }
    ….
    }
    void instantiation (File configurationFile) {
    Configuration cfg = parse(configurationFile);
    Canvas canvas;
    CircleDrawingTool ctool;
    if (cfg.property(“canvas.type”)== DEFAULT_CANVAS) {
    Canvas = new DefaultCanvas();
    //… set canvas attributes
    }
    // canvas injected through constructor
    ctool = new CircleDrawingTool(canvas)
    …
    }
    Or  se:er  injec>on


    View Slide

55. Basic  Advise  for  java,c++  like  programmers  III
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp
    collabora2on
    alloca2on
    op1()
    op2()
    op3()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a11=v1
    a12=v2
    …
    :Imp
    concrete  object   referenced  through  abstract  forms
    Circle
    Shape
    Shape
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp
    CircleDrawingTool
    Canvas
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp
    Canvas
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp
    op1()
    op2()
    …
    _class_Imp_op1()
    _class_Imp_op2()
    …
    a01=v1
    a02=v2
    …
    :Imp
    CircleDrawingTool
    dependency  injec2on
    Shape
    new
    addShape
    show
    draw
    draw
    Clearly  Separate  object  Alloca4on  and  Set  up  (aKributes,  rela4onships)  from  objects  Collabora4on  (message  passing)
    Instan4a4on   Execu4on


    View Slide

56. Basic  Advise  for  java,c++  like  programmers  IV
    •  A  switch-­‐case  by  type  (if  object  instanceof  )  it  is  a
    symptom  of  bad  polymorphic  interface-­‐class  design
    void handle(Shape* shape) {
    if (shape instanceof Circle) {
    Circle c = (Circle) shape;
    // handling a circle
    }
    else if (shape instanceof Line) {
    Line l = (Line) shape;
    // handling a line
    }
    else if …
    }
    void handle(Shape* shape) {
    shape->doHandle();
    }
    Or  more  sophis2cated  pa`ern  (i.e  Visitor,  Chain  of  Reponsabili2es)


    View Slide

57. Basic  Advise  for  java,c++  like  programmers  V
    Use  Design  PaKerns
    –  Help  you  to  have  polymorphic  designs  (Composite,  Builder,  Prototype,  Visitor,
    Chain  of  Responsibili2es,  Decorator,  Observer….)
    •  Composi4on  and  Delega4on  over  inheritance:
    –  Favor  extending  the  behavior  of  an  object  by  delega2ng  its  message  processing  to  a
    collabora2ng  object  that  are  part  of  it  (they  compose  it)

    •  Programing  to  an  interface  not  an  Implementa4on:
    –  Make  the  applica2on  work  through  a  set  of  objects  that  collaborate  between  them
    through  interfaces  or  abstrac2ons  that  hide  the  concrete  implementa2ons  or  concrete
    classes.
    h`p://www.amazon.com/Design-­‐Pa`erns-­‐Elements-­‐Reusable-­‐Object-­‐Oriented/dp/0201633612/ref=sr_1_1?s=books&ie=UTF8&qid=1383378933&sr=1-­‐1&keywords=design+pa`erns

    h`p://en.wikipedia.org/wiki/Design_Pa`erns

    Gang  of  Four
    Ward  Cunningham


    View Slide

58. Basic  Advise  for  java,c++  like  programmers  VI
    Follow  SOLID  principles  in  your  Design
    •  Single  Responsibility  Principle
    –  A  class  should  have  one,  and  only  one,  reason  to  change
    •  Open  Closed  Principle
    –  You  should  be  able  to  extend  a  classes  behavior,  without  modifying  it.  Classes  should  be  open  for
    extension,  but  closed  for  modifica2on.
    •  Liskov  Subs2tu2on  Principle
    –  Derived  classes  must  be  subs4tutable  for  their  base  classes  and  vice  versa  as  long  as  they  are  referenced
    by  the  same  abstract  interface.  The  base  abstrac2ons  must  be  really  polymorphic.
    •  Interface  Segrega2on  Principle
    –  Make  fine  grained  interfaces  that  are  client  specific.  Many  client  specific  interfaces  are  be`er  than  one
    general  purpose  interface
    •  Dependency  Inversion  Principle
    –  Depend  on  abstrac4ons,  not  on  concre4ons.  Never  have  references  or  directly  instan2ate  concrete  classes
    from  the  class  that  collaborates  with  them,  just  have  a  references  to  abstrac2ons.  Let  other  part  of  the
    program  do  the  concrete  instan2a2on  and  control  the  injec2on  of  the  dependency  object  referenced  as  an
    abstrac2on.
    h`p://butunclebob.com/Ar2cleS.UncleBob.PrinciplesOfOod
    “Uncle  Bob”  Robert  Cecil  Mar2n


    View Slide

59. But  …  (c++,  java  like  languages)
    •  S2ll  separa2on  between  Coding&Design  Time  vs
    Run2me
    –  Should  be  the  same  :  interac2ve  programming
    •  Once  classes  and  interfaces  are  “wired”  they  can  not
    be  (easily)  altered  at  run2me
    •  “Cumbersome”  and  complex  mechanisms  for
    separa2ng  instan2a2on  part  from  execu2on  part
    –  like  spring  framework,  xml  coding,  more  than  2100
    classes!!


    View Slide

60. Being  Closer  to  Alan  Kay  OOP  idea


    View Slide

61. Smalltalk  and  its  dialects
    A  dialect  of  Smalltalk  based  on  the  concept
    of  Prototypes
    Opensource  Smalltalk
    …..Only  in  academic  environments
    | myButton |!
    !
    myButton := Button new.!
    myButton label: 'press me'.!
    myButton action: [ myButton destroy ].!
    myButton open.!


    View Slide

62. JavaScript  object  model
    h`p://www.ecma-­‐interna2onal.org/publica2ons/files/ECMA-­‐ST/Ecma-­‐262.pdf

    prototype-­‐based  language
    objects  are  Associa2ve  Arrays  than  can  vary  at  run2me


    View Slide

63. Being  closer  to  OOP  Alan  Kay
    •  Objec2ve  C,  Java,  C#  provide  dynamic  mechanisms,
    most  of  them  inherited  from  smalltalk  language  and
    its  tools
    –  java.lang.reflect,  garbage  collector,  refactoring…
    @implementation GSTimeSliderCell!
    !
    - (void)stopTracking:(NSPoint)lastPoint at:(NSPoint)stopPoint inView:(NSView *)controlView mouseIsUp:(BOOL)flag!
    {!
    if (flag) {!
    [[NSNotificationCenter defaultCenter] postNotificationName:GSMouseUpNotification object:self];!
    }!
    [super stopTracking:lastPoint at:stopPoint inView:controlView mouseIsUp:flag];!
    }!
    !
    @end!


    View Slide

64. Being  closer  to  OOP  Alan  Kay
    •  Actors  model
    –  Proposed  by  by  Carl  HewiK  in  1973
    –  Actors  are  ac2ve  objects  which  communicate  by  message  passing
    •  Erlang,  Scala


    View Slide

65. Conclusions
    •  We  have  been  too  platonic  and  having  imperfect
    realiza2ons  of  the  OOP  idea
    •  We  should  try  to  be  more  aristotlelic,  focusing  on
    objects  as  message  processors  with  late  binding
    •  Be  aware  of  the  Compu2ng  Science  History
    –  Most  of  what  we  think  is  modern  was  invented  in  the  70s


    View Slide

66. END


    View Slide
