1. Android penetration testing By Abhay Kumar 1
2. Who Am I Abhay Kumar From Nalanda, Bihar Working at Castellumlabs HYD 2
3. Into to Android 3 BASED ON LINUX KERNEL IT IS OPEN-SOURCE SOFTWARE PLATFORM AND OS FOR MOBILES DEVICES ANDROID HAS ITS OWN VIRTUAL MACHINE, DVM (DALVIK VIRTUAL MACHINE), WHICH IS USED FOR EXECUTING THE ANDROID APPLICATION
4. Android Architecture 4
7. App components 7 Activity • To be simple an activity represents a single screen with a user interface. Content Provider • Content Provider component supplies data from one application to others on request. Services • A service is a component that runs in the background to perform long-running operations or to perform work for remote processes. Broadcast Receiver • A broadcast receiver is a component that responds to system-wide broadcast announcements.
8. Android Testing Requrements • Android Studio , Genymotion • ADB • Jdax • Apktool • Objection , Frida • Drozer • Db Browser for SQLite • Burp Suite 8
9. Android Debug Bridge • Android Debug Bridge (adb) is a versatile command-line tool that lets you communicate with a device. • Imp Commands Used in ADB • adb shell • adb devices • adb install • adb pull • adb push • adb forward 9
10. Drozer • Drozer allows you to search for security vulnerabilities in apps and devices by assuming the role of an app and interacting with the Dalvik VM, other apps’ Inter Process Communication(IPC) endpoints and the underlying OS. 10
11. Types of Testing in android STATIC TESTING DYNAMIC TESTING 11
12. Static Testing Reverse Engineering Leads to Source Code & Application Piravcy Insecure Application Certificate Signing Insecure Permission Requested Androidmainfest.xml Insecure Data Storage (Data/data) Data logging in log file Exploiting Debuggable Applications Component Exploitation 12
13. Reverse Engineering Testing for lack of obfuscation (reverse engineering). Checking for Application Decompilation Application build contains obsolete files Unauthorized code modification 13
14. Insecure Application Certificate Signing You can add your own certificate inside the application 14
15. Insecure Permission Requested 15
16. •Androidmainfest.xml BACKUP is set to TRUE DEBUG is set to TRUE Activities exported=true Services exported=true Broadcast Recivers exported=true content providers exported=true Search for API Key 16
17. Insecure Data Storage (Data/data) •Insecure data storage in shared preferences •insecure data storage in databases •Insecure data storage in Temporary file •Insecure data storage in sd card/ Internal Storage 17
18. Data logging in log file Adb logcat | grep ps_id of apk 18
19. Exploiting Debuggable Applications 19
20. Component Exploitation • Content providers:Path Traversal(clientside) • Directory browsing • Backing up Application Data • Data Extratction using DEBUG • Invoking Exported Activities • Invoking Exported Services • Invoking Exported Broadcast Receivers • Invoking Exported Content Providers • Intent spoofing • Intent spoofing validation bypass 20
21. Dynamic testing Application Works on Rooted Device. SSL unpining SQL Injection Cross-Site Scripting OTP Brute Force & Strength OTP Brute Force & Strength Lack of Authentication OTP Expiry. Improper Error Handling. 21
22. SSL unpining • SSL Pinning is a technique that we use in the client side to avoid man-in-the-middle attack by validating the server certificates again even after SSL handshaking. • Implementation-MITM attack( Man in the Middle Attack) or sniffing data. • Identification • Common Errors "The client failed to negotiate an SSL connection to example.com:443: Received fatal alert_certificate_unknown" 22
23. How to Do SSL unpining 23
24. Using Frida Server 24
25. Automating Static Analyis using MobSF • Mobile Security Framework (MobSF) is an automated, all-in-one mobile application (Android/iOS/Windows) pen-testing framework capable of performing static, dynamic and malware analysis. 25
26. Seting Up MoboSF • git clone https://github.com/MobSF/Mobile- Security-Framework-MobSF.git • cd Mobile-Security-Framework-MobSF • ./setup.sh • ./run.sh 127.0.0.1:8000 26
