1. ABHI S HEK J AI N MuleSoft Day4 Mule Flow
2. Agenda  Mule Flow  High Level Picture  Type of Flows  Advantages  Topic for next session  Reference
3. Mule Flow Mule applications are built around one or more flows. A Mule application begins processing a message it is received by an inbound endpoint in a flow. This flow can then either implement all processing stages, or route the message to other flows or subflows to perform specific tasks. Relative to the flow which triggered its execution, a flows and sub flows can process messages either synchronously or asynchronously Ref: https://developer.mulesoft.com/docs/display/current/Flows+and+Su bflows
4. High Level Picture Message Source Message Processor Message Processor Message Source Message Processor Message Processor
5. Type of Flows SubFlow • Process message Synchronously • Processing and Exception strategy would be of parent flow Synchronous • Similar to Subflow • Own exception handling strategy Asynchronous • Run in parallel • Separate processing and exception strategy
6. Advantages -Asynchronous flow can perform time consuming tasks -Flows can maintain their own threading and exception strategies -Break large application into small for readable perspective -Less documentation -Self Explanatory
7. Next Session Examples of Mule Flow Mule Variables
8. References  www.mulesoft.com  Mule in Action
9. Thank You
