The Web of the Future: Introduction to the Semantic Web - Bulgaria PHP 2019

Arnout Boks
November 09, 2019

The Web of the Future: Introduction to the Semantic Web - Bulgaria PHP 2019

What if we could evolve our web of individual documents and data to a web of interlinked knowledge, a web where machines can automatically combine data from multiple sources and draw conclusions from it? The Semantic Web technologies from W3C enable us to make sense of the data wilderness on the web and unlock the full potential of the data treasures hidden in it.

In this talk, we will see how RDF enables us to formally describe the meaning of data and how such data can be queried with SPARQL. We will look at how OWL lets us make more expressive statements about the world, so that a computer can logically reason about it and infer new information. We will demonstrate these technologies by showing how they can be used to query seemingly incompatible data sets as if they were one and letting a computer draw logical (and perhaps surprising) conclusions for us.

Contains: ‘retro’ technology, linked data, fundamental properties of the web, and Donald Trump’s opinion on PHP frameworks.

Arnout Boks

November 09, 2019
Tweet

More Decks by Arnout Boks

Other Decks in Technology

Transcript

  1. The Web of the Future:
    Introduction to the Semantic Web
    @arnoutboks
    Arnout Boks
    #bgphp19
    09-11-2019

    View Slide

  2. @arnoutboks #bgphp19
    What this talk is NOT about…

    View Slide

  3. @arnoutboks #bgphp19
    Finding info on the web
    An example

    View Slide

  4. @arnoutboks #bgphp19
    “Web 1.0”

    View Slide

  5. @arnoutboks #bgphp19
    “Web 1.0”

    View Slide

  6. @arnoutboks #bgphp19
    “Web 1.0”

    View Slide

  7. @arnoutboks #bgphp19
    Web 1.0
    Web of Documents
    for human consumption

    View Slide

  8. @arnoutboks #bgphp19
    “Web 2.0”
    Feed of events
    • iCalendar or vCalendar?
    • Different types of events?

    View Slide

  9. @arnoutboks #bgphp19
    “Web 2.0”
    Weather forecast API
    • XML or JSON?
    • Which fields and properties?
    • Which units?

    View Slide

  10. @arnoutboks #bgphp19
    Web 2.0
    Web of (individual) API’s
    for consumption by
    specialized software

    View Slide

  11. @arnoutboks #bgphp19
    Semantic web
    • Question to agent (e.g. Siri, Google Assistant)
    • Agent searches across different sources
    • Agent combines data
    • Agent answers question

    View Slide

  12. @arnoutboks #bgphp19
    Semantic Web
    (“Web 3.0”?)
    Web of Linked Data
    for consumption by
    intelligent agents/PA’s

    View Slide

  13. @arnoutboks #bgphp19
    Revolutionary?
    Term coined by Tim Berners-Lee in 2001

    View Slide

  14. @arnoutboks #bgphp19
    Revolutionary?
    Based on W3C-standards
    • RDF (1998)
    • RDFS (1998)
    • SPARQL (2008)
    • OWL (2004)
    • …

    View Slide

  15. @arnoutboks #bgphp19
    RDF
    Cornerstone of the Semantic Web
    Resource Description Framework
    Cornerstone of the Semantic Web

    View Slide

  16. @arnoutboks #bgphp19
    Records statements
    about things

    View Slide

  17. @arnoutboks #bgphp19
    RDF allows
    reading, merging, relaying
    and inferring statements
    without fully understanding them

    View Slide

  18. @arnoutboks #bgphp19
    RDF (triples)
    Subject Predicate Object

    View Slide

  19. @arnoutboks #bgphp19
    RDF (triples)
    Subject Predicate Object
    Arnout worksAt Moxio

    View Slide

  20. @arnoutboks #bgphp19
    RDF (triples)
    Subject Predicate Object
    Arnout worksAt Moxio
    Arnout twitterHandle “@arnoutboks”
    Arnout livesIn Delft
    Delft cityIn The Netherlands
    Moxio basedIn Delft

    View Slide

  21. @arnoutboks #bgphp19
    RDF (graph)
    Arnout Moxio
    Delft
    @arnoutboks
    worksAt
    basedIn
    The
    Netherlands
    Subject Predicate Object
    Arnout worksAt Moxio
    Arnout twitterHandle “@arnoutboks”
    Arnout livesIn Delft
    Delft cityIn The Netherlands
    Moxio basedIn Delft

    View Slide

  22. @arnoutboks #bgphp19
    Merging RDF (triples)
    Subject Predicate Object
    Arnout worksAt Moxio
    Arnout twitterHandle “@arnoutboks”
    Arnout livesIn Delft
    Delft cityIn The Netherlands
    Moxio basedIn Delft
    Subject Predicate Object
    The Netherlands hasCapital Amsterdam
    The Netherlands population “17.000.000”

    View Slide

  23. @arnoutboks #bgphp19
    Merging RDF (triples)
    Subject Predicate Object
    Arnout worksAt Moxio
    Arnout twitterHandle “@arnoutboks”
    Arnout livesIn Delft
    Delft cityIn The Netherlands
    Moxio basedIn Delft
    The Netherlands hasCapital Amsterdam
    The Netherlands population “17.000.000”

    View Slide

  24. @arnoutboks #bgphp19
    Merging RDF (graph)
    Arnout Moxio
    Delft
    @arnoutboks
    worksAt
    basedIn
    The
    Netherlands
    Amsterdam
    hasCapital
    17.000.000
    population

    View Slide

  25. @arnoutboks #bgphp19
    Serializing RDF: Turtle
    @prefix : .
    @prefix rdf: ns#> .
    @prefix xsd: .
    @base .
    :Arnout :livesIn :Delft ;
    :worksAt :Moxio ;
    :twitterHandle "@arnoutboks"^^xsd:string .
    :Delft :cityIn :The_Netherlands .
    :Moxio :basedIn :Delft .

    View Slide

  26. @arnoutboks #bgphp19
    Serializing RDF: RDF/XML

    >
    rdf:about="http://www.example.com/#Arnout">
    rdf:datatype="http://www.w3.org/2001/XMLSchema#string">@a
    rnoutboks
    rdf:resource="http://www.example.com/#Moxio"/>
    rdf:resource="http://www.example.com/#Delft"/>



    View Slide

  27. @arnoutboks #bgphp19
    Serializing RDF: JSON-LD
    [ {
    "@id" : "http://www.example.com/#Arnout",
    "http://www.example.com/#livesIn" : [ {
    "@id" : "http://www.example.com/#Delft"
    } ],
    "http://www.example.com/#twitterHandle" : [ {
    "@value" : "@arnoutboks"
    } ],
    "http://www.example.com/#worksAt" : [ {
    "@id" : "http://www.example.com/#Moxio"
    } ]
    }, ... ]

    View Slide

  28. @arnoutboks #bgphp19
    RDF is an abstract
    data model
    with different serialization formats

    View Slide

  29. @arnoutboks #bgphp19
    Identity
    Because there are multiple things named “Amsterdam”

    View Slide

  30. @arnoutboks #bgphp19
    Identity
    Subject Predicate Object
    Amsterdam numberOfGuns “42”
    Amsterdam status Wrecked
    National Maritime Museum (“Scheepvaartmuseum”)

    View Slide

  31. @arnoutboks #bgphp19
    Identity
    Subject Predicate Object
    Amsterdam numberOfGuns “42”
    Amsterdam status Wrecked
    Subject Predicate Object
    The Netherlands hasCapital Amsterdam
    The Netherlands population “17.000.000”
    National Maritime Museum (“Scheepvaartmuseum”)
    Lonely Planet

    View Slide

  32. @arnoutboks #bgphp19
    Identity
    The
    Netherlands
    Amsterdam
    hasCapital
    17.000.000
    population
    42
    Wrecked

    View Slide

  33. @arnoutboks #bgphp19
    URI’s for namespacing
    National Maritime Museum (“Scheepvaartmuseum”)
    https://www.hetscheepvaartmuseum.nl/ships/Amsterdam
    https://www.hetscheepvaartmuseum.nl/ships/numberOfGuns
    Lonely Planet
    https://www.lonelyplanet.com/Amsterdam
    https://www.lonelyplanet.com/hasCapital

    View Slide

  34. @arnoutboks #bgphp19
    Prefixes & QNames
    lonelyplanet:Amsterdam
    ===
    https://www.lonelyplanet.com/Amsterdam
    QName
    URI
    local name
    local name
    namespace
    prefix

    View Slide

  35. @arnoutboks #bgphp19
    Prefixes & QNames
    National Maritime Museum (“Scheepvaartmuseum”)
    nmm:Amsterdam
    nmm:numberOfGuns
    Lonely Planet
    lonelyplanet:Amsterdam
    lonelyplanet:hasCapital

    View Slide

  36. @arnoutboks #bgphp19
    Three fundamental laws
    of the (Semantic) Web

    View Slide

  37. @arnoutboks #bgphp19
    Different name, different concept?
    lonelyplanet-en:Brussels
    lonelyplanet-nl:Brussel
    lonelyplanet-bg:Брюксел
    lonelyplanet-zh:布魯塞爾

    View Slide

  38. @arnoutboks #bgphp19
    Different name, different concept?
    mi6:007
    mi6:JamesBond

    View Slide

  39. @arnoutboks #bgphp19
    Nonunique Naming Assumption
    Different names do not
    imply different concepts

    View Slide

  40. @arnoutboks #bgphp19
    Truth & authority
    Subject Predicate Object
    whitehouse:Obama nsa:tapped whitehouse:Trump
    Donald Trump

    View Slide

  41. @arnoutboks #bgphp19
    Truth & authority
    Subject Predicate Object
    php-fig:CakePHP fw:isBetterThan php-fig:Symfony
    Donald Trump

    View Slide

  42. @arnoutboks #bgphp19
    The AAA Slogan
    “[On the web] Anyone can say
    Anything about Any topic”

    View Slide

  43. @arnoutboks #bgphp19
    (this slide intentionally left blank)

    View Slide

  44. @arnoutboks #bgphp19
    Absence of information
    Subject Predicate Object
    whitehouse:Trump fw:knows php-fig:Symfony
    whitehouse:Trump fw:knows php-fig:CakePHP
    whitehouse:Trump fw:knows php-fig:CodeIgniter

    View Slide

  45. @arnoutboks #bgphp19
    Open World Assumption
    We never have all information

    View Slide

  46. @arnoutboks #bgphp19
    SPARQL
    Query language for Semantic Web data

    View Slide

  47. @arnoutboks #bgphp19
    Triple Store
    Database for RDF triples

    View Slide

  48. @arnoutboks #bgphp19
    SPARQL
    SELECT ?employee ?company
    WHERE {
    ?employee :worksAt ?company .
    ?company :basedIn :Delft .
    }

    View Slide

  49. @arnoutboks #bgphp19
    SPARQL
    SELECT ?employee ?company
    WHERE {
    ?employee :worksAt ?company .
    ?company :basedIn :Delft .
    }
    ?employee ?company
    :Arnout :Moxio

    View Slide

  50. @arnoutboks #bgphp19
    SPARQL
    SELECT ?employee ?company ?city
    WHERE {
    ?employee :worksAt ?company .
    ?company :basedIn ?city .
    ?employee :livesIn ?city .
    }
    ?employee ?company ?city
    :Arnout :Moxio :Delft

    View Slide

  51. @arnoutboks #bgphp19
    Online SPARQL endpoints
    http://dbpedia.org/sparql

    View Slide

  52. @arnoutboks #bgphp19
    Online SPARQL endpoints

    View Slide

  53. @arnoutboks #bgphp19
    Online SPARQL endpoints
    PREFIX dbo:
    PREFIX dbr:
    SELECT ?song ?runtime
    WHERE {
    ?song dbo:artist dbr:The_Beatles .
    ?song dbo:runtime ?runtime .
    ?song rdf:type dbo:Song .
    } ORDER BY DESC (?runtime)

    View Slide

  54. @arnoutboks #bgphp19
    Online SPARQL endpoints

    View Slide

  55. @arnoutboks #bgphp19
    Online SPARQL endpoints
    PREFIX dbo:
    PREFIX dbr:
    SELECT ?ancestor
    WHERE {
    dbr:Willem-Alexander_of_the_Netherlands
    dbo:parent+ ?ancestor .
    }

    View Slide

  56. @arnoutboks #bgphp19
    RDF Schema
    Schema language for Semantic Web data

    View Slide

  57. @arnoutboks #bgphp19
    RDF Schema (RDFS)
    Describes the structure of RDF-data… in RDF
    • Classes
    • Properties
    • Domain and range of properties
    • Inheritance of classes
    • ‘Inheritance’ of properties

    View Slide

  58. @arnoutboks #bgphp19
    RDF Schema (RDFS)
    Subject Predicate Object
    :DonaldTrump :isFatherOf :IvankaTrump

    View Slide

  59. @arnoutboks #bgphp19
    RDF Schema (RDFS)
    Subject Predicate Object
    :DonaldTrump :isFatherOf :IvankaTrump
    :isFatherOf rdfs:range :Person
    :isFatherOf rdfs:domain :Father
    :Father rdfs:subclassOf :Parent
    :Parent rdfs:subclassOf :Person
    :isFatherOf rdfs:subpropertyOf :isParentOf

    View Slide

  60. @arnoutboks #bgphp19
    RDF Schema & Inference
    Subject Predicate Object
    :DonaldTrump :isFatherOf :IvankaTrump
    :isFatherOf rdfs:range :Person
    :isFatherOf rdfs:domain :Father
    :Father rdfs:subclassOf :Parent
    :Parent rdfs:subclassOf :Person
    :isFatherOf rdfs:subpropertyOf :isParentOf
    :IvankaTrump rdf:type :Person
    :DonaldTrump rdf:type :Father
    :DonaldTrump rdf:type :Parent
    :DonaldTrump rdf:type :Person
    :DonaldTrump :isParentOf :IvankaTrump

    View Slide

  61. @arnoutboks #bgphp19
    Inference
    Reasoner
    (asserted) triples
    inferred/virtual triples

    View Slide

  62. @arnoutboks #bgphp19
    Inference
    Reasoner
    (asserted) triples
    inferred/virtual triples

    View Slide

  63. @arnoutboks #bgphp19
    SPARQL & Inference
    SELECT ?person
    WHERE { ?person rdf:type :Person . }
    ?person
    :IvankaTrump
    :DonaldTrump

    View Slide

  64. @arnoutboks #bgphp19
    Combining data using inference
    Subject Predicate Object
    a:DonaldTrump rdf:type a:Person
    Datasource A
    Subject Predicate Object
    b:MelaniaTrump rdf:type b:Human
    Datasource B

    View Slide

  65. @arnoutboks #bgphp19
    Combining data using inference
    Subject Predicate Object
    a:DonaldTrump rdf:type a:Person
    Datasource A
    Subject Predicate Object
    b:MelaniaTrump rdf:type b:Human
    Datasource B
    Subject Predicate Object
    a:Person rdfs:subclassOf b:Human
    b:Human rdfs:subclassOf a:Person
    Mapping rules

    View Slide

  66. @arnoutboks #bgphp19
    Combining data using inference
    Subject Predicate Object
    a:DonaldTrump rdf:type a:Person
    b:MelaniaTrump rdf:type b:Human
    a:Person rdfs:subclassOf b:Human
    b:Human rdfs:subclassOf a:Person
    a:DonaldTrump rdf:type b:Human
    b:MelaniaTrump rdf:type a:Person

    View Slide

  67. @arnoutboks #bgphp19
    Query different sources
    as if they were one

    View Slide

  68. @arnoutboks #bgphp19
    RDF Schema vs. JSON/XML Schema
    Subject Predicate Object
    mi6:JamesBond rdf:type mi6:SecretAgent
    mi6:JamesBond nmm:numberOfGuns “1”
    MI6 files

    View Slide

  69. @arnoutboks #bgphp19
    RDF Schema vs. JSON/XML Schema
    Subject Predicate Object
    mi6:JamesBond rdf:type mi6:SecretAgent
    mi6:JamesBond nmm:numberOfGuns “1”
    MI6 files

    View Slide

  70. @arnoutboks #bgphp19
    RDF Schema vs. JSON/XML Schema
    Subject Predicate Object
    mi6:JamesBond rdf:type mi6:SecretAgent
    mi6:JamesBond nmm:numberOfGuns “1”
    MI6 files
    Subject Predicate Object
    nmm:numberOfGuns rdf:domain nmm:Ship
    National Maritime Museum (“Scheepvaartmuseum”)

    View Slide

  71. @arnoutboks #bgphp19
    RDF Schema vs. JSON/XML Schema
    Subject Predicate Object
    mi6:JamesBond rdf:type mi6:SecretAgent
    mi6:JamesBond nmm:numberOfGuns “1”
    nmm:numberOfGuns rdf:domain nmm:Ship
    mi6:JamesBond rdf:type nmm:Ship

    View Slide

  72. @arnoutboks #bgphp19
    RDF Schema vs. JSON/XML Schema

    View Slide

  73. @arnoutboks #bgphp19
    RDF Schema will never
    consider data to be invalid

    View Slide

  74. @arnoutboks #bgphp19
    Web Ontology Language (OWL)
    Even smarter inferencing
    Web Ontology Language (OWL)
    Even smarter inferencing

    View Slide

  75. @arnoutboks #bgphp19
    OWL
    OWL ≈ RDFS++

    View Slide

  76. @arnoutboks #bgphp19
    OWL
    Power comes at a price…

    View Slide

  77. @arnoutboks #bgphp19
    OWL: Inverse properties
    Subject Predicate Object
    :DonaldTrump :isParentOf :IvankaTrump
    :isParentOf owl:inverseOf :isChildOf
    :IvankaTrump :isChildOf :DonaldTrump

    View Slide

  78. @arnoutboks #bgphp19
    OWL: Symmetric properties
    Subject Predicate Object
    :DonaldTrump :isMarriedTo :MelaniaTrump
    :isMarriedTo rdf:type owl:SymmetricProperty
    :MelaniaTrump :isMarriedTo :DonaldTrump

    View Slide

  79. @arnoutboks #bgphp19
    OWL: Equality
    Subject Predicate Object
    :DonaldTrump :isMarriedTo :MelaniaTrump
    :DonaldTrump owl:sameAs :TheDon
    :TheDon :isMarriedTo :MelaniaTrump

    View Slide

  80. @arnoutboks #bgphp19
    OWL: Functional properties
    Subject Predicate Object
    :IvankaTrump :hasFather :DonaldTrump
    :IvankaTrump :hasFather :TheDon
    :hasFather rdf:type owl:FunctionalProperty
    :TheDon owl:sameAs :DonaldTrump

    View Slide

  81. @arnoutboks #bgphp19
    Inconsistency
    Subject Predicate Object
    :IvankaTrump :hasFather :DonaldTrump
    :IvankaTrump :hasFather :TheDon
    :hasFather rdf:type owl:FunctionalProperty
    :TheDon owl:differentFrom :DonaldTrump

    View Slide

  82. @arnoutboks #bgphp19
    Inconsistency

    View Slide

  83. @arnoutboks #bgphp19
    Inconsistency

    View Slide

  84. @arnoutboks #bgphp19
    It’s okay to be inconsistent…
    (remember the AAA slogan)

    View Slide

  85. @arnoutboks #bgphp19
    It’s okay to be inconsistent…
    (remember the AAA slogan)
    …but the reasoner won’t
    help you anymore

    View Slide

  86. @arnoutboks #bgphp19
    Self-test
    Subject Predicate Object
    :George :hasChild :Michelle
    :George :hasChild :James
    How many children does George have?

    View Slide

  87. @arnoutboks #bgphp19
    Further steps
    Get going with the Semantic Web

    View Slide

  88. @arnoutboks #bgphp19
    Leveraging the Semantic Web
    Network effect

    View Slide

  89. @arnoutboks #bgphp19
    Leveraging the Semantic Web
    Only useful when multiple parties
    speak the same ‘language’

    View Slide

  90. @arnoutboks #bgphp19
    Align with existing
    vocabularies

    View Slide

  91. @arnoutboks #bgphp19
    Leveraging the Semantic Web
    Mapping between vocabularies:
    • rdfs:subclassOf
    • rdfs:subpropertyOf
    • owl:inverseOf
    • owl:sameAs

    View Slide

  92. @arnoutboks #bgphp19
    Existing vocabularies
    • Dublin Core
    • Metadata about publications and authors
    • Friend of a Friend
    • People, connections, social networks
    • GoodRelations
    • Products, prices, eCommerce
    • CB-NL
    • Construction, infrastructure, spatial planning
    • QUDT
    • Quantities, units, dimensions, conversions

    View Slide

  93. @arnoutboks #bgphp19
    Resources
    • Apache Jena (includes Fuseki triple store)
    • Semantic web framework/tools (written in Java)
    • easyrdf/easyrdf
    • RDF parser/writer for PHP
    • semsol/arc2
    • PHP RDF library and MySQL-based triple store
    • FaCT++, HermiT & Pellet
    • Open source OWL reasoners
    • Protégé
    • RDF/OWL IDE with various reasoner plugins

    View Slide

  94. @arnoutboks #bgphp19
    Resources

    View Slide

  95. @arnoutboks #bgphp19
    Resources
    • https://www.w3.org/2013/data/
    • https://www.w3.org/2001/sw/wiki/
    • https://www.w3.org/TR/rdf11-primer/
    • https://www.w3.org/TR/owl2-primer/
    • https://www.w3.org/TR/sparql11-query/
    • http://wiki.dbpedia.org/OnlineAccess
    • https://www.data.gov/
    • http://lod-cloud.net/

    View Slide

  96. @arnoutboks #bgphp19
    Feedback & Questions
    Please leave your feedback on joind.in:
    https://joind.in/talk/de222
    @arnoutboks
    https://aboks.github.io
    Arnout Boks

    View Slide

  97. @arnoutboks #bgphp19
    Image Credits
    • https://www.flickr.com/photos/lex-photographic/32521124574
    • https://www.flickr.com/photos/rwoan/34676675925
    • https://www.flickr.com/photos/littlehuw/15236543728
    • https://www.flickr.com/photos/crdominguez/422517106
    • https://www.flickr.com/photos/pamwood707/5646757752
    • https://www.flickr.com/photos/blair25/3240686470
    • https://www.flickr.com/photos/tylerbeaulawrence/15167523690
    • https://www.flickr.com/photos/23975018@N04/3675503072
    • https://pixabay.com/nl/nuance-stalen-kleur-pantone-1074766/
    • https://www.flickr.com/photos/borkurdotnet/9682277597

    View Slide
