Speed at Scale: Web Performance Tips and Tricks from the Trenches

Getting your site fast and keeping it fast can be a challenge at scale. Learn 15 tips and tricks that real, production sites use to get great scores on Lighthouse and improve core business metrics. Understand a spectrum of optimizations from latency optimization to JavaScript, preloading, prefetching, data-fetching, and more.

This talk is from Google I/O 2019: https://events.google.com/io/schedule/events/9888b5c4-33eb-42d7-97c8-4cef89f20b98

Transcript

1. Speed at Scale
   WebPerf Tips & Tricks From The Trenches
   2019
   Google I/O
   Katie Hempenius
   @katiehempenius
   Addy Osmani
   @addyosmani


   View Slide

2. View Slide

3. addEventListener('')


   View Slide

4. Interactivity impacts rage clicks
   Based on Akamai’s 2018 research into UX & Metrics that matter


   View Slide

5. Page Weight Percentiles


   View Slide

6. Sending too much to the browser


   View Slide

7. Proprietary + Confidential
   Source: Lorem ipsum dolor sit amet, consectetur adipiscing elit. Duis non erat sem
   Delightful user experiences can be found everywhere


   View Slide

8. Performance Budgets


   View Slide

9. Cleaning up your
   site 6 months in


   View Slide

10. 40% of brands regress
    on web performance
    after 6 months.
    Internal Google study into Web Performance investments by large brands.


    View Slide

11. Performance budgets
    set standards for the
    performance of your
    site.


    View Slide

12. Time
    < 2 second TTI
    KB KB
    Resources
    < 150KB JS
    Lighthouse
    90+ Perf Score


    View Slide

13. Catch issues before they ship
    “Checking the size of our builds ensures
    that we don’t miss potential
    performance issues. For example, this
    has caught dependencies being added
    unnecessarily. Since the PR was blocked,
    we were able to pinpoint the issue and fix
    it before it impacted our build."
    “By setting a budget for tracking, and
    reporting build size deltas, we've prevented
    changes that would have increased
    metrics like TTI, TTFMC and Time to First
    Tweet by over 100%.”
    Paul Armstrong, Twitter
    Jeff McRiffey, Walmart eCommerce


    View Slide

14. Job checks and logs
    the size of all builds.
    PRs fail if size
    increases by > 1%
    (main bundles only)
    Issues are escalated
    to a performance
    engineer.
    > node bundle-check.js
    +4.4% - discoveryJS
    +0.0% - discoveryCSS
    +0.0% - coreJS
    -0.0% - checkoutJS
    +0.0% - checkoutCSS


    View Slide

15. Build tracker comments
    on PRs with a detailed
    breakdown of changes.
    Build tracker logs the size
    of all production builds.
    Engineers use this info
    when reviewing PRs.


    View Slide

16. Performance budget tooling for Lighthouse
    bit.ly/lightwallet-docs
    LightWallet


    View Slide

17. 1. Add a budget.json file
    2. Run Lighthouse 5.0+ from the CLI
    $ lighthouse https://example.com --budgetPath ./budget.json
    LightWallet bit.ly/lightwallet-docs


    View Slide

18. LightWallet bit.ly/lightwallet-docs


    View Slide

19. [{
    "resourceSizes": [
    {
    "resourceType": "image",
    "budget": 250
    },
    {
    "resourceType": "script",
    "budget": 125
    },
    {
    "resourceType": "font",
    "budget": 30
    },
    {
    "resourceType": "document",
    "budget": 25
    },
    {
    "resourceType": "stylesheet",
    "budget": 5
    },
    {
    "resourceType": "third-party",
    "budget": 400
    }
    ]
    }];
    budget.json
    Budget types:
    ● Resource Sizes
    ● Resource
    Counts


    View Slide

20. 750KB
    3.5 MB
    JavaScript
    Other
    Time to Interactive of 3.9 million mobile sites
    Median: 8.9 seconds
    Data source: HTTP Archive


    View Slide

21. f(JS
    KB,
    Non-JS
    KB
    ) →TTI
    bit.ly/perf-budget-calculator
    Performance
    Budget
    Calculator


    View Slide

22. 4.1s
    Range:
    3.2-5.1s
    5.1s
    Range:
    4.1-6.4s
    6s
    Range:
    4.8-7.5s
    100 KB JS 200 KB JS 300 KB JS
    300 KB other
    300 KB other
    300 KB other
    bit.ly/perf-budget-calculator


    View Slide

23. Image CDN
    Lazy-loading Responsive
    Images


    View Slide

24. Lazy Loading


    View Slide

25. Am I a joke to you?
    Data Plan
    5MB
    Images a page
    ~4.7MB images at P90 from HTTP Archive


    View Slide

26. Lazy-load
    offscreen images
    Eager Loading
    Load images right away
    Lazy Loading
    Load (offscreen) images on-demand
    2MB 1MB
    Potential Savings
    3MB (P90) and 416KB (Median)


    View Slide

27.

    Solid Color 1KB 13KB
    Progressive image loading
    LQIP (Low-quality placeholder)
    Lazy-loading images with JS
    Common


    View Slide

28. Optimizing
    Chrome.com Faster page load times
    (mobile)
    20%
    Faster page load times
    (desktop - Windows)
    26%
    chrome.com
    Credits:
    Vitaly Keyzla (Dev Lead, Infra) Wei-Hsin Chen (Senior
    Eng/Lead) Luis Villalba (Senior Eng/Lead) Felipe Angel (Eng)
    Cristian Perez (QA) Katia Pena (QA Lead) Luis Jimenez
    (Director QA) Neil Shankar (UI Designer) Melissa Castano
    (Senior UI Designer) Esteban Lobo Guerrero (UI/UX
    Designer) McKenzy Germain (Web Product Manager) Kevin
    Furuichi (Android/Chrome Program Manager) Adam
    Dunlavey (Senior Web Analyst)


    View Slide

29. Lazy-Load
    Offscreen Images
    Fewer Image Bytes Loaded
    Upfront
    46%
    Chrome.com lazy-loads offscreen
    images. They use an SVG placeholder
    with image dimensions to avoid
    reflow. Their custom JS lazy-loader
    leverages Intersection Observer.


    View Slide

30. Lazy-load offscreen images Defer render until decode
    Before After
    Initial state Final state
    Or download if img.decode() unsupported


    View Slide

31. View Preview Experience


    View Slide

32. View Slide

33. Page load from server Page load after auto-loading
    all rows


    View Slide

34. Optimized
    CPU load, memory
    & network traffic
    Images
    4.4MB
    Images
    1.2MB
    Full Page Load Initial Page State
    ...leading to faster start
    times for video previews.
    DOM Nodes
    11,744
    Memory
    45MB
    DOM Nodes
    650
    Memory
    8MB
    bit.ly/netflix-previews


    View Slide

35. 46%
    Image Byte Savings
    After switching to image lazy-loading
    72%
    94%
    76%
    90%
    78%


    View Slide

36. View Slide

37. Introducing
    native image
    lazy-loading!

    Eager Loading

    Lazy Loading

    2MB 1MB
    chrome://flags/#enable-lazy-image-loading


    View Slide

38. Introducing
    native iframe
    lazy-loading!

    Eager Loading

    Lazy Loading

    3MB
    iframe
    0MB
    iframe
    chrome://flags/#enable-lazy-frame-loading


    View Slide

39. bit.ly/native-lazyload


    View Slide

40.




    <br/>if ('loading' in HTMLImageElement.prototype) {<br/>const images = document.querySelectorAll("img.lazyload");<br/>images.forEach(img => {<br/>img.src = img.dataset.src;<br/>});<br/>} else {<br/>// Dynamically load the lazysizes library<br/>let script = document.createElement("script");<br/>script.src = "/lazysizes.min.js";<br/>document.body.appendChild(script);<br/>}<br/>
    Cross-browser
    Image lazy-loading
    Feature Detection
    JS library fallback


    View Slide

41. Responsive Images


    View Slide

42. 101 KB 299 KB
    vs.
    Images for desktop & tablet can be
    ~2-4x larger than the mobile version.


    View Slide

43. By width By density
    srcset="cat-1x.jpg 1x,
    cat-2x.jpg 2x,
    cat-3x.jpg 3x">
    srcset="cat-240.jpg 240w,
    cat-480.jpg 480w
    cat-960.jpg 960w>
    Responsive Images
    Width descriptor
    w ≈ px
    window.devicePixelRatio
    Defines the relationship between
    device pixels and CSS pixels for a
    particular device.


    View Slide

44. Pixel density
    ● Limits image pixel density to <= 2x
    ● Exception: full-screen images
    where users can pinch zoom.
    33% decrease
    in image size
    1x 2x 3x
    Result:
    No distinguishable
    difference to the
    human eye.
    4x


    View Slide

45. Images CDNs


    View Slide

46. Successful image
    Optimizations


    View Slide

47. Image CDN
    images
    fancy


    View Slide

48. Popular Image CDNs
    Akamai Image Manager | Cloudinary | Imgix | Thumbor (self-hosted)
    ...cat.jpg?q=50&w=300&h=200
    Set quality level to 50 Resize to 300x200


    View Slide

49. Image CDNs
    "We realized that maintaining an inhouse image
    optimization solution would be enough work
    for a dedicated team. By using an Image
    CDN, our engineers can focus on our core
    business while our users benefit from fast,
    good-looking images across all devices &
    networks."
    Tobias Baldauf, Trivago


    View Slide

50. Image CDNs
    ● Auto quality
    ● Auto cropping
    ● WebP
    ● Color channel tuning
    Decrease in
    image size (KB)
    80%


    View Slide

51. 40%
    50%
    40-60%
    71%
    80%
    Image Byte
    Savings
    After switching
    to an image CDN


    View Slide

52. Code-Splitting
    Defer Third-Party
    Embeds
    Expensive
    Libraries
    JavaScript


    View Slide

53. Defer Third-Party
    JavaScript & Embeds


    View Slide

54. 57%
    Patrick Hulce, thirdpartyweb.today. Data from across top 4M sites.
    57%
    JavaScript execution time on
    the web is third-party code


    View Slide

55. How’s your JavaScript diet going?
    Me:
    @StumberVideos


    View Slide

56. Gareth Clubb
    Everyone wants ‘that tag’ on a page that
    will make the organisation money. It’s very
    important to get the right individuals in a
    room to educate, challenge and work
    together.
    Create a Performance Culture


    View Slide

57. Third-party JS
    2s 5s
    bit.ly/telegraph-3p
    Defer
    <br/><script defer><br/>bit.ly/telegraph-3p<br/>“Our biggest improvement was<br/>deferring all JS, including our own”<br/>“...this didn’t skew analytics<br/>or advertising. Lighthouse Perf +47”<br/>Other optimizations<br/>1MB reduction 1st & 3p JS<br/>4s faster “first ad” loading<br/>6s faster Time-to-Interactive<br/>

    View Slide

58. When load times decreased 71%,
    bounce rates decreased 31%
    Faster Page
    Load Times
    78%
    Decrease in
    Bounce Rates
    31%
    Mobile CVR
    Increase
    11%
    tui.se


    View Slide

59. Before After
    Defer Google Tag Manager
    Custom Third-Party
    Replace A/B Testing Library
    50% Reduction domComplete 100KB JS shaved from homepage


    View Slide

60. Loading third-party embeds eagerly has a cost
    Chrome.com’s Time to Interactive was 13.6s


    View Slide

61. Lazy-load
    Third-Party Embeds
    Lighthouse Performance
    Score (27 to 96)
    +69
    chrome.com
    Reduction in Time to
    Interactive (13.6s to 3.1s)
    10s
    Smaller JavaScript Payload
    511KB
    Before
    After
    Eagerly load YouTube embeds on
    page load.
    Lazy-load YouTube embeds on user
    interaction.


    View Slide

62. Remove expensive
    libraries


    View Slide

63. Remove expensive libraries
    There are other options too:
    ● Deprecate
    ● Replace
    ● Defer
    ● Update
    moment.js
    Bootstrap
    jQuery


    View Slide

64. lodash → lodash-es
    momentjs → date-fns
    fetch → fetch-unfetch
    async → async-es
    babel-preset-es2015 →babel-preset-env
    Replace expensive libraries
    The one function
    you care about
    Importing entire module


    View Slide

65. Defer
    dependencies
    ● Tokopedia serves a “lite”
    version of their app to new
    users.
    ● Lite version uses Svelte;
    service workers precache
    their React app in the
    background.
    React Version Svelte Version
    vs
    320 KB 37 KB
    JavaScript required to render above-the-fold content


    View Slide

66. lit-html, Preact, & Svelte


    View Slide

67. Update
    dependencies Improvement in load time
    100ms
    Uplift in revenue per session
    0.7%
    ● Zalando noticed that an
    older React version was
    impacting load times.
    ● Updated from React 15.6.1
    to 16.2.0.


    View Slide

68. Code-splitting
    & Component Loading
    Loading
    Render quickly
    Load minimal useful code
    Set user expectations
    Final state


    View Slide

69. Download JS Execution
    Critical for slow
    networks
    Critical for devices
    with slow CPUs


    View Slide

70. “If JavaScript doesn’t bring
    users joy, thank it and throw
    it away”
    Marie Kondo*
    * Probably


    View Slide

71. shopping.google.com
    Above-the-fold-rendering
    Interactivity for initial view
    Additional Search features
    Optimize
    UI Interactivity
    JS
    JS
    JS
    Tested on a Moto G4 over 3G
    Time to Interactive
    4.5s
    Lighthouse
    Performance
    90


    View Slide

72. JavaScript
    Code-splitting Smaller JavaScript bundle
    69%
    Faster Time-to-Interactive
    28%
    Reduction First-Input-Delay
    30%
    Walmart Grocery split up their JS bundles
    using granular code-splitting. They
    removed old / duplicate dependencies and
    cleaned up A/B test configs. Core bundles are
    cached with SWs for bytecode caching.
    grocery.walmart.com


    View Slide

73. Twitter


    View Slide

74. Route-based code-splitting

    50%
    36%

    18%
    *improvements from Twitter Lite traces, 2017.
    **This and other optimizations for Twitter Lite’s
    launch led to a 75% increase in tweets sent.
    Time to Interactive improvements


    View Slide

75. Review what your tools output!
    Efficiently bundling i18n for 34 languages
    Each build included i18n
    strings invalidating file
    hashes across the app.
    Each deploy invalidated your
    cache. Service Worker had to
    redownload everything.
    Issue caused by the tools.
    Generated files of same
    size, but different hashes.


    View Slide

76. Lazy-load
    Translation strings
    Reduction in overall bundle
    size
    30KB
    Saved loading Emoji picker
    on-demand
    50KB
    mobile.twitter.com
    Internationalization
    tooling improvements
    Faster JS exec from
    new i18n pipeline
    80%


    View Slide

77. JavaScript
    For first-time users
    Increase in
    day one plays
    54%
    mWeb users converted
    to native app installs
    30%
    This and other investments in the
    mobile web player led to...
    First time users trying to play
    a song get a fast sign-up
    55KB 300KB
    Once signed up, the mobile
    web player is lazy-loaded
    ~5s Time to Interactive on a Moto G4 over 4G


    View Slide

78. Spotify improved perceived performance
    Reusing data from one page to hydrate next, reduced API calls & kept blank pages minimum
    Enables quick
    navigations
    between pages,
    even on slow
    connections.


    View Slide

79. PRPL Pattern
    Interactive in 18KB JS
    Faster Time to
    Interactive
    82%
    This + other work
    Improvement
    in conversions
    25%
    Speed
    jabong.com
    Push minimal code to get interactive
    Render fast
    Precache other
    routes (SW)
    Lazy-load JS
    On demand
    HTML
    CSS
    JS
    JS
    JS
    JS


    View Slide

80. Fonts


    View Slide

81. Invisible Text
    By default, if a font is not loaded,
    the browser will hide text for up to:
    3 sec 3 sec 3 sec ∞
    Flash of
    Display font immediately


    View Slide

82. Flash of invisible text Flash of unstyled text


    View Slide

83. @font-face {
    font-family: 'Google Sans';
    src: url(...GoogleSans.woff2) format('woff2');
    font-display: swap;
    }
    Fonts
    chrome.com
    This & other techniques:
    Improvement in mobile
    page load times
    20%
    Improvement in “Visually
    Complete” on 3G
    .5s


    View Slide

84. fonts.googleapis.com/css?family=Lobster
    &font-display=swap
    fonts.googleapis.com/css?family=Lobster
    &font-display=swap


    View Slide

85. Get important vs meh
    resources first
    Why not both?
    Browser


    View Slide

86. Decrease in
    Latency
    0.7s
    Preconnect
    Critical Origins
    .com
    Resource Hints
    Faster Time
    to Interactive
    1.5s
    Preload
    Critical Scripts
    Faster Time to Interactive
    For future pages
    2.7s
    Prefetch
    Visible Links
    bit.ly/quicklinkjs


    View Slide

87. Prefetch
    Top Search Results
    Faster Median Above Fold Time
    (similar to FMP): 1.1s -> 0.39s
    759ms
    eBay prefetch the top 5 items in
    search results pages for fast
    subsequent loads. This happens during
    idle time with requestIdleCallback().
    “eBay saw a positive
    impact on conversions
    from prefetching”


    View Slide

88. Predictive
    Asset Prefetching
    Home
    Search
    Item
    eBay are doing predictive prefetching
    of static assets. Home prefetches assets
    for Search. Search prefetches for Item
    page (and so on).
    Machine Learning & Analytics based
    prefetching us under consideration.


    View Slide

89. Prefetch
    Popular Articles
    Faster article fetch time
    78%
    Article impressions
    +13% (after 1 week)
    +26% (after 2 weeks)
    Virgilio Sport prefetch articles based
    on analytics data. Service Workers and
    prefetch the most
    clicked posts for users not on 2G. SW
    updates the top articles every 7m.
    After 3 weeks
    45%
    Speed
    Prefetched


    View Slide

90. Critical CSS


    View Slide

91. Fold
    Inline critical CSS; deliver
    document in <= 14KB.
    Load CSS asynchronously.
    ● filamentgroup/loadcss
    ● addyosmani/critical
    ● filamentgroup/criticalcss
    ● pocketjoso/penthouse
    Critical CSS
    Other CSS


    View Slide

92. 0s 1s 1.2s
    2.4s
    Improvement in FCP
    1.4s
    Critical CSS


    View Slide

93. Determining
    Critical CSS
    Common factors:
    ● URL
    ● Device viewport
    Nikkei also dealt with these factors:
    ● Login state (logged in/out)
    ● Subscription (paying/free)
    ● Paywall (on/off)
    ● 300KB of “critical” CSS
    Challenge:


    View Slide

94. Application
    Server
    Critical CSS
    Server
    User
    CSS
    Document with
    inlined CSS CDN
    Dynamic Critical CSS
    API returns critical CSS based on parameters like user state and page.
    ...?service=article



    View Slide

95. User
    CSS
    Document with
    inlined CSS CDN
    Application
    Server
    Critical CSS
    Server
    Edge Side Inclusion (ESI)
    Caching
    Inlining ESI
    <br/>params<br/>Markup language for assembling documents; CDN feature.<br/>Example: <esi:include src="/critical.css?service=article"><br/>

    View Slide

96. ● +58% conversions (subscriptions)
    ● +49% daily active users
    Dynamic Critical CSS
    Improvement in FCP
    1s
    Reduction in inlined CSS
    80%
    This & other
    techniques:
    (without ESI)
    ● 2x page views per session
    ● 2.3x organic traffic


    View Slide

97. Brotli


    View Slide

98. Brotli: Reduce bytes over the wire
    Compress
    JS & CSS
    JavaScript
    reduction
    15%
    Latency
    Improvement (P50)
    37%
    Decrease in payload
    size for P75 sized
    payloads
    90%
    Reduction globally for
    P95 load latencies.
    ~15-20% in Emerging
    Markets
    5%
    Compress API
    Responses


    View Slide

99. Adaptive serving


    View Slide

100. Before
     Adaptive Serving
     Adapt based on network quality & data signals
     After
     Reading news
     navigator.connection.effectiveType
     // 3g
     navigator.connection.saveData
     // true


     View Slide

101. mBasic
     Site for low-end
     mTouch mBasic
     Time To Interactive
     1.6s
     mbasic.facebook.com
     m.facebook.com
     Facebook offer a basic version of
     their site for low-end devices. It
     has no JavaScript, very limited
     images and uses minimal CSS
     with tables mostly for layout.


     View Slide

102. Data Saver
     Mode For Images Reduction for data-usage
     from images on web. 96%
     incl disabled video autoplay
     80%
     Twitter’s Data Saver mode presents
     images as a preview. The web renders
     a 64x64 blurred image (LQIP style).
     Users can tap to load large images.
     Previews load quick on 2G & 3G.
     Reduction for data-usage from
     images on iOS + Android
     50%


     View Slide

103. Client-side compression of photo uploads
     Reduction in cancelled photo uploads
     ~9.5%
     On the server, compresses images to JPEG
     quality 85% & max dimensions of 4096x4096px.
     On the client, check if images appear above max
     dimensions or an MB limit. If so, draw to
     & output quality=85%.


     View Slide

104. Adaptive
     Serving (Experiment)
     Before After
     eBay are experimenting with adaptive
     serving using effectiveType. On a fast
     connection, features like product
     zooming will load on demand. On slow
     connections, they won’t.


     View Slide

105. View Slide

106. 1. Lazy-loading
     2. Responsive Images
     3. Image CDNs
     4. Defer Third-party JS
     5. Remove costly libraries
     6. Code-Splitting
     7. Avoid FOIT
     8. Prefetch
     9. Preconnect
     10. Preload
     11. Critical CSS
     12. Brotli
     13. Adaptive Serving
     Get fast
     web.dev/fast
     Stay Fast
     bit.ly/lightwallet-docs
     Performance Budgets
     LightWallet


     View Slide

107. Thank you!
     web.dev/fast
     bit.ly/lightwallet
     Helpful resources
     Katie Hempenius
     @katiehempenius
     Addy Osmani
     @addyosmani


     View Slide
