Patterns for Resilient Architecture

As presented at the AWS Loft in Stockholm - October 22nd, 2018.

We have traditionally built robust software systems by trying to avoid mistakes and by dodging failures when they occur in production or by testing parts of the system in isolation from one another. Modern methods and techniques take a very different approach based on resiliency, which promotes embracing failure instead of trying to avoid it. Resilient architectures enhance observability, leverage well-known patterns such as graceful degradation, timeouts and circuit breakers and embrace chaos engineering, a discipline that promotes breaking things on purpose in order to learn how to build more resilient systems. In this session, will review the most useful patterns for building resilient software systems and I will introduce chaos engineering methodology and especially show the audience how they can benefit from breaking things on purpose.

Transcript

1. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Patterns for Resilient Architecture Adrian Hornsby @adhorn
2. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. https://xkcd.com/1428/ About me … @adhorn
3. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
4. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Complex systems Amazon Twitter Netflix
5. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Partial failure mode
6. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Resiliency: Ability for a system to handle and eventually recover from unexpected conditions
7. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. People Application Network & Data Infrastructure
8. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Patterns for Resilient Architecture Infrastructure
9. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. About availability Availability Downtime per year 99% (2-nines) 3 days 15 hours 99.9% (3-nines) 8 hours 45 minutes 99.99% (4-nines) 52 minutes 99.999% (5-nines) 5 minutes 99.9999% (6-nines) 31 seconds
10. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. System availability Availability = Normal Operation Time Total Time MTBF** MTBF** + MTTR* = * Mean Time To Repair (MTTR) **Mean Time Between Failure (MTBF)
11. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Availability in series Part X Part Y A = Ax Ay
12. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Availability in series Component Availability Downtime X 99% (2-nines) 3 days 15 hours Y 99.99% (4-nines) 52 minutes X and Y Combined 98.99% 3 days 16 hours 33 minutes
13. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Availability in parallel A = 1 – (1 – Ax)2 Part X Part X
14. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Availability in parallel Component Availability Downtime X 99% (2-nines) 3 days 15 hours Two X in parallel 99.99% (4-nines) 52 minutes Three X in parallel 99.9999% (6-nines) 31 seconds
15. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Component redundancy increases availability significantly!
16. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Multi-AZ architecture Region Availability zone a Availability zone b Availability zone c Application
17. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. AWS Region and availability zones Region Availability zone a Availability zone b Availability zone c data center data center data center data center data center data center data center data center data center
18. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Redundancy across multiple regions
19. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. 18 Geographic Regions 55 Availability Zones (AZs) 4 regions and 12 more Availability Zones announced
20. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Improve latency for end-users ~300ms ~140ms
21. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Combined with disaster recovery Service 1 Service 2 Service 3 Service 4 Service 1 Service 2 Service 3 Service 4 US-WEST-2 US-EAST-1
22. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Netflix 2013
23. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Netflix 2016
24. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Global routing
25. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Routing policies with Route 53 Region Region Application Application
26. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Latency based routing Region Region Application Application
27. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Geo-based routing Region us-east-1 Region us-west-2 Application Application
28. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Weighted round robin routing Region us-east-1 Region us-west-2 Application Application
29. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. DNS failover Region us-east-1 Region us-west-2 Application Application
30. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Learn more about multi-region architecture
31. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Auto-Scaling • Compute efficiency • Node failure • Traffic spikes • Performance bugs
32. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Auto Scaling group Service A Availability zone 1 Auto Scaling group AWS Region Service A Availability zone 2 Service B Service B Auto-scaling
33. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Immutable Infrastructure • No updates on live systems • Always start from a new resource being provisioned • Deploy the new software • Test in different environments (dev, staging) • Deploy to prod (inactive) • Change references (DNS or Load Balancer) • Keep old version around (inactive) • Fast rollback if things go wrong
34. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Patterns for Resilient Architectures Network & Data
35. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. CAP Theorem Consistency Availability Partition Tolerance Data is consistent. All nodes see the same state. Every request is non-failing. Service still responds as expected if some nodes crash. Distributed System In the presence of a network partition, you must choose between consistency and availability!
36. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Embrase eventual consistency … if no new updates are made to a given data item, eventually all accesses to that item will return the last updated value. Availability An eventually consistent system can return any value before it converges!! https://en.wikipedia.org/wiki/Eventual_consistency Distributed System Every request is non-failing.
37. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Process A Process B Process A Process B Synchronous Asynchronous Waiting Working Continues get or fetch result Get result
38. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Decoupling with async pattern Listener Pub-Sub Queue Queue A A B B
39. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. API: {DO foo} PUT JOB: {JobID: 0001, Task: DO foo} API: {JobID: 0001} GET JOB: {JobID: 0001, Task: DO foo} {JobID: 0001, Result: bar} Cache node Worker Instance Worker Instance Queue API Instance API Instance API Instance
40. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Push Notification User Worker Instance Worker Instance Queue API Instance API Instance Cache node Fetch results API Instance
41. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Degrade & prioritize traffic with queues Worker Instance Worker Instance API Instance API Instance API Instance High Priority Queue Low Priority Queue
42. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Read / Write Sharding DB Instance DB instance read replica DB instance read replica DB instance read replica Instance Instance Instance
43. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Database Federation Users DB Products DB Instance Instance Instance DB Instance DB instance read replica DB Instance DB instance read replica
44. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Database Sharding User ShardID 002345 A 002346 B 002347 C 002348 B 002349 A C B A Instance Instance Instance DB Instance DB instance read replica DB Instance DB instance read replica DB Instance DB instance read replica
45. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Transient state does not belong in the database.
46. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Patterns for Resilient Architecture Application
47. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Auto Scaling group Service A Availability zone 1 Auto Scaling group AWS Region Service A Availability zone 2 Service B Service B Stateless Services
48. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Cascading Failures
49. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Let’s talk about timeouts & retries!
50. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Users App DB Conn Pool INSERT INSERT INSERT INSERT What happens if the DB “slows down”? Timeout client side Timeout backend side ? ?
51. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. User 1 App DB Conn Pool INSERT Timeout client side = 10s Timeout backend side = Not implemented Retry INSERT Retry INSERT ERROR: Failed to get connection from pool Retry
52. http://docs.python-requests.org/en/master/user/advanced/#timeouts
53. http://docs.python-requests.org/en/master/user/advanced/#timeouts
54. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. @timeout_decorator.timeout(5, timeout_exception=StopIteration) def timed_get(url): return requests.get(url) https://pypi.org/project/timeout-decorator/
55. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Timeouts
56. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. How else could we have prevented the error? User 1 DB Conn Pool INSERT Retry INSERT Retry INSERT Retry ERROR: Failed to get connection from pool
57. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. User 1 DB Conn Pool INSERT Timeout client side = 10s Timeout backend side = 10s Wait 2s before Retry INSERT INSERT Wait 4s before Retry Wait 8s before Retry Wait 16s before Retry Backing off between retries Releasing connections Backoff
58. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. No jitter With jitter https://aws.amazon.com/blogs/architecture/exponential-backoff-and-jitter/ Simple Exponential Backoff is not enough: Add Jitter
59. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Example: add jitter 0-1000ms def get_item(self, url, n=1): MAX_TRIES = 12 try: res = requests.get(url) except: if n > MAX_TRIES: return None n += 1 time.sleep((2 ** n) + (random.randint(0, 1000) / 1000.0)) return self.get_item(url, n) else: return res
60. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. @backoff.on_exception(backoff.full_jitter, max_time=60) def poll_for_message(queue): return queue.get() https://pypi.org/project/backoff/ As of version 1.2, the default jitter function backoff.full_jitter implements the ‘Full Jitter’ algorithm as defined in the AWS Architecture Blog’s Exponential Backoff And Jitter post.
61. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Idempotent operation No additional effect if it is called more than once with the same input parameters.
62. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Auto Scaling group Service A Availability zone 1 Auto Scaling group AWS Region Service A Availability zone 2 Service B Service B database Email Probing for health Cluster
63. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Shallow health check Instance Cache node Email database Cluster Are you healthy? yes
64. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Shallow health check Instance Cache node Email database Cluster Are you healthy? yes
65. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Deep health check Instance Cache node Email database Cluster Are you healthy? yes Are you healthy? yes yes yes yes
66. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Deep health check Instance Cache node Email database Cluster Are you healthy? no Are you healthy? no yes yes yes
67. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Service Degradation & Fallbacks
68. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Circuit Breaker • Wrap a protected function call in a circuit breaker object, which monitors for failures. • If failures reach a certain threshold, the circuit breaker trips. Producer Circuit Breaker Consumer Connection Monitoring Timeouts Breaking Circuit
69. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Non-blocking UI https://medium.com/@sophie_paxtonUX/stop-getting-in-my-way-non-blocking-ux-5cbbfe0f0158
70. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Exception Handling
71. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Patterns for Resilient Architecture People
72. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Conway’s Law User UI Team Application Team DBA Team ”Any organization that designs a system (defined broadly) will produce a design whose structure is a copy of the organization's communication structure.” http://www.melconway.com/Home/Conways_Law.html Siloed Teams Siloed Applications
73. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Conway’s Law http://www.melconway.com/Home/Conways_Law.html Services Cross-Functional Teams ”Any organization that designs a system (defined broadly) will produce a design whose structure is a copy of the organization's communication structure.”
74. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Fire Drills
75. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
76. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Building confidence through testing Unit testing of components: • Tested in isolation to ensure function meets expectations. Functional testing of integrations: • Each execution path tested to assure expected results. Is it enough???
77. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. GameDay at Amazon Creating Resiliency Through Destruction https://www.youtube.com/watch?v=zoz0ZjfrQ9s
78. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Chaos engineering https://github.com/Netflix/SimianArmy
79. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. What “really” is Chaos Engineering?
80. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. “Chaos Engineering is the discipline of experimenting on a distributed system in order to build confidence in the system’s capability to withstand turbulent conditions in production.” http://principlesofchaos.org
81. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Break your systems on purpose. Find out their weaknesses and fix them before they break when least expected.
82. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Failure injection • Start small & build confidence • Application level • Host failure • Resource attacks (CPU, memory, …) • Network attacks (dependencies, latency, …) • Region attacks • “Paul” attack
83. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved.
84. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. “Chaos doesn’t cause problems. It reveals them.” Nora Jones Senior Chaos Engineer, Netflix
85. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. © 2017, Amazon Web Services, Inc. or its Affiliates. All rights reserved. https://bit.ly/2uKOJMQ
86. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Chaos Engineering
87. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Steady State Hypothesis Design & Run Experiment Verify & Learn Fix
88. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Steady State
89. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. What is steady state? • ”normal” behavior of your system https://www.elastic.co/blog/timelion-tutorial-from-zero-to-hero
90. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. What is steady state? • ”normal” behavior of your system • Business Metric https://medium.com/netflix-techblog/sps-the-pulse-of-netflix-streaming-ae4db0e05f8a
91. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Business metrics at work Amazon: 100 ms of extra load time caused a 1% drop in sales (Greg Linden). Google: 500 ms of extra load time caused 20% fewer searches (Marissa Mayer). Yahoo!: 400 ms of extra load time caused a 5–9% increase in the number of people who clicked “back” before the page even loaded (Nicole Sullivan).
92. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Hypothesis
93. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. What if…? “What if this load balancer breaks?” “What if Redis becomes slow?” “What if a host on Cassandra goes away?” ”What if latency increases by 300ms?” ”What if the database stops?” Make it everyone’s problem!
94. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Disclaimer! Don’t make an hypothesis that you know will break you!
95. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Design & Run Experiment
96. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Designing experiment • Pick hypothesis • Scope the experiment • Identify metrics • Notify the organization
97. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Rules of thumbs • Start with very small • As close as possible to production • Minimize the blast radius. • Have an emergency STOP!
98. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Running Chaos Experiment Users Canary deployment Normal Version 99% Users 1% Users Start with ..
99. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Verify & Learn
100. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Quantifying the result of the experiment • Time to detect? • Time for notification? And escalation? • Time to public notification? • Time for graceful degradation to kick-in? • Time for self healing to happen? • Time to recovery – partial and full? • Time to all-clear and stable?
101. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. DON’T blame that one person …
102. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. PostMortems – COE (Correction of Errors) The 5 WHYs Outage Because of … Because of … Because of … Because of … NOT ENOUGH
103. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. More questions to ask • Can you clarify if there were any preceding events? • Why would they believe acting in this way was the best course of action to deliver the desired outcome? • Is there another failure mode that could present here? • What decisions or events prior to this made this work before? • Why stop there – are there places to dig deeper that could shine a light more on this? • Did others step in to help, to advise, or to intercede?
104. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Rules to remember! 1. Failure requires multiple faults 2. There is no isolated ‘cause’ of an accident. 3. There are multiple contributors to accidents.
105. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Fix
106. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Fix
107. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Never let a good crisis go to waste
108. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Big challenges to chaos engineering Mostly Cultural • no time or flexibility to simulate disasters. • teams already spending all of its time fixing things. • can be very political. • might force deep conversations. • deeply invested in a specific technical roadmap (micro-services) that chaos engineering tests show is not as resilient to failures as originally predicted.
109. © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Changing culture takes time! Be patient…
111. Thank you! © 2018, Amazon Web Services, Inc. or its affiliates. All rights reserved. Adrian Hornsby @adhorn
