"Enhancing Topological Data Analysis with Deep Learning" by Edward Kibardin, Lead Data Scientist at Badoo

Transcript

1. Enhancing ! Topological Data Analysis ! with semi-supervised ! Deep Learning Edward Kibardin
2. Data Map
3. The motivation
4. + Instead of asking data specific questions we can use traditional tools to join different data sources and prepare a holistic dataset This dataset can be automatically processed using topological data analysis and presented as map of dependencies and correlations The motivation = Get answers to questions you didn’t ask yet
5. A topological invariant is a map f that assigns the same object to homeomorphic spaces, that is: Homology: is a machine that converts local data about a space into global algebraic structure Reference: Wikipedia, 2010. Topological invariants
6. a   b   a.  Compute a combinatorial model approximating the structure of the underlying space b.  Then compute topological invariants of this structure c.  Represent these topological invariants in 2d space Topology Data Analysis Pipeline c
7. Barcodes Reference: Robert Adler, TOPOS: Applied topologists do it with persistence
8. Theorem: Suppose  h  :  X  g          is a discrete Morse function.   Then X is homotopy equivalent to a CW-complex with exactly one cell of dimension p for each critical simplex of dimension p. Reference:  Teng  Ma  ;  Zhuangzhi  Wu  ;  Pei  Luo  ;  Lu  Feng.  Reeb  graph  computa1on  through  spectral  clustering,  2011.   Morse Theory and Reeb Graph
9. Case study: Badoo A subset of user activity in the United States. Aggregated activity metrics over two weeks in August 2014. •  88,567 users •  867 metrics
10. Case study: Badoo Data Transformation Used aggregated representations of user activities per day: •  Number of likes •  Number of dislikes •  Number of matches •  Profiles visited •  Photos uploaded •  Number of messages sent (no content analysed) •  Number of message replies •  Interactions with different app features
11. Case study: Badoo
12. Case study: Badoo Messages sent / received
13. Case study: Badoo Results •  Genders can be very well identified purely by activity •  Found a group of male users, who are acting very similar to females, subject to further analysis •  Performed segmentation of users for potential product features with product team •  Distilled a group of blocked users •  Found several interesting correlations between usage and success on the app
14. Case study: 20 Newsgroups The 20 Newsgroups data set is a collection of approximately 20,000 newsgroup documents, partitioned (nearly) evenly across 20 different newsgroups. •  18,820 documents •  From 6 to 5000 words each •  20 newsgroups (classes) 20  Newsgroups     academic  dataset   (semi-­‐supervised)
15. Case study: 20 Newsgroups alt.atheism comp.graphics comp.os.ms-windows.misc comp.sys.ibm.pc.hardware comp.sys.mac.hardware comp.windows.x misc.forsale rec.autos rec.motorcycles rec.sport.baseball rec.sport.hockey sci.crypt sci.electronics sci.med sci.space soc.religion.christian talk.politics.guns talk.politics.mideast talk.politics.misc talk.religion.misc
16. Case study: 20 Newsgroups Data Transformation re albert sabin in article apr nntpd cxo dec com sharpe nmesis enet dec com system privileged account writes in article c ftjt sunfish usd edu rfox charlie usd edu rich fox univ of south dakota writes in article apr rambo atlanta albert sabin articl apr nntpd cxo dec sharp nmesi enet dec system privileg account write articl ftjt sunfish usd edu rfox charli usd edu rich fox univ south dakota write articl apr rambo atlanta … account albert articl apr atlanta cxo dec edu … 564 3 0 5 1 0 0 0 0 565 0 1 2 0 1 0 0 0 566 0 0 0 2 0 0 1 2 567 1 0 0 0 0 0 0 0 568 0 0 2 0 0 2 0 0 569 2 2 1 4 5 2 3 4 570 0 2 0 2 2 0 0 2 571 0 0 0 2 2 0 1 0 572 1 0 1 0 0 2 0 0 573 0 2 0 0 0 1 0 2 574 0 1 0 2 2 0 0 1 575 3 0 3 1 0 0 5 1 576 0 0 0 0 0 3 3 2 577 1 1 1 0 5 3 4 0 578 0 0 0 3 7 3 5 7 Source text Data format for TDA 1000 words 18820 documents Stemming and stop words removal Text vectorisation
17. Topology for different epsilon parameter Case study: 20 Newsgroups
18. Detailed topology Case study: 20 Newsgroups
19. Detailed topology (user group overlay) Case study: 20 Newsgroups
20. Selecting first two clusters Case study: 20 Newsgroups
21. Baseball cluster Case study: 20 Newsgroups “pitch” > 1.2 This must be baseball speed game margin realist chip ucdavi edu gari built villanova huckabai basebal game and shade hour that damn long don plai hour game watch game for that long butt fall asleep and watch channel surf pitch catch color
22. Motorcycles cluster Case study: 20 Newsgroups “bike” > 1.114 This must be motorcycles ride sixteen dai had put test drive honda final saturdai rain fact clear warm and sunni and wind di week ago long cool ride hawk cycl for test ride had sold and deliv demo fifteen hour arriv and demo vfr bike lock showroom surround bike and not like move todai even bike us dirt bike us street bike car and big tent full outlandishli fat tour bike trailer squeez park lot sort fat bike convent shelli and dave run msf each time classroom and back lot usual free cookout distribut severli affect will bike perform such load cling back rest secur shift increas chanc surf collect wisdom request can afford leather pant boot and jean can make you knee protector rollerblad us bean and sell
23. Denoising Autoencoders High-level feature extraction
24. Denoising Autoencoders A power of destruction   No destroyed inputs 25% destruction 50% destruction Neuron A (0%, 10%, 20%, 50% destruction) Neuron B (0%, 10%, 20%, 50% destruction)
25. Denoising Autoencoders Example of learning weights for MNIST dataset
26. Stacked Denoising Autoencoders High-level feature extraction
27. Stacked Denoising Autoencoders 20 Newsgroups network structure (learning)   Vector or word counts for each document 1000 500 500 Encoder 1 Encoder 2 f θ (1) f θ (2) x
28. Stacked Denoising Autoencoders 20 Newsgroups network structure (fine-tuning)   Vector or word counts for each document 1000 500 500 Labels for selected points Topological fine-tuner Encoder 1 Encoder 2 Fine-tuning weights Fine-tuning weights f θ (1) f θ (2) x
29. Learning high-level features for selected two clusters Case study: 20 Newsgroups Weights for autoencoder layer 1, corruption level = 0.2
30. Result of learning first two groups Case study: 20 Newsgroups Labeled baseball! Unlabeled baseball! Labeled Motorcycles! Unlabeled Motorcycles! Autos Pc.hardware Mac.hardware
31. Result of learning five groups Case study: 20 Newsgroups Mac.hardware Baseball! Pc.hardware Autos Motorcycles! Scy.med! Politics.misc! Politics.! mideast! Hockey!
32. Final result for 2nd layer Case study: 20 Newsgroups Motorcycles Christian Atheism Religion.misc Politics.guns Politics.misc Politics.mideast Scy.crypt Scy.med Hockey Baseball Autos Forsale Mac.hardware Electronics Scy.space Comp.graphics Windows.x Ms-windows.misc Pc.hardware
33. Links Topology And Data (Gunnar Carlsson): http://www.ams.org/journals/bull/2009-46-02/S0273-0979-09-01249-X/ S0273-0979-09-01249-X.pdf Discrete Morse Theory and Persistent Homology (Kevin P. Knudson): http://www.math.fsu.edu/~hironaka/FSUUF/knudson.pdf Topological Persistence and Simplification (Herbert Edelsbrunner, David Letscher, Afra Zomorodian): http://math.uchicago.edu/~shmuel/AAT-readings/Data%20Analysis%20/PersTop.pdf Extracting and Composing Robust Features with Denoising Autoencoders (Pascal Vincent, Hugo Larochelle, Yoshua Bengio, Pierre-Antoine Manzagol) http://www.iro.umontreal.ca/~vincentp/Publications/ denoising_autoencoders_tr1316.pdf
34. info@datarefiner.com www.datarefiner.com Please sign up for free beta access:
