AD Authenticate All The Things

Authentication and authorization to the AWS management console using your on-premise Active Directory isn't all that straightforward, at first. This deck covers the easily adaptable and scalable methodology we created and have been following over the past year, leveraging our existing IdP and adhering to strict conventions.

Transcript

1. AD  Authenticate  the  AWS  Management  Console Alan  Williams Enterprise  Architect Advanced  AWS  Meetup – June  2015
2. ©  2015   Autodesk § Technology  Generalist § Background  in  Infrastructure § @  Autodesk  ~10  years § Spoken  at  OpenWorld,  .conf and  re:Invent § AWS  user  for  ~5  years § Motorcyclist § Soft  spot  for  pit  bulls   § @alanwill on   Who  Am  I?
3. ©  2015   Autodesk § Leader  in  3D  design,  engineering  and   entertainment  software § Introduced  AutoCAD  in  1982 § Empowering  the  Maker  movement § Helping  our  customers  imagine,  design   and  create  a  better  world § ~11,000  global  employees Who  is  Autodesk?
4. autodesk.com/careers
5. ©  2015   Autodesk § Problem § Solution § Demo § How § Benefits § Next Agenda
6. Problem
7. ©  2015   Autodesk § Identity  Management § Too  many § Lots  of  AWS  accounts § Access  Control § Too  complex  to  manage § Too  difficult  to  enforce § Inconvenient § What’s  my  password? Problem
8. Solution
9. ©  2015   Autodesk
10. ©  2015   Autodesk § AWS  Federated  Logins § IAM  Identity  Providers § On-­premises  Identity  Provider § PingFederate,  Okta etc… § On-­premises  Identity  Store § Active  Directory § SAML   § Security  Assertion  Markup  Language Solution
11. Demo
12. How (the  gory  details)
13. ©  2015   Autodesk Workflow *Diagram  adapted  from AWS  STS  documentation for  Autodesk  relevance http://docs.aws.amazon.com/STS/latest/UsingSTS/STSMgmtConsole-­SAML.html
14. ©  2015   Autodesk § Go  to  IdP page § Example:  https://aws.company.com § Enter  AD  credentials § jdoe /  ******** #1  – IdP Initiated  SSO
15. ©  2015   Autodesk § AD   § Validates  credentials § Responds  with  all  user’s  security  groups  to  IdP § IdP § Applies  filters  and  performs  field  extraction § Sends  to  client  AWS  account(s)  +  IAM  role(s)  in   SAML  assertion   #2/3  – Authentication
16. ©  2015   Autodesk AD  Security  Group  Naming  Convention
17. ©  2015   Autodesk § Client  posts  assertion  to  AWS  SSO   endpoint § AWS  validates  request  and  matches  AWS   account  numbers  and  roles § Presents  list  of  AWS  accounts  to  user  for   sign  in #4/5/6  -­ Authorization
18. ©  2015   Autodesk
19. ©  2015   Autodesk
20. How (on  the  AWS  end)
21. ©  2015   Autodesk Create  IAM  Identity  Provider
22. ©  2015   Autodesk Create  IAM  Identity  Provider
23. ©  2015   Autodesk Create  IAM  Identity  Provider
24. ©  2015   Autodesk Create  IAM  Identity  Provider
25. ©  2015   Autodesk Create  IAM  Identity  Provider
26. ©  2015   Autodesk Create  an  IAM  Role
27. ©  2015   Autodesk Create  IAM  Role
28. ©  2015   Autodesk Create  IAM  Role
29. ©  2015   Autodesk Create  IAM  Role
30. ©  2015   Autodesk Create  IAM  Role
31. ©  2015   Autodesk
32. ©  2015   Autodesk Role  Name Example  IAM  Role  Policy Account-­Admin AdministratorAccess Policy Account-­ReadOnly ReadOnlyAccess Policy Application-­Admins PowerUserAccess Policy Database-­Admins AmazonRDSFullAccess +   AmazonRedshiftFullAccess Policies Network-­Admins AmazonVPCFullAccess +   AWSDirectConnectFullAccess Policies Security-­Admins SecurityAudit Policy Server-­Admins AmazonEC2FullAccess Policy Optional:  Multiple  Roles
33. ©  2015   Autodesk Optional:  Multiple  Roles,  same  account
34. ©  2015   Autodesk Optional:  Two  Factor  Authentication
35. ©  2015   Autodesk § Create  AD  Security  Groups   § following  naming  convention § Create  IAM  Identity  Provider § Create  IAM  Roles On-­boarding  New  Accounts
36. ©  2015   Autodesk § AD  security  group  membership § Role  based  access  control Managing  Access
37. Benefits
38. ©  2015   Autodesk § Standardized  authentication § Improved  security § Convenient  user  experience § Flexible § Scalable  to  100s+  accounts Benefits
39. What’s   Next
40. ©  2015   Autodesk § IAM  Keys  Vending  Machine § Access/Secret  Key  self  service  portal § Temporary,  expires  in  24  hours Next  Steps
41. ©  2015   Autodesk § Using  Identity  Providers § http://goo.gl/qf7NpN § Using  SAML  Providers § http://goo.gl/cBMswu § IAM  Federated  User  Access § http://goo.gl/5nIMt9 Documentation  Resources
42. ©  2015   Autodesk
