Rendre son IoT encore plus intelligent avec Tensorflow Lite @SnowCampIO

Rendre son IoT encore plus intelligent avec Tensorflow Lite @SnowCampIO

Alors que le Machine Learning est déployé habituellement dans le Cloud, des versions allégées de ces algorithmes et adaptées aux systèmes contraints de l’IoT comme les micro-contrôleurs commencent à apparaître.

Utiliser du Machine Learning « at-the-edge » présente en effet plusieurs avantages comme la réduction de la latence, la confidentialité des données, et le fonctionnement sans connexion internet.

Au cours de cette présentation, nous verrons qu’il est donc possible de déployer des algorithmes de Deep Learning sur des objets connectés grâce à TensorFlow Lite. Nous verrons alors comment l’utiliser pour concevoir l’« agriculture du futur » capable de prédire et optimiser la production de légumes, aussi bien chez soi que dans des pays en voie de développement où la connexion internet est intermittente.

Alexis DUQUE

January 23, 2020
Tweet

More Decks by Alexis DUQUE

Other Decks in Programming

Transcript

  1. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Make you IoT Smarter
    with Tensorflow Lite ...
    … to Design the Future of Vertical Farming
    @alexis0duque

    View Slide

  2. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Who am I?

    View Slide

  3. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI

    View Slide

  4. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI

    View Slide

  5. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI

    View Slide

  6. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Outline & What You Will Learn

    View Slide

  7. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Indoor Vertical Farming

    View Slide

  8. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    System Architecture

    View Slide

  9. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    System Architecture

    View Slide

  10. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Irrigation System




    https://www.hydroponic-urban-gardening.com/hydroponics-guide/various-hydroponics-systems

    View Slide

  11. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    System Architecture

    View Slide

  12. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Computer Vision

    View Slide

  13. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    System Architecture

    View Slide

  14. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI

    View Slide

  15. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    System Architecture

    View Slide

  16. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Why Machine Learning?
    Flavor-cyber-agriculture: Optimization of plant metabolites in an open-source control environment through surrogate
    modeling
    Johnson AJ, et al. (2019) Flavor-cyber-agriculture: Optimization of plant metabolites in an open-source control environment
    through surrogate modeling. PLOS ONE 14(4): e0213918.

    View Slide

  17. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Why Edge Computing?

    View Slide

  18. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Tensorflow

    View Slide

  19. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Tensorflow

    View Slide

  20. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Tensorflow Lite (TF-Lite)

    View Slide

  21. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Tensorflow Lite (TF-Lite)

    View Slide

  22. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    ML Workflow with Tensorflow Lite

    View Slide

  23. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    ML Workflow with Tensorflow Lite

    View Slide

  24. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Setup on your Laptop

    View Slide

  25. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Setup on your Laptop
    $ python3 --version
    $ pip3 --version
    $ virtualenv --version
    $ virtualenv --system-site-packages -p python3 ./venv
    $ source ./venv/bin/activate
    $ pip install --upgrade pip
    $ pip install --upgrade tensorflow=2.0
    $ pip install numpy pandas jupyter jupyterlab notebook
    matplotlib

    View Slide

  26. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Setup on your RPI

    View Slide

  27. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Setup on your RPI
    $ sudo apt install swig libjpeg-dev zlib1g-dev python3-dev
    python3-numpy unzip
    $ wget
    https://github.com/PINTO0309/TensorflowLite-bin/raw/master/2.0
    .0/tflite_runtime-2.0.0-cp37-cp37m-linux_armv7l.whl
    $ pip install --upgrade
    tflite_runtime-2.0.0-cp37-cp37m-linux_armv7l.whl

    View Slide

  28. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Setup on your RPI
    $ sudo apt install swig libjpeg-dev zlib1g-dev python3-dev
    python3-numpy unzip
    $ wget
    https://github.com/PINTO0309/TensorflowLite-bin/raw/master/2.0
    .0/tflite_runtime-2.0.0-cp37-cp37m-linux_armv7l.whl
    $ pip install --upgrade
    tflite_runtime-2.0.0-cp37-cp37m-linux_armv7l.whl
    $ sudo apt install swig libjpeg-dev zlib1g-dev python3-dev
    python3-numpy unzip
    $ wget
    https://github.com/PINTO0309/TensorflowLite-bin/raw/master/2
    .0.0/tflite_runtime-2.0.0-cp37-cp37m-linux_armv7l.whl
    $ pip install --upgrade
    tflite_runtime-2.0.0-cp37-cp37m-linux_armv7l.whl

    View Slide

  29. Demo
    @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI

    View Slide

  30. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Tensorflow Lite Benchmark
    Source: Alasdair Allan

    View Slide

  31. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Tensorflow Lite Benchmark
    Source: Alasdair Allan

    View Slide

  32. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Tensorflow Lite Limitations

    View Slide

  33. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    TFLite on Microcontrollers
    Arduino Nano 33

    View Slide

  34. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    TFLite on Microcontrollers
    #include
    // This is your tflite model
    #include "lg_weight_model.h"
    #include "tensorflow/lite/experimental/micro/kernels/all_ops_resolver.h"
    #include "tensorflow/lite/experimental/micro/micro_interpreter.h"
    #include "tensorflow/lite/schema/schema_generated.h"
    tflite::ErrorReporter *error_reporter = nullptr;
    const tflite::Model *model = nullptr;
    tflite::MicroInterpreter *interpreter = nullptr;
    TfLiteTensor *input = nullptr;
    TfLiteTensor *output = nullptr;
    #include
    // This is your tflite model
    #include "lg_weight_model.h"
    #include
    "tensorflow/lite/experimental/micro/kernels/all_ops_resolver.h"
    #include "tensorflow/lite/experimental/micro/micro_interpreter.h"
    #include "tensorflow/lite/schema/schema_generated.h"
    tflite::ErrorReporter *error_reporter = nullptr;
    const tflite::Model *model = nullptr;
    tflite::MicroInterpreter *interpreter = nullptr;
    TfLiteTensor *input = nullptr;
    TfLiteTensor *output = nullptr;

    View Slide

  35. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    TFLite on Microcontrollers
    // Finding the min value for your model may require tests!
    constexpr int kTensorArenaSize = 2 * 1024;
    uint8_t tensor_arena[kTensorArenaSize];
    // Load your model.
    model = tflite::GetModel(g_weight_regresion_model_data);
    // This pulls in all the operation implementations we need.
    static tflite::ops::micro::AllOpsResolver resolver;
    // Build an interpreter to run the model with.
    static tflite::MicroInterpreter static_interpreter(
    model, resolver, tensor_arena, kTensorArenaSize, error_reporter);
    interpreter = &static_interpreter;
    // Finding the min value for your model may require tests!
    constexpr int kTensorArenaSize = 2 * 1024;
    uint8_t tensor_arena[kTensorArenaSize];
    // Load your model.
    model = tflite::GetModel(g_weight_regresion_model_data);
    // This pulls in all the operation implementations we need.
    static tflite::ops::micro::AllOpsResolver resolver;
    // Build an interpreter to run the model with.
    static tflite::MicroInterpreter static_interpreter(
    model, resolver, tensor_arena, kTensorArenaSize, error_reporter);
    interpreter = &static_interpreter;

    View Slide

  36. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    TFLite on Microcontrollers
    // Allocate memory for the model's tensors.
    TfLiteStatus allocate_status = interpreter->AllocateTensors();
    // Obtain pointers to the model's input and output tensors.
    input = interpreter->input(0);
    output = interpreter->output(0);
    // Feed the interpreter with the input value
    float x_val = random(0, 1);
    input->data.f[0] = x_val;
    // Run Inference
    TfLiteStatus invoke_status = interpreter->Invoke();
    // Get inference result
    float y_val = output->data.f[0];
    // Allocate memory for the model's tensors.
    TfLiteStatus allocate_status = interpreter->AllocateTensors();
    // Obtain pointers to the model's input and output tensors.
    input = interpreter->input(0);
    output = interpreter->output(0);
    // Feed the interpreter with the input value
    float x_val = random(0, 10);
    input->data.f[0] = x_val;
    // Run Inference
    TfLiteStatus invoke_status = interpreter->Invoke();
    // Get inference result
    float y_val = output->data.f[0];

    View Slide

  37. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Further Work

    View Slide

  38. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Summary

    View Slide

  39. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    Thanks!
    frama.link/rtone-iot-tflite
    frama.link/rtone-jobs

    View Slide

  40. @alexis0duque
    #Snowcamp #IoT #Tensorflow #AI
    References
