La 5G, 15' pour (presque) tout comprendre

La 5G arrive à grands pas et de nombreux médias et industriels commencent à en parler. Ce fut notamment le cas lors duMobile World Congress (MWC) qui s'est tenu à Barcelone en mars dernier.

Alors que le processus de standardisation n'est pas encore tout à fait finalisé, certains d'entre vous se posent sûrement de nombreuses questions : qui sont les acteurs ? quand ? que cela va-t-il changer ? quelles sont les technologies qui se cachent derrière le terme "5G" ?

Au cours de cette présentation, j'essayerais de répondre à ces questions. Nous parlerons notamment de 3GPP de mmWave, NFV, 5G-New Radio, Massive IoT, LPWAN, ou de beamforming.

83124b745752d1a1b0ca2eee1af0bd48?s=128

Alexis DUQUE

November 13, 2019
Tweet

Transcript

  1. @alexis0duque #DevoxxMA #5G #Mobile #Science 5G, 15’ to understand (almost)

    everything @alexis0duque
  2. 2 HELLO! I am Alexis Duque Director of Research at

    Rtone PhD @alexis0duque alexisd@rtone.fr rtone.fr
  3. 3GPP IoT Edge 3 5G Beamforming Fog low latency Massive

    MIMO mmWave
  4. DISCLAIMERS 4 Mobile generations do not reflect technological evolution, marketing

    terms Mobile communications generations result from many evolutions and thus are not perfectly distinct Commercial, economical, and financial issues greatly influence the mobile technologies development
  5. WHO? 5 3GPP: groups of telecommunications standards associations, in Europe,

    Japan, USA ⇒ defines the standard NGMN: leading network operators organization, Verizon, O2, Telefonica, Orange, etc. 5GPPP: European initiative with industrial and institutional partners, Nokia, Ericsson, ...
  6. 2. Before 5G ...

  7. 2G 7

  8. 3G 8

  9. 4G 9

  10. 5G 10 ?

  11. BENEFITS & GOALS 11

  12. PERFORMANCE INDICATORS 12 DL: 100Mbps UL: 50Mbps x3 500 km/h

    1M device/km2 ~10ms 100 Mbps/m2 100x
  13. STANDARDIZATION ROADMAP 13 2012 2014 2015 2016 2017 2018 2019

    2020 2000 2003 1985 … … … Year Deployment Of IMT-2020 DevelopmeDe velopmenntt OfOf Dev. of IMT-2020 Vision of IMT-2020 Vision of IMT-Adv Deployment of IMT-Adv Dev. of IMT-2000 Deployment Of IMT-2000 3G R16 R15 R14 5G 4G Dev. of IMT-Advanced Deployment of IMT-2020 9 years 15 years 5 years R13
  14. 2. HOW?

  15. 15 HOW? ▸ New Radio Spectrum ▸ New Radio Multiplexing

    Technologies ▸ New Efficient Spectrum Usage Techniques ▸ New Energy Saving Mechanisms ▸ Application Specific Improvements
  16. 16 NEW RADIO SPECTRUM

  17. 17 MMWAVE

  18. 18 NEW EFFICIENT SPECTRUM USAGE TECHNIQUES ▸ 3D Beamforming and

    Massive MIMO ▸ Distributed Antenna Systems (DAS) ▸ FDD-TDD Carrier Integration ▸ Simultaneous Transmission and Reception ▸ Dynamic TDD ▸ License Assisted Access (LAA) ▸ Multimode Base Stations ▸ Intelligent Multi-Mode RAT Selection ▸ Higher order modulations in small cells
  19. 19 MASSIVE MIMO Ref: https://futurenetworks.ieee.org/tech-focus/march-2017/massive-mimo-for-5g

  20. 20 BEAMFORMING & BEAMSTEERING Ref: G. Xu, et al, “Full-Dimension

    MIMO: Status and Challenges in Design and Implementation,” May 2014, http://www.ieee-ctw.org/2014/slides/session3/CTW_2014_Samsung_FD-MIMO.pdf
  21. ENERGY SAVING MECHANISMS

  22. CAPEX/OPEX REDUCTION TECHNIQUES

  23. 23 SOFTWARE DEFINED NETWORKING NETWORK FUNCTION VIRTUALIZATION Abstract the Hardware

    Virtualize all functions Create capacity on demand
  24. 24 MOBILE EDGE COMPUTING Computation needs to come to edge

    : router, mobile, IoT IoT Gateway, app specific computing
  25. 25 CLOUD RADIO ACCESS NETWORK

  26. APPLICATION SPECIFIC IMPROVEMENTS

  27. 4. NEXT STEPS? 27

  28. EU ROADMAP 28 2019 • Release of 3,5 GHz &

    26 GHz frequency bands • Frequency attribution strategy definition • Frequency attribution auction open • 5G pilot projects and cities
  29. 29

  30. EU ROADMAP 30 2020 ▸ Frequency attribution: decisions ▸ First

    5G services in ~ 1 city / EU country 2025 - 2030 ▸ 5G available in metropolitan areas and along major transport axes
  31. @alexis0duque #DevoxxMA #5G #Mobile #Science Thanks! frama.link/5G-devoxx frama.link/rtone-jobs
