Reconciling Everything

A talk I gave at PyCon US 2023.

Transcript

1. EVERYTHING
   ANDREW GODWIN // @andrew@aeracode.org
   RECONCILING


   View Slide

2. Andrew Godwin / @andrew@aeracode.org
   Hi, I’m
   Andrew Godwin
   • Principal Engineer at Astronomer.io (Airflow)
   • Django Migrations, Channels, Async, others
   • Building distributed systems since 2008


   View Slide

3. Andrew Godwin / @andrew@aeracode.org
   Let's start with a bold statement
   I hear it drives engagement. Maybe also heckling.


   View Slide

4. Andrew Godwin / @andrew@aeracode.org
   Event-Driven Via Queues
   Totally separate stores of truth that only talk via queues
   Reconciliation Loops
   Stateless components that talk to one store of truth
   There are only two good* ways to build
   distributed systems**:


   View Slide

5. Andrew Godwin / @andrew@aeracode.org
   What is "good"?
   Low maintenance and high reliability, for me at least.


   View Slide

6. Andrew Godwin / @andrew@aeracode.org
   What kinds of distributed systems?
   Remember, friends don't let friends write microservices


   View Slide

7. Andrew Godwin / @andrew@aeracode.org
   Due to size
   What companies often claim is the reason
   Due to team structure
   What the actual reason often is
   Due to federation
   It's what the internet was built on!


   View Slide

8. Andrew Godwin / @andrew@aeracode.org
   RPC Microservices
   Email Service
   Accounting
   Service
   Billing Service
   Reservation
   Service


   View Slide

9. Andrew Godwin / @andrew@aeracode.org
   A system is defined by its failure modes
   Nobody gets paged when it's up and running happily


   View Slide

10. Andrew Godwin / @andrew@aeracode.org
    Event-Driven (Message Passing)
    Task Runners
    Billing System
    QUEUE
    QUEUE Log Storage
    Analytics
    Aggregator
    QUEUE


    View Slide

11. Andrew Godwin / @andrew@aeracode.org
    What kind of queue is it?
    Hint: It will not deliver messages exactly once


    View Slide

12. Andrew Godwin / @andrew@aeracode.org
    At-most-once
    In case of failure, a message will not get delivered
    At-least-once
    In case of failure, a messages will get delivered twice or more


    View Slide

13. Andrew Godwin / @andrew@aeracode.org
    Backlogs
    Need more queue consumers, can be asymmetric
    Replays
    I hope you can cope with lots of duplicates!
    Overflow
    Do you grind to a halt? Or drop?


    View Slide

14. Andrew Godwin / @andrew@aeracode.org
    Neither is "perfect"
    (But I recommend at-least-once unless you truly do not care about the data)


    View Slide

15. Andrew Godwin / @andrew@aeracode.org
    Reconciliation (Control) Loop
    Kubelet Deployment
    Controller
    DATABASE
    Pod Controller
    Kubectl (User)


    View Slide

16. Andrew Godwin / @andrew@aeracode.org
    Reconciliation (Control) Loop
    Kubelet Deployment
    Controller
    apiserver
    Pod Controller
    Kubectl (User)
    etcd


    View Slide

17. Andrew Godwin / @andrew@aeracode.org
    Kubernetes Example
    ● User creates a new Deployment
    ● Deployment controller notices that the deployment has no pods
    ○ To reconcile this, it makes one
    ● Pod controller notices that the pod is not assigned
    ○ To reconcile this, it assigns it to a node
    ● Kubelet notices it has an assigned pod that is not running
    ○ To reconcile this, it creates it locally and starts it


    View Slide

18. Andrew Godwin / @andrew@aeracode.org
    One "single point of failure" is great
    Keeping one service up is much simpler


    View Slide

19. Andrew Godwin / @andrew@aeracode.org
    So how do reconciliation loops fail?
    They slow down and halt, but with easy restarts and no data loss


    View Slide

20. Andrew Godwin / @andrew@aeracode.org
    Each controller must be stateless
    This lets you scale them up, down, restart, upgrade, and recover easily


    View Slide

21. Andrew Godwin / @andrew@aeracode.org
    Practical example: Takahē
    Of course I wrote an ActivityPub/Fediverse server!


    View Slide

22. Andrew Godwin / @andrew@aeracode.org


    View Slide

23. Andrew Godwin / @andrew@aeracode.org
    The Fediverse is an event-driven system
    Well, mostly. It's also imperfect and still evolving.


    View Slide

24. Andrew Godwin / @andrew@aeracode.org
    Making a single Fediverse post
    QUEUE
    Sending Client Origin API
    Fanout System
    Destination
    Inbox
    Timeline Builder Receiving Client
    QUEUE


    View Slide

25. Andrew Godwin / @andrew@aeracode.org
    A server needs background workers
    Both to fan out sending of posts, and to process incoming posts


    View Slide

26. Andrew Godwin / @andrew@aeracode.org
    Stator
    Takahē's state-machine reconciliation system


    View Slide

27. Andrew Godwin / @andrew@aeracode.org
    See more inside github.com/jointakahe/takahe


    View Slide

28. Andrew Godwin / @andrew@aeracode.org
    You can also do this with Airflow
    We have an Astronomer executor which uses this for running tasks


    View Slide

29. Andrew Godwin / @andrew@aeracode.org
    Airflow Example
    ● A Task Instance is scheduled to run, and the scheduler passes it over
    ● The Executor makes a new Workload for the Task Instance
    ● Allocator notices that the Workload has no Runner
    ○ To reconcile this, it assigns it to a runner
    ● Runner notices it has an assigned Workload that is not running
    ○ To reconcile this, it creates it locally and starts it


    View Slide

30. Andrew Godwin / @andrew@aeracode.org
    So, how should you build them?
    Carefully! Ha, ha.


    View Slide

31. Andrew Godwin / @andrew@aeracode.org
    All state in the central store
    You can maybe get away with caching elsewhere
    Zero service-to-service comms
    Communication paths are failure modes
    Controllers should be simple loops
    Query database, reconcile, repeat


    View Slide

32. Andrew Godwin / @andrew@aeracode.org
    They are easy to test and refactor
    Mocking your datastore is all that's needed; everything else should flow


    View Slide

33. Andrew Godwin / @andrew@aeracode.org
    They self-heal!
    Provided your datastore stays up, everything else is flexible


    View Slide

34. Andrew Godwin / @andrew@aeracode.org
    There are downsides - mostly max scale
    But I generally design systems with upper bounds on their throughput


    View Slide

35. Andrew Godwin / @andrew@aeracode.org
    The datastore will be your bottleneck
    But modern DBs are very capable - and you can do replicas!


    View Slide

36. Andrew Godwin / @andrew@aeracode.org
    Queues are still fine!
    If you need the complexity and scale, then great. But they are harder!


    View Slide

37. Andrew Godwin / @andrew@aeracode.org
    Remember, there's no universal solution
    Just please, please, avoid building a mess of microservices that do RPC calls


    View Slide

38. Thanks!
    Andrew Godwin
    andrew@aeracode.org
    Want to talk more about Takahē and ActivityPub protocols?
    Come to the Open Space at 3pm in Room 251AB!


    View Slide
