1. MAGNETIC LEVEL GAUGES MAGNETIC LEVEL GAUGES PRINCIPLES AND APPLICATIONS
2. MAGNETIC LEVEL GAUGES MAGNETIC LEVEL GAUGES manufactured By KLINGER Limited Perth Western Australia
3. MAGNETIC LEVEL GAUGES Klinger manufactured their first magnetic level gauge in Europe in 1981. Australian manufacture commenced in 1993. Klinger and their licensees produce in excess of 3500 magnetic level gauges per year.
4. MAGNETIC LEVEL GAUGES MAGNETIC LEVEL GAUGE Operating principle On the dry side of the chamber is the Indicator, a display of magnetic wafers (red/white). As the float moves up or down the magnetic field of the permanent magnet pulls the wafers through a rotation of 180° thus changing their colour. As the float rises the flaps are turned from white to red, as the float falls, they are changed back to white again. The level is represented at any given wafer without any external power supply. The instrument consists of 3 main parts The Float The Chamber The Indicator
5. MAGNETIC LEVEL GAUGES MAGNETIC LEVEL GAUGE
6. MAGNETIC LEVEL GAUGES THE DISPLAY UNIT MAGNETIC LEVEL GAUGE
7. MAGNETIC LEVEL GAUGES •  Unique patented system of edge magnetised injection moulded ferrite wafers •  Aluminium display housing is used as a standard and are certified IP 67 THE DISPLAY UNIT •  For corrosive environments a stainless steel housing is available this housing also meets IP 67 approval •  The display is the only one capable of accommodating media surges of up to 400mm per second
8. MAGNETIC LEVEL GAUGES THE DISPLAY UNIT
9. MAGNETIC LEVEL GAUGES THE FLOAT MAGNETIC LEVEL GAUGE
10. MAGNETIC LEVEL GAUGES THE FLOAT •  Utilizes a vertically mounted omni directional magnet system •  The float is not pressurized or vented •  It is unguided and free to rotate in the chamber •  The magnets used can accommodate temperatures of up to 400°C 400mm per second
11. MAGNETIC LEVEL GAUGES THE FLOAT
12. MAGNETIC LEVEL GAUGES 321 Stainless Steel Maximum Pressure 63 bar Maximum Temperature 400oC Specific Gravity Range 0.72-1.38 THE FLOAT MATERIALS OF CONSTRUCTION
13. MAGNETIC LEVEL GAUGES Titanium Grade 2 Maximum Pressure 90 bar Maximum Temperature 315oC Specific Gravity Range 0.45-1.6 THE FLOAT MATERIALS OF CONSTRUCTION
14. MAGNETIC LEVEL GAUGES Titanium Grade 5 Maximum Pressure 200 bar (In Steam 150 bar) Maximum Temperature 400oC Specific Gravity Range 0.71-2.15 THE FLOAT MATERIALS OF CONSTRUCTION
15. MAGNETIC LEVEL GAUGES Monel 400 Maximum Pressure 28 bar Maximum Temperature 400oC Specific Gravity Range 0.60-1.50 THE FLOAT MATERIALS OF CONSTRUCTION
16. MAGNETIC LEVEL GAUGES For corrosive applications, we can : 1. Use PP, PVDF or UPVC plastic floats for low temperature low pressure applications 2. Use PFA, PVDF, HALAR or Carbon coated stainless steel and titanium floats for higher temperature and higher pressure applications THE FLOAT MATERIALS OF CONSTRUCTION
17. MAGNETIC LEVEL GAUGES THE FLOAT To enable us to design a float, we need the following information : 1. Pressure 2. Media and concentration 3. Temperature 4. Specific gravity For interface applications , we need the following additional information : 1. Both media 2. Both specific gravities
18. MAGNETIC LEVEL GAUGES THE CHAMBER MAGNETIC LEVEL GAUGE
19. MAGNETIC LEVEL GAUGES Seamless Stainless Steel 316/316L Welded Stainless Steel 316/316L Plastics: PVC, PP, PVDF THE CHAMBER MATERIALS OF CONSTRUCTION
20. MAGNETIC LEVEL GAUGES Other materials available include: Alloy 825 Hastelloy C276 Titanium Sanicro 28 Monel 400 AISI 304 Teflon lined stainless steel THE CHAMBER MATERIALS OF CONSTRUCTION
21. MAGNETIC LEVEL GAUGES THE CHAMBER
22. MAGNETIC LEVEL GAUGES THE CHAMBER
23. MAGNETIC LEVEL GAUGES THE CHAMBER
24. MAGNETIC LEVEL GAUGES THE CHAMBER
25. MAGNETIC LEVEL GAUGES Welded or seamless pipe. ASME B31.3 construction is possible Butt weld , x-ray are all possible Conformity to NACE
26. MAGNETIC LEVEL GAUGES The dead band low (DBL) or high (DBH) are dependent on Level, Pressure and Specific gravity. This corresponds to the minimum level of liquid to operate the float and the maximum level above that no higher levels are indicated MAGNETIC LEVEL GAUGE Top Mounted Gauge
27. MAGNETIC LEVEL GAUGES SWITCHES MAGNETIC LEVEL GAUGE H2 H1
28. MAGNETIC LEVEL GAUGES TYPE DR2 TYPE DR3 TYPE DR8 SWITCHES Type DR2 is a EEx ia IIC T3-T6 approved switch Type DR3 is for non hazardous areas Type DR8 is a EExd IIC T3-T6 approved switch
29. MAGNETIC LEVEL GAUGES Max contact rating 60VA Max switching current 1amp AC /0.5amp DC Max switching voltage 230V AC/DC Temperature range - 40oC - +150oC Approved EExia IIC T3- T6 (DR2) Simple apparatus (DR3) Approved EExd IIC T3- T6 (DR8) DR2/DR3/DR8 SPECIFICATIONS SWITCHES
30. MAGNETIC LEVEL GAUGES TYPE DR4 SWITCHES High temperature switch for safe area Type SPDT: Bistable
31. MAGNETIC LEVEL GAUGES SWITCHES DR4 SPECIFICATIONS Contact Reed Contact Contact Type 1 SPDT (Bistable) Switch Rating 230V AC, 60VA, 1 AMP 230V DC, 30W 0.5AMP Max Temperature 380ºC Cable Connection M20 Entry Housing Aluminium (Coated Red) Housing Protection IP65
32. MAGNETIC LEVEL GAUGES TYPE DR6 SWITCHES A robust corrosion, temperature, explosion proof switch Available in 2 types: SR – DPST switch CR – DPDT switch Microswitch version available – up to 6 amp capacity
33. MAGNETIC LEVEL GAUGES SWITCHES DR6 SPECIFICATIONS Approval EX version : EEx d IIC T4-T6 EX version : EEx d IIC T4-T6 Actuation Latching Reed Latching Reed Reed configuration SPDT DPDT Maximum contact rating 250 VA 250 VA Max. switching current 1 amp AC / 0.5amp DC 1 amp AC / 0.5amp DC Maximum switch voltage 230 V AC 230 V AC Switch housing Aluminium Aluminium Protection IP 66 IP 66 Temperature range - 50°C + 150°C - 50°C + 150°C 150°C + with insulation 150°C + with insulation DR6 type SR DR6 type CR
34. MAGNETIC LEVEL GAUGES LIQUID LEVEL TRANSMITTER KTX.IS and KTX.EXD
35. MAGNETIC LEVEL GAUGES Integral head electronics with M20 cable connections Transmitter Magnetic level gauge Flanged end connected arrangement Transmitter with alternative mounting KTX.IS and KTX.EXD
36. MAGNETIC LEVEL GAUGES •  Uses a 2 wire 4-20 mA current loop. •  It has standard 10mm resolution. A 20mm & 5mm resolution is an extra- option. KTX.IS and KTX.EXD TRANSMITTER FEATURES
37. MAGNETIC LEVEL GAUGES •  Can transmit up to a distance of 6km. •  It is very easy to fit and can be retro fitted. TRANSMITTER FEATURES KTX.IS and KTX.EXD
38. MAGNETIC LEVEL GAUGES •  Is available in a single length up to 6.5m •  Standard aluminium head transmitter approved to EExia IIc T4-T6 & EExd IIC T4-T6 •  Stainless steel head option is available •  Hart (Smart) optional •  Profibus / Foundation Fieldbus optional TRANSMITTER FEATURES KTX.IS and KTX.EXD
39. MAGNETIC LEVEL GAUGES Linear Transducer Magnetostrictive Transmitter KMS 2 TRANSMITTER Magnetostrictive Transmitter Mk II
40. MAGNETIC LEVEL GAUGES Magnetostrictive Transmitter Mk II HART communications E Exia & E Exd approvals (IEC EX) Microprocessor Based 2-wire loop 4-20 mA Continuous & high accuracy measurement Simple push button calibration Resolution & repeatability 0.8mm Float failure alarm Can be retrofitted to TC-Klinger MLG KMS 2 TRANSMITTER
41. MAGNETIC LEVEL GAUGES ‘LevelSure’ NEW PRODUCT Combined Magnetic Level Indicator and Guided Wave Radar
42. MAGNETIC LEVEL GAUGES ‘LevelSure’ NEW PRODUCT Guided wave radar – microwave pulses are transmitted along a waveguide suspended from the top of the measuring chamber. As the pulses come in contact with the media they are reflected back along the waveguide and are detected at the electronics in the headshell. The time elapsed is measured to determine the liquid level with a measurement accuracy of +- 3mm
43. MAGNETIC LEVEL GAUGES ‘LevelSure’ NEW PRODUCT Two independent levels in one instrument Guided Wave Radar and Float technology Additional 4-20 mA signals from Reed chain or Magnetostrictive transmitters Radar can be isolated from main chamber for maintenance (By-pass option only)
44. MAGNETIC LEVEL GAUGES ‘LevelSure’ NEW PRODUCT 2 Options:- By-Pass Mounted Radar Longer lengths Cost effective Simpler construction Radar Isolation possible
45. MAGNETIC LEVEL GAUGES NEW PRODUCT
46. MAGNETIC LEVEL GAUGES ‘LevelSure’ NEW PRODUCT 2 Options:- Integral Mounted Radar Compact unit Guided float system Limited placement of display, switch & transmitter position
47. MAGNETIC LEVEL GAUGES What are the positive benefits of using a TC-Klinger Magnetic Level Gauge ? BENEFITS
48. MAGNETIC LEVEL GAUGES •  It is easy to read and accurately responds to level change. •  The possibility of leakage to atmosphere is remote, making it particularly suitable for use with hazardous fluids. BENEFITS
49. MAGNETIC LEVEL GAUGES •  The powerful omni-directional magnet system ensures total harmony with the display, switches + transmitters irrespective of conditions. •  Automatic float warning systems fitted as standard BENEFITS
50. MAGNETIC LEVEL GAUGES •  It can withstand pressures of up to 200 bar. •  Has a wide standard specific gravity range 0.45 – 2.15 A wide temperature range from -120oC to +400oC. BENEFITS
51. MAGNETIC LEVEL GAUGES •  The TC-Klinger MLG can be produced in any length. •  It is simple to install and relatively maintenance free BENEFITS
52. MAGNETIC LEVEL GAUGES •  Alarm switches can be fitted to the gauges. •  Via a transmitter the gauge offers remote as well as local display. •  ISO 9001 approved quality with ATEX and PED approvals BENEFITS
53. MAGNETIC LEVEL GAUGES TYPICAL CUSTOMERS •  International contractors •  Gas •  Chemicals •  Power generation •  Hydrocarbons •  Food & Drink •  Pharmaceuticals
54. MAGNETIC LEVEL GAUGES Magnetic level gauges are used across a broad sector of industry : •  Power Generation •  Pharmaceutical •  Petrochemical •  Food & drink industries •  Water treatment •  Gas distribution •  Sugar refining •  Pulp and paper •  Mining •  Oil exploration •  Shipping
55. MAGNETIC LEVEL GAUGES REFERENCES •  BOROUGE •  RELIANCE PETROLEUM •  WEIR WESTGARTH •  ALFA LAVAL •  SASOL •  LINDE •  LURGI •  CALTEX •  SHELL •  DSM •  AKZO •  ELF •  BP •  SANTOS •  NORSK HYDRO •  BECHTEL •  TOTAL •  ELF
56. MAGNETIC LEVEL GAUGES TC Fluid Control are ISO 9001 approved for the manufacture of Magnetic Level Gauges. We can also supply TüV , Lloyds, FM and ATEX and PED approvals. APPROVALS
57. MAGNETIC LEVEL GAUGES Thank you for your time
