Docker orchestration with Kubernetes

Support for my talk at the AWS UG Munich Meetup (April 2015)

Transcript

1. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Docker orchestration with Kubernetes Managing containers at scale */koo-ber-nay’-tace/ *
2. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Who I am Antoine Cotten Technical operations engineer @ Freeletics GmbH What I do • Virtualisation, private clouds • Automation, conf management • Docker orchestration • Continuous integration
3. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP What this talk is not “about Docker” Contributor’s point of view Comparison with other container orchestrators
4. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP What it is Introduction to Google Kubernetes Live demo Experience sharing on AWS integration End-user oriented
5. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Motivation n°1
6. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Portability Abstraction level Build once, run anywhere Clear deliverable
7. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Motivation n°2
8. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Efficiency Reduce deploy overhead Boost scaling times provision VM / EC2 deploy OS / AMI config mngmt fail? no deploy app yes 14’
9. The realities of Docker in production When the puzzle pieces don’t quite fit http://blog.heavybit.com/blog/2015/3/23/dockermeetup
10. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Recipe for composing a distributed app Composition put together parts of application Scheduling run each bit on appropriate machine Networking ensure everyone can talk to each other Storage persist data
11. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP http://comp.photo777.org
12. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Enter Kubernetes
13. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Why Kubernetes? Orchestration Service discovery Load balancing Storage drivers Configuration management
14. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Architecture
15. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Node { "kind": "Node", "apiVersion": "v1beta3", "metadata": { "name": "ip-172-20-0-10.eu-west-1.compute.internal", "selfLink": "/api/v1beta1/nodes/ip-172-20-0-10.eu-west-1.compute.internal", "uid": "2b6e26fa-e350-11e4-87e9-0aa01ffbf345", "resourceVersion": "5954", "creationTimestamp": "2015-04-15T09:16:59Z" }, "spec": { "externalID": "i-755d0e93" }, "status": { "capacity": { "cpu": "2", "memory": "4046840Ki" }, "conditions": [ { "type": "Ready", "status": "True", "lastHeartbeatTime": "2015-04-15T11:55:16Z", "lastTransitionTime": "2015-04-15T10:58:00Z", "reason": "kubelet is posting ready status" } ], "addresses": [ { "type": "LegacyHostIP", "address": "172.20.0.10" } ], "nodeInfo": { "machineID": "046c50ecad79db790335c77454f7a66f", "systemUUID": "EC26CFE0-6753-82CA-40BC-D325E6710CD3", "bootID": "24ba1fdf-9072-4a4a-9c60-d619db66a312", "kernelVersion": "3.13.0-46-generic", "osImage": "Ubuntu 14.04.2 LTS", "containerRuntimeVersion": "docker://Unknown", "kubeletVersion": "v0.15.0", "KubeProxyVersion": "v0.15.0" } } }
16. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Kubernetes work units pod replication controller (rc) service (se)
17. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Pod collocated group of Docker containers shared volumes, shared network created individually… …but usually scaled using a replication controller Node pod cont cont cont
18. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Pod { "kind": "Pod", "apiVersion": "v1beta3", "metadata": { "name": "redis-master-5bch6", "selfLink": "/api/v1beta1/pods/redis-master-5bch6?namespace=default", "creationTimestamp": "2015-04-15T12:05:23Z", "labels": { "name": "redis-master" } }, "spec": { "volumes": null, "containers": [ { "name": "master", "image": "dockerfile/redis", "ports": [ { "containerPort": 6379, "protocol": "TCP" } ], } ], "restartPolicy": "Always", "host": "ip-172-20-0-10.eu-west-1.compute.internal" }, "status": { "phase": "Running", "podIP": "10.244.1.17", "containerStatuses": [ { "name": "master", "state": { "running": { "startedAt": "2015-04-15T12:05:27Z" } }, "ready": true, "restartCount": 0, "image": "dockerfile/redis", } ] } }
19. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Node Node Node Node Replication controller manage lifecycle of pods enforce number of running pods across cluster rolling updates Replication controller pod pod pod pod pod
20. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP RC { "kind": "ReplicationController", "apiVersion": "v1beta3", "metadata": { "name": "redis-master", "selfLink": "/api/v1beta1/replicationControllers/redis-master?namespace=default", "creationTimestamp": "2015-04-15T12:05:23Z", "labels": { "name": "redis-master" } }, "spec": { "replicas": 1, "selector": { "name": "redis-master" }, "template": { "metadata": { "labels": { "name": "redis-master" } }, "spec": { "volumes": null, "containers": [ { "name": "master", "image": "dockerfile/redis", "ports": [ { "containerPort": 6379, "protocol": "TCP" } ] } ], "restartPolicy": "Always" } } }, "status": { "replicas": 1 } }
21. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Service provide name and address for a set of pods can integrate with local DNS act as basic load balancers… …or create external load-balancers via cloud-provider integration Service pod pod pod pod pod
22. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Service
23. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP SE { "kind": "Service", "apiVersion": "v1beta3", "metadata": { "name": "redis-master", "namespace": "default", "selfLink": "/api/v1beta1/services/redis-master?namespace=default", "uid": "b20bac8e-e367-11e4-87e9-0aa01ffbf345", "resourceVersion": "6227", "creationTimestamp": "2015-04-15T12:05:23Z", "labels": { "name": "redis-master" } }, "spec": { "ports": [ { "name": "redis", "protocol": "TCP", "port": 6379, "targetPort": 6379 } ], "selector": { "name": "redis-master" }, "portalIP": "10.0.59.191", "sessionAffinity": "None" }, "status": {} }
24. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP rc Exemple Guestbook app frontend (pod) frontend (pod) frontend (service) redis-master (pod) redis-slave (pod) redis-master (service) redis-slave (service) redis-slave (pod) rc
25. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP
26. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Provisionning
27. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Kube up 1. Creates instances 2. Runs Salt 3. Runs add ons 4. Configures workstation $ export KUBERNETES_PROVIDER=aws $ export KUBE_AWS_ZONE=eu-west-1a $ export MINION_SIZE=t2.medium $ export NUM_MINIONS=2 $ ./kube-up.sh Ubuntu 14.04 Manual network config Not much control
28. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Cloudformation Cloud-config Limited Unsecure Cloud-config Works great with CoreOS Easy to re-use Need to rely on configuration management to make it fully functional * Ansible * Puppet-on-Coreos (https://github.com/jumanjihouse/puppet-on-coreos) +
29. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Cloudformation
30. AWS/CLOUD COMPUTING UG MUNICH APRIL MEETUP Thank you for listening! Questions?
