Elements of Learning Systems (Tianqi Chen, Carnegie Mellon University | OctoML)

Data, models, and computing are the three pillars that enable machine learning to solve real-world problems at scale. Making progress on these three domains requires not only disruptive algorithmic advances but also systems innovations that can continue to squeeze more efficiency out of modern hardware. Learning systems are at the center of every intelligent application nowadays. However, the ever-growing demand for applications and hardware specialization creates a huge engineering burden for these systems, most of which rely on heuristics or manual optimization. In this talk, I will discuss approaches to reduce these manual efforts. I will cover several aspects of such learning systems, including scalability, ease of use, and more automation. I will discuss these elements using the real-world learning systems that I built -- XGBoost and Apache TVM.

Transcript

1. Elements of Learning Systems Tianqi Chen
2. Software Landscape Wide Range of Applications Python LLVM/Cla ng . … Software Libraries •Broad coverage. •Compute performance is less critical. •Engineers handles most optimizations
3. AI Software Landscape ML Models Data Comput e •Diverse and fast evolving models •Big data •Specialized compute acceleration Transformer, ResNet, LSTM … …
4. Learning Systems Data science for everyone Deploy AI everywhere Acknowledgement: work from many open-source community members
5. Elements of Learning Systems Accessible and scalable Intelligent automated by machine learning Full stack, systems and hardware co-design
6. Elements of Learning Systems Accessible and scalable Intelligent automated by machine learning Full stack, systems and hardware co-design
7. Learning Systems Data science for everyone Deploy AI everywhere Acknowledgement: work from many open-source community members
8. A Scalable Tree Boosting System XGBoost: A Scalable Tree Boosting System. Chen and Guestrin. KDD 16 System for gradient tree boosting
9. Impact of XGBoost De-facto tool for data science 498 contributors, 21k stars on GitHub XGBoost: A Scalable Tree Boosting System. Chen and Guestrin. KDD 16
10. Technical Highlights •Automatic miss-value modeling •Sparse-aware tree learning • Weighted quantile sketch for approximate tree learning • Cache-aware parallelization • Out of core computation XGBoost: A Scalable Tree Boosting System. Chen and Guestrin. KDD 16
11. Automatic Missing-Value Modeling Samples V1 V2 X1 ? TRUE X2 15 ? X3 25 FALSE Missing Values V1 < 20 V2? Y N N Y X2 X1 X3 Default directions
12. Platform Agnostic Learning System Platform A Platform B SVM A MF A SVM A MF A Rabit abstration XGBoost Rabit abstration XGBoost Single Machine XGBoost Implementation of learning packages tied to each platform Depend on reusable abstractions(allreduce), not platforms. Portable to different platforms.
13. Use XGBoost as a Part of Your Platform In any language On any Platform • YARN, MPI, Dask, Spark, Ray ... • Easily extendible to distributed executors
14. Learning Systems Data science for everyone Deploy AI everywhere Acknowledgement: work from many open-source community members
15. Elements of Learning Systems Accessible and scalable Intelligent automated by machine learning Full stack systems and hardware co-design
16. Problem: Machine Learning Deployment Model Hardware Backends Deploy
17. Existing Deep Learning Frameworks High-level data flow graph Hardware Primitive Tensor operators such as Conv2D Offload to heavily optimized DNN operator library Frameworks
18. Limitations of Existing Approach cuDNN Frameworks Engineering intensive New operators introduced
19. Machine Learning based Program Optimizer TVM: Learning-based Learning System High-level data flow graph and optimizations Hardware Frameworks
20. Problem Setting Search Space of Possible Program Optimizations Low-level Program Variants
21. Example Instance in a Search Space Vanilla Code Search Space of Possible Program Optimizations
22. Example Instance in a Search Space Loop Tiling for Locality Search Space of Possible Program Optimizations
23. Example Instance in a Search Space Map to Accelerators Search Space of Possible Program Optimizations
24. Optimization Choices in a Search Space Loop Transformations Thread Bindings Cache Locality Thread Cooperation Tensorization Latency Hiding Billions of possible optimization choices
25. Problem Formalization Search Space Expression AutoTVM Progra m Cost: Execute Time Code Generator Optimization Configuratio n
26. Statistical Cost Model Search Space Expression AutoTVM Code Generator Training data Benefit: Automatically adapt to hardware type Statistical Cost Model learnin g
27. Optimization Search Space Construction Hardware Search space: Possible mappings from the expression to valid hardware programs Based on Halide’s compute/schedul e separation What is the search space
28. Search Space for CPUs L1D L1I L2 L3 L1D L1I L2 Compute Primitives scala r vecto r Memory Subsystem Loop Transformations Cache Locality Vectorization CPU s Reuse primitives from prior work: Halide, Loopy
29. Hardware-aware Search Space CPUs GPUs TPU-like specialized Accelerators
30. Search Space for TPU-like Specialized Accelerators Tensor Compute Primitives Unified Buffer Acc FIFO Explicitly Managed Memory Subsystem TPU s
31. Tensorization Challenge Compute primitives scalar vector tensor Challenge: Build systems to support emerging tensor instructions
32. Tensorization Challenge A = tvm.placeholder((8, 8)) B = tvm.placeholder((8,)) k = tvm.reduce_axis((0, 8)) C = tvm.compute((8, 8), lambda y, x: tvm.sum(A[k, y] * B[k], axis=k)) Tensorization
33. TVM: End to end Machine Learning Optimizer
34. TVM Case Study TVM log 2 fold improvement over baseline Over 60 model x hardware benchmarking studies Each study compared TVM against best* baseline on the target Sorted by ascending log 2 gain over baseline Model x hardware comparison points
35. Why ML Compilation: TVM Case Study at OctoML Model x hardware comparison points TVM log 2 fold improvement over baseline 34x for Yolo-V3 on a MIPS based camera platform 5.3x: video analysis model on Nvidia T4 against TensorRT 4x: random forest on Nvidia 1070 against XGBoost 2.5x: MobilenetV3 on ARM A72 CPU Source:
36. New Hardware Support -- Apple M1 Source: • 22% faster than CoreML on CPU • 49% faster on GPU • After only a few engineering weeks of effort
37. Open Source Community Apache Top-level Project Independent governance Open Source Code Open Development Open Governance
38. Elements of Learning Systems Accessible and scalable Intelligent automated by machine learning Full stack, systems and hardware co-design
39. Thank You •XGBoost https://xgboost.ai •Apache TVM https://tvm.apache.org/
