1. @fmaelbrancke #DV14 #AndroidTesting Testing your Android app Filip Maelbrancke AppFoundry
2. Your host Filip Maelbrancke Consultant @ AppFoundry ! filip.maelbrancke@appfoundry.be @fmaelbrancke
3. Android & Testing 01 02 03 Why? What? How?
8. Testing Avoid problems Android testing
9. TESTING Manual testing is tedious Humans are not very good at testing But computers are...
10. “Computers are designed to do simple repetitive tasks. The second you have humans doing repetitive tasks, all the computers get together late at night and laugh at you...” Neil Ford
11. Manual vs Automated
12. Manual vs Automated
13. Manual vs Automated
14. Mitigate issues? Be pro-active… and test.
15. EXCUSES We never make mistakes! The functionality is trivial Tests slow us down Management won’t let us WE = HERO TRIVIAL SLOW MANAGEMENT ǩ
16. TEST TRAITS (UNIT) TESTS ISOLATED REPEATABLE FAST SELF-DOCUMENTING ž
17. Repeatability (no matter what development stack he uses) in which they are being run Tests need to be run by every developer ♂ Tests must not rely on the environment
18. Speed The shorter, the less distraction less of an interruption to our workflow
19. Speed The shorter, the less distraction less of an interruption to our workflow
20. Self-documenting Testable code = clear Testable code = easy to follow we can just look at the test No need to explain how a component works No need to write documentation tests = usage examples
21. Tests should also be … Easy to execute Easy to debug Realistic Fluent API
22. Unit tests are real measure of project health and code quality
23. Android dev
24. Test types Unit tests Ŷ Functional tests Ŷ Acceptance tests Ŷ Integration tests Ŷ Regression tests Ŷ
25. Black and white Black box tests Ŷ Without knowledge Ŷ Testing software knows Ŷ White box tests Ŷ and tests the internal structures / workings of an application of the application
26. Black and white Black box tests Ŷ White box tests Ŷ • tests for precision / correctness • tester knows + is testing internal structure of the application • unit / integration testing • application internal structure is not known to the tester
 • acceptance / system testing
28. d.android.com
29. developer.android.com testing JUnit Ŷ Instrumentation tests Ŷ Monkey / MonkeyRunner Ŷ
30. Android testing start with the test prefix called setUp() called tearDown() Uses JUnit 3 Ŷ test methods Ŷ setup method Ŷ clean up method Ŷ
31. JUnit 3 JUnit 3 test import junit.framework.*;
 public class MyTestClass extends TestCase {
 @Override
 protected void setUp() throws Exception {
 super.setUp();
 ...
 }
 public void testMethodName() throws Exception {
 ...
 }
 }
32. Android testing to test Android components > junit.framework.TestCase to test a class that does not call the Android API > junit.framework.TestCase Uses JUnit 3 Ŷ plain JUnit Ŷ Android JUnit extensions Ŷ AndroidTestCase Ŷ InstrumentationTestCase Ŷ
33. Instrumentation component / application lifecycle the system has with the app independently from normal lifecycle loaded into the same process Set of hooks into Android Ŷ hooks control Android component Ŷ Monitor interaction Ŷ Test package + app under test Ŷ invoke methods Ŷ modify and examine fields Ŷ
34. Instrumentation Process Test package InstrumentationTestRunner Application package Test case classes JUnit
35. Instrumentation touches
 taps
 scrolling Runs on device/emulator Ŷ Can be started from IDE/shell Ŷ Allows direct control of UI Ŷ
36. Instrumentation Test Activity state saving and restoration // Start the main activity of the application under test
 mActivity = getActivity();
 // Get a handle to the Activity object's main UI widget, a Spinner
 mSpinner = (Spinner)mActivity.findViewById(com.android.example.spinner.R.id.Spinner);
 // Set the Spinner to a known position
 mActivity.setSpinnerPosition(TEST_STATE_DESTROY_POSITION);
 // Stop the activity - The onDestroy() method should save the state of the Spinner
 mActivity.finish();
 // Re-start the Activity - the onResume() method should restore the state of the Spinner
 mActivity = getActivity();
 // Get the Spinner's current position
 int currentPosition = mActivity.getSpinnerPosition();
 // Assert that the current position is the same as the starting position
 assertEquals(TEST_STATE_DESTROY_POSITION, currentPosition);
37. Android test case AndroidTestCase Ŷ InstrumentationTestCase Ŷ junit.framework.Assert junit.framework.TestCase Android test case classes
38. Assert assertEquals assertTrue assertFalse fail assertNull assertNotSame assertSame assertNotNull Assert
39. ViewAssertions
40. AndroidTestCase ApplicationTestCase Ŷ ProviderTestCase2 Ŷ ServiceTestCase Ŷ
41. InstrumentationTestCase ActivityInstrumentationTestCase2 Ŷ … Ŷ
42. Android instrumentation tests Application Ŷ Activity Ŷ Service Ŷ Content provider Ŷ
43. Isolate tests from the system MockApplication Ŷ MockContext Ŷ MockResources Ŷ MockContentProvider Ŷ MockContentResolver Ŷ MockPackageManager Ŷ
44. Test runner against and Android application Instrumentation runs TestCases Ŷ default config Ŷ test runner android { defaultConfig { testInstrumentationRunner "android.test.InstrumentationTestRunner" } }
45. Your first instrumentation test Activity test ! import android.test.ActivityInstrumentationTestCase2; ! public class ActivityTest extends ActivityInstrumentationTestCase2<Activity> { ! public ActivityTest() { super(Activity.class); } ! public void testSomething() { // test code ! } }
46. Testing demo Testing a temperature converter ☼
47. Testing demo Simple master-detail app ☼
48. Your first instrumentation test Activity test private ConverterActivity activity;
 private EditText celsiusTextField;
 private TextView fahrenheitTextField;
 private TextView celsiusTextLabel;
 private TextView fahrenheitTextLabel;
 private Button convertButton;

 @Override
 protected void setUp() throws Exception {
 super.setUp();
 activity = getActivity();
 celsiusTextField = (EditText) activity.findViewById(R.id.celsius_textview);
 fahrenheitTextField = (TextView) activity.findViewById(R.id.fahrenheit_textview);
 celsiusTextLabel = (TextView) activity.findViewById(R.id.celsius_label);
 fahrenheitTextLabel = (TextView) activity.findViewById(R.id.fahrenheit_label);
 convertButton = (Button) activity.findViewById(R.id.conversion_button);
 }
49. Your first instrumentation test Activity test public void testConversion() {
 // instrumentation commands
 TouchUtils.tapView(this, celsiusTextField);
 sendKeys(KeyEvent.KEYCODE_1, KeyEvent.KEYCODE_2);
 TouchUtils.tapView(this, convertButton);

 // check result against expected value
 String actualFahrenheit = fahrenheitTextField.getText().toString();
 String expected = "53.6";
 assertEquals("Temperature conversion incorrect", expected, actualFahrenheit);
 }!
50. Testing in an app in application project for testing using the Android testing framework Testing = integrated Ŷ No separate test project needed Ŷ main sourceSet Ŷ androidTest sourceSet Ŷ test apk is build Ŷ deploy to device Ŷ
51. Testing in an app assembleTest build tests task Ŷ test sourceSet dependencies Ŷ test dependencies dependencies { androidTestCompile 'com.google.guava:guava:18.0' }
52. Running tests ensure both your app and the test app are built! run in parallel on all devices both apps Build Ŷ Install Ŷ Run the tests Ŷ Uninstall both apps Ŷ Multiple devices Ŷ connectedCheck Ŷ
53. Test report build/outputs/androidTest-results build/reports/androidTests xml test results Ŷ html test report Ŷ
54. Drawbacks / limitations of implementation details you often have to add things like Thread.sleep(1000) to make tests always work Required knowledge Ŷ Flakiness Ŷ Complex Ŷ Tests run slow Ŷ
55. Drawbacks / limitations • widget IDs • widget properties • what has focus • … • menus • … when the UI changes -> tests often need dramatic changes too Deep knowledge required Ŷ Deep Android knowledge Ŷ Makes for brittle tests Ŷ
56. Instrumentation testing with Robotium Instrumentation testing framework Simplify tests making
57. Robotium Easier to write Ŷ Automatic timing / delays Ŷ Test execution is faster Ŷ Find views Ŷ
58. Robotium Write tests with Solo Ŷ Robotium main class public void setUp() { solo = new Solo(getInstrumentation(), getActivity()); ! }
59. Robotium API get views getView()
 getButton()
 getImage() … clicks clickOnButton()
 clickOnEditText()
 … scroll scrollListToTop()
 scrollDownList(index)
 … take screenshot takeScreenshot() send keys sendKey()
 … checks isCheckBoxChecked()
 isRadioButtonChecked()
 … wait waitForActivity()
 waitForDialogToOpen()
 … type typeText(index, text)
 typeText(id, text)
 … Solo
60. Instrumentation testing Testing a temperature converter ☼
61. Plain instrumentation test Activity test private ConverterActivity activity;
 private EditText celsiusTextField;
 private TextView fahrenheitTextField;
 private TextView celsiusTextLabel;
 private TextView fahrenheitTextLabel;
 private Button convertButton;

 @Override
 protected void setUp() throws Exception {
 super.setUp();
 activity = getActivity();
 celsiusTextField = (EditText) activity.findViewById(R.id.celsius_textview);
 fahrenheitTextField = (TextView) activity.findViewById(R.id.fahrenheit_textview);
 celsiusTextLabel = (TextView) activity.findViewById(R.id.celsius_label);
 fahrenheitTextLabel = (TextView) activity.findViewById(R.id.fahrenheit_label);
 convertButton = (Button) activity.findViewById(R.id.conversion_button);
 }
62. Your first instrumentation test Activity test public void testConversion() {
 // instrumentation commands
 TouchUtils.tapView(this, celsiusTextField);
 sendKeys(KeyEvent.KEYCODE_1, KeyEvent.KEYCODE_2);
 TouchUtils.tapView(this, convertButton);

 // check result against expected value
 String actualFahrenheit = fahrenheitTextField.getText().toString();
 String expected = "53.6";
 assertEquals("Temperature conversion incorrect", expected, actualFahrenheit);
 }!
63. Robotium test Robotium test public void testConversion() {
 solo.enterText(0, "12");
 solo.clickOnButton("Convert!");
 assertTrue(solo.searchText("53.6"));
 }
64. Robotium setup Robotium dependency Ŷ Uses SDK test runner Ŷ Robotium dependency dependencies { ! androidTestCompile ‘com.jayway.android.robotium:robotium-solo:5.2.1’ ! }
65. Robotium test base class Robotium base /**
 * Base class for Activity Instrumentation tests that utilise Robotium.
 */
 public abstract class RobotiumActivityInstrumentationTestCase<T extends Activity> extends
 ActivityInstrumentationTestCase2<T> {

 protected Solo solo;

 public RobotiumActivityInstrumentationTestCase(Class<T> activityClass) {
 super(activityClass);
 }

 @Override
 protected void setUp() throws Exception {
 super.setUp();
 solo = new Solo(getInstrumentation(), getActivity());
 }

 @Override
 protected void tearDown() throws Exception {
 super.tearDown();
 solo.finishOpenedActivities();
 }
 }
66. Robotium: ListView Robotium list public void testClickOnHowardInlist() {
 solo.clickOnText("Howard Wolowitz");
 }

 public void testClickOnSecondItemInList() {
 solo.clickInList(2);
 }
67. Robotium: menu item Robotium menu item public void testClickInfoMenuItem() {
 // open the ActionBar overflow
 solo.sendKey(KeyEvent.KEYCODE_MENU);
 solo.clickOnText("Info");
 }
68. Robotium: intra-activity Robotium wait & see public void testClickingOnPersonShouldShowDetails() {
 int ACTIVITY_WAITING_TIMEOUT = 10000;
 // first activity should start
 assertThat(solo.waitForActivity(PersonListActivity.class, ACTIVITY_WAITING_TIMEOUT), is(true));
 // click on a person
 solo.clickOnText("Howard Wolowitz");

 assertThat(solo.waitForActivity(PersonDetailActivity.class, ACTIVITY_WAITING_TIMEOUT), is(true));
 }
69. Robotium errors Robotium error junit.framework.AssertionFailedError:
 Button with text: 'test button' is not found!
 ! at com.robotium.solo.Getter.getView(Getter.java:67) at com.robotium.solo.Solo.getButton(Solo.java:1957) at com.devoxx.android.bigbang.test.RobotiumTests.testErrorMessages(RobotiumTests.java:24) public void testErrorMessages() {
 solo.getButton("test button");
 }
70. Robotium webview getWebElement(By by)
 clickOnWebElement(By by)
 enterTextInWebElement(By by) based on:
 id - tagName - textContent - className

 e.g. By.className(String className) Can interact with WebView Ŷ Select web content Ŷ Interact with web content Ŷ
71. Assert! Don’t assume Ŷ Assert Ŷ
72. Expressiveness 
73. Hamcrest assertThat(audience, is(payingAttention())) Verification Mocking Assertions
74. Hamcrest Library of matchers Ŷ Syntactic sugar Ŷ Assert assertThat(someString, is(equalTo(“Expected”))); actual value expectation on the value (Matcher)
75. Hamcrest Assert Hamcrest assertEquals(“Conversion failed”, “Expected”, someString); assertThat(someString, is(equalTo(“Expected”)));
76. Hamcrest: collections Assert assertEquals(person, bigbangCharacters.getPersons().iterator().next()); Hamcrest assertThat(bigbangCharacters.getPersons(), hasItem(person));
77. Hamcrest matchers Core anything
 is
 … Logical allOf
 anyOf
 not Object equalTo
 instanceOf
 (not)nullValue Custom Beans hasProperty Text equalToIgnoringCase
 startsWith
 … Number greaterThan(OrEqualTo)
 closeTo Collections hasItem, hasItems
 hasItemInArray
78. Hamcrest Lots of useful matchers Ŷ Custom matchers Ŷ not a number public void testSquareRootOfMinusOneIsNotANumber() {
 assertThat(Math.sqrt(-1), is(notANumber()));
 }
79. Hamcrest custom matcher Hamcrest matcher /**
 * Hamcrest matcher: test if a double has the value NaN (not a number)
 */
 public class IsNotANumber extends TypeSafeMatcher<Double> {

 @Override
 public boolean matchesSafely(Double number) {
 return number.isNaN();
 }

 public void describeTo(Description description) {
 description.appendText("not a number");
 }

 @Factory
 public static <T> Matcher<Double> notANumber() {
 return new IsNotANumber();
 }
 }
81. Espresso
82. Espresso on top of Instrumentation APIs Google’s new approach Ŷ Abstraction layer Ŷ * GTAC 10/2013 Ŷ Android API level ≥ 8 Ŷ Open source Ŷ https://code.google.com/p/android-test-kit/
83. Espresso readable tests fast based on Matchers Fluent API Ŷ Extensible Ŷ Better debugging / logging Ŷ Performance Ŷ
84. Espresso Easy API for test authors Find view Do stuff with view Check some state Without • waitUntil(timeout) • boilerplate
85. Espresso API onView(Matcher<View>) onData(Matcher<Object>) onView(Matcher<View>) onView(Matcher<View>) withId() / withText() is() / instanceOf() click() / enterText() / scrollTo() matches(Matcher<View>) isDisplayed / isEnabled / hasFocus withText / … Find stuff Do stuff Check
86. Espresso Espresso onView(withId(R.id.some_id)).perform(click());

 onView(withText("Hi there”)).check(matches(isDisplayed()));

 onView(withId(R.id.some_id)).check(matches(withText(containsString(“someString”))));

 onData(is(someObject)).perform(click());
87. Espresso Adapter views onData Ŷ Espresso ViewAction // search for a row and perform action
 onData(hasToString(startsWith("Sheldon"))).perform(click()); ! onData(is(instanceOf(DummyData.BigBangCharacter.class)))
 .atPosition(5)
 .perform(click()); ! // search for a row, and perform an action on a child view
 onData(hasToString(startsWith("Amy")))
 .onChildView(withId(R.id.list_item_photo))
 .perform(click());
88. Espresso swiping Espresso swiping public void testSwipingBackAndForward() {
 // Should be on position 0 to start with.
 onView(withText("Position #0")).check(matches(isDisplayed()));

 // Swipe left once.
 onView(withId(R.id.pager_layout)).perform(swipeLeft());

 // Now position 1 should be visible.
 onView(withText("Position #1")).check(matches(isDisplayed()));

 // Swipe back to the right.
 onView(withId(R.id.pager_layout)).perform(swipeRight());

 // Now position 0 should be visible again.
 onView(withText("Position #0")).check(matches(isDisplayed()));

 // Swipe right again.
 onView(withId(R.id.pager_layout)).perform(swipeRight());

 // Position 0 should still be visible as this is the first view in the pager.
 onView(withText("Position #0")).check(matches(isDisplayed()));
 }
89. Espresso scrolling Espresso scrolling // You can pass more than one action to perform. This is useful if you are performing two actions
 // back-to-back on the same view.
 public void testScrollToInScrollView() {
 onView(withId(is(R.id.bottom_view)))
 .perform(scrollTo(), click());
 }
90. Espresso API onView(Matcher<View>) onData(Matcher<Object>) Espresso withId() withText() ViewMatchers perform() check() ViewInteraction / DataInteraction click() enterText() scrollTo() ViewActions matches(Matcher<View>) doesNotExist() ViewAssertions find view to operate on composed of © Stephan Linzner (Google)
91. View Matchers Espresso uses Hamcrest Matchers Espresso Matchers = Hamcrest Ŷ Make assertions on views Ŷ Filter views Ŷ Reuse existing Matchers Ŷ Create your own Matchers Ŷ from hamcrest-core and hamcrest-library
92. View Matchers provides Android specific View Matchers ViewMatchers Ŷ
93. View Matchers Hamcrest Ŷ allOf() / anyOf() ➪ give more power Ŷ TestRunner // assert that textview does not start with with "XYZ" and contains "ABC" anywhere
 onView(withId(R.id.celsius_textview))
 .check(matches(allOf(withText(not(startsWith("XYZ"))), withText(containsString("ABC")))));
 // assert that textview ends with "XYZ" or contains "ABC" anywhere
 onView(withId(R.id.celsius_textview))
 .check(matches(anyOf(withText(endsWith("XYZ")), withText(containsString("ABC")))));
94. View Actions • click() • scrollTo() • writeText() Perform actions on Views Ŷ Guaranteed to run on UI thread Ŷ Create your custom Actions Ŷ Basic view actions Ŷ
95. Custom ViewAction Espresso ViewAction /**
 * Clears view text by setting {@link EditText}s text property to "".
 */
 public class ClearTextAction implements ViewAction {

 @Override
 public Matcher<View> getConstraints() {
 return allOf(isDisplayed(), isAssignableFrom(EditText.class));
 }

 @Override
 public void perform(UiController uiController, View view) {
 ((EditText) view).setText("");
 }

 @Override
 public String getDescription() {
 return "Clear the EditText component";
 }
 }
96. Custom ViewAction Espresso ViewAction /**
 * Your own custom View Actions.
 */
 public class CustomViewActions {

 private CustomViewActions() {
 }

 /**
 * Returns an action that clears text on the view. Extra thoroughly!
 */
 public static ViewAction clearTextExtraThoroughly() {
 return new ClearTextAction();
 }
 }
97. Use Custom ViewAction Espresso ViewAction public void testClearCelsiusTextField() {
 onView(withText("Celsius")).perform(clearTextExtraThoroughly());
 }
98. Reliability through synchronization between Instrumentation thread and UI thread for background resources Espresso synchronizes AsyncTasks default thread pool • wait until app is idle • perform operation on the UI thread • wait until completion • check result for custom implementations
 IntentService
 HandlerThread
 ThreadPool Synchronization Ŷ Synchronization Ŷ Synchronization Ŷ AsyncTask Ŷ IdlingResource interface Ŷ
99. Espresso synchronization Espresso IdlingResource public class IdleMonitor implements IdlingResource {

 @Override
 public String getName() {
 return IdleMonitor.class.getSimpleName();
 }

 @Override
 public boolean isIdleNow() {
 // return true if resource is idle
 return false;
 }

 @Override
 public void registerIdleTransitionCallback(ResourceCallback resourceCallback) {
 // store a reference to the resourceCallback
 // notify resourceCallback when idle
 }
 } ! ! Espresso.registerIdlingResources(idlingResource);
100. Espresso setup + collection of dependencies bundled = Espresso and all of its dependencies Espresso dependencies Ŷ Standalone Ŷ Separate library Ŷ
101. Espresso setup Espresso dependencies dependencies {
 androidTestCompile files('libs/espresso-1.1.jar',
 'libs/testrunner-1.1.jar',
 'libs/testrunner-runtime-1.1.jar')

 androidTestCompile 'com.google.guava:guava:14.0.1',
 'com.squareup.dagger:dagger:1.1.0',
 'org.hamcrest:hamcrest-core:1.1',
 'org.hamcrest:hamcrest-integration:1.1',
 'org.hamcrest:hamcrest-library:1.1'
 }
 android {
 packagingOptions {
 // exclude duplicated dependency files from being packaged in the apk
 exclude 'LICENSE.txt'
 }
 }
102. Double Espresso setup Espresso dependencies dependencies {
 androidTestCompile 'com.jakewharton.espresso:espresso:1.1-r3'
 androidTestCompile('com.jakewharton.espresso:espresso:1.1-r3') {
 exclude group: 'com.squareup.dagger'
 }
 androidTestCompile 'com.jakewharton.espresso:espresso-support-v4:1.1-r3'
 }
 android {
 packagingOptions {
 // exclude duplicated dependency files from being packaged in the apk
 exclude 'LICENSE.txt'
 }
 }
103. Test runner Custom test runner Ŷ GoogleInstrumentationTestRunner Ŷ TestRunner android {
 defaultConfig {
 testInstrumentationRunner "com.google.android.apps.common.testing.testrunner.GoogleInstrumentationTestRunner"
 }
 }
104. Custom test runner Application.onCreate() always returns before
 Instrumentation.onStart() before Instrumentation exits Lifecycle control Ŷ Ensure all activities finish Ŷ Activity lifecycle monitoring Ŷ Improved error logging Ŷ Improved stability / reliability Ŷ Can be used with other libraries Ŷ
105. TESTING ANNOUNCEMENT
106. android.support.test.* for all Google testing frameworks Unbundled static testing library Ŷ Android support library Ŷ Full Gradle support Ŷ Open source / AOSP Ŷ Container Ŷ
107. Testing support library AndroidJUnitRunner Ŷ Intento Ŷ UiAutomator Ŷ Espresso Ŷ
108. JUnit 4 support @Parameters Test annotations Ŷ Test suite annotations Ŷ Parameterized tests Ŷ @Suite.SuiteClasses @Test @Before @After @BeforeClass @AfterClass
109. Support testing library usage Espresso dependencies dependencies {
 androidTestCompile ‘android.test.support:support-lib:?’
 androidTestCompile ‘android.test.support:espresso-lib:1.2’ androidTestCompile ‘android.test.support:espresso-contrib:1.2’ androidTestCompile ‘android.test.support:idling-resource:1.2’
 }
110. Support testing library usage Test runner Ŷ TestRunner android {
 defaultConfig {
 testInstrumentationRunner "android.support.test.runner.AndroidTestRunner "
 }
 }
111. Espresso errors Espresso error com.google.android.apps.common.testing.ui.espresso.NoMatchingViewException: No views in hierarchy found matching: with text: is "Celcius" ! View Hierarchy: +>DecorView{id=-1, visibility=VISIBLE, width=768, height=1184, has-focus=true, has-focusable=true, has-window-focus=true, is-clickable=false, is-enabled=true, is-focused=false, is-focusable=false, is-layout-requested=false, is-selected=false, root-is-layout-requested=false, has-input-connection=false, x=0.0, y=0.0, child-count=1} | +->ActionBarOverlayLayout{id=16909075, res-name=action_bar_overlay_layout, visibility=VISIBLE, width=768, height=1184, has-focus=true, has-focusable=true, has-window-focus=true, is-clickable=false, is-enabled=true, is-focused=false, is-focusable=false, is-layout-requested=false, is-selected=false, root-is-layout-requested=false, has-input-connection=false, x=0.0, y=0.0, child-count=3} | … +---->ActionMenuView{id=-1, visibility=VISIBLE, width=112, height=96, has-focus=false, has-focusable=true, has-window-focus=true, is-clickable=false, is-enabled=true, is-focused=false, is-focusable=false, is-layout-requested=false, is-selected=false, root-is-layout-requested=false, has-input-connection=false, x=656.0, y=0.0, child-count=1} | +----->OverflowMenuButton{id=-1, desc=More options, visibility=VISIBLE, width=112, height=96, has-focus=false, has-focusable=true, has-window-focus=true, is-clickable=true, is-enabled=true, is-focused=false, is-focusable=true, is-layout-requested=false, is-selected=false, root-is-layout-requested=false, has-input-connection=false, x=0.0, y=0.0} | +--->ActionBarContextView{id=16909078, res-name=action_context_bar, visibility=GONE, width=0, height=0, has-focus=false, has-focusable=false, has-window-focus=true, is-clickable=false, is-enabled=true, is-focused=false, is-focusable=false, is-layout-requested=true, is-selected=false, root-is-layout-requested=false, has-input-connection=false, x=0.0, y=0.0, child-count=0} | +-->ActionBarContainer{id=16909079, res-name=split_action_bar, visibility=GONE, width=0, height=0, has-focus=false, has-focusable=false, has-window-focus=true, is-clickable=false, is-enabled=true, is-focused=false, is-focusable=false, is-layout-requested=true, is-selected=false, root-is-layout-requested=false, has-input-connection=false, x=0.0, y=0.0, child-count=0} |
112. Intento: inter-application testing through custom Instrumentation verify that a given Intent has been sent stub outgoing Intents stub the result from a broadcasted Intent Intercept Intents Ŷ Records all outgoing Intents Ŷ Intent stubbing in tests Ŷ Intent validation Ŷ
113. Robolectric
114. Android testing Android core libraries depend upon the actual Android operating system
115. Android testing Android core libraries depend upon the actual Android operating system
116. Android testing AndroidTestCase needs an instance of the emulator to run • spin up emulator • deploy the APK • run the actual tests Big time sink: Ŷ
117. Robolectric that would otherwise need an emulator / device (mock implementations of Android core libraries) too slow / hard for unit testing without the baggage of a device Replaces the behavior of code Ŷ Write JUnit tests Ŷ When? Ŷ Does this by using Shadow classes Ŷ InstrumentationTestCase Ŷ vs real device / speedy emulator Ŷ http://robolectric.org/
118. Robolectric • unit testing fast and easy • make your own Shadow objects • JUnit 4 supported • does not cover all functionality (sensors, OpenGL, …) ➪ device needed • integration testing (interaction Activities - Services, camera app, …) Advantages Ŷ Disadvantages Ŷ
119. Robolectric Robolectric
 public class MyActivityTest {

 @Test
 public void clickingButton_shouldChangeResultsViewText() throws Exception {
 MyActivity activity = Robolectric.buildActivity(MyActivity.class).create().get();

 Button pressMeButton = (Button) activity.findViewById(R.id.press_me_button);
 TextView results = (TextView) activity.findViewById(R.id.results_text_view);

 pressMeButton.performClick();
 String resultsText = results.getText().toString();
 assertThat(resultsText, equalTo("Testing Android Rocks!"));
 }
120. Robolectric setup • Robolectric • Novoda gradle-android-test-plugin see Paul Blundell Tests run inside the JVM Ŷ Gradle - Maven Ŷ Configure it yourself Ŷ Gradle plugin Ŷ http://blog.blundell-apps.com/android-gradle-app-with-robolectric-junit-tests/
121. Robolectric setup
122. Robolectric setup Robolectric setup apply plugin: 'java'

 dependencies {
 def androidModule = project(':appfoundry-app')
 compile androidModule

 testCompile rootProject.ext.libraries.junit
 testCompile rootProject.ext.libraries.robolectric

 testCompile androidModule.android.applicationVariants.toList().first().javaCompile.classpath
 testCompile androidModule.android.applicationVariants.toList().first().javaCompile.outputs.files
 testCompile files(androidModule.plugins.findPlugin("com.android.application").getBootClasspath())


 }
123. Robolectric setup where your AndroidManifest and resources are Custom test runner Ŷ tell Robolectric Ŷ
124. Robolectric setup Robolectric test runner public class RobolectricGradleTestRunner extends RobolectricTestRunner {

 private static final int MAX_SDK_SUPPORTED_BY_ROBOLECTRIC = 18;

 public RobolectricGradleTestRunner(Class<?> testClass) throws InitializationError {
 super(testClass);
 }

 @Override
 protected AndroidManifest getAppManifest(Config config) {
 String manifestProperty = "../appfoundry-app/src/main/AndroidManifest.xml";
 String resProperty = "../appfoundry-app/src/main/res";
 return new AndroidManifest(Fs.fileFromPath(manifestProperty), Fs.fileFromPath(resProperty)) {
 @Override
 public int getTargetSdkVersion() {
 return MAX_SDK_SUPPORTED_BY_ROBOLECTRIC;
 }
 };
 }
 }
125. Robolectric Annotate your class @RunWith(RobolectricTestRunner.class)
 public class MyActivityTest {

 @Test
 public void clickingButton_shouldChangeResultsViewText() throws Exception {
 MyActivity activity = Robolectric.buildActivity(MyActivity.class).create().get();

 Button pressMeButton = (Button) activity.findViewById(R.id.press_me_button);
 TextView results = (TextView) activity.findViewById(R.id.results_text_view);

 pressMeButton.performClick();
 String resultsText = results.getText().toString();
 assertThat(resultsText, equalTo("Testing Android Rocks!"));
 }
126. Robolectric Robolectric @RunWith(RobolectricTestRunner.class)
 public class MyActivityTest {

 @Test
 public void pressingSubmitButtonShouldStartSecondActivity() throws Exception {
 pressMeButton.performClick();

 ShadowActivity shadowActivity = shadowOf(activity);
 Intent startedIntent = shadowActivity.getNextStartedActivity();
 ShadowIntent shadowIntent = shadowOf(startedIntent);
 assertThat(shadowIntent.getComponent().getClassName(), equalTo(MyActivity.class.getName()));
 }
127. Robolectric
128. Android testing JUnit 4 Support JUnit 4 test @RunWith(JUnit4.class)
 public class AndroidJUnit4Test {

 Conference devoxx;

 @Before
 public void setUp() {
 devoxx = Conferences.newInstance(Conference.DEVOXX);
 devoxx.start();
 }

 @After
 public void tearDown() {
 devoxx.stop();
 }

 @Test
 public void testPreconditions() {
 assertThat(devoxx, is(notNullValue()));
 }

 @Test
 public void devoxxShouldBeGreat() {
 assertThat(devoxx, is(awesome()));
 }
129. Mocking & Stubbing
130. Mockito in isolation Change runtime implementation Ŷ That can be predictably tested Ŷ Verify behaviour Ŷ Mockito Ŷ
131. Mockito the behaviour of your components during a test Java mocking framework Ŷ Mock dependencies Ŷ Inject Mocks to validate Ŷ Mock function return values Ŷ https://code.google.com/p/mockito/
132. Mockito Mockito @Test
 public void testMockedConverter() throws Exception {
 // expectations
 final float expected_result = 32.0f;

 // given
 ConverterActivity activity = Robolectric.buildActivity(ConverterActivity.class).create().get();
 activity.onCreate(new Bundle());
 EditText celsiusField = (EditText) activity.findViewById(R.id.celsius_textview);
 celsiusField.setText("0");

 CelsiusFahrenheitConverter mockConverter = Mockito.mock(CelsiusFahrenheitConverter.class);
 Mockito.when(mockConverter.convertCelsiusToFahrenheit(Mockito.anyFloat())).thenReturn(expected_result);
 activity.setConverter(mockConverter);

 // when
 Button convertButton = (Button) activity.findViewById(R.id.conversion_button);
 convertButton.performClick();

 // then
 Mockito.verify(mockConverter, Mockito.times(1)).convertCelsiusToFahrenheit(Mockito.anyFloat());
 TextView fahrenheitField = (TextView) activity.findViewById(R.id.fahrenheit_textview);
 String fahrenheitString = fahrenheitField.getText().toString();
 assertThat(fahrenheitString, equalTo(String.valueOf(expected_result)));
 }
133. The Monkey
134. evil monkey…
135. Monkey pseudo-random stream of user events Generates events Ŷ clicks Ŷ touches Ŷ gestures Ŷ system-level events Ŷ Stress test your app Ŷ
136. Monkey number of events to attempt operational constraints, such as restricting the test to a single package Event types and frequencies command-line tool Ŷ basic configuration Ŷ $ adb shell monkey -p your.package.name -v 500 Ŷ
137. AssertJ Android for checking assertions to read / write http://square.github.io/assertj-android/ Syntactic sugar Ŷ Extension of the AssertJ library Ŷ Makes tests easier Ŷ Fluent syntax Ŷ
138. AssertJ Android Assertions for Android objects Ŷ + support libraries Ŷ
139. AssertJ Android Regular JUnit AssertJ Android assertEquals(View.GONE, view.getVisibility()); assertThat(view).isGone(); expected: <8> but was: <4> Expected visibility <gone> but was <invisible>.
140. AssertJ Android Regular JUnit assertEquals(View.VISIBLE, layout.getVisibility()); assertEquals(VERTICAL, layout.getOrientation()); assertEquals(4, layout.getChildCount()); assertEquals(SHOW_DIVIDERS_MIDDLE, layout.getShowDividers()); AssertJ Android assertThat(layout).isVisible() .isVertical() .hasChildCount(4) .hasShowDividers(SHOW_DIVIDERS_MIDDLE);
141. Testing network resources
142. Testing network resources Unit tests Ŷ Integration tests Ŷ Retrofit Ŷ
143. Testing network resources how to trigger edge cases like API rate limit exceeded? HTTP calls should be asynchronous … Hit a real server? Ŷ Brittle tests! Ŷ Slow tests Ŷ Network or server is down Ŷ Incomplete tests Ŷ Further complicated in Android Ŷ
144. Testing network resources Use a test server Ŷ Mock the Retrofit interface Ŷ
145. Using a test server • virtually no changes or code required in your app codebase • can be shared across multiple platforms (Android, iOS, web, …) • another dependency (that can fail) • something new to figure out • not always easy to trigger errors or edge cases • what if ‘state’ is needed? • ‘slow’ tests execution, still HTTP calls needed PROs Ŷ CONs Ŷ
146. Mocking the Retrofit interface • robust: no network errors, timeouts, … • easy to generate errors / edge cases • easy to control server-side state • write your dummy data in Java • extra test code needed • you don’t test the JSON deserialization (but you can add unit tests) • mock a part of your application ➪ not a true integration test PROs Ŷ CONs Ŷ You trust the test suites of Retrofit, Gson, … and mock out the data
147. Network testing Mock network interface ‘Fake’-‘real’ server
148. Mocking the Retrofit interface MockRestAdapter sample
149. Mocking the Retrofit interface Retrofit mock public interface GitHub {
 @GET("/repos/{owner}/{repo}/contributors")
 List<Contributor> contributors(@Path("owner") String owner, @Path("repo") String repo);
 }
150. Mocking the Retrofit interface Canned data /** A mock implementation of the {@link GitHub} API interface. */
 static class MockGitHub implements GitHub {
 private final Map<String, Map<String, List<Contributor>>> ownerRepoContributors;

 public MockGitHub() {
 ownerRepoContributors = new LinkedHashMap<String, Map<String, List<Contributor>>>();

 // Seed some mock data.
 addContributor("square", "retrofit", "John Doe", 12);
 addContributor("square", "retrofit", "Bob Smith", 2);
 addContributor("square", "retrofit", "Big Bird", 40);
 addContributor("square", "picasso", "Proposition Joe", 39);
 addContributor("square", "picasso", "Keiser Soze", 152);
 }
151. Mocking the Retrofit interface Mock @Override public List<Contributor> contributors(String owner, String repo) {
 Map<String, List<Contributor>> repoContributors = ownerRepoContributors.get(owner);
 if (repoContributors == null) {
 return Collections.emptyList();
 }
 List<Contributor> contributors = repoContributors.get(repo);
 if (contributors == null) {
 return Collections.emptyList();
 }
 return contributors;
 }
152. Mocking the Retrofit interface Mock // Create a very simple REST adapter which points the GitHub API endpoint.
 RestAdapter restAdapter = new RestAdapter.Builder()
 .setEndpoint(API_URL)
 .build();

 // Wrap our REST adapter to allow mock implementations and fake network delay.
 MockRestAdapter mockRestAdapter = MockRestAdapter.from(restAdapter);

 // Instantiate a mock object so we can interact with it later.
 MockGitHub mockGitHub = new MockGitHub();
 // Use the mock REST adapter and our mock object to create the API interface.
 GitHub gitHub = mockRestAdapter.create(GitHub.class, mockGitHub);

 // Query for some contributors for a few repositories.
 printContributors(gitHub, "square", "retrofit");
 printContributors(gitHub, "square", "picasso");
153. Network testing Mock network interface ‘Fake’-‘real’ server
154. Wiremock predictable requests-responses wiremock.org Ŷ Tom Akehurst Ŷ Reproduce real-world scenarios Ŷ Increase reliability Ŷ Stateful scenarios Ŷ Non-Android specific Ŷ
155. Wiremock via HTTP/JSON API • _admin/mappings/new • mappings folder HTTP server Ŷ configure responses Ŷ use with Java API Ŷ
156. Wiremock Wiremock JSON API { "request": { "method": "GET", "url": "/api/mytest" }, "response": { "status": 200, "body": "More content\n" } } wiremock.org documentation
157. Wiremock Wiremock Java API stubFor(get(urlEqualTo("/some/thing")) .willReturn(aResponse() .withStatus(404) .withBody(“No!!”))); wiremock.org documentation
158. Wiremock Wiremock Java test @Test public void exampleTest() { // make your app do requests to http://localhost:8080 stubFor(get(urlEqualTo("/my/resource")) .willReturn(aResponse() .withStatus(200) .withBody("<response>Some content</response>"))); ! onView(withId(R.id.submit_button)).perform(click()); onView(withText(“error message”)).check(matches(isDisplayed())); ! verify(postRequestedFor(urlMatching(“/my/resource/[a-z0-9]+”))); } wiremock.org documentation
159. Wiremock … out-of-the-box Android support is coming… Stateful Ŷ Errors / delays Ŷ Wiremock in the test APK Ŷ Wiremock as server on network Ŷ
160. Application ARCHITECTURE
162. Software design patterns Good code = testable code Ŷ Dependency injection Ŷ
163. Software design patterns Architecting Android Applications with Dagger Dependency injection Ŷ Dagger Ŷ Avoid reflection at runtime Ŷ Define dependencies Ŷ Jake Wharton Ŷ
164. AUTOMATION &
 REPORTING
165. Automated distributed testing Automated distributed instrumentation testing Screenshots share with the designers…? in parallel Run tests on multiple devices Reports / logs captured for each test
166. Spoon https://square.github.io/spoon/ Automate test execution Ŷ across multiple devices Ŷ Aggregation of screenshots Ŷ Aggregate the results Ŷ
167. Spoon High level tests overview Ŷ Test failure specific Ŷ to a single device or all devices
168. Spoon: device view Results of each test on one device Ŷ Useful for tracking down Ŷ device-specific failures of individual tests
169. Spoon: test view Results of single test on all devices Ŷ
170. Spoon: screenshots Visual inspection of test execution Ŷ screenshots Spoon.screenshot(activity, "initial_state"); /* Normal test code... */ Spoon.screenshot(activity, "after_login"); http://square.github.io/spoon/sample/
171. Build pipeline Commit stage Automated test/QA stage Manual QA testing UAT test Production Capacity / load testing
172. Build pipeline Checkout / compile Unit tests Test coverage Code analysis Create deployable artifact Deploy for automatic QA test Trigger automated QA stage
173. Build pipeline tools Build (maven - gradle) Dependency repo (nexus - artifactory) Testing framework (JUnit - ...) Test coverage (Cobertura - Emma - Jacoco) Code analysis (Checkstyle, findbugs, pmd, Android Lint) Creation of deployable artifact (buildtool, artifact repo) Trigger next stage
174. Continuous integration benefits without additional effort Fast feedback - fewer errors Ŷ Test everything on every (nightly) build Ŷ Regression tests Ŷ Less manual testing Ŷ
175. Jenkins
176. Jenkins
177. Continuous integration • Jenkins • Bamboo Travis … Server Ŷ Hosted Ŷ https://travis-ci.org
178. Test coverage open-source toolkit for measuring and reporting Java code coverage Metrics Ŷ Code safely Ŷ JaCoCo Ŷ Find risky code Ŷ
179. Android test coverage
180. Coverage 88%
181. References
182. Suggested reading Android Application Testing Guide Diego Torres Milano (9781849513500) Robotium Automated Testing for Android Hrushikesh Zadgaonkar (9781782168010) The Busy Coder’s Guide to Android Development Mark Murphy - http://commonsware.com/Android/
183. Suggested reading Test Driven Development: By Example Beck, Kent (978-0321146533) Continuous Integration: Improving Software Quality and Reducing Risk Duvall, Paul M. et al. (978-0321336385) Working Effectively with Legacy Code Feathers, Michael (978-0131177055)
184. Questions? Filip Maelbrancke Consultant @ AppFoundry ! filip.maelbrancke@appfoundry.be @fmaelbrancke
