Droidcon Berlin: Leveraging Android Data Binding with Kotlin

Android databinding is considered as both a powerful toolchain, empowering your views with access to view data without the necessity to build cumbersome presenters, and conversely as an overly complex, convoluted mess of binding statements opening the door to unnecessary, irresponsible domain logic in your view layouts.

Whilst the latter of these statements can be true, databinding offers a very powerful code generation syntax, allowing you to utilise the power of the compiler to ensure that your binding statements are runtime safe. Combining this with the concise syntax afforded by Kotlin allows us to dramatically cut down on boilerplate and build complex user interfaces with relative ease.

In this talk, you can learn how to utilise extension bindings and property delegates with your layouts, and manage your screen state transformations with true, and safe two-way binding, allowing you to build a fully reactive observable view layout.

Transcript

1. Leveraging Android Databinding
   with Kotlin
   ashdavies.io 1


   View Slide

2. What is Data Binding?
   ashdavies.io 2


   View Slide

3. Data Binding Beta
   2015
   ashdavies.io 3


   View Slide

4. Data Binding v2
   ashdavies.io 4


   View Slide

5. Data Binding v2
   Incremental class generation ⚡
   ashdavies.io 5


   View Slide

6. Data Binding v2
   Incremental class generation ⚡
   Pre-compilation class generation !
   ashdavies.io 6


   View Slide

7. Data Binding
   class RepoActivity : AppCompatActivity() {
   override fun onCreate(savedInstanceState: Bundle?) {
   super.onCreate(savedInstanceState)
   setContentView(R.layout.activity_repo)
   }
   }
   ashdavies.io 7


   View Slide

8. Data Binding
   class RepoActivity : AppCompatActivity() {
   private lateinit var binding: ActivityRepoBinding
   override fun onCreate(savedInstanceState: Bundle?) {
   super.onCreate(savedInstanceState)
   binding = DataBindingUtil.setContentView(this, R.layout.activity_repo)
   }
   }
   ashdavies.io 8


   View Slide

9. Data Binding
   internal class RepoActivity : AppCompatActivity() {
   private lateinit var binding: ActivityRepoBinding
   override fun onCreate(savedInstanceState: Bundle?) {
   super.onCreate(savedInstanceState)
   binding = DataBindingUtil.setContentView(this, R.layout.activity_repo)
   binding.setLifecycleOwner(this)
   }
   }
   ashdavies.io 9


   View Slide

10. Data Binding
    class RepoActivity : AppCompatActivity() {
    private lateinit var binding: ActivityRepoBinding
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    binding = DataBindingUtil.setContentView(this, R.layout.activity_home)
    binding.setLifecycleOwner(this)
    }
    }
    ashdavies.io 10


    View Slide

11. Delegated Properties
    ashdavies.io 11


    View Slide

12. Delegated Properties
    val value: String by lazy {
    println("computed!")
    "Hello"
    }
    ashdavies.io 12


    View Slide

13. Delegated Properties
    interface ReadOnlyProperty {
    operator fun getValue(thisRef: R, property: KProperty<*>): T
    }
    interface ReadWriteProperty {
    operator fun getValue(thisRef: R, property: KProperty<*>): T
    operator fun setValue(thisRef: R, property: KProperty<*>, value: T)
    }
    ashdavies.io 13


    View Slide

14. Delegated Properties
    class ActivityBindingProperty(
    ) : ReadOnlyProperty {
    override operator fun getValue(thisRef: Activity, property: KProperty<*>): T {
    TODO("not implemented")
    }
    }
    ashdavies.io 14


    View Slide

15. Delegated Properties
    class ActivityBindingProperty(
    @LayoutRes private val resId: Int
    ) : ReadOnlyProperty {
    private var binding: T? = null
    override operator fun getValue(thisRef: Activity, property: KProperty<*>): T {
    return binding ?: createBinding(thisRef).also { binding = it }
    }
    private fun createBinding(activity: Activity): T {
    return DataBindingUtil.setContentView(activity, resId)
    }
    }
    ashdavies.io 15


    View Slide

16. ProTip: Extension Function! !
    class RepoActivity : AppCompatActivity() {
    private val binding by activityBinding(R.layout.activity_repo)
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    binding.setLifecycleOwner(this)
    }
    }
    fun FragmentActivity.activityBinding(
    @LayoutRes resId: Int
    ) = ActivityBindingProperty(resId)
    ashdavies.io 16


    View Slide

17. Introducing
    Android Architecture Components
    ashdavies.io 17


    View Slide

18. Model-View-ViewModel
    ashdavies.io 18


    View Slide

19. ashdavies.io 19


    View Slide

20. Model-View-ViewModel
    class RepoActivity : AppCompatActivity() {
    private val binding by activityBinding(R.layout.activity_repo)
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    binding.setLifecycleOwner(this)
    }
    }
    ashdavies.io 20


    View Slide

21. Model-View-ViewModel
    class RepoActivity : AppCompatActivity() {
    private val binding by activityBinding(R.layout.activity_repo)
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    binding.setLifecycleOwner(this)
    binding.model = ViewModelProviders
    .of(this, RepoViewModelFactory())
    .get(RepoViewModel::class.java)
    }
    }
    ashdavies.io 21


    View Slide

22. ProTip: Extension Function! !
    class RepoActivity : AppCompatActivity() {
    private val binding by activityBinding(R.layout.activity_repo)
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    binding.setLifecycleOwner(this)
    binding.model = getViewModel(RepoViewModelFactory())
    }
    }
    inline fun FragmentActivity.getViewModel(
    factory: ViewModelProvider.Factory = ViewModelProvider.NewInstanceFactory()
    ) = ViewModelProviders.of(this, factory).get(T::class.java)
    ashdavies.io 22


    View Slide

23. Model-View-ViewModel
    class RepoActivity : AppCompatActivity() {
    private val binding by activityBinding(R.layout.activity_repo)
    private val model by lazy { getViewModel(RepoViewModelFactory()) }
    override fun onCreate(savedInstanceState: Bundle?) {
    super.onCreate(savedInstanceState)
    binding.setLifecycleOwner(this)
    binding.model = model
    // val items = model.items.get()
    }
    }
    ashdavies.io 23


    View Slide

24. ViewModel
    class RepoViewModel(service: RepoService) : ViewModel {
    val items: ObservableField> = ObservableField()
    fun query(value: String) {
    service.fetch(value, items::set)
    }
    }
    ashdavies.io 24


    View Slide

25. Observable
    class RepoViewModel(service: RepoService) : ViewModel {
    val items: ObservableField> = ObservableField()
    fun query(value: String) { /* ... */ }
    }
    ashdavies.io 25


    View Slide

26. LiveData Data Binding
    ashdavies.io 26


    View Slide

27. LiveData Data Binding
    class RepoViewModel(service: RepoService) : ViewModel {
    val items = MutableLiveData>()
    fun query(value: String) { /* ... */ }
    }
    ashdavies.io 27


    View Slide

28. ProTip: Extension Functions! !
    class RepoViewModel(service: RepoService) : ViewModel {
    val items = mutableLiveData>()
    fun query(value: String) { /* ... */ }
    }
    fun ViewModel.mutableLiveDataOf() = MutableLiveData()
    ashdavies.io 28


    View Slide

29. ViewModel
    class RepoViewModel(private val service: RepoService) : ViewModel {
    val items = mutableLiveDataOf>()
    fun query(value: String) {
    service.fetch(value) {
    items.value = it
    }
    }
    }
    ashdavies.io 29


    View Slide

30. ViewModel
    class RepoViewModel(private val service: RepoService) : ViewModel {
    val items = mutableLiveDataOf>()
    val loading = mutableLiveDataOf()
    fun query(value: String) {
    loading.value = true
    service.fetch(value) {
    loading.value = false
    items.value = it
    }
    }
    }
    ashdavies.io 30


    View Slide

31. Layout Expressions
    xmlns:app="http://schemas.android.com/apk/res-auto">


    name="model"
    type="io.ashdavies.databinding.RepoViewModel"/>

    android:visibility="@{model.loading ? View.VISIBLE : View.GONE}"/>

    ashdavies.io 31


    View Slide

32. Layout Expressions
    xmlns:app="http://schemas.android.com/apk/res-auto">


    name="model"
    type="io.ashdavies.databinding.RepoViewModel"/>

    android:text="@string/activity_repo_empty"/>
    android:visibility="@{model.loading ? View.VISIBLE : View.GONE}"/>

    ashdavies.io 32


    View Slide

33. Layout Expressions
    xmlns:app="http://schemas.android.com/apk/res-auto">


    name="model"
    type="io.ashdavies.databinding.RepoViewModel"/>

    android:text="@string/activity_repo_empty"
    android:visibility="@{model.items.count == 0 ? View.VISIBLE : View.GONE}"/>
    android:visibility="@{model.loading ? View.VISIBLE : View.GONE}"/>

    ashdavies.io 33


    View Slide

34. Layout Expressions
    xmlns:app="http://schemas.android.com/apk/res-auto">


    name="model"
    type="io.ashdavies.databinding.RepoViewModel"/>

    android:text="@string/activity_repo_empty"
    android:visibility="@{model.items.count == 0 && !model.loading ? View.VISIBLE : View.GONE}"/>
    android:visibility="@{model.loading ? View.VISIBLE : View.GONE}"/>

    ashdavies.io 34


    View Slide

35. Too Complicated!
    ashdavies.io 35


    View Slide

36. class RepoViewModel(private val service: RepoService) : ViewModel {
    val items = mutableLiveDataOf>()
    val loading = mutableLiveDataOf()
    val empty = mutableLiveDataOf()
    fun query(value: String) {
    loading.value = true
    empty.value = true
    service.fetch(value) {
    items.value = it
    empty.value = it.isEmpty()
    loading.value = false
    }
    }
    }
    ashdavies.io 36


    View Slide

37. xmlns:app="http://schemas.android.com/apk/res-auto">


    name="model"
    type="io.ashdavies.databinding.RepoViewModel"/>

    android:text="@string/activity_repo_empty"
    android:visibility="@{model.empty ? View.VISIBLE : View.GONE}"/>
    android:visibility="@{model.loading ? View.VISIBLE : View.GONE}"/>

    ashdavies.io 37


    View Slide

38. @BindingAdapter
    ashdavies.io 38


    View Slide

39. @BindingAdapter
    @BindingAdapter("goneUnless")
    fun goneUnless(view: View, visible: Boolean) {
    view.visibility = if (visible) View.VISIBLE else View.GONE
    }
    ashdavies.io 39


    View Slide

40. ProTip: Extension Property! !
    @set:BindingAdapter("isVisible")
    inline var View.isVisible: Boolean
    get() = visibility == View.VISIBLE
    set(value) {
    visibility = if (value) View.VISIBLE else View.GONE
    }
    ashdavies.io 40


    View Slide

41. @BindingAdapter
    xmlns:app="http://schemas.android.com/apk/res-auto">


    name="model"
    type="io.ashdavies.databinding.RepoViewModel"/>

    android:text="@string/activity_repo_empty"
    app:isVisible="@{model.empty}"/>
    app:isVisible="@{model.loading}"/>

    ashdavies.io 41


    View Slide

42. @Bindable
    ashdavies.io 42


    View Slide

43. @Bindable
    ObservableViewModel
    ashdavies.io 43


    View Slide

44. @Bindable
    PropertyChangeRegistry
    ashdavies.io 44


    View Slide

45. @Bindable
    abstract class ObservableViewModel : ViewModel(), Observable {
    private val callbacks: PropertyChangeRegistry = PropertyChangeRegistry()
    override fun addOnPropertyChangedCallback(callback: Observable.OnPropertyChangedCallback) {
    callbacks.add(callback)
    }
    override fun removeOnPropertyChangedCallback(callback: Observable.OnPropertyChangedCallback) {
    callbacks.remove(callback)
    }
    fun notifyChange() {
    callbacks.notifyCallbacks(this, 0, null)
    }
    fun notifyPropertyChanged(fieldId: Int) {
    callbacks.notifyCallbacks(this, fieldId, null)
    }
    }
    ashdavies.io 45


    View Slide

46. @Bindable
    class RepoViewModel(private val service: RepoService) : ObservableViewModel {
    val items = mutableLiveDataOf>()
    val loading = mutableLiveDataOf()
    fun query(value: String) {
    loading.value = true
    service.fetch(value) {
    loading.value = false
    items.value = it
    }
    }
    }
    ashdavies.io 46


    View Slide

47. @Bindable
    class RepoViewModel(private val service: RepoService) : ObservableViewModel {
    @get:Bindable
    var items: List = emptyList()
    private set(value) {
    notifyPropertyChanged(BR.items)
    field = value
    }
    val loading = mutableLiveDataOf()
    fun query(value: String) {
    loading.value = true
    service.fetch(value) {
    loading.value = false
    items = it
    }
    }
    }
    ashdavies.io 47


    View Slide

48. @Bindable
    Delegated Properties
    ashdavies.io 48


    View Slide

49. Property Delegate
    ObservableProperty
    ashdavies.io 49


    View Slide

50. @Bindable
    class BindableProperty(
    initial: T, private val observable: ObservableViewModel, private val id: Int
    ) : ObservableProperty(initial) {
    override fun beforeChange(
    property: KProperty<*>, oldValue: T, newValue: T
    ): Boolean = { /* ... */ }
    override fun afterChange(
    property: KProperty<*>, oldValue: T, newValue: T
    ) { /* ... */ }
    }
    ashdavies.io 50


    View Slide

51. @Bindable
    class BindableProperty(
    initial: T, private val observable: ObservableViewModel, private val id: Int
    ) : ObservableProperty(initial) {
    override fun beforeChange(
    property: KProperty<*>, oldValue: T, newValue: T
    ): Boolean = oldValue != newValue
    override fun afterChange(
    property: KProperty<*>, oldValue: T, newValue: T
    ) { /* ... */ }
    }
    ashdavies.io 51


    View Slide

52. @Bindable
    class BindableProperty(
    initial: T, private val observable: ObservableViewModel, private val id: Int
    ) : ObservableProperty(initial) {
    override fun beforeChange(
    property: KProperty<*>, oldValue: T, newValue: T
    ): Boolean = oldValue != newValue
    override fun afterChange(property: KProperty<*>, oldValue: T, newValue: T) {
    observable.notifyPropertyChanged(id)
    }
    }
    ashdavies.io 52


    View Slide

53. ProTip: Extension Function! !
    @Bindable
    class RepoViewModel(private val service: RepoService) : ObservableViewModel() {
    @get:Bindable
    var items by bindable>(emptyList(), BR.items)
    private set
    val items = mutableLifeDataOf>()
    init {
    service.fetch(items::setValue)
    }
    }
    fun ObservableViewModel.bindable(initial: T, id: Int): BindableProperty {
    return BindableProperty(initial, this, id)
    }
    ashdavies.io 53


    View Slide

54. ! Awesome! !
    ashdavies.io 54


    View Slide

55. Data Binding Sample
    github.com/ashdavies/data-binding
    ashdavies.io 55


    View Slide

56. Android Data Binding with Kotlin
    bit.ly/2yU8qUz
    ashdavies.io 56


    View Slide

57. Additional Resources
    ashdavies.io 57


    View Slide

58. 4 Android Data Binding Library samples
    Google Samples - [bit.ly/2MK5GMb]
    4 Make your view-model properties great again
    Aiden McWilliams - [bit.ly/2llVVHz]
    4 MVVM, Viewmodel and architecture components
    Danny Preussler - [bit.ly/2yxvGay]
    4 Android Data Binding: RecyclerView
    George Mount - [https://bit.ly/2IgwY9w]
    ashdavies.io 58


    View Slide

59. Cheers! !
    _ashdavies
    ashdavies.io 59


    View Slide
