Do more with less: How to reduce your PostgreSQL costs on Azure | Citus Con: An Event for Postgres 2023 | Varun Dhawan

Azure Database for PostgreSQL - Flexible Server is a fully-managed relational database based on PostgreSQL open source on Azure.

One of the greatest benefits of running your application on PostgreSQL in the cloud is being able to scale up and down to meet demand and reduce operational expenditures. And that is especially true when you are experiencing unexpected changes in workload. With Flexible Server in the PostgreSQL managed service on Azure, you can take control of your costs and continuously optimize your cloud spend, while building modern, scalable applications to meet your customers’ needs.

If this sounds exciting, come watch this session where you will learn 10 things you can do today to reduce the cost of Azure Database for PostgreSQL. This talk is for anyone who wants to reduce costs in their PostgreSQL spend in the cloud, whether you are an early-stage startup or a large enterprise with a global footprint.

Transcript

1. An Event for Postgres 2023
   Varun Dhawan | Senior PM @ Microsoft Azure
   @iVarund


   View Slide

2. An Event for Postgres 2023
   • Hi! I’m a Product Manager at Open-
   Source Database team at Microsoft
   • I bring over 15 years experience working
   on relational database systems
   • My previous experiences includes working
   as DevOps engineer at Target Corp and
   Database SRE at McKinsey&Company
   • Some of my fav things – Hiking, Music and
   Blogging >


   View Slide

3. Tools and Recommendations
   to reduce cost on
   Azure Database for
   PostgreSQL Flexible Server


   View Slide

4. Flexible Server – Overview
   The 10 ways to reduce your
   Flexible Server Cost
   Conclusion


   View Slide

5. Extensions
   JSONB
   Full text
   search
   Geospatial
   Rich
   indexing
   Rich Data
   types
   ACID
   Constraints
   Management
   Automation
   Extension
   support
   Global
   reach
   Security
   Scale up
   & out
   High
   Availability
   Compliance
   Intelligent
   performance
   Ecosystem
   integration


   View Slide

6. “For 81% of organizations,
   managing spend is their
   top cloud challenge”
   -- Flexera 2022 State of Cloud Report


   View Slide

7. Usage
   Total units describing
   usage of each
   underlying service
   Rate*
   Amount paid per
   unit of usage
   $0.138 GB / month
   128 GB stored this month
   $0.214 / hour
   720 hours this month
   How is Azure cost calculated?
   Azure Cost
   Total amount to
   be paid for usage
   of all services
   USD 156.22/month
   USD 17.66/month
   =
   Compute
   Storage
   * Azure PostgreSQL Flexible Server pricing for West Central US region. Cost of an Azure service can vary between locations based on demand and local
   General Purpose (2-64 vCores)
   Max IOPS 3200
   X


   View Slide

8. To reduce cost
   Optimize Rate
   Optimize Usage
   Ultimately, there are two levers to reduce costs
   Use only what you need
   Pay less for what you use
   Bring your Azure
   Postgres bill down.


   View Slide

9. Scale compute Up/Down
   Azure advisor for right sizing resources
   Evaluate HA and DR requirements
   Consolidate databases and servers
   Starting and Stopping servers
   Archive old data for cold storage
   Azure Advisor to shutdown unused database
   Manage spending via budgets and alerts
   Save on cost with reserved capacity pricing
   Place test servers in cheaper geo-regions


   View Slide

10. Save on compute cost
    with reserved capacity
    pricing


    View Slide

11. Scenario – Using “Pay as you go” Pricing
    You are using Flexible Server
    You are paying for default “Pay as you go” pricing
    You can save cost by using Azure reservations
    Recommendation
    Leverage reserved capacity pricing


    View Slide

12. What?
    - Reserved capacity pricing
    allows to save costs by
    committing to a specific
    amount of capacity for 1- or
    3-year term.
    - This can be used to cover
    the costs of Azure
    PostgreSQL servers created
    in the same region.
    Potential savings
    Up to 58% saving with 3
    year reserved
    Up to 38% saving with 1
    year reserved
    Refer - What are Azure
    Reservations?
    Save on compute cost with reserved capacity pricing


    View Slide

13. Get Started with Azure Reservations
    Steps:
    1. Sign into the Azure portal.
    2. Select All services > Reservations.
    3. Select Add and then in the Purchase
    reservations pane, select Azure Database for
    PostgreSQL to purchase a new reservation
    for your PostgreSQL databases.
    4. Fill in the required fields. Existing or new
    databases that match the attributes you
    select qualify to get the reserved capacity
    discount.


    View Slide

14. Place test servers in
    cheaper geo-regions


    View Slide

15. Scenario – Using same geo-region for all instances
    You are using Flexible Server
    You might be overpaying by having all databases
    instances created in same geo region
    Recommendation
    Spread your some of your non-mission critical
    workloads in geo-regions with less pricing


    View Slide

16. What?
    - Creating a test server in a
    cheaper Azure region can
    be a cost-saving strategy.
    - For non-mission critical
    applications consider
    keeping the app and
    database in a single region
    to leverage the advantages
    of the lower-cost region
    and lower latency.
    Potential savings
    Can save up to 25% or
    more on the cost in
    cheaper geo region
    Refer - Cost impact of
    Azure regions - Microsoft
    Learn
    Place test servers in cheaper geo-regions


    View Slide

17. Get Started with Azure regions
    Steps:
    1. Sign into the Azure portal.
    2. Identify a cheaper region with lower
    cost of computing resources.
    3. Create a new Flexible Server instance
    in the cheaper region with the right
    configuration for your test
    environment.
    4. Migrate the test data to the new
    Flexible Server instance. You can use
    tools such as pg_dump and pg_restore
    to export and import databases.
    5. Monitor the performance of the test
    server and adjust the resources as
    needed to ensure optimal performance.
    50%
    60%
    90%
    40%
    50%
    20%


    View Slide

18. Scale compute
    Up/Down


    View Slide

19. Scenario – Using fixed capacity of resources
    You are using Flexible Server
    Your app traffic is unpredictable and is well below peak
    You might be paying for provisioned capacity you don’t use
    Recommendation
    Scale compute Up/Down


    View Slide

20. What?
    - Scaling up or down the
    resources based on usage
    can help you optimize
    costs.
    - Increase or decrease the
    number of vCores or
    increase the storage size
    of your database as
    needed, to ensure you are
    only paying for the
    resources you are using.
    Potential savings
    Can save up to 49%
    by right-sizing the
    capacity
    Refer - Scale
    operations in Flexible
    Server
    Scale compute Up/Down


    View Slide

21. Get Started with scaling resources
    Steps:
    1. Sign into the Azure portal.
    2. Click Compute+storage.
    3. You can choose the compute class
    between burstable, general purpose,
    and memory optimized tiers.
    4. If you want to change the number of
    vCores, you can click the drop-down
    of Compute size and click the desired
    number of vCores/Memory from the
    list.
    5. Click Save.


    View Slide

22. Use Azure advisor
    recommendations for right
    sizing resources


    View Slide

23. Scenario – Using Azure advisor recommendations
    You are using Flexible Server
    You have not performed any Azure advisor recommendation
    You might be overpaying for unused capacity
    Recommendation
    Use Azure advisor recommendations for right
    sizing resources


    View Slide

24. What?
    - Advisor analyzes
    resource configuration and
    usage patterns and
    provides
    recommendations on how
    to improve the
    performance and lower
    the cost.
    - Recommendations
    included compute,
    storage, networking and
    databases.
    Potential savings
    Up to 30% is cost
    saving on the
    cleaning-up unused
    resourced.
    Refer - Azure Advisor
    for PostgreSQL
    Azure advisor recommendations for right sizing resources


    View Slide

25. Get Started with Azure advisor
    Steps:
    1. Sign into the Azure portal.
    2. Recommendations are available from
    the Overview navigation sidebar in the Azure
    portal. A preview will appear as a banner
    notification, and details can be viewed in
    the Notifications section located just below the
    resource usage graphs.
    3. Recommendations as categorized as:
    • Performance: Includes CPU usage, memory
    pressure, connection pooling, disk utilization,
    and product-specific server parameters.
    • Reliability: Includes storage limits, and
    connection limits.
    • Cost: This includes server right-sizing
    recommendations.


    View Slide

26. Evaluate HA (high availability)
    and DR (disaster recovery)
    requirements


    View Slide

27. Scenario – Configuring HA/DR for all workload types
    You are using Flexible Server
    You have configured High Availability for all servers or setup
    Read-Replica for all the databases
    You might be overpaying for HA/DR capacity you don’t need
    Recommendation
    Evaluate HA (high availability) and DR (disaster recovery)
    requirements


    View Slide

28. What?
    - PostgreSQL Flexible
    Server has built-in
    node and storage
    resiliency at no extra
    cost
    - Non mission critical
    workload can leverage
    this and save on the
    cost of having a
    separate HA or DR
    instance.
    Potential savings
    50% is cost saving on
    rightsizing resources.
    Refer - Azure Advisor
    for PostgreSQL
    Evaluate HA and DR requirements


    View Slide

29. Get Started - Enable high availability
    Steps:
    1. In the Azure portal, choose Flexible Server
    and click create.
    2. Choose your availability zone. This is useful
    if you want to collocate your application in
    the same availability zone as the database to
    reduce latency. Choose No Preference if
    you want the flexible server to deploy the
    primary server on any availability zone.
    3. Click the checkbox for Enable high
    availability. That will open up an option to
    choose high availability mode. If the region
    does not support AZs, then only same-zone
    mode is enabled.


    View Slide

30. Get Started – Disable high availability
    Steps:
    1. In the Azure portal, select your existing
    PostgreSQL flexible server.
    2. On the flexible server page, click High
    Availability from the left panel to open
    high availability page.
    3. Un-Check on the High
    availability checkbox to disable the
    option. Then click Save to save the
    change.


    View Slide

31. Consolidate databases
    and servers


    View Slide

32. Scenario – Having too many small instances
    You have created multiple database instances for your different
    apps
    You might be paying more for resources when they are
    underutilized or idle
    Recommendation
    Consolidate databases and servers


    View Slide

33. What?
    - Consolidating databases in
    a few larger instances is
    more cost-effective than
    many smaller instances.
    - It is important to measure
    the impact of consolidation
    on the performance, to
    ensure that the server is
    appropriately sized to meet
    application requirements.
    Potential savings
    Realize Up to 30% is cost
    saving on the unused
    resourced.
    Refer - Azure Advisor for
    PostgreSQL
    Consolidate databases and servers


    View Slide

34. Get Started with database consolidation
    Steps:
    1. Identify server that can be
    consolidated, considering size,
    region, configuration (CPU, memory,
    IOPS), performance requirements,
    workload type.
    2. Create a new instance with enough
    vCPUs, memory, and storage to
    support the consolidated databases.
    3. Migrate the databases to the new
    instance. Use pg_dump and
    pg_restore to export and import
    databases.
    4. Monitor the performance of the
    new instance and adjust the
    resources.


    View Slide

35. Starting and Stopping
    servers


    View Slide

36. Scenario – Running instances 24/7 for all workload types
    You are using Flexible Server
    You leave instances running during evenings, weekends, and
    holidays when they are not used.
    You might be paying for compute capacity even when database
    is not being used.
    Recommendation
    Starting and Stopping servers


    View Slide

37. What?
    - Starting and stopping
    servers can be a cost-saving
    strategy PostgreSQL Flexible
    Server.
    - By only running the server
    when you need it, can
    significantly reduce the cost.
    - It is important to ensure
    that you have a reliable
    process for starting and
    stopping the server as
    needed.
    Potential savings
    Start/Stop instances can
    save up to $1000s in
    compute saving.
    Refer - Stop/Start an
    Azure Database for
    PostgreSQL - Flexible
    Server
    Starting and Stopping servers


    View Slide

38. Get Started with start/stop instance
    Steps:
    1. In the Azure portal, Identify the
    instance you want to Start and Stop.
    2. Start the instance when you need it.
    You can start the server using the Azure
    portal, Azure CLI, or Azure REST API.
    3. Stop the instance when you do not
    need it. You can stop the server using
    the Azure portal, Azure CLI, or Azure
    REST API.
    4. Also, if a server has been in a stopped
    (or idle) state for several continuous
    weeks, you can consider dropping the
    server after the required due diligence.


    View Slide

39. Archive old data for cold
    storage


    View Slide

40. Scenario – Operating data set includes historical data
    You have a large database with multiple years of data, however
    only current year of data is used for transactions and reporting
    You might be paying for provisioned storage that you don’t use
    Recommendation
    Archive old data for cold storage (Azure blob store)


    View Slide

41. What?
    - Archiving infrequently
    accessed data to Azure
    archive store (while still
    keeping access) can help
    reduce costs
    - Export data from
    PostgreSQL to Azure
    Archived Storage and store it
    in a lower-cost storage tier
    - You can also use Azure Data
    Factory to automate this
    process
    Potential savings
    Organizations can save up to
    95% monthly storage cost, by
    archiving infrequently
    accessed to lower-cost
    storage tier
    Also, besides cost, this will
    also benefit the query
    performance,
    Refer - Migrate your
    PostgreSQL database by
    using dump and restore
    Archive old data for cold (archive) storage


    View Slide

42. Get Started- archive old data to cold tier storage
    Steps:
    1.Setup Azure Blob Storage account and
    create a container for your database
    backups.
    2. Use pg_dump to export the old data to a
    file.
    3.Use the Azure CLI or PowerShell to upload
    the exported file to your Blob Storage
    container.
    4.Set up a retention policy on the Blob
    Storage container to automatically delete old
    backups.
    5.Modify the backup script to export the old
    data to Blob Storage instead of local storage.
    6.Test the backup and restore process to
    ensure that the archived data can be restored
    if needed.


    View Slide

43. Leverage Azure Advisor
    to find and shutdown
    unused database


    View Slide

44. Scenario – Having unused/idle instances
    You are running Flexible Server
    Your have over provisioned database instances
    You might be paying for provisioned capacity you don’t use
    Recommendation
    Leverage Azure Advisor to find and shutdown
    unused database


    View Slide

45. What?
    - Azure Advisor identifies
    resources that haven't been
    used at all over the last 7 days
    and makes a recommendation
    to shut them down.
    - Recommendation criteria
    include CPU and Outbound
    Network utilization metrics.
    Potential savings
    Leveraging Azure advisor
    recommendations to
    shutdown unused instanced
    can save up to $1000s in
    compute saving.
    Refer - Reduce service costs
    by using Azure Advisor
    Leverage Azure Advisor to find and shutdown unused database


    View Slide

46. Get Started with Azure advisor cost recommendation
    Steps:
    1. In the Azure portal, Open the Advisor
    service page, navigate to the "Cost" section
    and select "High-cost resources“
    2. In the list of high-cost resources, filter for
    the "Azure PostgreSQL servers" category.
    3. Identify any Azure PostgreSQL servers that
    have been inactive for an extended period
    and are no longer needed.
    4. Click on the identified PostgreSQL server
    from the list and check the Activity log for
    any activity over the last few days.
    5. If there has been no recent activity, In the
    "Settings" section, select the "Pause" option
    to shut down the PostgreSQL server.
    6. Confirm the shutdown process.


    View Slide

47. Manage spending better
    by setting up budgets
    and alerts


    View Slide

48. Scenario – Using Azure budgets to manage cloud spend
    You are using Flexible Server with database that are always on
    You have not configured budgets to get alert when consumption reaches
    a given threshold
    You might be overspending on Azure services
    Recommendation
    Manage spending better by setting up budgets
    and alerts


    View Slide

49. What?
    - Azure Budget alerts helps
    control costs by providing
    real-time notifications when
    your spending exceeds
    thresholds.
    - This enables you to reduce
    your spending and avoid
    unexpected charges.
    - Besides cost, budgets are
    critical for visibility and
    better planning of your
    Azure cloud spend.
    Potential savings
    Organizations can save up to
    65% on cost when using
    Azure budget and alerts.
    Refer - cost alerts to monitor
    usage and spending
    Manage spending better by setting up budgets and alerts


    View Slide

50. Get Started – Create Azure budget
    Steps:
    1. In the Azure portal, Open the Azure
    Cost Management + Billing service
    page.
    2. Navigate to the "Cost Management"
    section and select "Budgets.“
    3. Click on the "Add" button to create a
    new budget.
    4. Enter a name for the budget and select
    the subscription to associate it with.
    5. Choose the budget amount and time-
    period for which it applies.
    6. Select the scope of the budget
    7. Choose the budget alert threshold
    and frequency for notifications


    View Slide

51. Get Started – Create Azure budget alerts
    Steps:
    1. Once the budget is created, you can also
    set up alerts to notify you when the
    budget threshold is exceeded.
    2. In the "Budgets" section of the Cost
    Management + Billing dashboard, click
    on the name of the budget you want to
    set up alerts for.
    3. In the budget details page, navigate to
    the "Alerts" section and click on the
    "Add" button.
    4. Enter the email addresses or phone
    numbers of the recipients to be notified
    when the budget threshold is exceeded.
    5. Choose the alert threshold and
    frequency for notifications.
    6. Click on the "Create alert rule"


    View Slide

52. 3. Scale compute Up/Down
    4. Azure advisor for right sizing resources
    5. Evaluate HA and DR requirements
    6. Consolidate databases and servers
    7. Starting and Stopping servers
    8. Archive old data to cold storage
    9. Azure Advisor to shutdown unused database
    10. Manage spending via budgets and alerts
    1. Save on cost with reserved capacity pricing
    2. Place test servers in cheaper geo-regions


    View Slide

53. If your specific scenario was not covered in the presentation, please
    feel free to reach out to us.
    We’re happy to help.


    View Slide

54. | Resources
    Azure Database for Postgres homepage
    http://aka.ms/postgres
    Azure Postgres documentation
    http://aka.ms/postgresdocs
    Azure Postgres on Twitter
    @AzureDBPostgres
    Ask Questions
    AskAzureDBforPostgreSQL@service.microsoft.com
    Get Started for Free with an Azure Free Account
    https://aka.ms/try-postgres-free
    Azure Postgres on LinkedIn
    https://www.linkedin.com/company/azure-database-for-postgresql/
    Azure Postgres Blog
    https://aka.ms/Azure-Postgres-Blog


    View Slide

55. View Slide
