July 2020: Hold my state - Creating Workflows with Azure Durable Functions by Maxime Rouiller

July 2020: Hold my state - Creating Workflows with Azure Durable Functions by Maxime Rouiller

Check out the video to this session here:

Do your functions have asynchronous dependencies or long running requirements? Fan out and fan in? Jumping through hoops or creating additional overhead trying to maintain state? Take a load off, Durable Functions has your back. Come learn how to simplify complex workflows and win your weekends back.

I've been in the tech industry since the 2000s. I've always been working with .NET for as far as I can remember. I've built my profile on being a master of all trade. I've setup VMs, SharePoint environments, built servers and what not. I've coded from desktop apps to server apps, but I've truly found my passion around the web, however. Since then, I've been consulting independently for 3 years before seeing an opportunity to join Microsoft. I co-manage a local user group in Montreal, I own my own blog.

If you want to talk bread and bicycling, I'm your man.

You can find him at


More Decks by Azure Zurich User Group

Other Decks in Programming


  1. Author functions in C#, F#, Node.JS, Java, and more Code

    Events React to timers, HTTP, or events from your favorite Azure services, with more on the way Outputs Send results to an ever- growing collection of services
  2. Language 1.x 2.x 3.x C# GA (.NET Framework 4.7) GA

    (.NET Core 2.2) GA (.NET Core 3.1) JavaScript GA (Node 6) GA (Node 8 & 10) GA (Node 10 & 12) F# GA (.NET Framework 4.7) GA (.NET Core 2.2) GA (.NET Core 3.1) Java N/A GA (Java 8) GA (Java 8) PowerShell N/A GA (PowerShell Core 6) GA (PowerShell Core 6) Python N/A GA (Python 3.6 & 3.7) GA (Python 3.6, 3.7, & 3.8) TypeScript N/A GA1 GA1 https://docs.microsoft.com/azure/azure-functions/supported-languages
  3. // calls functions in sequence public static async Task<List<string>> Run(DurableOrchestrationContext

    context) { var outputs = new List<string>(); outputs.Add(await context.CallActivityAsync<string>("SayHello", “Seattle")); outputs.Add(await context.CallActivityAsync<string>("SayHello", “Amsterdam")); // returns ["Hello Seattle!", "Hello Amsterdam!"] return outputs; }
  4. // calls functions in sequence module.exports = df.orchestrator(function*(context){ const output

    = []; output.push(yield context.df.callActivity("E1_SayHello", "Seattle")); output.push(yield context.df.callActivity("E1_SayHello", "Amsterdam")); // returns ["Hello Seattle!", "Hello Amsterdam!"] return output; });
  5. # calls functions in sequence def orchestrator_function(context: df.DurableOrchestrationContext): task1 =

    yield context.call_activity("SayHello", "Seattle") task2 = yield context.call_activity("SayHello", "Amsterdam") outputs = [task1, task2] # returns ["Hello Seattle!", "Hello Amsterdam!"] return outputs main = df.Orchestrator.create(orchestrator_function)
  6. “Hello Amsterdam!” [“Hello Amsterdam!”] Orchestrator Function Activity Function Execution History

    var outputs = new List<string>(); outputs.Add(await context.CallActivityAsync<string>("SayHello", “Amsterdam")); return outputs; Orchestrator Function ? Activity Function “Hello Amsterdam!” Orchestrator Started Execution Started Task Scheduled, SayHello, “Amsterdam” Orchestrator Completed Task Completed, “Hello Amsterdam!” Orchestrator Started Execution Completed, ["Hello Amsterdam!"] Orchestrator Completed
  7. F1 F2 F3 F4 // calls functions in sequence public

    static async Task<object> Run(DurableOrchestrationContext ctx) { try { var x = await ctx.CallFunctionAsync("F1"); var y = await ctx.CallFunctionAsync("F2", x); var z = await ctx.CallFunctionAsync("F3", y); return await ctx.CallFunctionAsync("F4", z); } catch (Exception) { // global error handling/compensation goes here } }
  8. public static async Task DurableOrchestrationContext var new int // get

    a list of N work items to process in parallel object await object "F1" for int Task int int "F2" await Task // aggregate all N outputs and send result to F3 int await "F3"
  9. public static async Task Run(DurableOrchestrationContext ctx) { await ctx.CallActivityAsync<object[]>("RequestApproval"); using

    (var timeoutCts = new CancellationTokenSource()) { DateTime dueTime = ctx.CurrentUtcDateTime.AddHours(72); Task durableTimeout = ctx.CreateTimer(dueTime, 0, cts.Token); Task<bool> approvalEvent = ctx.WaitForExternalEvent<bool>("ApprovalEvent"); if (approvalEvent == await Task.WhenAny(approvalEvent, durableTimeout)) { timeoutCts.Cancel(); await ctx.CallActivityAsync("HandleApproval", approvalEvent.Result); } else { await ctx.CallActivityAsync("Escalate"); } } }
  10. [FunctionName("ProvisionNewDevices")] public static async Task ProvisionNewDevices([OrchestrationTrigger] DurableOrchestrationContext ctx) { string[]

    deviceIds = await ctx.CallActivityAsync<string[]>("GetNewDeviceIds"); // Run multiple device provisioning flows in parallel var provisioningTasks = new List<Task>(); foreach (string deviceId in deviceIds) { Task provisionTask = ctx.CallSubOrchestratorAsync("DeviceProvisioningOrchestration", deviceId); provisioningTasks.Add(provisionTask); } await Task.WhenAll(provisioningTasks); // ... }
  11. List<SampleLinks> links = await context.CallActivityAsync<List<SampleLinks>>("LinkResolving_SampleLinks_GetAllLink s", null); List<Task<List<(int id, string

    resolvedLink)>>> tasks = new List<Task<List<(int id, string resolvedLink)>>>(); foreach (IEnumerable<SampleLinks> batch in links) { tasks.Add(context.CallActivityAsync<List<(int id, string newLink)>>("LinkResolving_ResolveLinkBatch", batch.Select(link => (link.Id, link.Link)))); } await Task.WhenAll(tasks); // . . .
