Design a Voxel Rendering Engine for iOS Shipeng Xu 20
Oct 2017 @1991bill
What is Voxel? • Volume Pixel • Data Structure ◦
Integral X, Y, Z coordinates ◦ Color Pokemon Voxel, Playiku, 2016
None
Voxel Rendering Engine for iOS • Rendering ◦ Beautiful •
Performance ◦ Blocks can be added or removed at interactive speeds ◦ E.g. A 64x64x64 voxel world = 262,144 voxels! Add Delete Move Change Color
Rendering - 1 Voxel 12 Triangles
Rendering - 5,911 Voxels
Rendering - Meshing • Naive way... • Draw a 3D
cube for each voxel. ◦ 5,911 Voxels ◦ 5,911 x 12 = 70,932 triangles
Rendering - Meshing • Skip the unseen voxels ◦ Before:
5,911 Voxels ▪ 5,911 x 12 = 70,932 triangles ◦ After: 5,868 triangles ▪ 8.2% of original
Rendering - Meshing
• Combine small faces into bigger ones Rendering - Meshing
280 Triangles 22 Triangles(7.9%!)
Rendering - Lighting
Rendering - Ambient Occlusion
Rendering - Ambient Occlusion Occlusion level 3 2 1 0
Rendering - Ambient Occlusion
X Basic Lighting X Ambient Occlusion ✔ Basic Lighting X
Ambient Occlusion ✔ Basic Lighting ✔ Ambient Occlusion Rendering - Lighting
Links • Voxel Meshing - https://0fps.net/category/programming/voxels/ • Voxel Rendering Techniques
- https://medium.com/@fogleman/voxel-rendering-techniques-fa8d869457 ca • Volume Rendering - http://bytebash.com/2012/03/opengl-volume-rendering/ • http://shipeng.studio
