Navigating the Campaign Contribution Network

A brief intro to complex systems, and a preview of work I'm doing exploring FEC campaign contribution data as a complex network.

Transcript

1. NAVIGATING THE CAMPAIGN CONTRIBUTION NETWORK Bobby Norton 1 Dev Day - Detroit, MI November 17, 2012 image: http://skyeome.net/wordpress/?p=102
2. Learning Systems Institute Lockheed Martin Simulation & Training ThoughtWorks DRW Trading Group Aurelius Education Startup (Coming soon...)
3. If string theory fails to provide a testable prediction, then nobody should believe it. S. James Gates, Jr. - University of Maryland
4. In string theory, the Planck length is the order of magnitude of the oscillating strings that form elementary particles, and shorter lengths do not make physical sense. http://en.wikipedia.org/wiki/Planck_length
5. Charge radius of a proton: 0.8768 x 10-15m
6. A difference of 1020m
7. 1020m: Approximate width of the Milky Way galaxy
8. http://ut-images.s3.amazonaws.com/wp-content/uploads/2010/11/milkyway.jpg
9. It’s difficult to make scientific claims about something that can’t be measured.
10. Testable predictions about complex systems GOAL
11. Graph databases provide us with an efficient means to create predictive models of complex systems. CLAIM
12. COMPLEX SYSTEMS • Cascading failures • Unclear boundaries • May be capable of adaptation • Nonlinear (exhibit a “Butterfly Effect”) • May be nested, a system of systems • Often exhibit small world and scale-free topologies http://en.wikipedia.org/wiki/Complex_system#Features_of_complex_systems
13. Complexity can emerge from simple components
14. http://en.wikipedia.org/wiki/File:KochFlake.svg
15. Text http://flowingdata.com/2008/03/12/17-ways-to-visualize-the-twitter-universe/
16. Skitter data depicting a macroscopic snapshot of Internet connectivity, with selected backbone ISPs By K. C. Claffy Email: kc@caida.org http://www.caida.org/publications/papers/bydate/index.xml
17. http://upload.wikimedia.org/wikipedia/commons/0/03/C.elegans-brain-network.jpg
19. Exploring the network of campaign contributions WORK IN PROGRESS
20. http://www.fec.gov/finance/disclosure/ftpdet.shtml#2011_2012
21. C00514893|N|Q1|P|12951391265|15E|IND|KATZ, DAVID|SAN FRANCISCO|CA|94110|GROUPON, INC.|VP/ GM|03202012|1000|C00401224|C3694043A|776253||* EARMARKED CONTRIBUTION: SEE BELOW| 4051020121155797607 C00496778|A|Q1|P|12951584507|15|IND|KALATHIL, VINOD|CHICAGO|IL|60607|GROUPON/DIRECTOR OF INTERNAL AUDIT|DIRECTOR OF INTERNAL AUDIT|03152012|1000||C6914012|781193||| 4051520121155972880 C00420760|N|Q2|P|12020554070|15|IND|KIMET, CAROLYN|EVANSTON|IL|80201|GROUPON|E-MARKETING DIRECTOR|06052012|1000||SA0802094012139|802475|||2080220121160111657 C00494740|N|M8|P|12952683408|15|IND|GERSTER, DAVID|BURLINGAME|CA|94010|GROUPON, INC.| DIRECTOR OF ANALYTICS|07112012|2000||C17532152|805999|||4082820121161649967 C00431445|N|M9|P|12972391292|15|IND|KATZ, DAVID|SAN FRANCISCO|CA|94110|GROUPON, INC.|VP/ GM MOBILE|08312012|1000||C20387409|811365|||4100320121165864857 C00494740|N|M10|P|12960022928|15|IND|KLATT, KYLE|CHICAGO|IL|60657|GROUPON|SENIOR CAMPAIGN ORGANIZER|09092012|250||C21392360|821033|||4102520121168451880 C00501692|A|Q3|P|12950510503|15|IND|BAVDA, MRUGESH|CHICAGO|IL|60622|GROUPON|MARKET PLANNER|09272011|500||C7251377|765709|||4030120121152599889 C00401224|N|M4||12971009695|24T|IND|KATZ, DAVID|SAN FRANCISCO|CA|94110|GROUPON, INC.|VP/ GM|03202012|1000|C00514893|SA11AI_5025357|778552||EARMARKED FOR PEOPLE FOR DEREK KILMER (C00514893)|4060920121156872726 C00494930|N|Q2|G|12020551850|15|IND|KLAUMINZER, JAY|ROCKY RIVER|OH|44116|GROUPON| REGIONAL VICE PRESIDENT|06292012|1000||SA0803123312246|802781|||2080620121160328596 C00494740|A|Q2|P|11971580062|15|IND|LEFKOFSKY, ERIC|GLENCOE|IL|60022|GROUPON|OWNER| 04152011|35800||C11008231|748092|||4101820111143685060 C00494740|N|M9|P|12972228143|15|IND|BAKER, CAROLINE|CHICAGO|IL|60616|GROUPON|OPERATIONS| 08312012|250||C20245573|810872|||4092720121165000105 C00431445|N|M9|P|12972342658|15|IND|HUTMACHER, AMY|GRAND JUNCTION|CO|81506|GROUPON| PRODUCT MANAGER|08082012|250||C18876006|811365|||4100320121165718953 C00494740|N|M9|P|12972226974|15|IND|MASON, ANDREW DIVVENS|CHICAGO|IL|60612|GROUPON| CEO|08102012|35800||C19080692|810872|||4092720121164996598 C00431445|N|M9|P|12972331365|15|IND|RASMUSSEN, ERIC|MENLO PARK|CA|94025|GROUPON.COM| MARKETING|08312012|250||C20380155|811365|||4100320121165685074
23. FEC NODES AND EDGES • candidates --contribute_to--> committees • committees --contribute_to--> committees • donors --contribute_to--> committees • donors --employed_by--> companies • companies --contribute_to--> committees • committees --contribute_to--> candidates
24. Property graph: “key/value-based, directed, multi-relational” http://github.com/tinkerpop/gremlin/wiki/Defining-a-Property-Graph
25. http://philcrissman.com/images/posts/3618515225_6446a9876b.jpg
26. ETL Extract Transform Load
27. CREATING NODES
28. public int saveEntries(BatchInserter inserter, BatchIndex index) { int count = 0; try { for (String line : lines) { String[] fields = line.split("\\|"); // Candidate address data is the most inconsistent in this file, so we skip that entirely. // There are also incomplete records, e.g. CAND_ID H2NJ02177, that we can skip since they // aren't referenced anywhere else. if (dirty(fields, 10)) continue; Map<String, Object> candidate = transform(fieldEnum, fields); long candidateId = inserter.createNode(candidate); index.add(candidateId, candidate); // TODO: Convert the COMMITTEE_ID property to a relationship with a committee count++; } } catch (Exception e) { throw new RuntimeException("Failed to write candidates:", e); } return count; }
29. CREATING EDGES
30. for (String line : lines) { String[] fields = line.split("\\|"); if (dirty(fields, 10)) { dirty++; continue; }
31. Map<String, Object> props = transactionProperties(fields); String sourceData = fields[Fields.SOURCE_COMMITTEE_ID.ordinal()]; String targetData = fields[Fields.TARGET_COMMITTEE_ID.ordinal()]; Long sourceId = committeeIndex.find("committee_id", sourceData); Long targetId = committeeIndex.find("committee_id", targetData); if (sourceId == null || targetId == null) { props.put("source", sourceData); props.put("target", targetData); int amount = Integer.parseInt(fields[Fields.AMOUNT.ordinal()].trim()); dirtyMoney += amount; dirty++; } else { inserter.createRelationship(sourceId, targetId, Relationships.CONTRIBUTED, props); count++; }
32. INDEXING
33. public BatchIndex(BatchInserter inserter, String indexName, String indexProperty) { this.indexProperty = indexProperty; indexProvider = new LuceneBatchInserterIndexProvider(inserter); index = indexProvider.nodeIndex(indexName, MapUtil.stringMap("type", "exact")); index.setCacheCapacity(indexProperty, 100000); } http://lucene.apache.org
34. public void add(long nodeId, Map<String, Object> properties) { if (!properties.containsKey(indexProperty)) { throw new RuntimeException( String.format("Node %d is missing property %s", nodeId, indexProperty)); } index.add(nodeId, properties); }
35. public Long find(String key, String value) { IndexHits<Long> ids = index.get(key, value); if (!ids.hasNext()) { ids.close(); return null; } Long nodeId = ids.next(); ids.close(); return nodeId; }
36. NETWORK ANALYSIS Queries Algorithms
37. How much has the Obama campaign spent? obama = g.V.filter {it.name == "OBAMA, BARACK"}.next() x = [] obama.outE.amount.store(x) { it.toInteger() } x.inject(0) { acc, val -> acc + val } ==>187447424* *given the data I’ve loaded so far...
38. To which committee did the Obama campaign make the most number of contributions? obama = g.V.filter {it.name == "OBAMA, BARACK"}.next() x = [:] obama.out.groupCount(x).iterate() top = x.sort {a,b -> b.value <=> a.value}[0..9] gremlin> top.keySet().toArray().first().name ==>WORKING AMERICA
39. Who is going to win the election? (according to eigenvector centrality) m = [:]; c = 0; g.V.out.groupCount(m).loop(2){c++ < 1000} top = m.sort{-it.value}[0..9] top.keySet().toArray().first().name ==>OBAMA FOR AMERICA
40. This approach relies on mining a network hidden in relational data
41. Chapter 13: Crouching Table, Hidden Network
43. NEXT STEPS • Open source release for hackers and data scientists - ANN coming soon via Twitter • Finish loading FEC data and continue network analysis • Visualize the network • Compare results to other implementations to validate the original claim
44. @bobbynorton linkedin.com/in/bobbynorton
