Cloudant Webinar: Integrate User Management and Cloudant Query into a Node.js & Cloudant Application

Join us to explore how we transformed IBM Cloudant's Location Tracker application from a CouchApp into a full three-tier Node.js app. You’ll learn how to add user management functionality and leverage Cloudant Query to display a map of individual user locations within the app.

Transcript

1. Integrate User Management and Cloudant
   Query into a Node.js & Cloudant Application
   IBM Cloudant Webinar
   Thursday, June 18, 2015
   Bradley Holt, Developer Advocate
   @BradleyHolt


   View Slide

2. View Slide

3. Location Tracker
   •  Stores data locally in PouchDB
   •  Front end built with AngularJS
   •  Authentication logic built with Node.js
   •  User interface built with Leaflet
   •  Replicates location data to Cloudant
   •  More info:
   https://cloudant.com/location-tracker/
   3


   View Slide

4. PouchDB
   •  A database in your web browser
   •  Also works in Node.js
   •  Can synchronize with any
   database that implements the
   CouchDB Replication Protocol
   4


   View Slide

5. Location Tracker: Parts 1 & 2
   •  Part 1
   •  Uses HTML5 geolocation API
   •  Uses PouchDB and Cloudant
   •  Part 2
   •  Polished single-page app
   •  Introduces AngularJS
   •  Both implemented as CouchApps
   •  Self-contained, hosted within Cloudant
   •  No middle tier
   5


   View Slide

6. Adding a Middle Tier
   •  CouchApps only have a data and
   a presentation tier
   •  Practical limitations to application
   logic within Cloudant/CouchDB
   •  For example, authentication requires
   a logic/application tier
   6
   Image Credit: Overview of a three-tier application, by Bartledan, based on a file by User:Foofy.Bartledan at en.wikipedia [Public domain], from Wikimedia Commons


   View Slide

7. Location Tracker: Part 3
   •  Authentication and authorization
   •  User registration
   •  User login
   •  User logout
   •  Map of individual user locations
   and movement
   •  Static web server and reverse
   proxy to Cloudant
   •  Deployable to IBM Bluemix
   7


   View Slide

8. 8
   Location Tracker Part 3: https://cloudant.com/location-tracker/


   View Slide

9. IBM Cloudant
   •  Globally distributed data layer for
   web and mobile applications
   •  MongoDB-style queries
   •  Advanced geospatial capabilities
   •  Full text search indexing
   9


   View Slide

10. JSON Documents
    10
    {

    _id: "6EF9D2B0-13D3-1378-8D30-39E3CE0B36C2",

    _rev: "1-0b457efcf82fb29492ef927ba5b6ee15",

    type: "Feature",

    geometry: {

    type: "Point",

    coordinates: [

    -71.1028,

    42.3691

    ]

    },

    properties: {

    session_id: "3486b13f-7b8a-8a96-dfbf-9b82800e367f",

    timestamp: 1422928591717

    }

    }


    View Slide

11. PouchDB and Cloudant Replication
    11


    View Slide

12. Managing User Access


    View Slide

13. PouchDB Authentication
    •  User authentication plugin
    for PouchDB and CouchDB
    https://github.com/nolanlawson/pouchdb-authentication
    •  Integrates with the CouchDB
    authentication API
    •  signup
    •  login
    •  session
    •  logout
    •  Does not map to the Cloudant
    security model
    13


    View Slide

14. Mapping to the Cloudant Security Model
    14
    .!
    ├── LICENSE.txt!
    ├── Procfile!
    ├── README.md!
    ├── admin.js!
    ├── app.js!
    ├── controllers!
    ├── ddocs!
    ├── manifest.yml!
    ├── node_modules!
    ├── package.json!
    ├── public!
    ├── routes!
    │ └── api.js!
    ├── tutorial!
    └── views


    View Slide

15. Authentication Methods
    •  Registration (api.putUser)
    PUT /api/_users/:id"
    •  Login (api.postSession)
    POST /api/_session"
    •  Session (api.getSession)
    GET /api/_session"
    •  Logout and Cloudant Service Proxy
    •  API is the same in Cloudant for logout
    •  All other requests to /api/* are
    proxied to Cloudant
    15


    View Slide

16. User Registration
    1.  Generates a Cloudant API key
    and API password
    2.  Grants the generated API key
    user read and write access to the
    location-tracker database
    3.  AES encrypts the API key password
    using the user's chosen password
    as the encryption key
    4.  Saves the user's metadata as a
    document to the users database
    16


    View Slide

17. User Login
    1.  Get's the user's document from
    the user database
    2.  Decrypts the API password using
    the password supplied by the user
    3.  Authenticates with Cloudant
    using the API key and decrypted
    API password
    4.  Passes along the authentication
    cookie from Cloudant (if login
    was successful)
    17


    View Slide

18. User Session
    1.  Passing along the cookie from
    the client, calls the corresponding
    session function from the
    Cloudant Node.js client library
    2.  Returns the response from
    Cloudant to the client
    18


    View Slide

19. User Logout and Cloudant Service Proxy
    19


    View Slide

20. View Slide

21. Querying Locations By User


    View Slide

22. Locations by User
    •  Shows a list of users
    •  Click a user to see that user's map
    •  Cloudant Query
    https://cloudant.com/blog/introducing-cloudant-query/
    •  PouchDB Find
    http://nolanlawson.github.io/pouchdb-find/
    22


    View Slide

23. Locations by User
    •  Shows a list of users
    •  Click a user to see that user's map
    •  Cloudant Query
    https://cloudant.com/blog/introducing-cloudant-query/
    •  PouchDB Find
    http://nolanlawson.github.io/pouchdb-find/
    22


    View Slide

24. Querying a Database with PouchDB Find
    •  Based on Cloudant Query (Mango)
    •  Local or remote queries
    •  MongoDB-style query language
    •  Define fields to index
    23
    Image Credit: Mango with section on a white background by bangdoll, on Flickr


    View Slide

25. Defining an Index (admin.js)
    24


    View Slide

26. View Slide

27. Querying the Index (public/script/app.js)
    26


    View Slide

28. Further Reading
    •  Location Tracker
    https://cloudant.com/location-tracker/
    •  Cloudant Node.js library
    https://github.com/cloudant/nodejs-cloudant
    •  PouchDB
    http://pouchdb.com/
    •  Cloudant For Developers
    https://cloudant.com/for-developers/
    27


    View Slide

29. Image Credits
    28
    •  Overview of a three-tier application, by Bartledan, based on a file by User:Foofy.Bartledan at
    en.wikipedia [Public domain], from Wikimedia Commons

    •  Mango with section on a white background by bangdoll, on Flickr



    View Slide

30. Bradley Holt
    Developer Advocate
    bradley.holt@us.ibm.com
    @BradleyHolt
    github.com/bradley-holt
