Purple Packets - BSides Austin 2019

There are two sides to every story. Yin and yang. Day and night. Host and network. Unfortunately, when it comes to enterprise security, many organizations tend to focus heavily on host-based defenses, and apply “just-enough” monitoring to their network. However, the network can be one of the best places to not only defend against the attacker, but also observe and understand the capabilities.

In this talk, we’ll examine techniques with which advanced adversaries utilize your networks. Whether it’s via intricate protocol abuse, malleable traffic, or combinations of protocols to avoid standard detection, there is much to glean from an observation of network traffic.

To help our audience discover just how impactful proper network defenses can be, we’re going to emulate the top techniques followed by a detailed explanation of each attack. Furthermore, we’ll outline specific steps that would have detected and stopped the malicious traffic. Our goal, by the end of the session, is for our attendees to have a solid understanding of how the attacks work and what they need to do to protect themselves.

Transcript

1. Purple Packets Effective Network Defense Against Real-World Attacks BSides Austin 2019 Aaron Soto & Matt Bromiley
2. Today’s Agenda Who We Are The Importance of Red vs and Blue Why Packets? Traffic Examples ATTACK! Choose Your Weapon Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
3. Who We Are
4. Who We Are Aaron Soto * Exploit Developer * CCDC Coach/Mentor * OpenSOC Volunteer * Ham Radio Nerd Lover of exploits and open source tools. Matt Bromiley * Incident Responder * SANS Instructor * OpenSOC Volunteer * Nerdy ink Lover of DFIR and open source tools. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
5. The Importance of Red and Blue
6. The Importance of Red and Blue • In many situations, red and blue are often thought of as rivals - not teammates. • Blue gains strength by learning how red operates. • Red gains strength by learning how blue detects. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
7. The Importance of Red and Blue • In many situations, red and blue are often thought of as rivals - not teammates. • Blue gains strength by learning how red operates. • Red gains strength by learning how blue detects. Increased security and environment awareness! Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
8. Why Packets?
9. Why Packets? There is a significant focus on detection via host-based artifacts, indicators, and tools. There is also a significant focus on developing techniques to evade host-based detection! Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
10. Why Packets? • Many attacks/malware will utilize unique and novel techniques to obfuscate/hide from endpoint detection tools. • Attackers often ignore/assume network traffic or “lightly” encrypt/obfuscate. ◦ Some attackers will create novel network techniques - this only provides more opportunity for detection! ◦ Some techniques are inherently encrypted (PowerShell, RDP, etc.). Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
11. Why Packets? • Unfortunately - network traffic is often also ignored or mishandled by enterprises. • This leaves an effective detection technique under (or not!) utilized. ..as always, this is easier said than done. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
12. Traffic Examples
13. Traffic Examples: “Commodity” Malware
14. “Commodity Malware” • “Commodity” malware (think TrickBot, Emotet, Qakbot, etc.) are often SUPER noisy - this makes for excellent network detection. • Detecting initial callout is preferred to detecting post-spread! • Initial callout/download is likely plaintext - grab malware before encryption kicks in. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley Huge thanks to Brad (@malware_traffic) for this sample: https://isc.sans.edu/forums/diary/Malspam+pushes+Emotet+with+Qakbot+as+the+followup+malware/24738/
15. Traffic example: Qakbot/Emotet Initial Callout (1) Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
16. Traffic example: Qakbot/Emotet Initial Callout (2) Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
17. Traffic Examples: Reverse Shells
18. Shells • Primary mechanism of gaining & maintaining access in an environment • Get a user to run ${thing}, and attacker gets a call-back • Attacker can hardcode an IP address or domain, but may also move to dynamic (read: potentially harder to detect) C2 Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
19. Traffic example: reverse_tcp meterpreter over port 80 Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
20. Traffic example: reverse_http meterpreter over port 80 (1) Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
21. Traffic example: reverse_http meterpreter over port 80 (2) Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
22. Traffic example: reverse_http meterpreter over port 80 (3) Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
23. ATTACK!
24. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
25. Initial Access Social Engineering tools make it easy • Social Engineering Toolkit (SET) • Phishing Frenzy • GoPhish Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
26. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
27. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
28. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
29. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
30. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
31. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
32. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
33. LEGIT Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
34. FAKE Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
35. Initial Access Methods of detection: • Email: Monitoring for previously identified malicious emails or suspicious emails targeting high-profile employees • DNS: Watch for resolution of unique hosts • HTTP: Watch for transfer of potentially malicious file formats • User agents: Watch for uncommon, unique, or malformed strings • Failed attempts: HTTPS aborted connections, HSTS failures Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
36. Acquiring credentials Mimikatz is the best game in town • Integrated into PowerShell Empire and Metasploit Framework ◦ Note: Metasploit Framework calls it `kiwi` for x64 systems • Mimikatz supports 24 methods for credential gathering, escalation, and more! ◦ DCsync is my favorite so far... Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
37. • lsadump is a module that targets the Local Security Authority • lsadump::dcsync uses the Directory Replication Service (DRS) to trigger update naming context (NC) between hosts . ◦ Includes SID, along with current and previous password hashes • TL;DR: We pretend to be another domain controller. Acquiring credentials Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
38. Acquiring credentials meterpreter > getuid Server username: GOTHAM\batman meterpreter > dcsync GOTHAM\\batman [DC] 'gotham.packets.dev' will be the domain [DC] 'packets-dc01.gotham.packets.dev' will be the DC server [DC] 'GOTHAM\batman' will be the user account Object RDN : batman ** SAM ACCOUNT ** [...] Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
39. Acquiring credentials [...] SAM Username : batman Account Type : 30000000 ( USER_OBJECT ) User Account Control : 00000200 ( NORMAL_ACCOUNT ) Account expiration : 1/1/1601 12:00:00 AM Password last change : 3/10/2019 8:50:18 AM Object Security ID : S-1-5-21-552993230-966223408-4019343230-500 Object Relative ID : 500 Credentials: Hash NTLM: 6a8656b60d12f872cd1ef7006578e28c Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
40. Acquiring credentials Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
41. Acquiring credentials Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley DRSGetNCChanges
42. Acquiring credentials Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
43. Acquiring credentials Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley DRSGetNCChanges
44. Acquiring credentials Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley DRSGetNCChanges
45. • Meterpreter's mimikatz / kiwi only targets one account at a time ◦ An attacker wants everything (all users, machine accounts, service accounts, etc.) • DCsync supports the '/all' option ◦ Large or multi-fragment responses indicate a full DCsync dump, potentially containing hashes for all users and workstations. kiwi_cmd \"log debug.log\" \"lsadump::dcsync /all\" exit Acquiring credentials Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
46. Acquiring credentials Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
47. Acquiring credentials Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
48. Acquiring credentials Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
49. Acquiring credentials Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
50. Methods of detection: • Workstations should never use DRSUAPI / DCERPC opnum 3 • DRSGetNCChanges is a characteristic of DCSync ◦ (and also of domain controllers syncing) • Watch for DRSUAPI / DCERPC opnum 3 from an untrusted host ◦ also known as DSGetNCChanges or DRSGetNCChanges() Reference: https://blogs.technet.microsoft.com/askds/2012/01/24/rpc-over-itpro/ Acquiring credentials Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
51. How about that shell? • Our Aattacker (hint hint) used a reverse_https shell. • HTTPS = encryption. If it’s encrypted, it’s not worth analyzing. Right? Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
52. Traffic example: reverse_https meterpreter over port 8443 Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
53. Pro Tip: Fingerprint the Encrypted Traffic • Just because you cannot read the traffic, doesn’t mean you can’t make use of the traffic. • Encrypted traffic can be fingerprinted: ◦ SSL/TLS: JA3 and JA3S hashes ◦ SSH: HASSH • Examine x.509 details for key indicators Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
54. JA3 Hash • Created by John B. Althouse, Jeff Atkinson, Josh Atkins (see the JAs?) • Provides a fingerprint for Client Hello • Hashes Decimal Values of: ◦ SSL Version ◦ Cipher ◦ SSL Extension ◦ Elliptic Curve ◦ Elliptic Curve Point Format Reference: https://github.com/salesforce/ja3 Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
55. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
56. JA3S Hash • Also Created by John B. Althouse, Jeff Atkinson, Josh Atkins (see the JAs?) • Provides a fingerprint for Server Hello • Hashes Decimal Values of: ◦ SSL Version ◦ Cipher ◦ SSL Extension Reference: https://github.com/salesforce/ja3 Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
57. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
58. X.509 • X.509 is the standard that describes public key certificates • As attackers encrypt their traffic, they are needing to create (or steal) certificates. This leaves behind even more metadata! • Attackers will also reuse certificates (who’s checking anyways, right?) across multiple domains/infrastructure. Check out: https://threatconnect.com/using-fancy-bear-ssl-certificate-information-t o-identify-their-infrastructure/ Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
59. X.509 X.509 Fields of Interest: • Issuer Name • Subject • Validity Period (Before and After) • Algorithm Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
60. X.509 X.509 Fields of Interest: • Issuer Name ◦ I want trustworthy issuers • Subject • Validity Period (Before and After) • Algorithm Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
61. X.509 X.509 Fields of Interest: • Issuer Name ◦ I want trustworthy issuers • Subject ◦ Common Name (CN), Organizational Unit (OU), Organization (O), Locality (L), State or Province (S), Country (C) • Validity Period (Before and After) • Algorithm Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
62. X.509 X.509 Fields of Interest: • Issuer Name ◦ I want trustworthy issuers • Subject ◦ Common Name (CN), Organizational Unit (OU), Organization (O), Locality (L), State or Province (S), Country (C) • Validity Period (Before and After) • Algorithm Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
63. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
64. Let’s return to our reverse_https traffic: Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
65. Let’s return to our reverse_https traffic: Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley JA3 Hashes
66. Choose Your Weapon
67. Zeek Zeek (formerly Bro) is a network security analysis framework. • Originally developed in 1994 • Zeek focuses on protocol analysis, logging, and data correlation, as opposed to simple data dump/capture. • Open source, highly-scriptable, and fast! http://zeek.org/ Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
68. Zeek (cont.) Zeek output: Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
69. Zeek (cont.) • Example logs: ◦ conn.log - closest thing to NetFlow ◦ dns.log - DNS lookups ◦ files.log - Observed file details ◦ http.log - Observed HTTP data ◦ smtp.log - Observed SMTP data ◦ ssl.log - Observed SSL/TLS data ◦ x509.log - Observed x509 data Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
70. Zeek (cont.) • Every Zeek log entry has a uuid that correlates to additional data sets Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
71. Network Monitoring - Moloch Moloch is a large scale, open source full PCAP monitoring and analysis tool. Moloch provides a unique web interface that allows for PCAP analysis in the browser. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
72. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
73. Conclusion While host-based analysis has earned a place, we quickly forget the power of packet analysis. • Protect your network in a single effort. • Don't shy away from encrypted traffic. • Obfuscated or deviations from well-established protocols make attackers stand out more. Purple Packets - BSides Austin - Aaron Soto & Matt Bromiley
74. Questions? Thanks for joining us this afternoon! Keep in touch after the talk: Aaron: @_surefire_ Matt: @mbromileyDFIR
