1. Edgecore Networks Ethernet Switch Solution CK Ng
2. • Edge-Core providing high quality, advanced features but cost effective Access/Aggregation solution for ISP, MSO world wide • Helping service provider building up Fiber To The Building (FTTB) , Fiber to the Home (FTTH) infrastructure for Broadband Access services • Service Providers can provide home user broadband access, IP-TV and VoIP services with affordable price Edge-Core Ethernet Switch for ISP/MSO
3. Core Aggregation Access Home Storage Storage Multicast Source Satellite VoD server Middleware SIP Server PSTN PPPoE router VPN Server DHCP Server Internet 10G AGG Ethernet Ring ECS4510-28F AS5710-54X-EC 40G AGG Ethernet Ring ETTH ES3528MV2 ECS3510-28T ES3510MA ECS3510-52T ECS4510-28F ECS4210-12T AS5710-54X-EC ECS4510-28F ECS4110-28T GETTH AS5710-54X-EC Carrier Aggregation & Access Solution EWS4502 Wireless Controller ECS4210-12P ECW720L ECWO5110L PC Phone Setop box TV SMCWBR14S-N5 PC IP Phone Setop box TV PC IP Phone Setop box TV FTTH
4. Russia & CIS countries Fiber from one apartment to another over the sky Fiber to the apartment Metro FTTB for business user
5. East Europe Cable TV box Corner Cable TV box Apartment
6. Western Europe
7. • Edge-Core showed our commitment to customer by continuously enhancing our software to meet different demands, application and customer’s need • Enhance robustness of multicast control to provide high quality IP-TV service • Ensure fully security of the services provider’s network against attack • Easing the management and troubleshooting Edge-Core Commitments
8. • Provide next generation switch with more advance functions such as IPv6 management; IPv6 security; IPv6 multicast control; Bundle rate limiting, Egress ACL; Egress policy mapping etc • Service providers can expand their business from home user to business user by providing more reliable and resiliency network (ITU-T G.8032 ERPS), Connectivity Fault Management (802.1ag, Y.1731) and ensuring SLA • Expand the business to mobile operator with Sync-E, IEEE 1588 PTP • High end L3 solution for Aggregation network Edge-Core Commitments
9. • Power Device (802.3at PD) support on any of the 8 port for booting up and operation (ideal for environment with no AC/DC source) • 1 port PSE connect to AP for Hotspot service ECS4510-12PD Residential Client ECS4000-5P Home user PoE switch PC Setop box MT-2520 x 2 TV ECS4000-5P PC TV 802.3at Power Feeding Filing no. 100129989 2012/8/22 Model No. Product Description ECS4510-12PD 8 port 10/100/1000BaseT (802.3at Power Device) + 2 port GE (Port 10 802.3af PoE) + 2 Gigabit SFP port (RJ45/SFP [100BaseX & 1000BaseX]) Hardware Customization Capability 802.3af Power Feeding Setop box MT-2520 x 2
10. Service Provider VeeTime T– Taiwan MSO
11.  Switching Feature  Flow control  Broadcast/ Multicast/ Unknown unicast control  Auto MDI/MDIX  ITU-T G.8032 Ethernet Ring Protection Switch  Spanning Tree Protocol  IEEE 802.1D /.1w/.1s  STP fast forwarding/Auto Edge  BPDU Guard/BPDU filtering  Root Guard  BPDU transparent  Loopback detection  VLAN  4K VLAN  Port-based VLAN  802.1Q VLAN  GVRP (256 VLAN)  802.1v Protocol based VLAN/MAC-based/IP subnet-based VLAN  Multiple session PVLAN (isolated VLAN)  VLAN trunking (VLAN transparent)  VLAN translation  Voice VLAN  Auto VLAN Assignment  QinQ  Selective QinQ  L2PT  Port Trunk  Static trunk  IEEE 802.3ad LACP  QoS  8 hardware queues  802.1p CoS  CoS based on IP precedence, DSCP, TCP/UDP Port, ACL  WRR/Strict or Hybrid  DiffServ  Ingress traffic policing  Egress traffic shaping  Marking/remarking  Two Rate Three Color Marking  Bundling Rate Limiting  Auto QoS profile assignment  Rate limiting  Multicast control  IGMP snooping v1/v2/v3  IGMP Querier  IGMP snooping filtering/throttling  IGMP snooping proxy  Immediate leave  MVR  MLD snooping v1/v2 EdgeCOS-Rich and Field Proven Software MEF 9 MEF 14
12.  Security  Port security (dynamic & static)  Port security intrusion action  802.1x Port-based authentication  802.1x MAC-based authentication  EAPOL transparent  Guest VLAN  Web authentication  MAC authentication  MAC filtering  DHCP snooping/snooping 82  IP Source Guard  Dynamic ARP Inspection  Access Control List  Denial of Service Protection  AAA (Authentication, Authorization, Accounting)  SSH v1/v2  SSL/HTTPS  Management access filter (WEB/SNMP/Telnet)  OAM  IEEE 802.3ah  IEEE 802.1ag  ITU-T Y.1731  Management  Cisco like CLI  Telnet/WEB/SNMP v1/v2/v3  RMON(1,2,3,9)/RMON II (Probe config.)  sFlow & sFlow over IPv6  FTP/TFTP/HTTP/Xmodem download  DHCP dynamic provision (option 66&67)  BootP  DHCP client/relay/server  Time zone for SNTP  DNS client/proxy  IP clustering  Delay reload  Event/error log, system log  Auto upgrade  Port monitor MAC/VLAN  LLDP (802.1ab)  Auto Traffic Control  Cable diagnostic/TDR\  UDLD  IPv6  IPv4/IPv6 Dual Protocol Stack  IPv6 Address types: Unicast  IPv6 Neighbor Discovery  SNMP over IPv6  HTTP over IPv6  Remote IPv6 ping EdgeCOS-Rich and Field Proven Software IPv6 ready logo Phase 2 Host
13.  L3 Feature  ARP  Proxy ARP  Routing Protocol  Static Route  RIP v1/v2  OSPFv2  BGPv4  Policy based Routing  Equal Cost Multi Path  Multicast Routing Protocol  DVMRP  PIM-DM  PIM-SM  Redundant Router Routing Protocol  VRRP  DHCP  DHCP Server  DHCP Relay  UDP Helper IPv6 Feature  IPv6 Management  IPv6 ACL  IPv6 QoS IPv6 Routing Protocol  RIPng  OSPFv3  BGP4+ Multicast Routing Protocol  IGMP-MLD Snooping  PIM-DM6  PIM-SM6 EdgeCOS L3 Features IPv6 ready logo Phase 2 router
14. ECS3510-52T (48 FE+ 4CG) ECS3510-28T (24 FE+ 4 CG) ES3510MA/DC (8 FE+ 2 CG) ECS4210-28T 24GE+ 4 GE SFP GE L2 GE L3 10 GE L3 ECS4660-28F 24 GE SFP + 2 10G XFP ports ECS4620-28F/DC 22 FE/GE SFP + 2 CG + 2 10G SFP+ + 1 Slot ECS4510-28F 22 FE/GE SFP + 2 CG + 2 10G SFP+ + 1 Slot GE L2+ ECS4210-12T (8 GE + 2 GE + 2 GE SFP) ECS4810-12M 12 CG AS5710-54X-EC 48 10G SFP+ +6 40G QSFP+ ES3528MV2 /DC (24 FE+ 4 CG) ECS4510-12PD (8 GE PD+ 2 CG) FE L2 Carrier Aggregation & Access Solution ECS4110-28T 24GE+ 4 GE SFP Carrier Grade ECS4120-28T 24GE+ 4 10G SFP+ ECS4120-52T 48GE+ 4 10G SFP+ ECS4120-28F 20 GE SFP + 4CG +4 10G SFP+ ECS4110-52T 24GE+ 4 GE SFP
15. ECS3510-52T (48 FE+ 4CG) ECS3510-28T (24 FE+ 4 CG) ECS4110-28T 24GE+ 4 GE SFP GE L2 GE L3 Stacking 10 GE L3 GE L2+ Stacking ECS4210-12P (8 GE PoE+ 2 GE + 2 GE SFP) AS5710-54X 48 10G SFP+ +6 40G QSFP+ FE L2 Enterprise Solution ECS4510-28F 22 FE/GE SFP + 2 CG + 2 10G SFP+ + 1 Slot ECS4510-28T 24GE + 2 10G SFP+ + 1 Slot ECS4510-52T 48GE+ 2 10G SFP+ + 1 Slot ECS4510-52P 48GE + 2 10G SFP+ + 1 Slot ECS4110-28P 24GE+ 4 GE SFP ECS3510-26P (24 FE PoE +2CG) ECS4620-28F 22 FE/GE SFP + 2 CG + 2 10G SFP+ + 1 Slot ECS4620-28T 24GE + 2 10G SFP+ + 1 Slot ECS4620-52T 48GE+ 2 10G SFP+ + 1 Slot ECS4620-52P 48GE + 2 10G SFP+ + 1 Slot ECS4620-28P 24GE+ 2 10G SFP+ + 1 Slot ECS4110-52T 48GE+ 4 GE SFP ECS4110-52P 48GE+ 4 GE SFP GE L2+ ES4120-28T 24GE+ 4 10G SFP+ ES4120-52T 48GE+ 4 10G SFP+ ES4120-28F 20 GE SFP + 4CG +4 10G SFP+ ECS4510-28P 24GE+ 2 10G SFP+ + 1 Slot
16. Hardware Stacking • Stack up to 4 units, 192 GE ports • Stack via 10G SFP+ port • Stack with DAC cable (short distance) or 10G transceiver & Fiber cable (for long distance connection) • Single IP management • Managed switch stack as a single entity, don’t need to login to individual switch • Redundant link • Backup master • Cross stack trunking • Cross stack mirroring Master Slave Slave Slave
17. GE Access Switch Application PSTN IP-PBX WiFi Phone •Access switch of small-to-mid size networks •Branch office of enterprise •Campus workgroups ECS4620-24T/52T/28F ECS4620-24T/52T/28F ECS4110-28T/52T ECS4110-28T/52T ECS4110-28P/52P ECS4110-28P/52P ECW3110 11n AP IP Phone WiFi Phone IP Phone IP Camera Laptop IP Camera Laptop ECW3110 11n AP 100M Copper 1G Copper 10G Fiber Internet IP Phone WiFi Phone ECS4210-12P ECW3110 11n AP IP Camera Laptop
18. GE with 10G uplink Access Switch Application ECS4510-28T/52T Server Farm ECS5710-54X-EC Storage PSTN IP-PBX ECS5710-54X-EC ECS4510-28P/52P EAP8518 11n AP IP Phone WiFi Phone EAP8518 11n AP IP Phone WiFi Phone ECS4510-28P/52P IP Camera Laptop IP Camera Laptop Gigabit to the desktop ECS4510-28T-S/52T ECS4510-28T-S/52T Server Farm Storage Internet •Access switch of small-to-mid size networks •Branch office of enterprise •Campus workgroups 100M Copper 1G Copper 10G Fiber
19. ECS2100-10P (8 GE PoE + 2 GE SFP) ECS2100-10T (8 GE+ 2 GE SFP) Web Smart Pro Series ECS2100-28T (24 GE +2 GE SFP) ECS2100-10PE External Power (8 GE PoE + 2 GE SFP) ECS2100-28P (24 GE PoE+2 GE SFP) ECS2100-28PP (24 GE PoE+2 GE SFP) EPS460W PS3000+EPS460W 65w 125w 384W 192W 740W
20. Target Market •Access switch for small-to-mid size networks •Branch office of enterprise •Campus workgroups ECS2100-28T ECS2100-28T Server ECS4620-28F PSTN IP-PBX IP Phone IP Phone 1G Fiber 10G Fiber Internet IP Phone IP Camera IP Camera NVR 1G Copper ECS4620-28F ECS2100-28P/28PP ECS2100-28P/28PP Laptop EWS4502 WiFi Controller ECW7220L 11ac AP Laptop Smart Phone ECW7220L 11ac AP Smart ECS2100-10P/10PE ECW3110 11n AP IP Camera Laptop Server Smart Phone
21. Plug and Play • Can be used as unmanaged switch for end user • Just need to configure a IP from monitoring • Loopback detection to prevent loop • Power Saving (IEEE 802.3az EEE) 0% 5% 10% 15% 20% 25% 100M cable <1M cable No Link Active Idle No Link Power Saving %
22. Loopback detection • Able to detect various loop conditions to prevent broadcast storm breakdown the network Loop Storm Loop Storm Loop Storm Storm
23. Advanced Features • High Availability – RSTP, MSTP, Link Aggregation • Comprehensive Security – User access Security: 802.1x, MAC auth, Guest VLAN, Voice VLAN – Network Security: Port security, DHCP snooping, IPSG, DAI, Traffic Segmentation, ACL – Management Security: SSH,HTTPS, SNMPv3, Management IP filtering • Robust Multicast Control – IGMP Snooping, MLD Snooping • Advanced QoS – 8 Queues, 802.1p CoS, DSCP, WRR, Strict Priority, rate limiting, Policy map
24. Diversify Manageability • User friendly Web GUI ( port range setting), informative log (helpful for troubleshooting) • Dash board • Console port, CLI • SNMP, for most popular Network Traffic Grahper (MRTG) to analyse, Edge-Core Ecview Pro Network Management Software
25. • PoE port priority • Power allocation configurable • Enable /Disable PoE by time range for Power saving PoE
26. Dash Board • Switch Front Panel – Status: Up/Down/Admin down/ Speed/ duplex mode • Switch Information – Uptime, Model, Serial No., Firmware Version • CPU/Memory Utilization • Event Log overview
27. Dash Board • Recent 4 events • Port Utilization • User numbers • Neighbors
28. 15 min/ Daily Traffic Analysis • Per port • Input/output • % BW Utilization/ Octets • Traffic type • Discard/ Error
29. • Provide high quality products with field-proven • Products with same quality as 1st tier customers approval and field deployment experience • 6 months visibility into the market • Provide flexible software customization, service and support • Different market has different demand so need customization to meet customer requirement • In house R&D can flexibly response to customer requirement • Provide best cost performance product • Leveraging Accton design and manufacturing power • Deliver consistent long term commitment • With 20+ years experience and high reputation in networking field, we insist to invest networking technology to provide best products to customers Summary
