Controller based AP Training

Introduce how to control the light AP ECW7220-L by Controller EWS4502/4606

Transcript

1. Wireless Controller and Fit Access Point Training C.K.Ng
2. Agenda • AC/AP Basic Setup • Switch Configuration • 802.1x/MAC Authentication • Captive Portal • Mitigate Wireless Interference and Improve Performance • AC Cluster
3. Controller-based Product List Model EWS4502 EWS4606 Product Type Wireless Access Controller Wireless Access Controller Description - 2 x GE, manage 500 pcs AP - Support 3+1 clustering backup - 6 x GE with 2 x USB, manage 2000pcs AP - Support 3+1 clustering backup Wireless Access Controller Model ECW7220-L Product Type Indoor AP Description 11ac, dual band 3x3 MIMO Controller-based AP
4. Controller based Wireless Network Scenario
5. Scenario ECS2100-10P 192.168.1.10 EWS4502 WiFi Controller 192.168.1.1 192.168.1.2 ECW7220L 11ac AP 192.168.1.11 Internet Laptop HQ_Staff Vlan 10 Smart Phone HQ_Guest Vlan 20 PVID =1 Vid=10,20 tagged PVID =1 Vid=10,20 tagged PVID =1 Vid=1 untagged DHCP Server 192.168.1.200 PVID =1 Vid=1 untagged PVID =1 Vid=1,10,20 tagged ECS4620-28P/52P GE L3 PoE Switch 192.168.2.1 ECW7220L 11ac AP 192.168.1.11 Laptop HQ_Staff Vlan 30 Smart Phone HQ_Guest Vlan 40 PVID =1 Vid=30,40 tagged PVID =1 Vid=30,40 tagged HQ Branch Office ECS4620-28F GE L3 Fiber Switch 192.168.2.1
6. HQ Topology ECS2100-10P 192.168.1.10 EWS4502 WiFi Controller 192.168.1.1 192.168.1.2 ECW7220L 11ac AP 192.168.1.11 Internet Laptop HQ_Staff Vlan 10 Smart Phone HQ_Guest Vlan 20 PVID =1 Vid=10,20 tagged PVID =1 Vid=10,20 tagged PVID =1 Vid=1 untagged DHCP Server 192.168.1.200 PVID =1 Vid=1 untagged PVID =1 Vid=1,10,20 tagged HQ ECS4620-28F GE L3 Fiber Switch 192.168.2.1
7. Basic Setup of AC
8. Clear Config (Reset to Factory Default)
9. Set IP address on AC
10. Check IP Address on AC
11. Login to AC Web GUI Default Username: admin, No Password
12. Set Country Code Set the country code
13. Modify Band_plan & Country_code for AP • From AP Console, check band plan and country code ECW7220-L-ff68c0# nvram show : band_plan=ETSI : country_code=TR : • Change Band plan & Country code ECW7220-L-ff68c0# nvram set band_plan=FCC ECW7220-L-ff68c0# nvram set country_code=US ECW7220-L-ff68c0# nvram commit ECW7220-L-ff68c0# factory-reset Are you sure you want to reset the system to factory defaults (y/n)? y
14. Configure Wireless Network
15. Create New Wireless Network (HQ_Staff)
16. Configure Wireless Network (HQ_Staff)
17. Create New Wireless Network (HQ_Guest)
18. Configure Wireless Network (HQ_Guest)
19. 2 Wireless Networks (SSID) Created
20. Create AP Profile
21. Modify Default Profile Enable: Data will keep on forwarding even when AP disconnected from AC
22. Modify Radio Configuration of Default Profile
23. Add SSID to Default Profile (5 GHz Radio )
24. Add SSID to Default Profile (2.4 GHz Radio)
25. Manage AP by AC
26. Manage the Discovered AP
27. Managed AP in Local AP Database
28. Reset Managed AP
29. Configuration Provision Successfully
30. Radio Status of Managed AP
31. VAP(SSID) of Managed AP 2 SSID Discovered by WiFi Client
32. Associated Client
33. Save Configuration
34. Save Configuration
35. Configuration of Switch
36. L3 Switch Play DHCP Server Role ECS2100-10P 192.168.1.10 EWS4502 WiFi Controller 192.168.1.1 192.168.1.2 ECW7220L 11ac AP 192.168.1.11 Internet Laptop HQ_Staff Vlan 10 Smart Phone HQ_Guest Vlan 20 PVID =1 Vid=10,20 tagged PVID =1 Vid=10,20 tagged PVID =1 Vid=1 untagged PVID =1 Vid=1 untagged PVID =1 Vid=1,10,20 tagged HQ ECS4620-28F GE L3 Fiber Switch 192.168.2.1
37. Configuration of Switch • Create HQ_Staff VLAN & HQ_Guest VLAN • Add Port 7 connected to AP VLAN 10, 20 Tagged port • Default VLAN 1 for communication between AP & AC
38. VLAN Configuration of Port Connected to AP
39. Configure HQ_Staff VLAN member port • Configure Port 1 VLAN 10 member port, Wireless client associated to SSID HQ_Staff can communicate with device connected to port 1
40. Configure HQ_Guest VLAN member port • Configure Port 1 VLAN 20 member port, Wireless client associated to SSID HQ_Guest can communicate with device connected to port 2
41. Configure IP Interfaces on L3 Switch • Set IP address (default gateway) for 3 VLANs (Subnets), so traffic can be routed from one subnet to the other
42. Create DHCP Server IP Pool for Management VLAN • Create DHCP server IP pool for management VLAN • Exclude the IP range for static IP such as IP of the AC and Switches • AP will be assigned IP address dynamically after configuration auto- provision from AC
43. Managed AP Obtained IP • AP obtained IP address from DHCP Server so will not have IP address conflict with default IP (192.168.1.10)
44. Create DHCP Server IP Pool for HQ_Staff VLAN • Create DHCP Server IP Pool for HQ_Staff VLAN so wireless clients associated to HQ_Staff SSID will obtain IP from corresponding subnet dynamically
45. Create DHCP Server IP Pool for HQ_Guest VLAN • Create DHCP Server IP Pool for HQ_Guest VLAN so wireless clients associated to HQ_Guest SSID will obtain IP from corresponding subnet dynamically
46. L3 Switch Play DHCP Relay Role ECS2100-10P 192.168.1.10 EWS4502 WiFi Controller 192.168.1.1 192.168.1.2 ECW7220L 11ac AP 192.168.1.11 Internet Laptop HQ_Staff Vlan 10 Smart Phone HQ_Guest Vlan 20 PVID =1 Vid=10,20 tagged PVID =1 Vid=10,20 tagged PVID =1 Vid=1 untagged DHCP Server 192.168.1.200 PVID =1 Vid=1 untagged PVID =1 Vid=1,10,20 tagged HQ ECS4620-28F GE L3 Fiber Switch 192.168.2.1
47. DHCP Relay • If there is a DHCP Server in the network, configure L3 for DHCP relay, so clients for all subnet will get IP address from DHCP Server
48. Branch Office AC/AP Configuration
49. Branch Office Topology Internet ECS4620-28P/52P GE L3 PoE Switch 192.168.2.1 ECW7220L 11ac AP 192.168.1.11 Laptop HQ_Staff Vlan 30 Smart Phone HQ_Guest Vlan 40 PVID =1 Vid=30,40 tagged PVID =1 Vid=30,40 tagged Branch Office
50. Remote Fit AP Configuration • AP default IP mode is DHCP, default IP is 192.168.1.10 • Need specify AC IP address if they not at the same network • Remember save configuration
51. Set Static IP on Remote AP • Disable DHCP mode and set static IP and default gateway on AP • Ping default GW and Remote AC to make sure it can be reachable
52. Set Remote AC IP • Set IP address of the Remote AC on Fit AP
53. Remote AP Discovered
54. Create 2 Wireless Network for Branch Office
55. Create Branch Office Profile
56. Add Wireless Network to Profile
57. Select Profile for Managed AP
58. Reboot the AP to change the Profile
59. AP Reboot
60. New Profile Applied
61. Auto-Upgrade Firmware of AP From AC
62. Upload Firmware of AP to AC
63. Upload Firmware of AP to AC
64. Set AP Auto Upgrade
65. Upgrade Firmware of AC
66. Upload AC Firmware
67. Upload AC Firmware
68. Reset Factory Default
69. Reset to Factory Default
70. Captive Portal
71. Captive Portal Topology ECS2100-10P 192.168.1.10 EWS4502 WiFi Controller 192.168.1.1 ECW7220-L 11ac AP 192.168.1.11 Internet Smart Phone HQ_Guest Vlan 1 PVID =1 Vid=1 untagged PVID =1 Vid=1 untagged PVID =1 Vid=1 untagged DHCP Server 192.168.1.200
72. Enable Captive Portal
73. Enable Captive Portal
74. Set Verification Mode Local
75. Create New User Account
76. Auto Generation User Account
77. Account Generator
78. Account Generated
79. Local User Summary
80. Associate Interface for Captive Portal
81. Associate Interface for Captive Portal
82. Configure the Network for Captive Portal as Native VLAN 1
83. Captive Portal Login Web Page
84. How to set 802.1x/Mac Authentication
85. 802.1x Authentication Scenario EWS4502/EWS4606 RADIUS Server Radius Frames
86. WPA/WPA2 Enterprise with 802.1x Authentication AC: • 1. Add RADIUS server and Accounting Server • 2. Go to AP profiles, enabled Security with WPA/WPA2 Enterprise
87. RADIUS Configuration Enabled Accounting Mode
88. RADIUS Server Configuration Add RADIUS server
89. Accounting Server Configuration Add Accounting Server
90. AP Profiles Enabled Security with WPA/WPA2 Enterprise at AP Profiles
91. Remote RADIUS MAC Authentication Scenario EWS4502/EWS4606 Radius Frames CAPWAP Frames RADIUS Server
92. Remote RADIUS MAC Authentication Radius Server: • 1. Create account username with client MAC address, password with NOPASSWORD AC: • 1. At WLAN Configuration>Global, set MAC Authentication Mode to white-list • 2. Go to AP Profiles, set MAC Authentication as RADIUS at the VAP
93. Global At WLAN Configuration>Global, set MAC Authentication Mode to white-list
94. AP Profiles Set MAC Authentication as RADIUS at the AP Profile
95. Local MAC Authentication Scenario EWS4502/EWS4606 CAPWAP Frames
96. Local MAC Authentication • 1. At WLAN Configuration>Global, set MAC Authentication Mode to white-list • 2. At WLAN Configuration>Known Client, add client MAC address and select Authentication Action as Global Action • 3. Go to AP Profiles, set MAC Authentication as Local at VAP
97. Known Client Add client MAC address and select Authentication Action as Global Action
98. AP Profiles Set MAC Authentication as Local at AP Profiles
99. Tip • Accounting can work independence with others authentication method
100. Radius Accounting Frames
101. Mitigate Wireless Interface And Improve Performance
102. Automatic Channel
103. Automatic Power
104. RF Management Go to RF Management, modify Channel Plan Mode and Power Adjustment Mode
105. AP Profiles Make sure Automatic Channel and Automatic Power is enabled
106. Band Steering 2.4Ghz 5Ghz SSID : Taipei-Free SSID : Taipei-Free Dual Band User
107. AP Profiles Enabled Band Steering Configuration
108. AP Load Balance and Maximum Clients AP 1 AP 2 AP 3 Full !! Full !! Wireless Clients
109. AP Profile Enabled AP Load Balance
110. AP Profiles Set maximum Clients at Radio
111. AP Profiles Or set Maximum Clients at VAP
112. Client Bandwidth Limitation 512kbps 512kbps New User
113. AP Profiles Set Client Bandwidth Limitation
114. VAP Bandwidth Limitation & Equal Share Bandwidth 51200kbps/2 51200kbps/3 New User VAP Bandwidth Limitation 51200kbps 51200kbps/3
115. AP Profiles Set VAP Bandwidth Limitation and enabled Equal Share Bandwidth
116. AC Cluster
117. AC Cluster • The switch with highest priority in a cluster becomes the Cluster Controller. If the priority is the same then the switch with lowest IP address becomes the Cluster Controller. • The highest cluster priority is 255. • The Cluster Controller collects status and statistics from all the other AC in the cluster, including information about the APs peer switches manage and the clients associated to those APs
118. EWS4502-2 192.168.1.31 EWS4502-1 192.168.1.30 Cluster Controller Peer Group ID : 1 Cluster Priority : 225 Slave AC Peer Group ID : 1 Cluster Priority : 1 AP managed by Cluster Controller.
119. Status of Cluster Controller
120. Status of slave AC
121. Managed AP Status of slave AC 192.168.1.31 Managed AP Status of Cluster Controller 192.168.1.30
122. Slave AC Peer Group ID : 1 Cluster Priority : 1 Cluster Controller Peer Group ID : 1 Cluster Priority : 225 EWS4502-2 192.168.1.31 EWS4502-1 192.168.1.30 AP managed by slave AC.
123. Status of slave AC 192.168.1.30
124. Status of Cluster Controller 192.168.1.31
125. Managed AP Status of slave AC 192.168.1.30 Managed AP Status of Cluster Controller 192.168.1.31
