DeveloperWeek SF: A DevOps State of Mind with Microservices and Containers

Rapid innovation, changing business landscapes, and new IT demands force businesses to make changes quickly. In the eyes of many, containers are at the brink of becoming a pervasive technology in Enterprise IT to accelerate Microservices delivery. In this presentation, you'll learn about the • The transformation of IT to a DevOps, Microservices, and Container based Architecture • What are containers and how DevOps practices can operate in a Microservices based environment • How Kubernetes can reduce software delivery cycle times, drive automation, and increase efficiency • How other organizations are using DevOps + Containers with Microservices and how to replicate their success Also, a demonstration of automated container based Microservices builds and pipelines, running Jenkins CI on Kubernetes, and continuous deployments of containerized Microservices with Kubernetes.

Transcript

1. A DevOps State of Mind with Microservices and Containers Chris Van Tuin Chief Technologist, West cvantuin@redhat.com
2. “Only the Paranoid Survive” - Andy Grove, 1998
3. Retail Finance Media Transportation ? ? SOFTWARE DISRUPTS BUSINESS
4. + ≠ TAXI TRANSPORTATION DISRUPTER https://goo.gl/MP7QQH Ack: Andrew Ng APP IT’S NOT JUST A… +
5. Culture of experimentation A B 20% vs. 25% Empowered organization Time Change Rapid Innovation THE DISRUPTORS = AI /
 ML Data-driven intelligence Data, Data, Data
6. I.T. ENABLING
 BUSINESS DIFFERENTIATION Taxi Ridesharing $2.50/mile, $0.50/idle Fare Static
 Pricing Dynamic
 Pricing vs. Ack: William Benton Fare
 based on
 real-time and historical data: supply/demand distance, time
 route, traffic etc.
7. BUT…
8. Innovation Months THE AVERAGE ENTERPRISE DOES
 DEPLOYMENTS EVERY 6 TO 9 MONTHS.
9. DEV QA OPS Walled off people, walled off processes, walled off technologies “THROW IT OVER THE WALL”
10. HOW DOES I.T. TRANSFORM FROM A COST CENTER INTO AN INNOVATION CENTER? Months Innovation
11. DEV QA OPS Collaborative and empowered teams,
 consistent processes, consistent technologies MOVE FAST, BREAK THINGS Line of Business Security , DBA, Network, etc.
12. I.T. MUST EVOLVE Development Model Application Architecture Deployment & Packaging Application Infrastructur e Storage Waterfall Agile Monolithic N-tier Bare Metal Virtual Servers Data Center Hosted Scale Up Scale Out DevOps MicroServices Containers Hybrid Cloud Storage as a Service
13. DEV QA OPS Open organization +
 cross-functional teams Software factory automation Linux + Containers IaaS Orchestration CI/CD Source Control Management Collaboration Build and Artifact Management Testing Frameworks Open Source CI/CD pipelines with feedback Culture Process Technology + + THE SOFTWARE FACTORY
14. THE SOFTWARE FACTORY BARE METAL VIRTUAL PRIVATE CLOUD PUBLIC CLOUD
17. CI/CD PIPELINE Continuous Integration Continuous Build Continuous Deployment Developer -> Source -> Git Git -> RPMS -> Images-> Registry Images from
 Registry -> Clusters
18. 24x Faster Recovery From Failure 3x Lower Change Failure Rate 2555x Shorter Lead Times https://puppet.com/resources/whitepaper/2016-state-of-devops-report 200x More Deployments THE IMPACT…
19. Hybrid Cloud: Self-Service, On-Demand, Elastic Infrastructure Automation + Containers CI & CD Deployment Pipeline Advanced Deployment Techniques Microservices (and flying elephants!) Re-Org to DevOps THE EVOLUTION
20. CASE STUDY
21. CUSTOMER CHALLENGES “It could take 6 weeks to get a single word changed on the web site.” “It took 2 years after a competitive start-up launch to get a competing product to market.” “When developers work in Node.js, they can change the code they’re working on, direct it to run, and see whether it works-in the blink of an eye.” “The environment, while stable, didn’t use the sexiest technologies, which made recruiting difficult.”
22. DEVELOPMENT TO PRODUCTION
 IN <30 MINUTES Source CI Cloud Repo Repo
 Cloud
23. Re-Org to DevOps
24. ORGANIZATION COMMUNICATION AND DECISION MAKING Decision
 Making Decision Making Siloed Open
25. Today’s Reality is Hybrid Cloud
26. APPS IN MULTIPLE ENVIRONMENTS ANY COMBINATION, WHETHER TRADITIONAL OR CONTAINERIZED LEGACY APPS (1,000+) BARE METAL PRIVATE CLOUD (OpenStack) PUBLIC CLOUD (AMZ, MS, GOOG, etc.) VMware/
 Red Hat Virtualization PRODUCTION DEV/TEST
27. PRODUCTION & DATA ON-PREMISE,
 DEV/TEST OFF RED HAT OPENSHIFT CONTAINER PLATFORM RED HAT OPENSHIFT CONTAINER PLATFORM BARE METAL VIRTUAL PRIVATE CLOUD OFF-PREMISE ON-PREMISE AMAZON RELATIONAL DB (MySQL) RDS SERVICE
28. Automation + Containers
29. From development… …to production. COMMUNICATION IS THE KEY TO DEVOPS.
 DEV/TEST Q/A OPERATIONS MANAGEMENT OUTSOURCERS DEV/TEST Q/A AUTOMATION: CONFIGURATION MANAGEMENT + ORCHESTRATION BARE METAL VIRTUAL PRIVATE CLOUD PUBLIC CLOUD
30. • Application processes on a shared kernel • Simpler, lighter, and denser than VMs • Portable across different environments • Package apps with all dependencies • Deploy to any environment in seconds • Easily accessed and shared INFRASTRUCTURE APPLICATIONS WHAT ARE CONTAINERS? It depends who you ask…
31. docker.io Registry Private Registry Red Hat Certified FROM fedora:latest CMD echo “Hello” Build file Physical, Virtual, Cloud Image Container Build Run Ship CONTAINERS: BUILD, SHIP, RUN
32. 4 • Are there known vulnerabilities in the application layer? • Are the runtime and OS layers up to date? • How frequently will the container be updated and how will I know when it’s updated? CONTENT: EACH LAYER MATTERS CONTAINER OS RUNTIME APPLICATION AYER MATTERS CONTAINER OS RUNTIME APPLICATION JAR CONTAINER CONTAINERS
33. A CONVERGED SOFTWARE SUPPLY CHAIN
34. SECURITY IMPLICATIONS What’s inside matters…
35. Containers at Scale
36. TOP CHALLENGES WITH CONTAINERS AT SCALE Operational
 Efficiency Service Health Security & Compliance Financial Management
37. DEV QA OPS Open organization +
 cross-functional teams Software factory automation CI/CD pipelines with feedback Culture Process Technology + + THE SOFTWARE FACTORY
38. Scheduling Monitoring Persistence Discovery Lifecycle & health Scaling Aggregation Security CONTAINERS AT SCALE BARE METAL VIRTUAL PRIVATE CLOUD PUBLIC CLOUD
39. CrunchyData GitLab Iron.io Couchbase Sonatype EnterpriseDB and many more ...and virtually any docker image out there! PHP Python Java NodeJS Perl Ruby .NET Core Apache
 HTTP Server MySQL Redis nginx Tomcat Varnish JBoss EAP JBoss A-MQ JBoss Fuse JBoss BRMS JBoss BPMS JBoss Data Grid JBoss Data Virt RH Mobile RH SSO 3SCALE API mgmt JBoss Web Server Spring
 Boot Wildfly Swarm Vert.x PostgreSQ L MongoDB Phusion Passenger Third-party
 Language Runtimes Third-party
 Databases Third-party
 App Runtimes Third-party
 Middleware Third-party
 Middleware TRUE POLYGLOT PLATFORM
40. Enabling Microservices
41. code config data Kubernetes configmaps secrets Container image Traditional
 data services, Kubernetes
 persistent volumes TREAT CONTAINERS AS IMMUTABLE
42. Web Database replicas=1,
 role=db replicas=2,
 role=web ORCHESTRATION Deployment, Declarative Nodes Controller Manager & Data Store (etcd)
43. role=web role=web ORCHESTRATION Schedule + Provision Pods (Compute/Storage/Network) Image Registry Pods Nodes Web replicas=2,
 role=web ReplicaSet
44. role=web role=db role=web Pods Nodes Image Registry ORCHESTRATION Schedule + Provision Pods (Compute/Storage/Network) Web replicas=2,
 role=web ReplicaSet Database replicas=1,
 role=db StatefulSet
45. Web Database role=web role=db role=web replicas=1,
 role=db replicas=2,
 role=web ORCHESTRATION Service (Load Balancer) Pods Nodes Services Controller Manager & Data Store (etcd)
46. HEALTH CHECK Monitoring & Logging Pods Nodes Services Web Database role=web role=db role=web replicas=1,
 role=db replicas=2,
 role=web
47. HEALTH CHECK Pods Nodes Services Web Database role=web role=db role=web replicas=1,
 role=db replicas=2,
 role=web role=web Controller Manager & Data Store (etcd)
48. Web Database replicas=1,
 role=db replicas=2,
 role=web HEALTH CHECK Pods Nodes Services role=web role=db role=web Controller Manager & Data Store (etcd)
49. Web Database replicas=1,
 role=db replicas=2,
 role=web AUTO-SCALE Monitoring & Logging 80% CPU Pods Nodes Services role=web role=db role=web
50. Web Database replicas=1,
 role=db replicas=3
 role=web AUTO-SCALE 80% CPU Pods Nodes Services role=web role=db role=web role=web Controller Manager & Data Store (etcd)
51. Pods Nodes Services Web Database replicas=1,
 role=db replicas=3
 role=web AUTO-SCALE 50% CPU role=web role=db role=web role=web Controller Manager & Data Store (etcd)
52. CI/CD PIPELINES with CONTAINERS
53. CI/CD WITH CONTAINERS BARE METAL VIRTUAL PRIVATE CLOUD PUBLIC CLOUD
54. Security CI/CD PIPELINES
55. CONTINUOUS DELIVERY: DEPLOYMENT STRATEGIES
56. CONTINUOUS DELIVERY DEPLOYMENT STRATEGIES DEPLOYMENT STRATEGIES • Recreate • Rolling updates • Blue / Green deployment • Canary deployments • A / B testing
57. Recreate
58. Version 1 Version 1 Version 1 Version 1.2 ` Tests / CI RECREATE WITH DOWNTIME
59. Version 1 Version 1 Version 1 Version 1.2 ` Tests / CI RECREATE WITH DOWNTIME
60. Version 1.2 Version 1.2 Version 1.2 RECREATE WITH DOWNTIME Use Case • Non-mission critical services Cons • Downtime Pros • Simple, clean • No Schema incompatibilities • No API versioning
61. Rolling Updates
62. Version 1 Version 1 Version 1 Version 1.2 ` Tests / CI ROLLING UPDATES with ZERO DOWNTIME
63. Deploy new version and wait until it’s ready… Version 1 Version 1 V1.2 Health Check: readiness probe e.g. tcp, http, script V1
64. Each container/pod is updated one by one Version 1.2 50% Version 1 V1 V1.2
65. Each container/pod is updated one by one Version 1.2 Version 1.2 Version 1.2 100% Use Case • Horizontally scaled • Backward compatible API/data • Microservices Cons • Require backward compatible APIs/data • Resource overhead Pros • Zero downtime • Reduced risk, gradual rollout w/health checks • Ready for rollback
66. Blue / Green Deployment
67. Version 1 BLUE / GREEN DEPLOYMENT Route BLUE
68. Version 1 BLUE / GREEN DEPLOYMENT Version 1.2 BLUE GREEN
69. Version 1 Tests / CI BLUE / GREEN DEPLOYMENT Version 1.2 BLUE GREEN
70. Version 1 Version 1.2 BLUE / GREEN DEPLOYMENT Route Version 1.2 BLUE GREEN
71. Version 1 BLUE / GREEN DEPLOYMENT Rollback Route Version 1.2 BLUE GREEN Use Case • Self-contained micro services (data) Cons • Resource overhead • Data synchronization Pros • Low risk, never change production • No downtime • Production like testing • Rollback
72. A/B Testing
73. “Our experience at Microsoft is no different—only about 1/3 of ideas improve the metrics they were designed to improve.”
 Ronny Kohavi, Microsoft (Amazon) http://ai.stanford.edu/~ronnyk/ExPThinkWeek2009Public.pdf http://ai.stanford.edu/~ronnyk/ExPThinkWeek2009Public.pdf
74. A/B TESTING USING CANARY DEPLOYMENTS
75. Version 1.2 Version 1 100% Tests / CI Version 1.2 Route 25% Conversion Rate ?! Conversion Rate CANARY DEPLOYMENTS
76. 50% 50% Version 1.2 Version 1 Route Version 1.2 25% Conversion Rate 30% Conversion Rate CANARY DEPLOYMENTS
77. 25% Conversion Rate 100% Version 1 Version 1.2 Route Version 1.2 30% Conversion Rate CANARY DEPLOYMENTS
78. Version 1.2 Version 1 100% Route Rollback 25% Conversion Rate 20% Conversion Rate CANARY DEPLOYMENTS
79. IMPACT
80. Deployment Frequency Change Volume Lead Time Deployment
 Failure Rate Mean Time to Recover 99.999 Service Availability DEVOPS METRICS
81. ROI Improve business agility Improve business predictability Improve developer productivity Improve operational efficiency and costs
82. THANK YOU linkedin: Chris Van Tuin email: cvantuin@redhat.com twitter: @chrisvantuin
