Python Concurrency and Distributed Computing Workshop

Copyright (C) 2010, David Beazley, http://www.dabeaz.com
Python Concurrency and
Distributed Computing Workshop
1
November 1-4, 2011
Chicago
David Beazley
(http://www.dabeaz.com)

View Slide

Welcome!
• Welcome to Andersonville!
• Hope you're ready to code
• ... and drink lots of coffee
2

View Slide

Overview - Day 1
3
Threads and Tasks

View Slide

Overview - Day 2
4
Threads and Tasks
Multiprocessing

View Slide

Overview - Day 2
5
Threads and Tasks
Multiprocessing
Async/Events

View Slide

Overview - Day 2
6
Threads and Tasks
Multiprocessing
Async/Events
Message Passing

View Slide

Overview - Day 3
7
Threads and Tasks
Multiprocessing
Async/Events
Message Passing
Distributed
Computing

View Slide

Overview - Day 4
8
Threads and Tasks
Multiprocessing
Async/Events
Message Passing
Distributed
Computing
Generators
Coroutines

View Slide

Overview - Day 4
9
Threads and Tasks
Multiprocessing
Async/Events
Message Passing
Distributed
Computing
Generators
Coroutines
x
head
explosion
x

View Slide

Important
• There are going to be a lot of moving parts
• Make sure you can cut/paste code
• Make sure you look at solution code
• Make sure you copy solution code as needed
10

View Slide

Introductions
11

View Slide

Introduction
1
Section 1

View Slide

Requirements
• There is a set of support ﬁles and exercises
2
http://www.dabeaz.com/python/concurrent2011/
• We are using Python 3.2 (concurrent.zip)
• Optional installs
• numpy
• ZeroMQ and pyzmq
• Redis

View Slide

Concurrency
• A topic that's on a lot of programmer's minds
• Multicore CPUs, clusters, distributed computing,
cloud computing, etc.
• Increased interest in concurrent and functional
programming languages (e.g., Erlang, Scala,
Clojure, Haskell, etc.)
3

View Slide

My Personal Interest
• Concurrent programming is cool (and fun)
• In fact, it's the whole reason I went into CS
• As a book author, I'm interested in exploring
different ways to understand and present
advanced programming concepts
• Eventually, this workshop will become a book,
but that's for later (I want your feedback)
4

View Slide

Basic Concepts
5

View Slide

Concurrent Programming
• Applications that work on more than one
thing at a time--possibly spread out over a
whole cluster of machines
• Example : A network server that
communicates with several hundred clients
all connected at once
• Example : A big number crunching job that
spreads its work across hundreds of CPUs
6

View Slide

Multitasking
7
• On a single machine, concurrency typically
implies "multitasking"
run
run
run
run
run
Task A:
Task B:
task switch
• If a single CPU, the operating system rapidly
switches back and forth

View Slide

Parallel Processing
8
• You may have parallelism (many CPUs)
• Here, you often get simultaneous task execution
run
run
run
run
run
Task A:
Task B: run
CPU 1
CPU 2
• Note: If the total number of tasks exceeds the
number of CPUs, then each CPU also multitasks

View Slide

Shared Memory
9
• Tasks may run in the same memory space
run
run
run
run
run
Task A:
Task B: run
CPU 1
CPU 2
object
write
read
• Simultaneous access to objects
• Often a source of unspeakable peril
Process

View Slide

Processes
10
• Tasks might run in separate processes
run
run
run
run
run
Task A:
Task B: run
CPU 1
CPU 2
• Processes coordinate using IPC
• Pipes, FIFOs, memory mapped regions, etc.
Process
Process
IPC

View Slide

Distributed Computing
11
• Tasks may be running on distributed systems
run
run
run
run
run
Task A:
Task B: run
messages
• For example, a cluster of workstations
• Or servers out in the "cloud."

View Slide

Why Python?
12

View Slide

Some Issues
• Python is interpreted
13
• Frankly, it doesn't seem like a natural match
for this kind of programming
• Isn't this a serious business left to more
"serious" programming languages?
"What the hardware giveth, the software taketh away."

View Slide

"Enterprise" Python
• Is using Python even appropriate?
• Traditionally, distributed computing and parallelism
has only been available to those programmers
working at elite institutions with deep pockets.
(and they don't tend to use "hobby" languages)
• Times change. Cheap machines have multiple
CPU cores. Anyone can purchase CPU time out in
the "cloud" (even my mom).
14

View Slide

Why Use Python at All?
• It's very high level
• And it comes with a large library
• Useful data types (dictionaries, lists,etc.)
• Network protocols
• Text parsing (regexs, XML, HTML, etc.)
• Files and the ﬁle system
• Databases
• Python programmers think it's awesome
15

View Slide

Python as a Framework
• Python is often used as a high-level framework
• The various components might be a mix of
languages (Python, C, C++, etc.)
• Concurrency may be a core part of the
framework's overall architecture
• Python has to deal with it even if a lot of the
underlying processing is going on in C
16

View Slide

Programming Productivity
• Programmers are often able to get complex
systems to "work" in much less time using a
high-level language like Python than if they're
spending all of their time hacking C code.
17
"The best performance improvement is the transition from
the nonworking to the working state."
- John Ousterhout
"You can always optimize it later."
- Unknown
"Premature optimization is the root of all evil."
- Donald Knuth

View Slide

Performance is Irrelevant
• Many programs are "I/O bound"
• They spend virtually all of their time sitting
around waiting
• Python can "wait" just as fast as C (maybe
even faster--although I haven't measured it).
• If there's not much processing, who cares if
it's being done in an interpreter? (One
exception : if you need an extremely rapid
response time as in real-time systems)
18

View Slide

You Can Go Faster
• Python can be extended with C code
• Look at ctypes, Cython, Swig, etc.
• PyPy?
19

View Slide

Special Cases
• Of course, there are special cases where you
probably would not want to use Python
• Example :
• Flight avionics
• Nuclear power plants
• Sharks with laser beams
• Fine, we won't be talking about that. There
are still many other applications where
Python makes a lot of sense.
20

View Slide

The Roadmap
21

View Slide

Class Overview
• Day 1: Threads and multitasking concepts
• Day 2: Threads, multiprocessing, async I/O
• Day 3: Messaging, distributed computing
• Day 4: Coroutines
22

View Slide

Major Themes
• Software architecture. We're going to spend
a lot of time studying different concurrency
approaches and designs
• Tradeoffs. The good and bad of different
design choices.
• Doing it yourself. We're going to build all
sorts of cool things from scratch. I think it
will be fun and inspiring.
23

View Slide

Not a Focus
• Just plugging stuff into someone's already
built programming framework
• Frameworks are ﬁne, but this workshop is
about core concepts
• It's also not promoting any speciﬁc set of
tools (or even Python itself all that much)
• We will look at some frameworks as we go
24

View Slide

A Caution
• Many of the course exercises are advanced
• Try to do things yourself if you can
• Know that solution code is always given
• You should absolutely be looking at the
solution code throughout this workshop
25

View Slide

A Final Caution
• We're going to write a lot of code, but that
code should be viewed as a kind of "sketch"
• An exploration of different ideas
• It's not "production ready"
• You would need to add a lot (testing, corner
cases, error checking, etc.)
26

View Slide

Let's Get Started!
27

View Slide

2-
Python Multithreading
1
Section 2

View Slide

2-
Overview
• Introduction to thread programming
• How to reliably use threads
• Some programming idioms and common
practices related to working with threads
• Details on Python interpreter execution
2

View Slide

2-
Secondary Objective
• Develop common programming patterns and
designs related to all forms of concurrent and
distributed computing (not just threads)
• Investigate a variety of issues generally related
to concurrently executing tasks (debugging,
control, synchronization, messaging, etc.)
3

View Slide

2-
Background : Threads
• Understanding issues related to thread
programming is essential for any kind of work
with concurrent programming
• First, threads are one of the oldest and most
widely used approaches (so, if you ignore
them, you're missing the big picture)
• Problems associated with threads tend to
underly other concurrency techniques (thus
threads are the poster-child for every horrible
thing that can go wrong)
4

View Slide

2-
Threads in Practice
• Threads are an important part of almost every
framework or library related to network
programming and distributed computing
• Even in libraries where users don't see threads
• Sometimes threads are deeply buried inside
libraries to deal with very speciﬁc tasks related
to I/O, waiting, and synchronization
• Examples : multiprocessing, twisted, etc.
5

View Slide

2-
Concept: Threads
• What many programmers think of when they
hear about "concurrent programming"
• An independent task running inside a program
• Shares resources with the main program
(memory, ﬁles, network connections, etc.)
• Has its own independent ﬂow of execution
(stack, current instruction, etc.)
6

View Slide

2-
Thread Basics
7
% python program.py
Program launch. Python
loads a program and starts
executing statements
statement
statement
...
"main thread"

View Slide

2-
Thread Basics
8
% python program.py
Creation of a thread.
Launches a callable.
statement
statement
...
create thread(foo) def foo():

View Slide

2-
Thread Basics
9
% python program.py
Concurrent
execution
of statements
statement
statement
...
statement
statement
...
statement
statement
...

View Slide

2-
Thread Basics
10
% python program.py
thread terminates
on return or exit
statement
statement
...
statement
statement
...
statement
statement
...
return or exit
statement
statement
...

View Slide

2-
Thread Basics
11
% python program.py
statement
statement
...
statement
statement
...
statement
statement
...
return or exit
statement
statement
...
Key idea: Thread is like a little
"task" that independently runs
inside your program
thread

View Slide

2-
threading Module
• How to launch a callable in a separate thread
import threading
import time
def countdown(count):
while count > 0:
print("Counting down", count)
count -= 1
time.sleep(5)
t = threading.Thread(target=countdown,args=(10,))
t.start()
• Thread() creates a thread object
• start() method makes it run
12

View Slide

2-
Thread Objects
• Alternatively: A class that inherits from Thread
class CountdownThread(threading.Thread):
def __init__(self,count):
threading.Thread.__init__(self)
self.count = count
def run(self):
while self.count > 0:
print("Counting down", self.count)
self.count -= 1
time.sleep(5)
thr = CountdownThread(10)
thr.start()
• Comment: I don't like this approach because it
entangles your code with the implementation of
the Thread class (prefer decoupling)
13

View Slide

2-
Thread Execution
• A thread runs until the speciﬁed callable exits
• Unlike a function call, there is no return value (if
a value is returned, it is ignored)
• If a thread dies with an exception, it does not
stop your whole program--just that one thread
terminates (although you will see a traceback)
• Emphasis: Threads execute independently from
the code that launched them
14

View Slide

2-
Thread Operations
• Once started, threads only have a few operations
t.is_alive() # Check if thread t is still running
t.join([timeout]) # Wait for thread t to exit
t.name # Access the thread name
• You can't suspend threads
• You can't signal threads
• You can't kill threads
• More later...
15
"It's Alive!!!!!!!!!"

View Slide

2-
Interpreter Execution
• With threads, the Python interpreter stays alive
until all threads exit
• This is even true if the "main thread" exits
• Common confusion: The main program exits,
but the interpreter doesn't quit because other
threads are still executing
16

View Slide

2-
Daemonic Threads
• If a thread runs forever, make it "daemonic"
t = threading.Thread(target=func)
t.daemon = True
t.start()
• It is standard practice to use this for all non-
terminating background tasks
• I tend to use it for all threads
17
• Daemonic threads get killed on interpreter exit

View Slide

2-
Exercise thread.1
18

View Slide

2-
Using Threads
• Creating threads is easy
• It's awesome! Your program running in
multiple places at the same time
• Now what?!?
19

View Slide

2-
Using Threads
• There are two primary uses of threads.
• Waiting. Program has to wait for I/O, an event,
or for some other reason, but has other work
that still needs to be carried out elsewhere.
• Subdivision of work. Take a big computational
problem and subdivide into threads so that you
can use multiple CPUs or cores (parallelism)
• In Python, threads are almost exclusively used
for waiting (especially I/O).
20

View Slide

2-
The Waiting Problem
21
• An example: Reading on a socket
data = s.recv(1024)
• This operation blocks until data is available
• "blocks" - The program stops and waits
• If no concurrency, then everything stops
• Obviously, this can be undesirable (e.g., what if
there's a GUI or if it's a game?)

View Slide

2-
Multiple Clients
22
• Blocking is a major concern for servers
s1
s2
s3
s1.recv()
s2.recv()
s3.recv()
server
• If recv() blocks, how can multiple clients work?
clients

View Slide

2-
Multiple Clients
23
• A solution: handle each client in a thread
s1
s2
s3
s1.recv()
s2.recv()
s3.recv()
server
thread-1
thread-2
thread-3
• recv() still blocks, but it only affects one thread
• Other threads can still run (life is good)

View Slide

2-
Concurrent Network Server
24
def handle_client(client_sock,client_addr):
with client_sock:
... do stuff with the client ...
def run_server(serv_sock):
while True:
# Wait for a new client connection
c,a = serv_sock.accept()
# Spawn a thread to handle it
cthr = threading.Thread(target=handle_client,
args=(c,a))
cthr.daemon = True
cthr.start()
• A simple threaded server template
• Idea: Launch a new thread on each connection

View Slide

2-
Exercise thread.2
25

View Slide

2-
Interlude
• As mentioned, creating threads is really easy
• You can create thousands of them if you want
• Developing with threads is hard
• Really hard
26
Q: Why did the multithreaded chicken cross the road?
A: to To other side. get the
-- Jason Whittington

View Slide

2-
Threads and Memory
• Although threads have independent control
ﬂow, threads share the same memory
• So, all threads see global variables
• Multiple threads can hold references to the
same object and access it independently
• Threads can also share ﬁles, sockets, etc.
27

View Slide

2-
Shared Memory
• Example
28
items = [] # A global variable
def foo():
...
items.append(x)
...
def bar():
...
y = items.pop()
...
t1 = Thread(target=foo); t1.start()
t2 = Thread(target=bar); t2.start()
These operations are both
manipulating the global
variable "items"
• There is danger here: More shortly...

View Slide

2-
Shared Objects
• The same sharing applies to passed arguments
29
def foo(obj):
...
obj.method(args)
...
def bar(obj):
...
obj.method(args)
...
obj = SomeObject()
t1 = Thread(target=foo, args=(obj,))
t2 = Thread(target=bar, args=(obj,))
t1.start(); t2.start();
This might be the same
object in both threads
(remember, Python functions
don't copy arguments)
• Again, more danger lurks...

View Slide

2-
Nondeterminism
• Thread execution is non-deterministic
• Operations that take several steps might be
interrupted mid-stream (non-atomic)
• Thus, access to shared data structures is also
non-deterministic (which is a really good way
to have your head explode)
30

View Slide

2-
Synchronization Problems
• Events. An action must be performed in
response to an event in a different thread
• Concurrent updates. Multiple threads that
update a shared value.
31

View Slide

2-
Event Synchronization
• Consider a shared value
x = 0
• One thread sets the value, another reads it
Thread-1
--------
...
x = 42
...
Thread-2
--------
...
print(x)
...
• Problem : Which thread runs ﬁrst?
• Answer : It could be either one...
32

View Slide

2-
Concurrent Updates
• Consider a shared value
x = 0
• And two threads that modify it
Thread-1
--------
...
x = x + 1
...
Thread-2
--------
...
x = x - 1
...
• Here, it's possible that the resulting value will
be corrupted due to thread scheduling
33

View Slide

2-
Concurrent Updates
• The two threads
Thread-1
--------
...
x = x + 1
...
Thread-2
--------
...
x = x - 1
...
• Low level interpreter execution
Thread-1
--------
LOAD_GLOBAL 1 (x)
LOAD_CONST 2 (1)
BINARY_ADD
STORE_GLOBAL 1 (x)
Thread-2
--------
LOAD_GLOBAL 1 (x)
LOAD_CONST 2 (1)
BINARY_SUB
STORE_GLOBAL 1 (x)
thread
switch
34
thread
switch

View Slide

2-
Concurrent Updates
• Low level interpreter code
Thread-1
--------
LOAD_GLOBAL 1 (x)
LOAD_CONST 2 (1)
BINARY_ADD
STORE_GLOBAL 1 (x)
Thread-2
--------
LOAD_GLOBAL 1 (x)
LOAD_CONST 2 (1)
BINARY_SUB
STORE_GLOBAL 1 (x)
thread
switch
35
thread
switch
These operations get performed with a "stale"
value of x. The computation in Thread-2 is lost.

View Slide

2-
Atomicity
• Can you assume any operations are atomic?
36
alist.append(x)
item = alist.pop()
adict[key] = value
del adict[key]
...
• In general, you can't assume anything
• Many implementations (jython, pypy, etc.)
• Might be a user-deﬁned class
• "Atomic" meaning noninterruptible

View Slide

2-
Race Conditions
• If program behavior depends on thread
scheduling, you have a "race condition."
• It's often rather diabolical--a program may
produce slightly different results each time it
runs (even though you aren't using any
random numbers)
• Or it may just have a mysterious gremlin
that shows up every couple of weeks
37

View Slide

2-
Thread Synchronization
• Identifying and ﬁxing a race condition will
make you a better programmer (e.g., it
"builds character")
• However, you'll probably never get that
month of your life back...
• To ﬁx : You have to synchronize threads
(e.g., coordinate their execution so that
things happen in the right order)
38

View Slide

2-
Events
• Event Objects
e = threading.Event()
e.is_set() # Return True if event set
e.set() # Set event
e.clear() # Clear event
e.wait([timeout]) # Wait for event
• Used to make one thread wait for an event
to occur in another thread
39

View Slide

2-
Event Waiting
• Using an event to synchronize execution order
x = 0
x_event = threading.Event()
40
Thread-1
--------
...
x = 42
x_event.set()
...
Thread-2
--------
...
x_event.wait()
print(x)
...
signals
• Caution : Events only have one-time use
• Can use to make sure threads do things in a
speciﬁc order

View Slide

2-
Mutex Locks
• Mutual Exclusion Lock
m = threading.Lock()
• Used to synchronize threads so that only
one thread can make modiﬁcations to
shared data at any given time
• Think transactions
41

View Slide

2-
Mutex Locks
• Using a lock
with m: # Acquires the lock
statements
statements
# Releases the lock
statements
• Key feature: Only one thread can execute
inside the 'with' statement at once
• If lock is already in use, a thread waits
42

View Slide

2-
Use of Mutex Locks
• Commonly used to enclose "critical sections"
x = 0
x_lock = threading.Lock()
43
Thread-1
--------
...
with x_lock:
x = x + 1
...
Thread-2
--------
...
with x_lock:
x = x - 1
...
Critical
Section
• Only one thread can execute in critical section
at a time (lock gives exclusive access)

View Slide

2-
Using a Mutex Lock
• It is your responsibility to identify and lock
all "critical sections"
44
x = 0
Thread-1
--------
...
with x_lock:
x = x + 1
...
Thread-2
--------
...
x = x - 1
...
If you use a lock in one place, but
not another, then you're missing
the whole point. All modiﬁcations
to shared state must be enclosed
by the with statement.

View Slide

2-
Locks and Deadlock
• If a thread already acquired a lock, don't have
it acquire it again---everything will freeze
45
lock = threading.Lock()
def foo():
with lock: # Freezes here (lock in use)
statements
def bar():
with lock:
foo()
bar()
• Sometimes occurs if you try to reuse the same
lock for too many things in your program (e.g.,
if you just had one global lock for everything)

View Slide

2-
Locks and Deadlock
• Never write code that acquires more than
one mutex lock at a time
46
x = 0
y = 0
y_lock = threading.Lock()
with x_lock:
statements using x
...
with y_lock:
statements using x and y
...
• This almost invariably ends up creating a
program that mysteriously deadlocks
(see dining philosophers)

View Slide

2-
Alternate Interface
• Alternate interface for locks
47
x = 0
x_lock.acquire()
statements using x
...
x_lock.release()
• Very tricky to use correctly due to
issues with exception handling
• Better to use the 'with' statement

View Slide

2-
Exercise thread.3
48

View Slide

2-
Other Kinds of Locks
• The threading library also deﬁnes
• RLock
• Semaphore
• Condition
• What are these used for?
49

View Slide

2-
RLock
• Reentrant Mutex Lock
m = threading.RLock() # Create a lock
m.acquire() # Acquire the lock
m.release() # Release the lock
• Similar to a normal lock except that it can be
reacquired multiple times by the same thread
• However, each acquire() must have a release()
• Common use : Code-based locking (where
you're locking function/method execution as
opposed to data access)
50

View Slide

2-
RLock Example
• Only allow one thread to execute methods
in a class at a given time
class Foo:
_lock = threading.RLock()
def bar(self):
with Foo._lock:
...
def spam(self):
with Foo._lock:
...
self.bar()
...
51
• Observe : Once any method is called, all of the
methods are locked until the method returns
• Nested calls and recursion are okay

View Slide

2-
Semaphores
• A counter-based synchronization primitive
m = threading.Semaphore(n) # Create a semaphore
m.acquire() # Acquire
m.release() # Release
• acquire() - Waits if the count is 0, otherwise
decrements the count and continues
• release() - Increments the count and signals
waiting threads (if any)
• Unlike locks, acquire()/release() can be called
in any order and by any thread
52

View Slide

2-
Semaphore Uses
• Limiting concurrency. You can limit the
number of threads performing certain
operations. For example, performing
database queries, making network
connections, etc.
• Signaling. Semaphores can be used to send
"signals" between threads. For example,
having one thread wake up another thread.
53

View Slide

2-
Limiting Concurrency
• Using a semaphore to limit concurrency
_fetch_limit = threading.Semaphore(5) # Max: 5-threads
def fetch_page(url):
with _fetch_limit:
u = urllib.urlopen(url)
return u.read()
54
• In this example, only 5 threads can be
executing in the function at once (if more
want to run, they have to wait)

View Slide

2-
Thread Signaling
• Using a semaphore to signal
done = threading.Semaphore(0)
55
...
statements
statements
statements
done.release()
done.acquire()
statements
statements
statements
...
Thread 1 Thread 2
• Here, acquire() and release() occur in different
threads and in a different order
• Sometimes used in queuing problems

View Slide

2-
Condition Variables
• Condition Objects
cv = threading.Condition([lock])
cv.acquire() # Acquire the underlying lock
cv.release() # Release the underlying lock
cv.wait() # Wait for condition
cv.notify() # Signal that a condition holds
cv.notifyAll() # Signal all threads waiting
56
• A combination of locking/signaling
• Lock is used to protect code that changes a
shared data value
• Signal is used to notify other threads that the
data has changed state ("condition" changed)

View Slide

2-
Condition Example
• Thread that prints value every time it changes
x = 0
x_cond = Condition()
57
...
...
with x_cond:
x = new value
x_cond.notify()
...
...
last_x = x
while True:
with x_cond:
while (last_x == x):
x_cond.wait()
print("x=",x)
last_x = x
Thread 1 Thread 2
• Somewhat similar to an Event except that you
can use it over and over again

View Slide

2-
Exercise thread.4
58

View Slide

2-
Problems with Threads
• Many things all going at once
• Weird control ﬂow and tricky data handling
• Ad-hoc coding hell and many bad examples
• Weak debugging support
• My advice : Focus on proper encapsulation
59

View Slide

2-
Tasks vs. Threads
• When you launch a thread, you are creating a
concurrently executing "task"
• A "task" is simply a representation of work
• Insight : Tasks are more general than threads
• Threads are an implementation detail related
to getting the task to run, but are unrelated to
the actual work being carried out
60

View Slide

2-
Task Features
• Some desirable features of tasks
• Start/stop/resume functionality
• Crash recovery
• Logging and diagnostics
• Debugging support
• To get this, you need planning and discipline
61

View Slide

2-
Task Classes
62
class CountdownTask:
self.count = count
def run(self):
self.count -= 1
time.sleep(5)
• Deﬁne your tasks as a class
• Minimally, it has a run() method that
performs the work associated with the task
• Notice: No use of threads here

View Slide

2-
Task Bootstrapping
63
self.count = count
def bootstrap(self):
self.run()
def run(self):
self.count -= 1
time.sleep(5)
• Always put an extra wrapper around run()
• Think of it as "booting" the task
• Purpose is to set up the runtime environment

View Slide

2-
Task Termination
64
...
self.runnable = True
self.run()
def stop(self):
self.runnable = False
def run(self):
while self.runnable and self.count > 0:
...
• Give tasks some way to stop
• Note: tasks must be programmed to check
• Food for thought: Is stopping == killing?

View Slide

2-
Task Exception Handling
65
...
try:
self.run()
except Exception:
self.exc_info = sys.exc_info() # Save it!
# Log/report/handle the exception
...
• Give tasks a catch-all exception handler
• Buggy tasks will crash. You want to have a way
to manage and debug it.
• Advice : Always report and save the exception

View Slide

2-
Task State
66
self.state = "INIT"
...
self.state = "RUNNING"
try:
self.run()
except Exception:
self.exc_info = sys.exc_info()
self.state = "EXIT"
• Give tasks a "state" attribute
• Having this is very useful for debugging
• Thought: Make it user-customizable

View Slide

2-
Task Logging
• Give your tasks some logging
67
import logging
...
self.log = logging.getLogger("countdown")
self.log.info("Starting")
...
try:
self.run()
except Exception:
self.log.error("Crashed", exc_info=True)
self.log.info("Exit")

View Slide

2-
Task Logging
• Set up the logging module for your program
import logging
logging.basicConfig(
filename="debug.log",
filemode="w",
format="%(process)d:%(threadName)s" \
"%(levelname)s:%(message)s",
level=logging.DEBUG)
68
• Examples of issuing log messages
log = logging.getLogger("name")
log.critical("A critical error occurred")
log.error("File %s not found", filename)
log.warning("This is your last warning")
log.info("Just some information")
log.debug("Debugging : n = %d", n)

View Slide

2-
Logging Information
• More information on logging
69
http://www.dabeaz.com/special/Logging.pdf
• We'll be using it throughout

View Slide

2-
Task Cleanup
70
...
def finalize(self):
del self.log
del self.exc_info
...
self.state = "FINAL"
• Deﬁne a ﬁnalization method
• This method should clean-up all attributes
related to the runtime environment (e.g.,
logging, exceptions, etc.)
• Think of it as "__del__" for the runtime

View Slide

2-
Task Resources
71
• Tasks have two runtime states
• Managed separately
Task
(inactive)
runtime environment
Task
(running)
Task
(inactive)
bootstrap()
finalize()

View Slide

2-
Task Class Recap
• You have a task class with this interface:
class Task:
def __init__(self):
...
def stop(self):
...
...
def run(self):
...
def finalize(self):
...
72
• There are start/stop methods
• There is error handling
• There is logging for diagnostics

View Slide

2-
Interlude
73
• Our task class is a general representation of
concurrently executing "work"
• Think of it as a task environment
• It is self-contained and decoupled
• Task object is like a basic building block

View Slide

2-
Adding Threads
• Question : How do threads enter?
• Think of threads as a very low-level
implementation detail (like assembly language,
low-level system calls, etc.).
• Threads just enable concurrent execution
74

View Slide

2-
Adding Threads
• One approach : Add a start() method
75
class Task:
...
def start(self):
thr = threading.Thread(target=self.bootstrap)
thr.daemon = True
thr.start()
...
• Threads are used internally, but users don't
know that--they just call start()

View Slide

2-
Big Picture
• Tasks have two parts
76
task execution thread
task = Task()
task.start()
task.stop()
task.finalize()
task creation and control
launches
self.run()
def run(self):
... do work ...
• Yes, there are many moving parts
• It looks complex, but you'll be thankful later

View Slide

2-
Commentary
• Isn't all of this task setup a lot of work?
77
• Yes, but using threads is like playing with ﬁre

View Slide

2-
Food For Thought
• Who is in charge here?
• The threading library?
• A third party library?
• A framework?
• Nobody?
• You want to be in control of the environment
• There is going to be complexity
• Better to manage it than to react
78

View Slide

2-
Counterpoint
• Don't go overboard abstracting away details
• Keep it simple
• Make sure you can test and debug it
79
"If you add the right abstraction layer, you can
make the jump from an unknown number of
problems to an unknowable number of problems."
- Cameron Laird

View Slide

2-
Exercise thread.5
80

View Slide

2-
Debugging Tips
• Debugging concurrent tasks is tricky
• Let's look at a few useful tips
• Don't repeat yourself
• Assigning thread/task names
• How to use the main thread
• Enabling post-mortem debugging support
81

View Slide

2-
Avoid Repeating Yourself
• Use inheritance to avoid code replication
82
class Task:
def __init__(self):
self.state = "INIT"
def start(self):
thr = threading.Thread(target=self.bootstrap)
thr.daemon = True
thr.start()
...
def stop(self):
...
• To use: inherit from Task and redeﬁne run()

View Slide

2-
Using the Main Thread
• Never use the main execution thread to
perform any real work
• If using threads, launch separate threads for
all parts of your application
• Why? If you do this, you can still use the
interactive interpreter during execution
• Incredibly useful for debugging (can examine
tasks, program state, etc.)
83

View Slide

2-
Main Thread Suggestion
• In production, have the main thread spin
84
def main():
import time
while True:
time.sleep(1)
• It consumes virtually no CPU (sleeps)
• Avoids annoyance of killing programs that
use threads (Ctrl-C will work properly)

View Slide

2-
Post-Mortem Debugging
• Here's a neat little trick involving pdb
85
class Task:
...
try:
self.run()
except Exception:
self.exc_info = sys.exc_info()
def pm(self):
import pdb
pdb.post_mortem(self.exc_info[2])
• If your task crashes with an exception, the
pm() method launches the debugger on the
saved traceback (can inspect internals)

View Slide

2-
Exercise thread.6
86

View Slide

2-
Threads and Memory
• How did we get on this topic?
• Oh yeah, threads share the same memory
• It's great except that...
• Shared memory sucks
• Mutable data sucks
• Locking sucks
• Blasphemy!
87

View Slide

2-
The Horror, The Horror!
• Writing reliable and maintainable programs
based on shared memory is a "sisyphean task"
• Shared state is not a feature
• At ﬁrst glance, it seems "convenient"
• Actually a trap that leads to nothing but sorrow
88

View Slide

2-
Personal Aside
• Computer Science professors love locks,
synchronization, and shared state!
• Gives them something to talk about for 3-4
weeks while teaching operating systems (e.g.,
dining philosophers)
• Easily applied to making students cry on exams
• Professors don't have to maintain real code
89

View Slide

2-
Concurrency Wisdom
• Experience : Concurrent programs involving
tasks, shared state, and complicated locking
can't be understood (or debugged) by humans
• Practical advice:
• Tasks should never share state
• Tasks can communicate, but should only
pass immutable data structures
• Strive for task isolation and simplicity
90

View Slide

2-
Shared State
91
"If there's one lesson we've learned from 30+ years of
concurrent programming it is: just don't share state. It's
like two drunkards trying to share a beer. It doesn't
matter if they're good buddies. Sooner or later they're
going to get into a fight. And the more drunkards you
add to the pavement, the more they fight each other
over the beer. The tragic majority of multithreaded
applications look like drunken bar fights."
- ØMQ (The Guide)

View Slide

2-
Question
• How do you get isolation?
92

View Slide

2-
Thread Communication
• Instead of having shared data structures,
focus on communication between threads
• Examples:
• Producer/consumer
• Publish/subscribe
• Request/response
• Big idea : think of threads as independent
actors (like network servers)
93

View Slide

2-
Producers & Consumers
• Threaded programs can often be organized
into into producers and consumers
94
Task 1
(Producer)
Task 2
(Consumer)
inbox
send(item)
• Instead of "sharing" data, threads only
coordinate by sending data to each other
• Think pipes, sockets, etc.

View Slide

2-
queue Library Module
• A thread-safe message queue
• Basic operations
from queue import Queue
q = Queue([maxsize]) # Create a queue
q.put(item) # Put an item on the queue
q.get() # Get an item from the queue
q.empty() # Check if empty
q.full() # Check if full
q.qsize() # Queue size
95
• To use: write your code so that it strictly
adheres to get/put operations.

View Slide

2-
Basic Queue Usage
• Example of setting up a producer and consumer
# Produce an item
msg_q.put(item)
96
while True:
item = msg_q.get()
consume_item(item)
from queue import Queue
msg_q = Queue()
Producer Thread Consumer Thread
• Items are sent from one thread to another
• No shared state except for the queue

View Slide

2-
Tasks as Consumers
• Recall our earlier task object
97
class Task:
def __init__(self):
...
def stop(self):
...
...
def run(self):
...
• Queuing can be added by extending this class
• Remember : You want encapsulation

View Slide

2-
Tasks as Consumers
98
import queue
class Task:
self._messages = queue.Queue()
...
def send(self,msg):
self._messages.put(msg)
def recv(self):
return self._messages.get()
def run(self):
while True:
# Get a message from the queue
msg = self.recv()
# Work on msg
...
• Add an internal queue, send(), and recv()
• send() stores incoming messages. run()
receives messages with recv()

View Slide

2-
Consumer Termination
99
class TaskExit(Exception): pass
class Task:
...
def send(self,msg):
self._messages.put(msg)
def stop(self):
# Use None to signal end of messages
self._messages.put(TaskExit)
...
• To gracefully shutdown, use a sentinel
• Sentinel value goes on the end of the queue
• Previous messages will get processed ﬁrst

View Slide

2-
Consumer Termination
100
class TaskExit(Exception): pass
class Task:
...
def recv(self):
msg = self._messages.get()
if msg is TaskExit:
raise TaskExit()
return msg
...
try:
self.run()
except TaskExit:
pass
...
• Check for sentinel in recv() and raise exception
• Can catch in bootstrap() behind the scenes

View Slide

2-
Exercise thread.7
101

View Slide

2-
Task Messaging
102
• Have built a messaging framework for tasks
Task 1 Task 2
Task 3 Task 4
• It's extremely general purpose
• Still some subtle details to work out

View Slide

2-
Message Immutability
103
• For sanity, messages should be immutable!
• Strings, Numbers, Tuples
• This means...
• No dictionaries or instances
• Recall : "Nothing but sorrow"
• Personal preference: Use tuples of immutables
• If you can't do that, at least send copies

View Slide

2-
Why Immutability?
104
• Passing data between threads involves a transfer
of information (and involves memory)
Task 1
msg
send() Task 2
• Are you sending a reference or a value?
Task 1
msg
Task 2
• If reference, there is shared state (danger)
refcnt=1
refcnt=2

View Slide

2-
Message Tagging
105
• With messages, it is often useful to have a tag
that identiﬁes the kind of message
task.send(('foo',msg))
task.send(('bar',msg))
• Allows the receiver to recognize different kinds
of messages and process accordingly
def run(self):
...
tag, msg = self.recv()
if tag == 'foo':
# Process 'foo' messages
...
elif tag == 'bar':
# Process 'bar' messages

View Slide

2-
Message Tagging
106
• Tagging can also be used to separate messages
originating from multiple sources
Task 1 Task 2
Task 3
('foo', msg) ('bar', msg)
• Example: A consumer that receives data from
multiple input sources

View Slide

2-
Queue Sizes
• Queues can be created with a max size
q = queue.Queue([maxsize]) # Bounded queue
107
• Can be used to prevent unbounded queue
growth of consumers
• Example: Limiting messages to slow or non-
responsive consumers

View Slide

2-
Non-blocking Queuing
• Normally, put/get block a thread
• Non-blocking get/put
q.get(False) # Get item or queue.Empty exception
q.put(item,False) # Put item or queue.Full exception
108
• Queuing with timeouts
q.get(timeout=PERIOD)
q.put(item, timeout=PERIOD)

View Slide

2-
Example : Receive Timeout
109
import queue
class Task:
...
def recv(self,*,timeout=None):
try:
self._messages.get(timeout=timeout)
except queue.Empty:
raise RecvTimeoutError()
...
• Implementation
• Receivers should have the option of not
blocking forever (if they want)

View Slide

2-
Caution
110
• Queue limits, non-blocking, and timeouts are
signiﬁcantly more complicated to use in practice
than you might imagine
• Introduces problem of "ﬂow-control"
• Queue limits might result in deadlock
• Non-blocking might result in discarded messages

View Slide

2-
Exercise thread.8
111

View Slide

2-
Publish/Subscribe
112
• Producers might use a subscription model
Publisher
Subscriber
channel
channel
Subscriber
Subscriber
• Think chat, RSS, XMPP, logging, etc...
• Publishers send message into a channel,
subscribers receive the feed

View Slide

2-
Publish/Subscribe
• To implement, it is common to deﬁne an
intermediary object for message handling
113
Publisher Subscriber
Subscriber
Subscriber
Gateway
• Gateway receives messages and deals with details
of distribution, routing, subscriptions, etc.
• Goal : Loose coupling

View Slide

2-
Example: Logging
• You're already familiar with something that works
exactly like this: the logging module
114
Handler
Handler
Handler
Logger
• Logger gets logging messages and publishes them
to various subscribed handlers
• Can use it as a rough design model
log.info("Hi")

View Slide

2-
Example Gateway
• Simplistic implementation of a Gateway
115
class Gateway:
def __init__(self):
self._channels = {}
def subscribe(self,task,channel):
self._channels.setdefault(channel,set()).add(task)
def unsubscribe(self,task,channel):
self._channels[channel].remove(task)
def publish(self,msg,channel):
for task in self._channels[channels]:
task.send(msg)
• Caution: It's missing some locking (added in
the exercise)

View Slide

2-
Example Gateway
• Internally, there are different channels
116
class Gateway:
def __init__(self):
self._channels = {}
for task in self._channels[channel]:
task.send(msg)

View Slide

2-
Example Gateway
• Subscribe/unsubscribe methods
117
class Gateway:
def __init__(self):
self._channels = {}
task.send(msg)

View Slide

2-
Example Gateway
• publish method
118
• Simply forwards messages to any tasks
subscribed on a channel
class Gateway:
def __init__(self):
self._channels = {}
task.send(msg)

View Slide

2-
Gateway Use
• There is at least one gateway in the system
• Used by all of the threads for publishing
119
Gateway
Subscriber
Subscriber
Subscriber
Publisher
Publisher
• Key: Multiple publishers and subscribers

View Slide

2-
Subscriber Disconnect
120
class Task:
...
def run(self):
gateway.subscribe(self)
try:
...
finally:
gateway.unsubscribe(self)
• Problem : Tasks come and go.
• Must be careful to manage subscriptions
• Example: unsubscribe on exception/return

View Slide

2-
Decoupling
121
_gateways = {}
def get_gateway(name):
if name not in _gateways:
_gateways[name] = Gateway()
return _gateways[name]
• Publishers should try to remain relatively
decoupled from the gateways (i.e., avoid passing
direct references around).
• One approach: Emulate the logging interface
• Use:
gateway = get_gateway("mygateway")
gateway.publish(msg,"channel")

View Slide

2-
Exercise thread.9
122

View Slide

2-
Food for Thought
123
• pub/sub is a very ﬂexible approach
• Promotes loose coupling of tasks
• Reliability features (task restart, redundancy, etc.)
• Scalability to multiple machines (later)
• Can also be used to implement system-level
features such as task monitoring, events, logging,
debugging, etc.

View Slide

2-
Monitoring/Debugging
• pub/sub allows diagnostic tools to be attached
124
Gateway
Monitoring
Consumer
Publisher
• Idea: Optional components can listen in on
the communication and report back

View Slide

2-
Events/Notiﬁcation
• Can have dedicated gateways for events
125
Task
• Special tasks for handling abnormal
situations, crashes, etc.
Task Task
Event Gateway
crash
☠
Crash Manager

View Slide

2-
Exercise thread.10
126

View Slide

2-
Worker Tasks
• Sometimes concurrent tasks/threads are used to
perform background work on behalf of other code
127
master worker task
Request
Response/result
• Scenario : Master hands work over to a separate
task and continues with other processing. Gets
the result at some later time

View Slide

2-
Worker Tasks
• Very tricky: Instead of just sending data, you have
an asynchronous request/response cycle
128
master worker
Request
Response/result ???
• Issue : How does the result come back?

View Slide

2-
The Problem
• This is nothing like a normal function call
• The work is ﬁnished at some undetermined
time in the future
• The master doesn't know when the result will
arrive--and it may want to do other things in the
meantime
• Comment: This problem also comes up in other
settings (distributed computing, etc.)
129

View Slide

2-
Returning Results
• Deﬁne an object that represents a future result
class UnavailableError(Exception): pass
class FutureResult:
def set(self,value):
self._value = value
def get(self):
if hasattr(self,"_value"):
return self._value
else:
raise UnavailableError("No result")
130
• The idea here: Return the result if it's been
set, otherwise raise an exception

View Slide

2-
Result Objects
• Sample use (interactive mode)
>>> r = FutureResult()
>>> r.get()
Traceback (most recent call last):
File "", line 1, in
File "result.py", line 9, in get
raise UnavailableError("no result")
__main__.UnavailableError: no result
>>> r.set(42)
>>> r.get()
42
>>>
131
• Now, let's see how you might use it

View Slide

2-
Worker Task
132
• FutureResult object is created by worker and
given back to the requestor
• Worker sets the result when work ﬁnished
class WorkerTask(Task):
def request(self,msg):
fresult = FutureResult() # Create FutureResult
self.send((fresult,msg)) # Send along with msg
return fresult # Return result object
def run(self):
while True:
# Get a message
fresult,msg = self.recv()
# Work on msg
...
# Set the result
fresult.set(response) # Set the response

View Slide

2-
Requesting Work
• Example of making a request:
133
fresult = worker.request(msg) # Make request to worker
...
... do other things while worker works
...
# Get the result (at a later time)
r = fresult.get()
• Keep in mind: the worker is operating
concurrently in the background
• When it ﬁnishes (at unknown time), it will store
data in the returned result object

View Slide

2-
Returning Exceptions
• What if a worker wants to communicate an
error or exception?
• This is tricky---you're basically passing an
exception between tasks
• It's not "normal" exception handling
134

View Slide

2-
Results w/ Exceptions
• Modiﬁed Result object
class UnavailableError(Exception): pass
class FutureResult:
self._value = value
def set_error(self):
self._exc = sys.exc_info()
def get(self):
if hasattr(self,"_exc"):
raise self._exc[1].with_traceback(self._exc[2])
elif hasattr(self,"_value"):
return self._value
else:
raise UnavailableError("No result")
135
Reraise the exception
that occurred in the
worker
Save current
exception
information

View Slide

2-
Setting Exceptions
• An example of setting an exception
136
class WorkerTask(Task):
def run(self):
...
try:
... some work ...
result.set(value)
except:
result.set_error()
fresult = worker.send(msg)
...
...
r = fresult.get()
Exception actually gets raised
here (when someone is
interested in the outcome)
Save the current
exception
• Admittedly, it's a little mind-bending

View Slide

2-
Exercise thread.11
137

View Slide

2-
A Coordination Problem
• How does the master thread know when
the result has been made available?
138
master worker
Request
Response/result
• Does it have to constantly poll?
• Does it just wait for awhile?
• This is a timing/synchronization issue

View Slide

2-
Event Waiting
• Using an event to signal "completion"
def master():
...
item = create_item()
evt = Event()
worker.send((item,evt))
...
# Other processing
...
...
...
...
...
# Wait for worker
evt.wait()
139
Worker Thread
item, evt = get_work()
processing
processing
...
...
# Done
evt.set()

View Slide

2-
Results with Waiting
• Using events in our result object
from threading import Event
class FutureResult:
def __init__(self):
self._evt = Event()
self._value = value
self._evt.set()
def get(self):
self._evt.wait()
return self._value
140
• Idea : get() will simply use the event to wait for
the result to become available

View Slide

2-
Exercise thread.12
141

View Slide

2-
Advanced Features
• FutureResult can be expanded to support a
variety of other very useful features
• Cancellation
• Progress/status
• Completion callbacks
142

View Slide

2-
Work Cancellation
• Allow requestor to cancel
143
class FutureResult:
def __init__(self):
self._cancel = False
def cancel(self):
self._cancel = True
• Example use in worker
def run(self):
while True:
fresult, msg = self.recv()
if fresult._cancel:
continue
...

View Slide

2-
Work Progress
• Results can include progress information
144
class FutureResult:
def __init__(self):
self.progress = 0
...
• Example use in worker (requestor can monitor)
def run(self):
while True:
fresult, msg = self.recv()
# Work on the result
...
fresult.progress += n # Update progress
...
# Done
fresult.set(response)
• Alternate: publish progress on a channel

View Slide

2-
Completion Callbacks
• A function that ﬁres when result is ready
145
class FutureResult:
def __init__(self):
self._callback = None
def set_callback(self,cb):
self._callback = cb
def set(self,result):
self._value = result
if self._callback: # Invoke callback (if set)
self._callback(result)
• Example use:
def when_done(result):
print(result)
fresult = worker.request(msg)
fresult.set_callback(when_done)

View Slide

2-
Exercise thread.13
146

View Slide

2-
Worker Pools
• It is common for work to be farmed out to
a pool of worker tasks
147
master worker pool
Request
Response/result
worker
worker
worker
worker
• Example : A pool of dozen different worker
threads handle incoming work

View Slide

2-
Pool Implementation
• Many possibilities
• Most common : launch multiple threads
that all receive messages from the same
message queue
148

View Slide

2-
Worker Pool
• Sketch of implementation
149
class WorkerPool(Task):
def __init__(self,nworkers=1):
...
self.nworkers = nworkers
def run(self):
for n in range(1,self.nworkers):
thr = threading.Thread(target=self.do_work)
thr.daemon = True
thr.start()
self.do_work()
def do_work(self):
while True:
fresult,msg = self.recv()
... do work ...
fresult.set(value)
• Tricky bits : Shutdown (see exercise)
Launch of
multiple
worker
threads

View Slide

2-
Worker Pool API
• In practice, worker pools tend to have an API
that is similar to this:
150
class WorkerPool(Task):
...
def apply(self,func,args=(),kwargs={}):
# Runs func(*args,**kwargs) in a worker thread
...
def map(self,func,sequence):
# Runs [func(s) for s in sequence] in worker
...
• apply() - Runs a callable in a worker
• map() - Applies a function to a sequence using
multiple workers. (related to map-reduce)

View Slide

2-
Exercise thread.14
151

View Slide

2-
Interlude
• We have done a lot of work putting it together
• Task objects
• Different communication patterns
• Task diagnostics, debugging, logging, etc.
• It sets the stage for other topics
152

View Slide

2-
Thread Implementation
• Let's conclude by peeling back the covers
• Some details of how Python operates
• Some limitations
153

View Slide

2-
What is a Thread?
• Python threads are real system threads
• POSIX threads (pthreads)
• Windows threads
• Fully managed by the host operating system
• All scheduling/thread switching
• Represent threaded execution of the Python
interpreter process (written in C)
154

View Slide

2-
Behind the Scenes
• There's not much going on...
• Here's what happens
• Python creates a small data structure
containing some interpreter state
• A new thread (pthread) is launched
• The thread calls PyEval_CallObject
• Last step is just a C function call that runs
whatever Python callable was speciﬁed
155

View Slide

2-
Thread-Specific State
• Each thread has its own interpreter specific
data structure (PyThreadState)
• Current stack frame (for Python code)
• Current recursion depth
• Thread ID
• Some per-thread exception information
• Optional tracing/profiling/debugging hooks
• It's a small C structure (~84 bytes)
156

View Slide

2-
PyThreadState Structure
157
typedef struct _ts {
struct _ts *next;
PyInterpreterState *interp;
struct _frame *frame;
int recursion_depth;
int tracing;
int use_tracing;
Py_tracefunc c_profilefunc;
Py_tracefunc c_tracefunc;
PyObject *c_profileobj;
PyObject *c_traceobj;
PyObject *curexc_type;
PyObject *curexc_value;
PyObject *curexc_traceback;
PyObject *exc_type;
PyObject *exc_value;
PyObject *exc_traceback;
PyObject *dict;
int tick_counter;
int gilstate_counter;
PyObject *async_exc;
long thread_id;
} PyThreadState;

View Slide

2-
Threads and sys module
• Certain functions in the sys module are tied to
thread-speciﬁc state (exceptions, diagnostics)
• Example : sys.exc_info()
158
try:
statements
except Exception:
# Get per-thread exception information
etype, value, tb = sys.exc_info()
• Some other thread-speciﬁc functions
sys.exc_clear()
sys.settrace()
sys.setprofile()
...

View Slide

2-
The Infamous GIL
• But there's a catch...
• Only one Python thread can execute in the
interpreter process at once
• There is a "global interpreter lock" that
carefully controls thread execution
• The GIL ensures that sure each thread gets
exclusive access to the entire interpreter
internals when it's running
159

View Slide

2-
GIL Behavior
• Whenever a thread runs, it holds the GIL
• However, the GIL is released on I/O
160
I/O I/O I/O
release
acquire
release
acquire
acquire
release
• So, any time a thread is forced to wait, other
"ready" threads get their chance to run
• Basically a kind of "cooperative" multitasking
run run run run
acquire

View Slide

2-
Thread Switching
• If threads hammer the CPU and don't do I/O,
they will periodically switch back and forth
• Python 3.1 and earlier: threads have option of
switching every 100 "instructions" (ticks)
• Python 3.2 and newer: threads switch every 5ms
• Switch period can be tuned (if needed)
161
sys.setcheckinterval(nticks) # Python 3.1 and earlier
sys.setswitchinterval(secs) # Python 3.2 and newer

View Slide

2-
Why is the GIL there?
• Simpliﬁes the implementation of the Python
interpreter (okay, sort of a lame excuse)
• Better suited for reference counting
(Python's memory management scheme)
• Simpliﬁes the use of C/C++ extensions.
Extension functions do not need to worry
about thread synchronization
• Is it ever going away? Probably not soon.
162

View Slide

2-
The GIL Explained
• In June, 2009, I gave a talk about the GIL
163
http://www.dabeaz.com/python/GIL.pdf
• I won't repeat it all here, but here's the gist:
Python threads should not be used for CPU-
bound processing (e.g., crunching data)
• This led to a PyCON'2010 presentation
http://www.dabeaz.com/GIL

View Slide

2-
CPU Bound Processing
• For heavy CPU processing, Python is limited
to a single CPU-core
• Thus, threads can not be used to provide any
kind of parallel processing
• No performance gain at all
• In older versions of Python (< 3.2), threads
might make the performance far worse
164

View Slide

2-
GIL Badness
• The worst part of the GIL is not the fact that it
limits the use of multiple cores
• There are other ways to utilize multicore (later)
• GIL actually causes all sorts of bizarre problems
with timing and scheduling of threads
• Examples: Response time, I/O throughput
165

View Slide

2-
Python Code Execution
• Code is compiled to interpreter instructions
166
def countdown(n):
while n > 0:
print n
n -= 1
>>> import dis
>>> dis.dis(countdown)
0 SETUP_LOOP 33 (to 36)
3 LOAD_FAST 0 (n)
6 LOAD_CONST 1 (0)
9 COMPARE_OP 4 (>)
12 JUMP_IF_FALSE 19 (to 34)
15 POP_TOP
16 LOAD_FAST 0 (n)
19 PRINT_ITEM
20 PRINT_NEWLINE
21 LOAD_FAST 0 (n)
24 LOAD_CONST 2 (1)
27 INPLACE_SUBTRACT
28 STORE_FAST 0 (n)
31 JUMP_ABSOLUTE 3
...
• Instructions in
the Python VM

View Slide

2-
Instruction Execution
• Interpreter instructions are non-interruptible
167
• Long operations can block everything
>>> nums = range(1000000000)
>>> sum(nums)
499999999500000000
>>>
1 instruction (~ 42 seconds)
• Try hitting Ctrl-C (uninterruptible)
>>> nums = range(1000000000)
>>> sum(nums)
^C^C^C (nothing happens, very long pause)
...
KeyboardInterrupt
>>>

View Slide

2-
Why You Care
• Long running instructions block progress
• Would manifest itself as an annoying "pause" in a
GUI, game, or network application
• Example : A request is sent to a server, but it
doesn't respond for 10 seconds
168

View Slide

2-
Long Running Instructions
• Illustration
169
Thread 1
Thread 2 STALLED
long instruction (running)
GIL release
event
arrives
• No way for a long instruction to be preempted
• All other threads stall, waiting for completion
running
sleeping
done
response

View Slide

2-
I/O Throughput Issues
170
• Consider this code fragment:
def receive_data(s):
msg = bytearray()
while True:
data = s.recv(1024)
! if not data:
break
! msg.extend(data)
return msg
• It receives and assembles a message on a socket
• Imagine it's part of some web/messaging code

View Slide

2-
171
• A test: Send 1MB of data between interpreters
python python
1MB
• Time to receive : ~0.009s (116Mbytes/sec)
• Python 3.2, quad-core MacPro

View Slide

2-
172
• Now, introduce a CPU bound thread
msg = bytearray()
while True:
data = s.recv(1024)
! if not data:
break
! msg.extend(data)
return msg
• Thread 2 is just doing some "work"
Thread 1 Thread 2
def spin():
while True:
pass

View Slide

2-
173
• A test: Sending 1MB of data between interpreters
python
python
(2 threads)
1MB
• Time to receive : ~2.23s (470Kb/sec)
• Almost 250x times slower! Yikes!

View Slide

2-
Exercise thread.15
174

View Slide

2-
Thread Switching
175
• GIL performance problems are related to the
mechanism used to switch threads
• In particular, the preemption mechanism and
lack of thread priorities
• Must illustrate

View Slide

2-
Thread Switching
176
Thread 1
running
• Suppose there is just one thread
• It runs forever
• Never releases the GIL
• Life is great!

View Slide

2-
Thread Switching
177
Thread 1
Thread 2 SUSPENDED
running
• Now, a second thread makes an appearance...
• It is suspended because it doesn't have the GIL
• Somehow, it has to get it from Thread 1

View Slide

2-
Thread Switching
178
Thread 1
Thread 2 SUSPENDED
running
• Second thread does a timed wait on GIL
• The idea : Thread 2 waits to see if the GIL gets
released voluntarily by Thread 1 (e.g., if Thread
1 performs I/O or goes to sleep)
wait(gil, TIMEOUT)
By default TIMEOUT
is 5 milliseconds, but it
can be changed

View Slide

2-
Thread Switching
179
Thread 1
Thread 2 SUSPENDED
running
• A thread might give up the GIL voluntarily
• This is straightforward--the GIL is just handed
to the waiting thread (all is well)
wait(gil, TIMEOUT)
I/O wait
release
running
SUSPENDED

View Slide

2-
Thread Switching
180
Thread 1
Thread 2 SUSPENDED
running
• What if a thread doesn't suspend? (CPU bound)
• After timeout, the waiting thread initiates a
"drop request" and repeats the wait operation
wait(gil, TIMEOUT)
TIMEOUT
drop_request
wait(gil, TIMEOUT)

View Slide

2-
Thread Switching
181
Thread 1
Thread 2 SUSPENDED
running
• Thread 1 suspends when drop request received
• GIL released after the current instruction
completes (recall, it might take awhile)
wait(gil, TIMEOUT)
TIMEOUT
wait(gil, TIMEOUT)
drop_request release
running

View Slide

2-
Thread Switching
182
Thread 1
Thread 2 SUSPENDED
running
• On a forced release, Thread 1 waits for an ack
• Signal indicates that the other thread
successfully got the GIL and is now running
wait(gil, TIMEOUT)
TIMEOUT
wait(gil, TIMEOUT)
drop_request
release
running
WAIT
wait(ack)
SUSPENDED
ack

View Slide

2-
Thread Switching
183
Thread 1
Thread 2 SUSPENDED
running
• The process now repeats itself for Thread 1
• This sequence happens over and over again as
CPU-bound threads execute
wait(gil, TIMEOUT)
TIMEOUT
wait(gil, TIMEOUT)
drop_request
release
running
WAIT
wait(ack)
SUSPENDED
wait(gil, TIMEOUT)
ack

View Slide

2-
Problem : Response Time
184
• If a thread wants the GIL, it might wait 5ms
• There is no way for a "high priority" thread to
grab the GIL away from a CPU-bound thread
• Example : Critical event received on network
• You can't guarantee an immediate response

View Slide

2-
Response Time
• Illustration
185
Thread 1
Thread 2 READY
running
wait(gil, TIMEOUT)
release
running
IOWAIT
data
arrives
wait(gil, TIMEOUT)
TIMEOUT
drop_request
• To handle I/O, thread 2 must go through the
entire timeout sequence to get control

View Slide

2-
Problem: Thread Selection
186
Thread 1
Thread 2 SUSPENDED
running
TIMEOUT
drop_request
SUSPENDED
Thread 3
SUSPENDED
SUSPENDED
running
release
• Thread that ﬁrst wants the GIL might not get it
• Not only can you not guarantee response time,
you can't guarantee scheduling

View Slide

2-
Problem : GIL Release
• CPU-bound threads degrade I/O
187
Thread 1
Thread 2 READY
running
run
data
arrives
• Each I/O call (e.g., recv/send) drops the GIL and
restarts the CPU-bound Thread 1
• Each time Thread 1 runs, need 5ms to preempt
data
arrives
running
READY
run
release
running
READY
data
arrives
5ms 5ms 5ms

View Slide

2-
I/O Experiment Explained
188
• Recall our original code
msg = bytearray()
while True:
data = s.recv(1024)
! if not data:
break
! msg.extend(data)
return msg
• It required ~2.23s to receive 1MB (vs. 0.009s)
• ~1024 recv() operations (each releases the GIL)
• Thread 2 gets scheduled more than it ought to
Thread 1 Thread 2
def spin():
while True:
pass

View Slide

2-
Exercise thread.16
189

View Slide

2-
The GIL and C Code
• C/C++ extensions can release the
interpreter lock and run independently
• Caveat : Once released, C code shouldn't
do any processing related to the Python
interpreter or Python objects
• You might be able to use this to take
advantage of multiple cores
190

View Slide

2-
The GIL and C Extensions
• Having C extensions release the GIL is how
you get into true "parallel computing"
191
Python
instructions
C code
GIL release
GIL acquire
C threads
Python
instructions
Thread 1
Thread 2
Python
instructions
GIL acquire
GIL release
• Python and C can run in parallel

View Slide

2-
• Having C extensions release the GIL is how
you get into true "parallel computing"
192
Python
instructions
C code
GIL release
GIL acquire
C threads
Python
instructions
Thread 1
Thread 2
Python
instructions
GIL acquire
GIL release
• Python and C can run in parallel
Key part: This
execution must not
involve the Python
interpreter

View Slide

2-
How to Release the GIL
• C extensions use special macros
193
PyObject *pyfunc(PyObject *self, PyObject *args) {
...
Py_BEGIN_ALLOW_THREADS
// Threaded C code
...
Py_END_ALLOW_THREADS
...
}
• Certain extensions such as ctypes also release
the GIL automatically

View Slide

2-
• The trick with C extensions is that you have
to make sure they do enough work
• You won't get any beneﬁt if the C code only
runs a few simple calculations
• You need to do a lot of calculation (e.g.,
thousands of ﬂoating point ops).
194

View Slide

2-
Using Processes
• Another GIL workaround is to delegate
CPU-intensive work to a subprocess
• Example : Send work to a separate Python
interpreter over a pipe or socket
• Have that interpreter operate independently
and send results back when done
• We're going to look at this later...
195

View Slide

2-
Exercise thread.17
196

View Slide

2-
Cost of Threads
• Threads are often considered expensive
• Somewhat true, but the actual overhead
tends to be overblown (especially in blog
posts and rants about threads)
197

View Slide

2-
Under the Covers
198
• Operating systems know how to deal with threads
• For I/O waiting, it's highly optimized
s1
s2
sockets
OS Kernel
thr1
thr2 thr3
wait queues
thr thr thr
ready queue
thr
running
recv
data
• Basically a scheduler and a bunch of queues
• Waiting/waking are just queue operations
recv()

View Slide

2-
Context Switching
199
• Each time the system switches threads, it performs
a "context-switch."
• Saves CPU state (registers, etc.)
• Might ﬂush CPU cache, TLB, etc.
• Actual behavior depends on system
• However: excessive context switching is bad
• Biggest killer of thread performance? (maybe)

View Slide

2-
Impact on Messaging
200
• Context-switching overhead is a practical concern
for threading based on messaging
• Does every message sent involve a context-switch
from the sender to the receiver for processing?
• Or do messages get queued up for awhile
• What happens during rapid messaging?
• Requires detailed study and performance analysis

View Slide

2-
Rapid Messaging
201
• Tasks that send messages at a high frequency,
should be modiﬁed to group messages
Producer Consumer
messages
Producer Consumer
grouped messages
• Results in fewer actual send() calls, less locking,
less context switching, etc.

View Slide

2-
I/O Considerations
202
• Every I/O operation also involves a potential
context switch because the GIL is released
• For best performance : Threads should perform a
small number of large I/O operations instead of a
large number of small I/O operations (buffering)
• Example : It's better to write a single 1Mb message
to a socket than 1024 1K messages.
• Make the operating system work for you...

View Slide

2-
I/O Performance
203
• Don't send a bunch of small fragments
while expression:
...
s.sendall(fragment)
...
• Use buffering and a single send
msgbuf = bytearray()
while expression:
...
msgbuf.extend(fragment)
...
s.sendall(msgbuf)
• Will greatly reduce system overhead, amount of
thread switching, locking, etc.

View Slide

2-
Thread Memory Use
• Each thread gets its own C stack
204
t1 = Thread()
t1.start()
t2 = Thread()
t2.start()
t3 = Thread()
t3.start()
virtual memory
thread 1
(8MB)
thread 2
(8MB)
thread 3
(8MB)
main
thread
...
...
Heap
• The size is determined
by the system (Python
uses the default settings)
• Creating many threads
may quickly eat up the
VM address space
stack

View Slide

2-
Thread Stack Space
• Thread stack size can be adjusted
205
import threading
threading.stack_size(65536)
t1 = threading.Thread(...)
t2 = threading.Thread(...)
• Must be a 4K multiple, minimum is 32K
• 32K is adequate for a lot of Python code
• Each function call < 512 bytes of stack
• Might need more for C extensions (if too
small, may get a violent crash - SegFault)

View Slide

2-
Performance Thoughts
206
"The best performance optimization is the transition
from the non-working to the working state."
-- John Ousterhout
• If you are going to program with threads,
correctness and reliability must have higher
priority than all other concerns
• You can optimize it later
• There are other ways to scale things up

View Slide

2-
Final Comments
207
• Threads are very useful for certain kinds of
problems involving I/O, waiting, etc.
• In some cases, they're the best choice
• In other cases, they're terrible
• And sometimes, they're the only way

View Slide

2-
Final Comments
208
• We've covered a lot of ground
• Threads/Tasks
• Various design patterns
• Messaging idioms
• Performance considerations
• All of this forms the foundation for other
topics (processes, distributed computing, etc.)

View Slide

2-
Final Final Comments
209
• If you're going to use threads, keep them
hidden in the background
• Don't make end-users mess around with them
• Observe: In our task library, end-user task
classes don't do anything with threads (they
receive messages, but details are hidden)
• Again: Encapsulation is key

View Slide

3-
Multiprocessing
1
Section 3

View Slide

3-
Introduction
• As you know, Python has a global interpreter
lock (GIL) that limits thread performance
• It means that you can only utilize a single
CPU within any given program
• In this section, we look at a workaround--
carrying out work in a subprocess
2

View Slide

3-
Concept : Process
• Each running program is a "process"
• Executes independently
• Has own memory
• Has own resources (ﬁles, sockets, etc.)
• Can be scheduled on different CPUs by OS
• Each instance of the Python interpreter that
runs on your system is a process
3

View Slide

3-
Cooperating Processes
• For CPU-intensive work, a common strategy is
to use cooperating processes
4
python
(master)
python
(worker)
python
(worker)
• Multiple copies of the python interpreter that run
on different CPUs and exchange data
• Not networking (all on the same machine)
CPU 1
CPU 2

View Slide

3-
Commentary
• Our thread-based programs were strongly tied
to this kind of design (messaging, queues, etc.)
• That was intentional
• Threads have known scalability problems as
problems and systems get large
• To solve that, you are almost forced to move to
processes (and later distributed systems)
• This is a universal problem--not just Python
5

View Slide

3-
multiprocessing Module
• A standard library module for carrying out
work in separate processes
• Can be used to distribute work to other
CPUs and to take advantage of multiple cores
• Also has some distributed computing features
(to be covered a little later)
6

View Slide

3-
Process Pools
• A process-based worker pool
7
p = Process(target=somefunc)
p = multiprocessing.Pool([numprocesses])
• This is the main feature you should use
• It executes functions in a subprocess
• It's very high-level (you don't need to worry a
lot about internal details)

View Slide

3-
Process Pools
• Core pool operations
8
p = multiprocessing.Pool([numprocesses])
p.apply(func [, args [, kwargs]])
p.apply_async(func [, args [, kwargs [, callback]]])
p.map(func, [, iterable [, chunksize]])
• There are some others, but these are
enough to get started
• Let's see some examples

View Slide

3-
Pool apply()
• Running a function in another process
9
def add(x,y):
return x+y
if __name__ == '__main__':
p = Pool(2)
r = p.apply(add,(2,3))
print(r)
• apply() runs a function in one of the
worker processes and returns the result
• Note: It waits for the result to come back

View Slide

3-
apply() Illustrated
• Suppose you have a lot of threads
10
Thread 1
Thread 2
Thread 3
Thread 4
• If they're all I/O bound, life is good
• Mostly they sleep, hardly any GIL contention

View Slide

3-
apply() Illustrated
• Now suppose a thread wants to do work
11
Thread 1
Thread 2
Thread 3
Thread 4
CPU-bound processing
• Thread holds GIL
• Causes contention with other threads
GIL contention

View Slide

3-
apply() Illustrated
• Delegating work to a pool
12
Thread 1
Thread 2
Thread 3
Thread 4
CPU-bound processing
Pool
apply() result
• Pool is separate process. No GIL
waiting

View Slide

3-
Pool apply_async()
• Asynchronous execution
13
def add(x,y):
return x+y
if __name__ == '__main__':
p = Pool(2)
r = p.apply_async(add,(2,3))
# Other work
...
# Collect the result at a later time
print(r.get())
• Here, you get a handle to an object for
retrieving the result at some later time (like
a future result)

View Slide

3-
Async Results
• For asynchronous execution, you get a
special AsyncResult object
• Here is a mini reference on it
14
a.get([timeout]) # Get the result
a.ready() # Result ready?
a.successful() # Completed without errors
a.wait([timeout]) # Wait for result
• get() is the most useful method, but there
are other operations for polling, querying
error status, etc.

View Slide

3-
apply_async() Callbacks
• Asynchronous execution with callback
15
def add(x,y):
return x+y
def gotresult(result):
print(result)
if __name__ == '__main__':
p = Pool(2)
r = p.apply_async(add,(2,3),callback=gotresult)
• Here, a callback function ﬁres when the
result is received

View Slide

3-
apply_async() Illustrated
• Used to initiate parallel computation
16
Thread
Pool
apply_async()
• Thread initiates multiple operations
• Collects results later
results

View Slide

3-
apply() vs apply_async()
• Usage depends on the context
• Use pool.apply() if you're using a pool to do
work on behalf of a thread (and there are a
lot of threads)
• Use pool.apply_async() if there's only one
execution thread and it's trying to farm out
work to multiple workers at once
17

View Slide

3-
Pool map()
• pool.map() - Maps a function onto a sequence
18
def square(x):
return x*x
if __name__ == '__main__':
p = Pool(2)
nums = range(1000)
squares = p.map(square,nums,100)
• This subdivides a sequence into chunks and
farms out work to the pool workers
p1 p2
result
input
pool workers

View Slide

3-
Pool map()
• pool.map() is similar to a list comprehension
19
def square(x):
return x*x
# Compute [x*x for x in nums]
nums = range(1000)
squares = p.map(square,nums)
• Restrictions:
• Mapped function must be module-level
• No lambda
• No instance methods (won't work)

View Slide

3-
Exercise process.1
20

View Slide

3-
Some Technicalities
• Pool workload
• Pool creation and startup
• Pool termination
• Long-term execution/reliability
21

View Slide

3-
Pool Workload
• To effectively use a process pool, you need to
make sure enough work gets carried out to
recover the cost of communication
• So, you probably wouldn't do it for just
simple operations like adding two numbers
• Likewise, you may not want to send massive
amounts of data back and forth
22

View Slide

3-
Pool Creation
• Pools should only be created by the main
thread of an application
• If created at script-level, must be protected
by a __main__ check
23
if __name__ == '__main__':
p = Pool()
...
• If you forget, may get in a recursive process
creation loop (e.g., fork-bomb) on Windows

View Slide

3-
Pool Shutdown
• To be nice, you should shut down pools
24
p.close() # Indicate no further work
p.join() # Wait for all pending work to finish
• Do this at program termination
• To immediately kill
p.terminate()

View Slide

3-
Pools and Shared State
• Every worker in a process pool is completely
isolated (no sharing)
• They do not have access to any state in the
master process that created the pool
• This is the complete opposite of threads
25

View Slide

3-
Pool Startup
• Pools have an initialization option for startup
26
def my_init(a,b,c):
# Initialize myself
...
if __name__ == '__main__':
p = Pool(initializer=my_init, initargs=(1,2,3))
...
• This is the only safe way to initialize the state
of worker processes in a pool
• It is not safe to rely upon the values of global
variables set prior to pool creation

View Slide

3-
A Unix Caution
• Pool workers will share any open ﬁles or
sockets that were in use at Pool creation
• You might want this
• You might not
• Could cause "unexplicable" system behavior
related to resource management (e.g., ﬁles
not being closed correctly, etc.)
27

View Slide

3-
Pools and Threads
28
• Pools should be created before threads
• Created immediately at program startup
• Before any other threads are running
• Do not create/launch pools within threads
• It might "work", but you'll be on weak ground

View Slide

3-
Using Process Pools
• How to add to your application?
• Best advice: Create a single pool at
application startup and use it everywhere
you want to do work in a subprocess
29
application
task1
task3
task2
task4
pool
subprocess
subprocess
subprocess
subprocess

View Slide

3-
Process Pool Example
• Pool is then used as needed
• For example, in a task-thread
30
class MyTask(Task):
def run(self):
while True:
msg = self.recv()
...
# Go run some CPU-intensive function
r = pool.apply(some_func,arg)
# Process the result
...
• The pool is just a utility that tasks use when
they they're going to do expensive work

View Slide

3-
Process Pool Tips
• Some other good rules of thumb
• Functions should not depend on global
state and have no side effects
• Passed arguments should only consist
of simple data structures (strings,
nums, tuples, lists, dicts, etc.).
• Also: No instance methods allowed
31

View Slide

3-
Pools and Instance Methods
• An example:
32
pool = Pool()
# Does this make any sense?
items = []
pool.apply(items.append,123)
• If you think about it long enough, you'll
realize that it's nonsense (would have to
send the whole instance and any
modiﬁcations would be lost)
• Anyways, it's not allowed (get exception)

View Slide

3-
Exercise process.2
33

View Slide

3-
Processes
• The fundamental building block used by
multiprocessing is the Process object
• It's pretty low-level, but its interface mimics
threads
• Allows you to launch a speciﬁc python function
inside a subprocess
34

View Slide

3-
Functions as Processes
• Launching a function in a process
def countdown(count):
while count > 0:
print "Counting down", count
count -= 1
time.sleep(5)
if __name__ == '__main__':
p1 = multiprocessing.Process(target=countdown,
args=(10,))
p1.start()
• You create a Process object
• Use start() to launch it
35

View Slide

3-
multiprocessing Example
• Deﬁning a process by a class
import time
import multiprocessing
class CountdownProcess(multiprocessing.Process):
multiprocessing. Process.__init__(self)
self.count = count
def run(self):
print "Counting down", self.count
self.count -= 1
time.sleep(5)
return
if __name__ == '__main__':
p1 = CountdownProcess(10) # Create the process object
p1.start() # Launch the process
36

View Slide

3-
Other Process Features
• Joining a process (waits for termination)
p.start()
...
p.join()
• Making a daemonic process
37
p.daemon = True
p.start()
• Terminating a process
...
p.terminate()
• These mirror similar thread functions

View Slide

3-
Commentary
• Launching processes is really easy
• Correct use of processes is hard
• Partly due to platform differences
• Also due to the means of process creation
• Too many layers of abstraction?
38

View Slide

3-
Process Creation
• In order create a new process, multiprocessing
carries out a process "fork"
• A clone of the calling process is created
p1 = Process()
p1.start()
39
python
python python
fork()
parallel
execution
• The clone is identical to the original process

View Slide

3-
Process Forking on Unix
• Processes are created using os.fork()
• Child process is identical to parent
• Same state (e.g., variables, instances)
• Same open ﬁles
• Same open sockets
• All threads except the caller are discarded
• Assume that the worker gets the entire state of
the parent process (sans threads)
40

View Slide

3-
Windows Forking
• Windows has no such OS feature
• Process creation on windows
• A new Python process is created, and the
process arguments are pickled across a pipe
connecting the two processes
• The startup time is horrible (vs. Unix)
• Can not rely on any sharing
• Assume that the worker only gets the
parameters passed to it
41

View Slide

3-
Process Coordination
• Multiprocessing provides large assortment of
primitives for coordinating and communicating
with low-level processes
• Queue, JoinableQueue, Pipe, etc.
• Lock, Rlock, Semaphore, Event, Condition
• Shared memory objects, etc.
• My advice: Don't bother (seriously)
42

View Slide

3-
Queue Example
• A consumer process
43
def consumer(input_q):
while True:
# Get an item from the queue
item = input_q.get()
# Process item
print(item)
• A producer process
def producer(output_q):
while not done:
# Produce some item
...
# Put on the output queue
output_q.put(item)

View Slide

3-
Queue Example
• Running the two processes
44
if __name__ == '__main__':
from multiprocessing import Process, Queue
q = Queue()
# Launch the consumer process
cons_p = Process(target=consumer,args=(q,))
cons_p.daemon = True
cons_p.start()
# Run the producer function on some data
producer(q)

View Slide

3-
Final Comments
• Multiprocessing serves a very speciﬁc purpose
• If your system has multiple CPUs/cores, then
pools can be used to take advantage of them
• Advice : Do not use Process objects as the
foundation for building a concurrent programming
framework (like we did for threads)
• Too many mind-boggling problems related to the
reliable use of process forking and environment
45

View Slide

3-
Exercise process.3
46

View Slide

4-
Event Driven I/O
(a.k.a. Async)
1
Section 4

View Slide

4-
Introduction
• Many programs are heavily based on I/O
• For example, network servers
• Due to thread issues, some programmers have
turned to alternative concurrency approaches
• Usually based on event-driven programming
2

View Slide

4-
Goal
• Cover some basic I/O concepts
• Discuss event-driven approach
• Call attention to problems and limitations
3

View Slide

4-
I/O Basics
• I/O is a fundamental part of most programs
• However, there are many different
programming models for carrying it out
• Blocking
• Nonblocking
• Polling/multiplexing ("async")
4

View Slide

4-
Blocking I/O
• If an I/O operation (e.g., read or write) does
not return until the operation actually
completes, the operation is said to "block."
• Example : s.recv() on a network socket
• Normally, this operation temporarily stops
your program and waits until some kind of data
is available to be read
• This is the normal programming model 99% of
programmers know about
5

View Slide

4-
Blocking I/O
• Underneath the covers, blocking I/O is tied to
the underlying operating system and buffering
• Every ﬁle descriptor (ﬁle, socket, etc.) has
some internal memory buffers
6
send
recv
in out
OS Kernel
Python
send
recv
in out
buffers
s1 s2

View Slide

4-
Blocking I/O
• The decision to block is entirely based on the
buffer contents
• Empty buffers (recv) or full buffers (send)
7
send
recv
in out
OS Kernel
Python
send
recv
in out
blocked sender
(no buffer space)
s1 s2
blocked
receiver
(no data)

View Slide

4-
Blocking I/O Rules
• Reading : If buffered data is available, return it.
Otherwise block until data becomes available.
• Writing : If buffer space is available, store
output data in the buffer. If no more space is
available, block until space becomes available
• The buffering aspect of this is essential
• Tuned to deal with mismatch between CPU
speed and speed of I/O devices
8

View Slide

4-
Caution : Partial Sends
• In network programs, send() often only sends
the number of bytes that will actually ﬁt into
the system buffers
• If writing low-level code, you have to check for
this and use repeated sends for all data
9
s = socket(AF_INET, SOCK_STREAM)
...
index = 0
while index < len(msg):
index += s.send(msg[index:])
...
• Alternative: Use s.sendall(data)

View Slide

4-
Socket Tuning Parameters
• The amount of buffer space can often be tuned
10
s = some socket
# Set the receive buffer size
s.setsockopt(SOL_SOCKET, SO_RCVBUF, 65536)
# Set the send buffer size
s.setsockopt(SOL_SOCKET, SO_SNDBUF, 65536)
• By changing these, you might be able to improve
network performance, ﬂow control, etc.
• There are other TCP tuning parameters (see
documentation for setsockopt)

View Slide

4-
Non-blocking I/O
• An alternative I/O model that changes the
behavior of I/O waiting
• If an I/O operation would have blocked, the
operation returns immediately with a raised
exception instead of waiting
11

View Slide

4-
Non-blocking Sockets
• Example of setting up non-blocking socket I/O
12
from socket import *
s = socket(AF_INET, SOCK_STREAM)
s.bind(("",15000))
s.listen(5)
# Wait for a connection
c,a = s.accept()
# Turn on nonblocking mode on client connection
c.setblocking(False)
• Now, try to read from it
>>> c.recv(8192)
File "", line 1, in
socket.error: [Errno 35] Resource temporarily unavailable
>>>

View Slide

4-
Non-blocking Exceptions
• Catching a non-blocking error
13
import errno
try:
data = s.recv(8192)
...
except socket.error as e:
if e.errno == errno.EWOULDBLOCK:
# Would have blocked
...
else:
# Some other socket error
...
• It can get messy fast

View Slide

4-
Using Non-blocking I/O
• Non-blocking I/O is useful if you're trying to
overlap I/O with other kinds of processing
• Achieving a kind of concurrency between I/O
operations and other computation
• It offers a guarantee that an I/O operation won't
cause your program to get "stuck."
• It's heavily used in some network programming
frameworks (especially those based on event
handling, generators, and coroutines).
14

View Slide

4-
Exercise io.1
15

View Slide

4-
I/O Polling/Multiplexing
• Polling - An approach where you manually
check for I/O activity and respond to it
• Typically associated with event-loops
16
while True:
...
processing
...
if poll_for_io():
process I/O
...
...
processing
• For example, a program might check for I/O
activity every few milliseconds

View Slide

4-
select module
• Used to support polling
• Provides interfaces to the following
• select() - Unix and Windows
• poll() - Unix
• epoll() - Linux
• kqueue() - BSD
• kevent() - BSD
17

View Slide

4-
select() function
• Used for I/O multiplexing/polling
• Usage : select(rset,wset,eset [,timeout])
18
readers = [...] # sockets waiting to read
writers = [...] # sockets waiting to write
exc = [...] # sockets to check for exceptions
rset,wset,eset = select(readers,writers,exc)
for r in rset: # Handle readers
handle_read(r)
for w in wset: # Handle writers
handle_write(w)
for e in eset: # Handle exceptions
handle_exception(e)

View Slide

4-
select() function
• You just give select() sets of all sockets/ﬁle
descriptors of interest
• select() then returns the sets of descriptors
on which different actions can be performed
• read - Data is available in read-buffer
• write - Buffer space is available
• exception - An exceptional condition
(meaning depends on the kind of ﬁle)
19

View Slide

4-
select() function
• select() blocks until some activity is detected
• There is an optional timeout parameter
• Use the timeout if some other processing is
going on at the same time
• For example, if I/O polling is also embedded
inside a GUI event loop
20

View Slide

4-
select() Limitations
• There is often an OS limit of 1024 ﬁles
• This limits the number of sockets/ﬁles that
can be monitored by a single select()
• Performance is O(n), n is # sockets
• Causes scalability issues as n gets large
• There are workarounds for both issues, but
they aren't cross platform and you'll need to
experiment (e.g., poll(), epoll(), etc.)
21

View Slide

4-
Exercise io.2
22

View Slide

4-
Event Driven I/O
• Can use select() to build event-driven systems
• The underlying idea is actually pretty simple
• You monitor a collection of I/O streams and
create a stream of "events" that put pushed
into callback or handler functions
23

View Slide

4-
Event Driven I/O
• First deﬁne a handler base class
24
class IOHandler:
# Method to return a file descriptor
def fileno(self):
pass
# Reading
def readable(self):
return False
def handle_read(self):
pass
# Writing
def writable(self):
return False
def handle_write(self):
pass

View Slide

4-
Event Driven I/O
• Next, write an I/O event dispatcher using polling
25
class EventDispatcher:
def __init__(self):
self.handlers = set()
def register(self,handler):
self.handlers.add(handler)
def unregister(self,handler):
self.handlers.remove(handler)
def run(self,timeout=None):
while self.handlers:
readers = [h for h in self.handlers
if h.readable()]
writers = [h for h in self.handlers
if h.writable()]
rset,wset,e = select(readers,writers,[],timeout)
for r in rset:
r.handle_read()
for w in wset:
w.handle_write()

View Slide

4-
Event Driven I/O
• Event handler registration
26
def __init__(self):
if h.readable()]
if h.writable()]
for r in rset:
r.handle_read()
for w in wset:
w.handle_write()
Registration and
management of
event handlers

View Slide

4-
Event Driven I/O
• Collecting handler read/write status
27
def __init__(self):
if h.readable()]
if h.writable()]
for r in rset:
r.handle_read()
for w in wset:
w.handle_write()
Collect all of the
sockets that want
to read or write

View Slide

4-
Event Driven I/O
• Polling for activity handlers that want I/O
28
def __init__(self):
if h.readable()]
if h.writable()]
for r in rset:
r.handle_read()
for w in wset:
w.handle_write()
poll

View Slide

4-
Event Driven I/O
• Invocation of I/O callback methods
29
def __init__(self):
if h.readable()]
if h.writable()]
for r in rset:
r.handle_read()
for w in wset:
w.handle_write()
invoke handlers
for sockets that
can read/write

View Slide

4-
Event Driven "Tasks"
• In this framework, applications get implemented
as IOHandler objects wrapped around a
specific file or socket object
30
class SomeHandler(IOHandler):
def __init__(self,sock):
self.sock = sock
...
def fileno(self):
return self.sock.fileno()
• The internals don't really matter, but there must
be a fileno() method to supply a file descriptor
to select()/poll() operations

View Slide

4-
• Tasks must keep internal state that determines
if they are interested in reading or writing
31
def __init__(self,sock):
...
self.wants_to_read = True
self.wants_to_write = False
...
def readable(self):
return self.wants_to_read
def writable(self):
return self.wants_to_write
...
• These methods tell the polling loop what events
it should be looking for at any given time

View Slide

4-
• Tasks must deﬁne methods to actually handle
read/write events
32
...
...
data = self.sock.recv(8192)
...
...
self.sock.send(somedata)
...
• These methods only get called if the event loop
has received some kind of matching event

View Slide

4-
Multitasking
• To run multiple tasks, you just register multiple
handlers with the event loop and run its main
event loop
33
dispatcher = EventDispatcher()
dispatcher.register(SomeHandler(s1)) # s1 is a socket
dispatcher.register(SomeHandler(s2)) # s2 is a socket
...
dispatcher.run()
• In theory, this set up allows your program to
monitor multiple network connections

View Slide

4-
Example : Time Handler
• Here is a very simple UDP time handler
34
from socket import *
import time
class TimeHandler(IOHandler):
def __init__(self,address):
self.sock = socket(AF_INET, SOCK_DGRAM)
self.sock.bind(address)
def fileno(self):
def readable(self):
return True
msg,addr = self.sock.recvfrom(8192)
resp = time.ctime().encode('ascii')
self.sock.sendto(resp,addr)

View Slide

4-
Example : Time Handler
• How to run it
35
dispatcher.register(TimeHandler(('',10000)))
dispatcher.run()
• How to test it
>>> from socket import *
>>> s = socket(AF_INET, SOCK_DGRAM)
>>> s.sendto(b"",("localhost",10000))
>>> s.recvfrom(8192)
(b'Thu Dec 23 10:52:07 2010', ('127.0.0.1', 10000))
>>>

View Slide

4-
Exercise io.3
36

View Slide

4-
A Complication
• How to handle streaming connections?
• Many network applications have long-lived
network connections and bidirectional data
transmission (TCP)
• Further complication: Each connection request
creates a new socket to manage
37

View Slide

4-
Solution
• To handle long-lived connections, you deﬁne a
IOHandler just for the client connection
• Handler instances are then dynamically added
and removed from the event dispatcher as
connections are opened and closed
• Added when a new connection is received
• Removed when a connection is closed
38

View Slide

4-
Example : Echo Client
39
class EchoClientHandler(IOHandler):
def __init__(self,sock,addr,dispatcher):
self.sock = sock
self.dispatcher = dispatcher
self.outgoing = bytearray()
self.closed = False
self.dispatcher.register(self)
def fileno(self):
def readable(self):
return not self.closed
msg = self.sock.recv(65536)
if not msg:
self.closed = True # Closed
if not self.outgoing:
self.dispatcher.unregister(self)
self.close()
else:
self.outgoing.extend(msg)
Read handlers get data
and save it in an
outgoing data buffer
Handle client
shutdown

View Slide

4-
Example : Echo Client
40
class EchoClientHandler(IOHandler):
def __init__(self,sock,addr,dispatcher):
self.sock = sock
self.outgoing = bytearray()
self.closed = False
...
def writable(self):
return True if self.outgoing else False
nsent = self.sock.send(self.outgoing)
self.outgoing = self.outgoing[nsent:]
if not self.outgoing and self.closed:
self.dispatcher.unregister(self)
self.sock.close()
Write handler
sends as much
outgoing data as it
can
Handle client
shutdown

View Slide

4-
Creating Servers
• The handler class we just deﬁned is for already
established connections.
• Still need to plug it into some kind of server
• Recall : This is a traditional TCP server
41
sock = socket(AF_INET, SOCK_STREAM)
sock.bind(address)
sock.listen(5)
while True:
client, addr = sock.accept()
# Go handle the client
• Need to have an event-driven version

View Slide

4-
Example : TCP Server
• Event-driven server for accepting connections
42
class TCPServerHandler(IOHandler):
def __init__(self,address,handler,dispatcher):
self.handler = handler
self.sock = socket(AF_INET, SOCK_STREAM)
self.sock.setsockopt(SOL_SOCKET, SO_REUSEADDR,1)
self.sock.listen(5)
self.sock.setblocking(False)
def fileno(self):
def readable(self):
return True
c,a = self.sock.accept()
self.handler(c,addr,self.dispatcher)

View Slide

4-
Example : TCP Server
43
This is the key part. On
each new connection, a
new client handler is
created and added to
the dispatcher
class TCPServerHandler(IOHandler):
def __init__(self,address,handler,dispatcher):
self.handler = handler
self.sock = socket(AF_INET, SOCK_STREAM)
self.sock.setsockopt(SOL_SOCKET, SO_REUSEADDR,1)
self.sock.listen(5)
self.sock.setblocking(False)
def fileno(self):
def readable(self):
return True
c,a = self.sock.accept()
self.handler(c,addr,self.dispatcher)
• Event-driven server for accepting connections
Triggered on
each new
connection

View Slide

4-
Example : Echo Server
• Running the server
44
serv = TCPServerHandler(('',20000),
EchoClientHandler,
dispatcher)
dispatcher.run()
• If it works, you'll be able to open up multiple
connections and interact with it
• Assuming your head hasn't exploded

View Slide

4-
Exercise io.4
45

View Slide

4-
Commentary
• The overall concept underlying the last example
is the basis for the much misunderstood (or
maligned?) asyncore library module
• Also the basis for the Twisted framework
• As you will observe, the resulting programs can
respond to multiple I/O channels without
threads or processes
46

View Slide

4-
Events and Asyncore
• asyncore standard library module
• Implements a wrapper around sockets that
turn all blocking I/O operations into events
47
s = socket(...)
s.accept()
s.connect(addr)
s.recv(maxbytes)
s.send(msg)
...
from asyncore import dispatcher
class MyApp(dispatcher):
def handle_accept(self):
...
def handle_connect(self):
...
...
...
# Create a socket and wrap it
s = MyApp(socket())

View Slide

4-
Using Asyncore
• You manipulate wrapped sockets that operate
both as normal sockets and as event dispatchers
• The general idea is the same as what we just
covered so I won't go into more detail here
• "Python Essential Reference, 4th Ed." has some
detailed examples of using asyncore and the
related asynchat module
48

View Slide

4-
Twisted
49
• A large event-driven framework built around
I/O polling and multiplexing concepts
http://twistedmatrix.com
• It's similar to what you would get if you
started with asyncore and then built the entire
universe on top of it using nothing but event
handlers and callbacks

View Slide

4-
Twisted Example
50
• Here is an echo server in Twisted (straight
from the manual)
from twisted.internet.protocol import Protocol, Factory
from twisted.internet import reactor
class Echo(Protocol):
def dataReceived(self, data):
self.transport.write(data)
def main():
f = Factory()
f.protocol = Echo
reactor.listenTCP(45000, f)
reactor.run()
if __name__ == '__main__':
main()
An event callback
Running the event loop

View Slide

4-
Event Driven Issues
51
• All event-driven I/O systems have a variety of
really tricky programming issues
• Scalability
• Long-running calculations
• Blocking operations
• Interoperability with other code
• Let's brieﬂy discuss

View Slide

4-
Scaling Problems
52
• Event-driven I/O is often based on polling
mechanisms such as select() or poll()
• Both of those operations scale rather poorly
as the number of monitored objects increases
• So, as the number of clients increases, more
and more time is going to be spent performing
the poll operation
• A real issue if there is rapid messaging
(although solvable in a non-portable manner)

View Slide

4-
A Scaling Benefit
53
• One benefit of event-driven I/O is that it has
predictable resource use (especially memory)
• Reduced context-switching (?)
• Having thousands of open files/sockets doesn't
really consume any significant memory
• Unlike threads, you don't have to allocate
extra stack space and other resources

View Slide

4-
Long-Running Calculations
54
• If an event handler runs a long calculation, it
blocks everything until it completes
• Example : Parsing a large XML message
• Remember, there are no threads or preemption
• This would manifest itself as program "stall".
You've probably seen this with GUIs.

View Slide

4-
Blocking Operations
55
• Event-driven systems also have a really hard
time dealing with blocking operations
• Reading from the ﬁle system
• Performing database queries
• Connecting to other services
• If any of these operations take place in an
event handler, the entire server/application
stalls until it completes (no threads)

View Slide

4- 56
Blocking Illustrated

View Slide

4-
The Blocking Problem
57
• Consider this code...
class ApplicationHandler(object):
...
def handle_request(self):
...
results = db.execute("select * from table where ...")
for r in results:
...
A database query
(blocks?)
• Everything waits until the callback method
ﬁnishes its execution
• An issue if it happens to take a long time
Processing of the
results (CPU-intensive?)

View Slide

4-
Using Threads
58
• Blocking operations might be handed to a
separate thread/process to avoid stalling
...
...
launch_thread(do_query,
"select * from table where ...")
• But there is the tricky of problem of
coordinating what happens upon completion

View Slide

4-
Using Threads
59
• Common approach: Completion Callback
...
...
launch_thread(do_query,
"select * from table where ...",
callback=self.process_results)
def process_results(self,results):
...
continued processing
• Behind the scenes, system will run the
operation in a separate thread, collect the
result, coordinate with the event-handling
framework, and then ﬁre the callback

View Slide

4-
Exercise io.5
60

View Slide

4-
Workers and Polling
61
• Commentary: Coordinating workers and I/O
polling is a lot trickier than it looks
select()
Event Loop Worker Thread
select()
launch thread
Event Loop
result
callback(result)
What happens here?

View Slide

4-
Workers and Polling
62
• Problem: select() only works with sockets
• Workers utilize queues, messaging, other means
Event Loop
sockets queues
select()
???
• Question: How do you make this work?

View Slide

4-
Selectable Queues
63
• Common approach: Attach a loopback socket
Event Loop
• Sample code (ugly, but portable)
queue
getsocket
putsocket
connected
select listens on
# Create a pair of connected sockets
server = socket(AF_INET, SOCK_STREAM)
server.bind(('127.0.0.1', 0))
server.listen(1)
putsocket = socket(AF_INET,SOCK_STREAM)
putsocket.connect(server.getsockname())
getsocket, _ = server.accept()
server.close()

View Slide

4-
Selectable Queues
64
Event Loop
• Add internal I/O to get/put operations
class SelectableQueue(queue.Queue):
def __init__(self):
super().__init__()
# Set up the connected sockets
...
def put(self,item):
super().put(item)
self.putsocket.send(b"x")
def get(self):
self.getsocket.recv(1)
return super().get()
def fileno(self):
return self.getsocket.fileno()
key idea:
puts do I/O for
triggering select()

View Slide

4-
Interoperability Problems
65
• Event-driven programming tends to force an
event-driven programming style across your
entire application program
• This includes all external libraries and
everything else used by your application
• However, most programming libraries are not
written in an event-driven style
• For instance, the entire standard library

View Slide

4-
Personal Bias
66
• I don't like event-driven I/O programming
• Applying it across a large application is a very
good way to create unmaintainable code that's
a maze of twisty little passages, all different.
• I put it in the same category as assembly code
(although not as easy to follow - sic)
• Okay to use it internally (in libraries), but
don't expose it to the rest of the world

View Slide

4-
Final Words
67
• Event-driven I/O is still useful is certain domains
• Programs that are already event-based (for
example GUI programs)
• Games
• Most normal network programs are better
served by using threads or processes
• Especially small-to-medium scale projects

View Slide

4-
Exercise io.6
68

View Slide

5-
Message Passing
and Serialization
1
Section 5

View Slide

5-
Concept: Message Passing
• Multiple independent copies of the Python
interpreter (or programs in other languages)
• Running in separate processes
• Possibly on different machines
• Sending/receiving messages
2

View Slide

5-
Commentary
• Message passing is a well-established
technique for concurrent programming
• It has been successfully scaled up to systems
involving tens of thousands of processors
(e.g., supercomputers, Linux clusters, etc.)
• The foundation of distributed computing
• We've already covered some basic ideas
3

View Slide

5-
Message Passing
4
Process Process
send() recv()
connection
• On the surface, it's really simple
• Processes only send and receive messages
• There are really only two main issues
• What is a message?
• How is it transported?

View Slide

5-
An Issue
• There is no universally accepted programming
interface or implementation of messaging
• There are dozens of different packages that
offer different features and options
• Covering every possible angle of message
passing interfaces is simply impossible here
• And a reference manual would be rather dull
5

View Slide

5-
Massive Complexity
• There are actually many other issues
• Reliability, redundancy, fault tolerance
• Security, authentication, encryption
• Performance (bandwidth, latency, load-
balancing, quality of service, etc.)
• Routing, network topology
• Interoperability, systems integration
• Messaging libraries are often a terror
6

View Slide

5-
Section Focus
• Our focus is going to be on general
programming idioms related to messaging
• This mostly concentrates on the boundary
between Python and the messaging layer
7
message transport
message library
Python
message library
Python
Our Focus
recv
send send
recv

View Slide

5-
What is a Message?
• Usually just a collection of bytes (a buffer)
• A "serialized" representation of some data
8

View Slide

5-
Message Encoding
9
• Messages have to be formatted or encoded
in some manner that enables transport
• To send, a message is encoded
• To receive, a message is decoded

View Slide

5-
Encoding Example
10
• A minimal encoding (size preﬁxed bytes)
size Message (bytes)
• Message is just bytes with a size header
• No interpretation of the bytes (opaque)
• So, payload could be anything at all (any
encoding, any programming language, etc.)

View Slide

5-
Message Transport
• Messages have to be transmitted (somehow)
between running processes
• Inter-Process Communication (IPC)
• Some low-level communication primitives
• Pipes
• FIFOs
• Sockets (Network Programming)
11

View Slide

5-
Pipes
• A ﬁle-like abstraction that allows a byte
stream to be transmitted across processes
• Perhaps the most portable way to set up a
pipe is to use the subprocess module
• A standard library module for launching
subprocesses that works cross-platform
12

View Slide

5-
An Example
• Launching a subprocess and hooking up the
child process via a pipe
• Use the subprocess module
13
import subprocess
p = subprocess.Popen(['python','child.py'],
stdin=subprocess.PIPE,
stdout=subprocess.PIPE)
p.stdin.write(data) # Send data to subprocess
p.stdout.read(size) # Read data from subprocess
Parent
p.stdin
p.stdout
Child
sys.stdin
sys.stdout
Pipe

View Slide

5-
Named Pipes/FIFOs
• It is also possible to set up a named pipe
• Creating (in Unix)
14
import os
os.mkfifo("/tmp/myfifo")
• Using in different processes
f = open("/tmp/myfifo","wb")
f.write("Some data\n")
f.flush()
f = open("/tmp/myfifo","rb")
line = f.readline()
Writer Reader
• Note : Not on Windows with this API

View Slide

5-
Sockets
• Setting up a listener
15
# Set up a listener
s = socket(AF_INET,SOCK_STREAM)
s.bind(("",12345)
s.listen(5)
c,a = s.accept()
• Connecting as a client
s.connect(("localhost",12345))

View Slide

5-
Exercise msg.1
16

View Slide

5-
High-Level Messaging
17
• There are many messaging frameworks
• AMQP
• ØMQ
• RabbitMQ
• Celery
• Common theme : Putting a higher-level interface
on top of sockets, pipes, etc.

View Slide

5-
Messaging Features
18
• Support for common messaging patterns
• Push/Pull (Queues)
• Request/Reply
• Publish/subscribe
• Reliability/scalability features
• Load balancing
• Durable connections

View Slide

5-
Example : ØMQ
19
• ZeroMQ (http://www.zeromq.org/)
• In a nutshell : Message-based sockets
• In their own words...
"A ØMQ socket is what you get when you take a normal TCP socket,
inject it with a mix of radioactive isotopes stolen from a secret Soviet
atomic research project, bombard it with 1950-era cosmic rays, and put
it into the hands of a drug-addled comic book author with a badly-
disguised fetish for bulging muscles clad in spandex."
• I would cautiously agree

View Slide

5-
Example : ØMQ
20
• Here's an example of an echo server:
• That's it
• And this server can already handle requests
from 100s (or 1000s) or connected clients
# echoserver.py
import zmq
context = zmq.Context()
sock = context.socket(zmq.REP)
sock.bind("tcp://*:6000")
while True:
message = sock.recv() # Get a message
sock.send(b"Hi:"+message) # Send a reply

View Slide

5-
Example : ØMQ
21
• Here's an example of a echo client
• That's also pretty simple (it just works)
# echoclient.py
import zmq
sock = context.socket(zmq.REQ)
sock.connect("tcp://localhost:6000")
sock.send(b"Spam") # Send a request
resp = sock.recv() # Get response
print(resp)

View Slide

5-
Example : ØMQ
22
• Some cool features
• Can start server or client in any order
• Clients can connect to multiple servers
(load balancing, redundancy, etc.)
• Variety of socket types (Reply, Request,
Push, Pull, Publish, Subscribe, etc.)

View Slide

5-
Example : ØMQ
23
• Example client connected to multiple servers
• Request gets sent to one of the servers
• Think about scaling, redundancy, etc.
import zmq
sock = context.socket(zmq.REQ)
sock.connect("tcp://host1.com:6000")
sock.send(b"Spam") # Send a request
resp = sock.recv() # Get response

View Slide

5-
Exercise msg.2
24

View Slide

5-
Security Concerns
25
• Messaging systems are meant to be used
internally, not exposed to end-users
Web
server
HTTP
"Mom"
Messaging
• Used by all of the back-end code--hidden
away in dark server rooms, etc.

View Slide

5-
Security Concerns
26
• As a general rule, you don't want internal
messaging to be exposed to the outside
• The usual techniques apply
• Firewalls
• Secure sockets (SSL)
• Digital certiﬁcates, public/private key
• VPNs

View Slide

5-
Message Authentication
27
• You may have situations where messaging
uses an exposed connection (e.g., allowing
anyone to connect if they know the right
address and port)
• For this, you probably want to have some
kind of authentication scheme
• Common approach : Use cryptographic hash
authentication (MD5, SHA, etc.)

View Slide

5-
Hashing Authentication
28
• Both endpoints pick a secret key/password
key = b"peekaboo" key = b"peekaboo"
• Just to emphasize--it's secret

View Slide

5-
Hashing Authentication
29
• Connection involves challenge/response
01ea7f6a72fae8129
client server
connect
challenge
make random bytes
compute hash
digest (with
secret key)
01ea7f6a72fae8129
compute hash
digest (with
secret key)
65aef25472
65aef25472
response
65aef25472
=
yes?
(authenticated)

View Slide

5-
hmac module
30
• Python has a library for helping (hmac)
import os
import hmac
key = b"peekaboo"
client, addr = sock.accept()
message = os.urandom(32)
client.send(message)
hash = hmac.new(key,message)
digest = hash.digest()
response = client.recv()
if digest == response:
# Authenticated
import hmac
key = b"peekaboo"
sock.connect()
message = sock.recv()
hash = hmac.new(key,message)
digest = hash.digest()
sock.send(digest)
Challenge (Server)
Response (Client)
• See IETF RFC 2104

View Slide

5-
Commentary
31
• This is only an authentication scheme
• Can be used to keep unwanted clients and
outsiders from establishing a connection to
the messaging framework
• Reasonably secure (based on difﬁculty of
breaking cryptographic hashes)
• It's not encryption. Messages themselves
could be seen by a packet sniffer, etc.
(although key is never transmitted)

View Slide

5-
Exercise msg.3
32

View Slide

5-
Object Serialization
33
• Serialization of Python objects
• pickle
• Serialization of foreign (binary) data
• struct

View Slide

5-
The Problem
34
• How to serialize Python objects?
• Lists, dictionaries, sets, instances, etc.
• An issue here is that Python is extremely
ﬂexible with respect to data types
• Containers can also hold mixed data
• There is no easy format for describing
Python objects (e.g., a simple array or by
ﬁxed binary data structures)

View Slide

5-
pickle Module
• A module for serializing Python objects
35
• Serializing an object onto a "file"
import pickle
...
pickle.dump(someobj,f)
• Unserializing an object from a file
someobj = pickle.load(f)
• Here, a file might be a file, a pipe, a wrapper
around a socket, etc.

View Slide

5-
pickle Compatibility
• What objects are compatible?
• Nearly any object that consists of data
• None, numbers, strings
• Tuples, lists, dicts, sets, etc.
• Instances of objects
• Functions and classes (tricky)
• The underlying message encoding is "self-
describing" (which hides a lot of details)
36

View Slide

5-
pickle Incompatibility
• Objects not compatible with pickle
• Anything involving system or runtime state
• Open ﬁles, sockets, etc.
• Threads
• Running generator functions
• Stack frames
• Closures
37

View Slide

5-
Pickling to Strings
• Pickle also creates byte strings
import pickle
# Convert to a string
s = pickle.dumps(someobj)
...
# Load from a string
someobj = pickle.loads(s)
• This can be used if you need to embed a
Python object into some other messaging
protocol or data encoding
38

View Slide

5-
Pickling Class Instances
• Pickle supports class instances
class Point:
def __init__(self,x,y):
self.x = x
self.y = y
• Example:
39
p = Point(23,24)
pickle.dump(p,f)
• Caveat: Class deﬁnition must be on receiver
• Advice : Don't send instances around in
messaging systems (too fragile)

View Slide

5-
Pickle and Large Objects
• Large objects can cause problems
• Depending on the object, pickle might make a
memory copy of the entire object (either
while sending or during reconstruction)
• Example: Arrays (array module)
40
import array
a = array.array('i',range(10000000))
...
pickle.dump(a,f) # Makes a memory copy (40MB)
• Better to split into smaller messages

View Slide

5-
Classes and Functions
• Functions and classes can be pickled, but they
are only name references
41
# foo.py
def bar(x,y):
return x+y
• Example of pickled data
>>> import pickle
>>> pickle.dumps(bar)
'cbar\nfoo\np0\n.'
>>>
• When unpickled, the name references are
resolved by importing the needed modules
Notice module and
function name

View Slide

5-
Pickle Security
• It's not secure at all
• Never use pickle with untrusted clients
(malformed pickles can be used to execute
arbitrary system commands)
• Bottom line : Never receive pickled data on
an untrusted or unauthenticated connection
42

View Slide

5-
Miscellaneous Comments
• Pickle is really only useful for Python
• Would not use if you need to communicate
to other programming languages
• However, you can do some pretty amazing
things with it if Python is your environment
• There is already built-in messaging support
43

View Slide

5-
Connection Objects
• multiprocessing provides Listener and Client
objects that transmit pickled data
• A Listener (receives connections)
44
from multiprocessing.connection import Listener
serv = Listener(('',15000),authkey='12345')
# Wait for a connection
client = serv.accept()
# Now, wait for messages to arrive
while True:
msg = client.recv()
# process the message

View Slide

5-
Connection Objects
• Example Client
45
from multiprocessing.connection import Client
conn = Client(('localhost',15000),authkey='12345')
conn.send(msg)
• You will notice a similarity to sockets
• Except that it's much higher level and it sends
pickled objects

View Slide

5-
Connection Objects
• Some important features of connections
• Authentication (uses HMAC, a technique
based on message digests such as SHA)
• Instead of bytes, you send Python objects
• Data is encoded using pickle
• Is extremely useful if you're just going to hook
two Python interpreters together
46

View Slide

5-
Exercise msg.4
47

View Slide

5-
Foreign Objects
• If dealing with C/C++ extensions or foreign
software (non-python), you often turn to
binary-encoded data
• Such software might transmit data in a binary
encoding of some sort
• If you know what you are using, you can bridge
Python to it as long as you speak the protocol
48

View Slide

5-
Binary Protocols
• There are some standard binary messaging
protocols in use
• Protocol Buffers (Google)
• Thrift (Facebook)
• BSON (MongoDB??)
• All of these have Python libraries and tools
• Under the covers, they have to deal with binary
data encoding/decoding
49

View Slide

5-
struct module
• Packs/unpacks binary records and structures
• Example: Suppose you had this structure
struct Stock {
char name[8];
int shares;
double price;
};
50
• Now, suppose you wanted to encode/
decode raw byte streams with that record?
name shares price
8 bytes 4 bytes 8 bytes

View Slide

5-
struct module
• First, create a Struct object
from struct import Struct
StockStruct = Struct("8sid")
51
• Structure is described by a "format string"
"8s" = char [8]
"i" = int
"d" = double
• To write the format string, you have to
precisely know what the structure is
• And you need to know the format codes...

View Slide

5-
struct module
• Packing/unpacking codes (based on C)
'c' char (1 byte string)
'b' signed char (8-bit integer)
'B' unsigned char (8-bit integer)
'h' short (16-bit integer)
'H' unsigned short (16-bit integer)
'i' int (32-bit integer)
'I' unsigned int (32-bit integer)
'l' long (32 or 64 bit integer)
'L' unsigned long (32 or 64 bit integer)
'q' long long (64 bit integer)
'Q' unsigned long long (64 bit integer)
'f' float (32 bit)
'd' double (64 bit)
's' char[] (String)
'p' char[] (String with 8-bit length)
'P' void * (Pointer)
52

View Slide

5-
struct module
• Each code may be preceded by a repetition
count
'4i' 4 integers
'20s' 20-byte string
• Integer alignment and byte order modifiers
'@' Native byte order and alignment
'=' Native byte order, standard alignment
''>' Big-endian, standard alignment
'!' Network (big-endian), standard align
• Only one modifier is allowed and it goes first
53
''!hi' Network order short and integer

View Slide

5-
Structure Alignment
• By default, structure ﬁelds are concatenated
together with no padding or alignment
'8sid'
• Be aware that this differs from C/C++
struct Stock {
char name[8];
int shares;
double price;
};
• Use '@' if native C alignment is needed
54
name shares price
8 bytes 4 bytes 8 bytes
name
shares
shares
price
0-7
8-15
16-23
unused
padding
StockStruct = Struct("@8sid")

View Slide

5-
Packing Binary Records
• Packing Python values into a byte string
stock = {
'name' : 'GOOG',
'shares' : 100,
'price' : 490.10
}
rawbytes = StockStruct.pack(stock['name'],
stock['shares'],
stock['price'])
>>> rawbytes
'GOOG\x00\x00\x00\x00d\x00\x00\x00\x9a\x99\x99\x99\x99\[email protected]'
55
• You do this if you're sending/writing

View Slide

5-
Unpacking Records
• Unpacking a byte string into a tuple
rawbytes = f.read(StockStruct.size)
name, shares, price = StockStruct.unpack(rawbytes)
stock = {
'name' : name.strip('\x00'),
'shares' : shares,
'price' : price
}
56
• You do this for reading/receiving
• If you need to create other datatypes
(dicts, instances), that's an extra step

View Slide

5-
Performance Tip
• struct has some module-level functions
57
struct.pack("8sid", "GOOG", 100, 490.10)
struct.unpack("8sid", rawbytes)
• They can be used without having to create a
special Struct object
• However, they don't run as fast because they
have to interpret the format each time
• Probably best avoided in code that is doing a
lot of packing/unpacking

View Slide

5-
struct Cautions
• Binary records are inherently "unportable"
• Great attention to detail is required
• Encoding can vary by platform (e.g., 32-bit vs.
64 bits)
• Still useful if you have control over the
environment and you know what you're doing
58

View Slide

5-
Exercise msg.5
59

View Slide

6-
Distributed Computing
1
Section 6

View Slide

6-
Introduction
• Independent systems, networks, and message
passing are the basis of distributed computing
• So far, we've covered some basic design
patterns and underlying mechanics
• Topics not yet covered : more advanced
messaging techniques
• Connecting to the outside world (foreign
systems, interoperability, etc.)
2

View Slide

6-
Major Topics
• More on messaging (actors, registries,
message brokers, etc.)
• Distributed data (key-value stores)
• Remote Procedure Call (RPC)
• Distributed Objects
• Interoperability, foreign systems, etc.
3

View Slide

6-
Tasks Revisited
• In the thread section, we deﬁned tasks that
received and acted upon messages sent to them
4
class MyTask(Task):
def run(self):
while True:
msg = self.recv() # Get a message
...
# Do something with it
...
m = MyTask()
m.start()
m.send(msg) # Send a task a message
• Formally: this is an example of an "actor"

View Slide

6-
Actors
• Many actors might work together
5
actor actor
actor
send()
send()
send()
• Again, independent tasks sending messages
actor
send()
send()

View Slide

6-
Features of Actors
• Some desirable characteristics
• No shared state (messages only)
• One operation : sending a message
• Messages are asynchronous
• Concurrent execution
• Again, we already built all of this
6

View Slide

6-
Why Study Actors?
• The programming model is very minimal
• Thus, you can understand it (maybe)
• There is a large body of theoretical knowledge
(computer scientists have been studying them
since the 1970s)
• Techniques involving actors are applicable to
more advanced scenarios
7

View Slide

6-
Exercise dist.1
8

View Slide

6-
Problem : Decoupling
• Consider an application built from a large
collection of independent actors/tasks
• How do the actors ﬁnd and link to each other?
• What happens if actors crash, restart, etc?
• As a general rule, you want decoupling
9

View Slide

6-
Tight Coupling
• Don't want: Actors programmed so that they
hold direct references to other actor instances
10
class Actor(Task):
def __init__(self,target):
self.target = target
def run(self):
...
self.target.send(msg)
...
• This results in a very rigid/fragile design
• Makes it nearly impossible to make
adjustments to the system organization
Actor
Actor
.target

View Slide

6-
Name Registry
• Better : Indirectly refer to actors through some
kind of naming registry
11
_registry = {}
def register(name, actor):
_registry[name] = actor
def unregister(name):
del _registry[name]
def lookup(name):
return _registry.get(name)
• Give all actors an identifying name
• Have them register/unregister as needed

View Slide

6-
Name Registry
• Registration of actors
12
register("spam", SpamActor())
register("foo", FooActor())
register("bar", BarActor())
• This is just building a centralized table
_registry = {
'spam' : ,
'foo' : ,
'bar' : ,
...
}

View Slide

6-
Redeﬁning send()
• Perform all messaging through a global function
that relies upon the registry
13
def send(target_name,msg):
target = lookup(target_name)
if target:
target.send(msg)
• All actors now always use the global send()
class Actor(Task):
def __init__(self,target_name):
self.target_name = target_name
def run(self):
...
send(self.target_name, msg)
...

View Slide

6-
Exercise dist.2
14

View Slide

6-
Distributed Actors
• To distribute actors, you additionally need to
have some kind of IPC/networking component
15
process 1 process 2
• You can use the earlier messaging techniques
• multiprocessing, ØMQ, etc.

View Slide

6-
Distributed Send
• To implement distributed actors, you must
focus on send() and actor names
16
local process
local
actors
remote process
remote
actors
"a"
"b"
"c"
"d"
"e"
"f"
"g"
send()
• Essentially, send() has to seamlessly work with
both local and remote actors

View Slide

6-
Proxy Actors
• Messages can be directed to a remote system
through the use of a proxy
17
local process remote process
remote
actors
"e"
"f"
"g"
send()
proxy
"e"
• A proxy receives messages for a remote actor
and forwards them to a remote process
"a"
proxy
"g"
send()

View Slide

6-
Proxy Implementation
• Implementing a proxy
18
class ProxyTask(Task):
def __init__(self,proxyname,target,conn):
super().__init__(name="proxy")
self.proxyname = proxyname
self.target = target
self.conn = conn
def run(self):
try:
while True:
msg = self.recv()
conn.send((self.target,msg))
finally:
unregister(self.proxyname)
• Receives messages and forwards them on
some kind of connection

View Slide

6-
Creating Proxies
19
• Create a utility function for it
from multiprocessing.connection import Client
def proxy(proxyname,target,address,authkey):
conn = Client(address,authkey=authkey)
pxy = ProxyTask(proxyname,target,conn)
pxy.start()
register(proxyname,pxy)
proxy("e","e",("localhost",15000),authkey=b"12345")
proxy("ext:f","f",("localhost",15000),authkey=b"12345")
# Send a message to a remote actor
send("e","hello world")
send("ext:f","hello world")
• Creates a connection using multiprocessing
and registers a proxy task to accept messages

View Slide

6-
Message Dispatching
• A dispatcher is needed to receive messages
20
local process
actors
"e"
"f"
"g"
• The dispatcher is a server that accepts
connections, receives messages, and forwards
them to the local actors
"a"
dispatch
proxy
"e"
proxy
"g"

View Slide

6-
Message Dispatcher
21
class DispatchClientTask(Task):
def __init__(self,conn):
super().__init__(name="dispatchclient")
self.conn = conn
def run(self):
try:
while True:
target,msg = self.conn.recv()
send(target,msg)
finally:
self.conn.close()
• First, you need a task that receives messages
from the proxy class
• It just takes messages from the connection and
sends them locally
message
handling

View Slide

6-
Message Dispatcher
22
from multiprocessing.connection import Listener
class DispatcherTask(Task):
def __init__(self,address,authkey):
super().__init__(name="dispatcher")
self.address = address
self.authkey = authkey
def run(self):
serv = Listener(self.address,authkey=self.authkey)
while True:
try:
client = serv.accept()
DispatchClientTask(client).start()
except Exception as e:
self.log.info("Error : %s", e, exc_info=True)
• Next, you need a server that accepts connections
• Launches a new client task each connection
connection
handling

View Slide

6-
Message Dispatcher
23
_dispatcher = None
def start_dispatcher(address,authkey):
global _dispatcher
if _dispatcher:
return
_dispatcher = DispatcherTask(address,authkey)
_dispatcher.start()
• Finally, a function to start the dispatcher
• Important point
• There is usually only one dispatcher
• A singleton

View Slide

6-
Using the Dispatcher
• You launch it and forget about it
24
start_dispatcher(("localhost",15000),authkey=b"12345")
• It operates entirely in the background and
doesn't interfere with other tasks
• It just delivers outside messages

View Slide

6-
Putting it All Together
• Every process will have
• A set of local actors/tasks
• A dispatcher
• A set of proxies for remote actors
25

View Slide

6-
Big Picture
26
"b"
"a"
dispatch
proxy
proxy
send()
send()
Incoming
messages from
remote actors
Messages sent to
remote actors
• Each process
local actors
• Many parts working together
• Note: Think about failure modes

View Slide

6-
Exercise dist.3
27

View Slide

6-
Actor-Actor Messaging
• So far, actors have been sending messages
directly to other actors
28
actor actor
• This is ﬁne, but what if you want to support
some more advanced features?
• Example : Replication, load balancing, etc.

View Slide

6-
Actor-Actor Messaging
• Example: An actor pool
29
actor actor
actor
actor
pool
• Message goes to one actor in the pool
(selected round-robin, system load, or some
other criteria)

View Slide

6-
Problem
• How much does the sender of a message have
to know about its destination?
• Does it have to know about that pool?
• Does it have to do all of the routing?
• Or should it be blissfully unaware?
30

View Slide

6-
Message Brokers
• Messages might be sent to an intermediary
31
actor actor
actor
actor
pool
• Broker is responsible for handling the
message in some manner (selecting a target,
routing, etc.)
broker

View Slide

6-
Message Brokers
• Decoupling is an essential feature
• sender doesn't have to know anything
about how the broker operates
• This kind of approach is essential for
scaling and other features
• Broker could transparently add/remove
actors from the pool depending on load
32

View Slide

6-
Broker Downsides
• Message brokers become critical parts
that can never fail under any circumstance
• Failure of a broker is far more serious
than loss of a single node (e.g., it takes all
1000 servers ofﬂine instead)
• Obvious solution (sic) is to add even
more complexity (replicated brokers,
managers for the brokers, etc.).
33

View Slide

6-
Reliability Assumptions
• In distributed code, never assume that the
mere act of sending a message is reliable
• There are too many things that can go
wrong in too many places
• So, better to plan for the worst
• We'll say more in a minute, but if a
message must be delivered, you need to
take extra steps to verify
34

View Slide

6-
Exercise dist.4
35

View Slide

6-
Actor Addressing
• Trying to keep track of actor locations is hard
• Especially if you force programmers to do it
manually by hard-coding everything
• Better solution: Create a global registry for
mapping actor names to dispatchers (hosts)
• Basically, a shared table that tracks actor names
and locations
36

View Slide

6-
Name Registry
37
process 1
process 2
"a"
"b"
"c"
"d"
"e"
"f"
"g"
dispatcher
dispatcher
("foo.com",15000)
("bar.com",16000)
"a" : ("foo.com",15000)
"b" : ("foo.com",15000)
"c" : ("foo.com",15000)
"d" : ("foo.com",15000)
"e" : ("bar.com",16000)
"f" : ("bar.com",16000)
"g" : ("bar.com",16000)
global registry

View Slide

6-
Registry Details
• In each process, the registry is consulted
whenever send() is used to send a message to
an unknown actor (maybe the registry knows)
• To implement the registry, you need to the
address the problem of managing state across
the entire application
• Problem : Registry has to be available to all
tasks, all machines, etc.
38

View Slide

6-
Building a Registry
• Registry is essentially just a centralized table
• A sensible option: Use a key-value store
• It's exactly what it sounds like--a dictionary
• You can easily build your own
• Or use an existing one : memcached, redis,
CouchDB, MongoDB, Cassandra,
39

View Slide

6-
Exercise dist.5
40

View Slide

6-
Key-value Stores
• Key-value stores can be used for a variety of
other purposes (more than just a registry)
• Maintain system-wide conﬁguration data
• Store results from distributed calculation
• Provide work queues
• Etc.
41

View Slide

6-
Example: Results
42
actor actor
actor
• Obtaining results
actor
key-value
DB
get
results
• Example : Actor sends out some message that
disappears into a "cloud" of other actors
• Picks up results by watching the DB.
request

View Slide

6-
Exercise dist.6
43

View Slide

6-
Request/Reply Messaging
• With actors, communication is one way
44
actor actor
send()
• However, two-way messaging is also common
client server
request
reply
• Mainstay of client/server computing
• It's also the most "tricky"

View Slide

6-
Request/Reply Issues
• Request/reply messaging adds connection state
45
send request wait request
request
wait reply
reply
client
send reply
server
• If anything goes wrong, the connection may enter
a deadlocked or invalid state

View Slide

6-
Potential Problems
• Failure modes for request/reply
• Request message sent, but is lost
• Server crashes before sending reply
• Reply message gets lost
• In all of these cases : client loses the connection
or freezes waiting for a reply that never arrives
46

View Slide

6-
Fixing Lost Replies
• Lost requests/replies can be ﬁxed
• Have client retry requests after timeout/crash
• However, this opens up even more problems
47

View Slide

6-
Repeated Requests
• Server may act upon duplicate requests
• Maybe it was only the ﬁrst reply that was lost
48
client
• What if the request changes server state?
• Example: "Do not hit reload or your credit card
might be charged twice."
server
request
reply
lost???
request
reply
retry

View Slide

6-
Repeated Replies
• Client might get two replies (slow server)
49
client server
request
reply
request
reply
retry
request
reply
• Client should be smart enough to discard reply
from the duplicated request
Notice how
retried request
results in a
duplicate reply
Which request?

View Slide

6-
Sequence Numbers
• Duplicates ﬁxed with sequence numbers
50
client server
request
reply
request
reply
retry
request
reply
• Included in every request/reply and used to
detect duplicate transactions, etc.
seq: 13
seq: 13
seq: 13
seq: 14
seq: 13
seq: 14
discard

View Slide

6-
Commentary
• Using reliable messaging such as TCP means that
you don't have to worry about any of this
• Wrong. Dead wrong.
• If you write code where a reply is expected, you
have to account for failure
• What if server dies unexpectedly (software crash,
hardware failure, power-loss, etc.)
51

View Slide

6-
Exercise dist.7
52

View Slide

6-
Remote Procedure Call
• Remote invocation of procedures implemented
on a server process
53
Server
def foo():
...
def bar():
...
def spam():
...
Client
s.foo()
Client
s.bar()

View Slide

6-
Remote Procedure Call
• RPC implementation uses a similar technique as
used for distributed actors (dispatcher, proxies)
54
Server
def foo():
...
def bar():
...
def spam():
...
Client
s.foo()
Client
s.bar()
Dispatcher
proxy
proxy

View Slide

6-
RPC Details
• RPC messages simply identify a method name
and include method arguments
55
# funcname = name of function
# args = tuple of positional args
# kwargs = dict of keyword args
msg = (funcname, args, kwargs) # Make an RPC message
send(target, msg) # Send it somewhere
• In the server, just dispatch
# Get a message
funcname, args, kwargs = receive()
# Look up the function and dispatch
func = _functions[funcname]
result = func(*args, **kwargs)
send(sender, result)

View Slide

6-
RPC Cautions
• RPC is a request/reply pattern
• It has all of the reliability concerns discussed in
the previous section
• Missing replies
• Crashed servers
• Duplicate requests/replies
• But it has other problems as well
56

View Slide

6-
RPC Cautions
• A major philosophy of RPC is that a remote
procedure call should look exactly identical to a
normal function call (user doesn't know)
• Except that it's a ﬂawed concept
• Too much RPC leads to horrible performance
(far worse than a local procedure)
• Potential for partial system failures that are very
difﬁcult to debug and untangle
57

View Slide

6-
RPC Cautions
• It's very hard to scale to large systems (hard
to incorporate features such as caching, fan-in,
fan-out, monitoring, ﬁltering, etc.)
• Hard to maintain over time (software
versions, API changes, etc.)
• Rather than reconsider the design, there's a
tendency to just keep pounding harder
(resulting in even more complexity)
58

View Slide

6-
Exercise dist.8
59

View Slide

6-
Distributed Objects
• Objects live on a server (where they stay put)
• Clients remotely invoke instance methods
60
Server
Client
a.spam()
Client
c.bar()
instances
a
b
c
spam()
bar()

View Slide

6-
Distributed Objects
• In principle, supporting distributed objects is
similar to remote procedure call (RPC)
• But there is one really big difference
• Distributed objects involves the manipulation of
state (instances) stored on the server
• With state comes extra complication (memory
management, locking, persistence, etc.)
61

View Slide

6-
Server Instances
• Objects are deﬁned by a normal class
62
class Foo(object):
def bar(self):
...
def spam(self):
...
• On the server, various instances are created
a = Foo()
b = Foo()
c = Foo()
• These are normal Python objects

View Slide

6-
Providing Remote Access
• We build upon everything so far
• Distributed objects are similar to actors except
that they have more methods than just send()
• Method invocation is usually like RPC (methods
return results)
• To implement, you still need dispatchers,
proxies, registry services, etc.
63

View Slide

6-
Server Dispatching
• For remote access, a dispatcher is needed
64
Server
instances
a
b
c
spam()
bar()
Dispatcher
Client
Requests
• Exactly the same idea as with actors, RPC

View Slide

6-
Request Messages
• Incoming requests must identify both the
instance and a method to execute
65
Server
instances
a
b
c
spam()
bar()
Dispatcher
Client
Requests
("a","spam",...)
"a" : a
"b" : b
"c" : c
instance registry
instance names and
methods are
embedded

View Slide

6-
Client Interfaces
• Clients generally want to use the same
programming interface as the class
66
class Foo(object):
def bar(self):
...
def spam(self):
...
a
b
Server
a.bar()
b.spam()
Client
• Ideally, client code
shouldn't even be aware
of the server (looks like
a normal instance)
bar()
spam()

View Slide

6-
Client Proxies
• To emulate the API, proxy classes are needed
67
class FooProxy(object):
def __init__(self,name,serveraddr):
self.name = name
self.conn = connect_to(serveraddr)
def bar(self,*args):
# send "bar" request to server
# return result
...
def spam(self,*args):
# send "spam" request to server
# return result
...
• The proxy has the same programming API as the
original object (same methods)
• Proxy methods issue RPC requests to server

View Slide

6-
Problem : Synchronization
• In a distributed environment, many clients may
be connected simultaneously
• There might be server threads
• May be concurrent access to the objects
• Thus, you may need locking
• All is lost (back to manipulating shared state)
68

View Slide

6-
Problem : Instance Creation
• What happens if new instances get created on
the server in response to requests?
• How are they referenced by clients?
• Who is responsible for managing them?
• How long do they live?
• Do they persist? (In a database)
• Countless things can go wrong...
69

View Slide

6-
Problem : Reliability
• What happens if the server crashes? (objects
disappear and clients crash?)
• Can software on the server be fixed/updated?
• Can class definitions be modified?
• API changes?
70

View Slide

6-
Comments
• Using distributed objects is really bad idea for
most projects
• Massive amounts of added complexity, library
dependencies, programming sophistication
• Example: I once had a consulting gig where I was
supposed to analyze a one million line
distributed C++ application. 95% of the code
was related to distributed objects (and it sucked)
71

View Slide

6-
Objects and RPC
• Distributed objects have all of the same issues
and limitations as RPC
• But, with even more complexity!
72

View Slide

6-
A Flawed Concept?
• Distributed object systems often follow the
"objects all the way down" philosophy
73
Machine A Machine A Machine B
Machine C
==
same
• If objects are perfectly encapsulated, they can live
anywhere (magically, out the cloud somewhere)
• Fine except that experience says it doesn't work

View Slide

6-
The Issue
• Too much high-level abstraction?
• Poor performance : Objects may interact in a
suboptimal manner (excessive communication)
• Partial failure : Part of the system dies, leaving
the rest of it running, but not fully operational
• Debugging and diagnostics?
74

View Slide

6-
Some Resources
• pyro (Python Remote Objects). A python-
centric distributed object framework. Assumes
that you're only working in Python. Simpliﬁes
many tasks that are harder in other systems.
• CORBA. Distributed object framework
designed for multiple languages. Look at:
OmniORB, fnorb. Note: as far as I can tell
CORBA is not hugely popular in the Python
world (excessive complexity?)
75

View Slide

6-
Exercise dist.9
76

View Slide

6-
Interoperability
• You may want parts of your distributed system
to interoperate with other components
• Possibly written in other languages
• Possibly located elsewhere
• Possibly implemented by someone else
77

View Slide

6-
Interoperability Tips
• To connect to foreign systems, you really want
to focus on well-documented standards
• Use common data encodings (XML, JSON, etc.)
• Use common protocols (HTTP, XML-RPC, etc.)
78

View Slide

6-
XML-RPC
• Remote Procedure Call
• Uses HTTP as a transport protocol
• Parameters/Results encoded in XML
• Supported by languages other than Python
79

View Slide

6-
Simple XML-RPC
• How to create a stand-alone server
80
from xmlrpc.server import SimpleXMLRPCServer
def add(x,y):
return x+y
s = SimpleXMLRPCServer(("",8080))
s.register_function(add)
s.serve_forever()
• How to test it (xmlrpclib)
>>> from xmlrpc.client import ServerProxy
>>> s = ServerProxy("http://localhost:8080")
>>> s.add(3,5)
8
>>> s.add("Hello","World")
"HelloWorld"
>>>

View Slide

6-
Simple XML-RPC
• Adding multiple functions
81
from xmlrpc.server import SimpleXMLRPCServer
s = SimpleXMLRPCServer(("",8080))
s.register_function(add)
s.register_function(foo)
s.register_function(bar)
s.serve_forever()
• It's fairly straightforward...

View Slide

6-
XML-RPC Undercover
• Here's what gets sent for a request:
82
POST /RPC2 HTTP/1.0
Content-Type: text/xml
Content-Length: 187

add

3

5

s = ServerProxy("...")
s.add(3,5)

View Slide

6-
XML-RPC Commentary
• XML-RPC is extremely easy to use
• Almost too easy to be honest
• I have encountered a lot of major projects that
are using XML-RPC for distributed control
• Users seem to love it
• I'm not so sure although I do love the quick and
dirty hack aspect of it
83

View Slide

6-
Other RPC Libraries
• Some RPC libraries of interest.
• Thrift. A cross-language RPC framework
developed by Facebook and released as open-
source.
• Protocol Buffers. A cross-language RPC
framework developed by Google. Also open-
source.
• Both use much more efﬁcient data serialization
than XML-RPC (and have other features)
84

View Slide

6-
RESTful Services
• REST (Representation State Transfer)
• It's a data-centric software architecture where
servers host data (resources) and implement
methods for remotely interacting with the data
• Strongly tied to HTTP, but think about
structured data instead of hacky HTML pages.
85

View Slide

6-
REST Resources
• Core component of REST is a "resource"
• A resource usually represents data
• Resources have an associated identiﬁer (URI)
86
http://somehost.com/someresource
• The URI alone contains everything needed to
locate and identify the resource (protocol,
hostname, path, etc.)

View Slide

6-
Resource Representation
• Data associated with a resource is typically
represented using a standard data encoding
87
• Common formats are used (XML, JSON, etc.)
• May be multiple representations
resource
client representation

View Slide

6-
REST Actions
• Clients interact with servers and resources
using a preset vocabulary of actions (verbs)
88
• These are usually just HTTP methods
• PUT and DELETE are related to creating/updating
a resource (not common with browsers)
GET resource
PUT resource
DELETE resource
POST resource
HEAD resource

View Slide

6-
REST Examples
• Retrieving a resource (GET)
89
resource
client
GET /some/resource
HTTP/1.1 200 OK
Content-type: application/xml
...

...

HTTP Server

View Slide

6-
REST Examples
• Updating a resource (PUT)
90
resource
client
PUT /some/resource
Content-type: application/xml
Content-length: 45123

...
HTTP/1.1 200 OK
...
HTTP Server
• Typically, this creates a new resource if it doesn't
already exist on the server

View Slide

6-
Stateless Implementation
• REST services are stateless
• Server does not record client state
• GET, PUT, etc. are the only operations
• May occur in any order and at any time
• It's a critical feature of the architecture
• May have multiple servers (heavy load)
• Fault handling (if a server crashes, etc.)
91

View Slide

6-
Reuse of HTTP
• REST web services build upon HTTP
• Authentication/security
• Caching
• Proxies
• Integrates well with existing software
• HTTP servers
• Middleware libraries
• Almost anything that speaks HTTP
92

View Slide

6-
Implementing REST
• You typically build a REST service using the
same techniques for other web programming
• CGI scripting
• WSGI
• Web frameworks (Django, Zope, etc.)
• Stand-alone HTTP server
• My preference: WSGI + WebOb
93

View Slide

6-
REST Links
• Too many packages to list (all Python 2)
• restlib
• restkit
• restish
• Many others on PyPI
• Note: Don't confused with packages related to
reStructured Text (reST)
94

View Slide

6-
Exercise dist.10
95

View Slide

7-
Generators and Coroutines
1
Section 7

View Slide

7-
Introduction
• In this section we look at generators and
coroutines as a concurrency tool
• These features of Python are not as well
understood as other language elements
• However, can be used as an alternative
implementation tool for various aspects of
distributed computing and I/O handling
2

View Slide

7-
Reference Material
• I've given some related PyCon tutorials
• "Generator Tricks for Systems Programmers"
at PyCON'08
3
http://www.dabeaz.com/generators
• "A Curious Course on Coroutines and
Concurrency" at PyCON'09
http://www.dabeaz.com/coroutines
• This is a highly condensed version

View Slide

7-
Background Material
4

View Slide

7-
Generators
• A generator is a function that produces a
sequence of results instead of a single value
5
def countdown(n):
while n > 0:
yield n
n -= 1
>>> for i in countdown(5):
... print(i,end=' ')
...
5 4 3 2 1
>>>
• Instead of returning a value, you generate a
series of values (using the yield statement)
• Typically, you hook it up to a for-loop

View Slide

7-
Generators
6
• Behavior is quite different than normal func
• Calling a generator function creates an
generator object. However, it does not start
running the function.
def countdown(n):
print("Counting down from", n)
while n > 0:
yield n
n -= 1
>>> x = countdown(10)
>>> x

>>>
Notice that no
output was
produced

View Slide

7-
Generator Functions
• The function only executes on __next__()
>>> x = countdown(10)
>>> x

>>> x.__next__()
Counting down from 10
10
>>>
• yield produces a value, but suspends the function
• Function resumes on next call to __next__()
>>> x.__next__()
9
>>> x.__next__()
8
>>>
Function starts
executing here
7

View Slide

7-
Generator Functions
• When the generator returns, iteration stops
>>> x.__next__()
1
>>> x.__next__()
File "", line 1, in ?
StopIteration
>>>
8

View Slide

7-
A Practical Example
• A Python version of Unix 'tail -f'
9
import time
def follow(thefile):
thefile.seek(0,2) # Go to the end of the file
while True:
line = thefile.readline()
if not line:
time.sleep(0.1) # Sleep briefly
continue
yield line
• Example use : Watch a web-server log ﬁle
logfile = open("access-log")
for line in follow(logfile):
print(line)

View Slide

7-
Generators as Pipelines
• One of the most powerful applications of
generators is setting up processing pipelines
• Similar to shell pipes in Unix
10
generator
input
sequence
for x in s:
generator generator
• Idea: You can stack a series of generator
functions together into a pipe and pull items
through it with a for-loop

View Slide

7-
A Pipeline Example
• Print all server log entries containing 'python'
11
def grep(pattern,lines):
for line in lines:
if pattern in line:
yield line
# Set up a processing pipe : tail -f | grep python
logfile = open("access-log")
loglines = follow(logfile)
pylines = grep("python",loglines)
# Pull results out of the processing pipeline
for line in pylines:
print(line)
• This is just a small taste of what's possible

View Slide

7-
Exercise gen.1
12

View Slide

7-
Yield as an Expression
• In Python 2.5, a slight modiﬁcation to the yield
statement was introduced (PEP-342)
• You could now use yield as an expression
• For example, on the right side of an assignment
13
def grep(pattern):
print("Looking for", pattern)
while True:
line = yield
if pattern in line:
print(line)
• Question : What is its value?

View Slide

7-
Coroutines
• If you use yield like this, you get a "coroutine"
• These do more than just generate values
• Instead, functions can consume values sent to it.
14
>>> g = grep("python")
>>> next(g) # Prime it (explained shortly)
Looking for python
>>> g.send("Yeah, but no, but yeah, but no")
>>> g.send("A series of tubes")
>>> g.send("python generators rock!")
python generators rock!
>>>
• Sent values are returned by (yield)

View Slide

7-
Coroutine Execution
• Execution is the same as for a generator
• When you call a coroutine, nothing happens
• They only run in response to next() and send()
methods
15
>>> g = grep("python")
>>> next(g)
Looking for python
>>>
Notice that no
output was
produced
On ﬁrst operation,
coroutine starts
running

View Slide

7-
Coroutine Priming
• All coroutines must be "primed" by first
calling .next() (or send(None))
• This advances execution to the location of the
first yield expression.
16
.next() advances the
coroutine to the
first yield expression
def grep(pattern):
print("Looking for", pattern)
while True:
line = yield
if pattern in line:
print(line)
• At this point, it's ready to receive a value

View Slide

7-
Using a Decorator
• Remembering to call .next() is easy to forget
• Solved by wrapping coroutines with a decorator
17
def coroutine(func):
def start(*args,**kwargs):
cr = func(*args,**kwargs)
next(cr)
return cr
return start
@coroutine
def grep(pattern):
...

View Slide

7-
Processing Pipelines
18
• Coroutines can also be used to set up pipes
coroutine coroutine coroutine
send() send() send()
• You just chain coroutines together and push
data through the pipe with send() operations
• Notice the striking similarity to actors

View Slide

7-
An Example
19
• A source that mimics Unix 'tail -f'
import time
def follow(thefile, target):
thefile.seek(0,2) # Go to the end of the file
while True:
line = thefile.readline()
if not line:
time.sleep(0.1) # Sleep briefly
continue
target.send(line)
• A sink that just prints the lines
@coroutine
def printer():
while True:
line = yield
print(line)

View Slide

7-
An Example
20
• A grep ﬁlter coroutine
@coroutine
def grep(pattern,target):
while True:
line = yield # Receive a line
if pattern in line:
target.send(line) # Send to next stage
• Hooking it up
f = open("access-log")
follow(f,
grep('python',
printer()))
follow() grep() printer()
send() send()
• A picture

View Slide

7-
Exercise gen.2
21

View Slide

7-
Generators as Tasks
22
• Generators and coroutines can clearly be used to
set up problems in pipelining, dataﬂow, actors, etc.
• However, generators can also serve the role of
tasks as an alternative to threads or processes
• It's subtle, but let's look at the big idea

View Slide

7-
Program Execution
23
• When programs run, they alternate
between CPU processing and I/O
• For I/O, a program requests the services
of the operating system (system calls)
• I/O may cause the program to suspend
run run run run
I/O I/O I/O
System calls in the
operating system

View Slide

7-
Task Switching
24
• Underneath the covers the operating
system task-switches on I/O
run
I/O
run
I/O
run
I/O
run
I/O
I/O
run
Task A:
Task B:
task switch
• Since I/O operations might take awhile, the
system does other work while waiting

View Slide

7-
An Insight
25
• The yield statement can be used to implement
user-deﬁned "task" switching
• When a generator function hits a "yield"
statement, it immediately suspends execution
• If you are very clever, you can get your
program to task switch between a collection
of generator functions

View Slide

7-
Multitasking Example
• First, you set up a collection of "tasks"
26
def countdown_task(n):
while n > 0:
print(n)
yield
n -= 1
# A queue of tasks to run
from collections import deque
tasks = deque([
countdown_task(5),
countdown_task(10),
countdown_task(15)
])
• Each task is a generator function that yields

View Slide

7-
Scheduling Example
• Now, write a simple task scheduler
27
def scheduler(tasks):
while tasks:
task = tasks.popleft()
try:
next(task) # Run to the next yield
tasks.append(task) # Reschedule
except StopIteration:
pass
# Run it
scheduler(tasks)
• This loop will just run all of the generators
(cycling between them) until there's nothing left
to work on

View Slide

7-
Scheduling Example
• Output
28
5
10
15
4
9
14
3
8
13
...
• You'll see the different tasks cycling
• Okay, that's kind of interesting...

View Slide

7-
Exercise gen.3
29

View Slide

7-
Yielding For I/O
30
• If you are a littler clever, you can have yield
integrate with "blocking" I/O requests
• The big idea : set up some kind of operation
and then yield to have it carried out in the
background by the generator scheduler

View Slide

7-
More About Yield
31
• In last section, we used yield to yield control,
not a value
• Although generators are used for iteration,
we're talking about something completely
different here
• When yielding, control goes back to the
scheduler which is free to choose what task
to run next

View Slide

7-
Talking to the Scheduler
32
• Tasks can send values back to the scheduler
by yielding an "interesting" value
• Consider the following classes
class IOWait:
def __init__(self,f):
self.fileno = f.fileno()
class ReadWait(IOWait): pass
class WriteWait(IOWait): pass
• These classes represent the concept of
"waiting" for a speciﬁc kind of I/O event on a
given ﬁle object

View Slide

7-
An Example Task
33
• Now, consider this generator function
# Echo data received on s back to the sender
def echo_data(s):
while True:
yield ReadWait(s) # Wait for data
msg = s.recv(16384) # Read data
yield WriteWait(s) # Wait for writing
s.send(msg)
• This generator yields instances of the classes
just deﬁned back to the scheduler
• Now, let's go back to the scheduler code...

View Slide

7-
Signaling an I/O Request
• Here is the scheduler
34
while tasks:
try:
next(task)
tasks.append(task)
pass
# Run it
scheduler(tasks)
• When the task yields, an instance of ReadWait
or WriteWait is going to be returned by next
def echo_data(s):
...
yield ReadWait(s)
...
Task

View Slide

7-
Signaling an I/O Request
• A modiﬁed scheduler
35
while tasks:
try:
r = next(task)
if isinstance(r,ReadWait):
handle_read_wait(r,task)
elif isinstance(r,WriteWait):
handle_write_wait(r,task)
else:
tasks.append(task)
pass
# Run it
scheduler(tasks)
Looking for
different I/O wait
requests and taking
action

View Slide

7-
Implementing I/O Waits
36
• We haven't built the I/O yet, but it's easy
• To implement I/O waiting, you need two pieces
• A holding area for tasks that are waiting
for an I/O operation
• An I/O poller that looks for I/O activity
and removes tasks from the holding area
when I/O is possible
• Let's look at an example

View Slide

7-
Building a Scheduler
• A scheduler class
37
class Scheduler:
def __init__(self):
self.numtasks = 0
self.ready = deque()
self.read_waiting = {}
self.write_waiting = {}
def iopoll(self):
rset,wset,eset = select(self.read_waiting,
self.write_waiting,[])
for r in rset:
self.ready.append(self.read_waiting.pop(r))
for w in wset:
self.ready.append(self.write_waiting.pop(w))

View Slide

7-
38
class Scheduler:
def __init__(self):
self.numtasks = 0
def iopoll(self):
for r in rset:
for w in wset:
Total number
of tasks being
managed
Queue of tasks
that can run

View Slide

7-
39
class Scheduler:
def __init__(self):
self.numtasks = 0
def iopoll(self):
for r in rset:
for w in wset:
Dictionaries that
serve as I/O
holding areas
{
3 : ,
7 : ,
6 : ,
}
ﬁle
descriptor task

View Slide

7-
40
class Scheduler:
def __init__(self):
self.numtasks = 0
def iopoll(self):
for r in rset:
for w in wset:
An I/O polling
function. This looks
for any I/O activity on
suspended tasks.
If there is I/O,
move the task
back to the
ready queue

View Slide

7-
• Add some scheduling methods (convenience)
41
class Scheduler:
def __init__(self):
self.numtasks = 0
...
def new(self,task):
self.ready.append(task)
self.numtasks += 1
def readwait(self,fileno,task):
self.read_waiting[fileno] = task
def writewait(self,fileno,task):
self.write_waiting[fileno] = task

View Slide

7-
• Implement the main scheduler loop
42
class Scheduler:
...
def run(self):
while self.numtasks:
try:
task = self.ready.popleft()
try:
r = next(task)
self.readwait(r.fileno,task)
self.writewait(r.fileno,task)
else:
self.numtasks -= 1
except IndexError:
self.iopoll()

View Slide

7-
43
class Scheduler:
...
def run(self):
try:
try:
r = next(task)
else:
self.numtasks -= 1
except IndexError:
self.iopoll()
Run a task
until it yields,
check the
return value

View Slide

7-
44
class Scheduler:
...
def run(self):
try:
try:
r = next(task)
else:
self.numtasks -= 1
except IndexError:
self.iopoll()
Poll for I/O
(only runs if
no other
work to do)

View Slide

7-
Example : Time Server
45
from socket import socket, AF_INET, SOCK_DGRAM
import time
def timeserver(addr):
s = socket(AF_INET, SOCK_DGRAM)
s.bind(addr)
while True:
yield ReadWait(s)
msg,addr = s.recvfrom(8192)
yield WriteWait(s)
s.sendto((time.ctime()+"\n").encode('ascii'),
addr)
sched = Scheduler()
sched.new(timeserver(('',15000)) # Create three server
sched.new(timeserver(('',16000)) # instances and add
sched.new(timeserver(('',17000)) # to the scheduler
sched.run()

View Slide

7-
46
class EchoServer:
def __init__(self,addr,sched):
self.sched = sched
sched.new(self.server_loop(addr))
def server_loop(self,addr):
s.bind(addr)
s.listen(5)
while True:
yield ReadWait(s)
c,a = s.accept()
print("Got connection from", a)
self.sched.new(self.client_handler(c))
def client_handler(self,client):
while True:
yield ReadWait(client)
msg = client.recv(8192)
if not msg: break
yield WriteWait(client)
client.send(msg)
client.close()
print("Client closed")

View Slide

7-
47
sched = Scheduler()
echo = EchoServer(('',15000),sched)
sched.run()
• Running the echo server
• Test it out with telnet
• Will ﬁnd that it works ﬁne with multiple clients

View Slide

7-
Exercise gen.4
48

View Slide

7-
Comments
49
• Multitasking with generators has some interesting
aspects to it
• First it's based on I/O polling--just like event-
driven I/O systems
• However, the execution model takes a completely
different direction
• Instead of triggering callbacks, I/O events merely
cause suspended generators to resume

View Slide

7-
Comments
50
• Generators have normal looking control ﬂow
class EchoServer:
...
def client_handler(self,client):
while True:
yield ReadWait(client)
msg = client.recv(8192)
if not msg: break
yield WriteWait(client)
client.send(msg)
client.close()
print("Client closed")
• Notice how it closely mimics what you would
write with threads

View Slide

7-
Problems
51
• The yield statement can only be used in the top-
level function, not subroutines
• This makes it really difﬁcult to write subroutine
libraries based on generators
• It's not impossible, but you have to play some
clever tricks (e.g., generator "trampolining")
• Being addressed in PEP-380

View Slide

7-
Problems
52
• Generators also have the same sorts of
problems as with event-driven systems
• Scalability of I/O polling
• Long running calculations
• How to handle blocking operations
• Solutions are similar. For example, to handle a
blocking operation, you might run it in a
separate thread until it completes

View Slide

7-
Some Links
53
• Some related projects (not an exhaustive list)
• gevent
• Cogen
• Greenlet
• Eventlet
• Stackless
• Do a search on http://pypi.python.org

View Slide

7-
More Information
54
• Look at my PyCon'09 presentation for a more in-
depth study of coroutines and concurrency
http://www.dabeaz.com/coroutines
• I've intentionally not included all of that here
mainly because I don't want to just duplicate my
PyCON presentation (which is freely available
online) and we're probably short on time

View Slide

Python Concurrency and Distributed Computing Workshop

Python Concurrency and Distributed Computing Workshop

David Beazley

More Decks by David Beazley

Other Decks in Programming

Featured

Transcript
