Introduction to Celery

A short presentation I held at the Zurich Python User Group in December 2014. It introduces Celery and the different task workflows (canvas) that can be implemented with it.

Transcript

1. Introduction to Celery Zürich Python User Group 2014-12-04
2. Message Oriented Middleware “Software or hardware infrastructure supporting sending and receiving messages between distributed systems”
3. Message Queues “Put some stuff into one end of a queue, get it out at the other end”
4. Architecture: Pipe Producer Consumer Queue
5. Architecture: Multiple producers / consumers Producer Consumer Queue Producer Consumer Consumer
6. Architecture: Multiple queues / Routing Consumer Queue 1 Producer Consumer Consumer Queue 2 Router
7. Celery • A task queueing system • Distribute tasks across systems • Written in Python, but the protocol can be implemented in any language
8. When To Use Celery • Asynchronous task processing • Long running background jobs • Offloading heavy web backend operations • Scheduling tasks • ...
9. Celery: The Broker The broker is the part of the system that does message distribution. Supported transports: • RabbitMQ • Redis • MongoDB (exp) • ZeroMQ (exp) • CouchDB (exp) • SQLAlchemy (exp) • Django ORM (exp) • Amazon SQS (exp) • ...and more
10. Celery: Result Stores A result store stores the result of a task. It is optional. Supported stores: • AMQP • Redis • memcached • MongoDB • SQLAlchemy • Django ORM • Apache Cassandra
11. Celery: Serializers The serialization is necessary to turn Python data types into a format that can be stored in the queue. The serialized data can be compressed and signed cryptographically. Supported serializers: • Pickle • JSON • YAML • MessagePack
12. Server 1 Celery: Workers The workers take tasks out of the queues, process them and return the result. Transport Worker 1 Worker 2 Server 2 Worker 3
13. Celery: Worker Concurrency Celery workers allow the following forms of concurrency: • Prefork (multiprocessing) • Eventlet, Gevent • Threading
14. Celery: Other Features • Real time monitoring • Workflows (Grouping, chaining, chunking…) • Time & Rate Limits • Scheduling (goodbye cron!) • Autoreloading • Autoscaling • Resource Leak Protection
15. Celery: Framework Integration • Django • Pyramid • Pylons • Flask • web2py • Tornado ...or use it directly!
16. Celery: Installing $ pip install celery[redis,msgpack,threads]
17. Celery: Defining a Task from celery import Celery app = Celery('hello', broker='redis://localhost/') @app.task def add(x, y): return x + y
18. You can call a task synchronously like a regular function, without Celery: >>> add(19, 23) 42 Or you can call it asynchronously through Celery: >>> add.delay(19, 23) <AsyncResult: 257d9f84-cd4b-4248-b7ba-93ed24ce6804> Celery: Calling a Task
19. The “delay” method is actually a shortcut for the “apply_async” method: >>> add.apply_async(args=(19, 23)) <AsyncResult: df5abf5e-737a-4a36-acd2-c0ffe8bad305> You can also delay the execution of a task (and many other things): >>> add.apply_async((19, 23), countdown=10) <AsyncResult: def99720-ea55-4280-957b-23bbcbc7646c> Celery: Calling a Task
20. To block until the result is ready, use “.get()”: >>> add.delay(19, 23).get() 42 Or you can poll the result asynchronously: >>> res = add.delay(19, 23) >>> res.status, res.ready(), res.result 'SUCCESS', True, 42 Celery: Retrieving a Result
21. Designing Workflows • Celery allows you to create workflows • Works by passing around call signatures • Primitives: Chains, Groups, Chords, Maps, Starmaps, Chunks
22. Call Signatures: Creation Signatures are like a recipe on how to call a function. You can manually create a signature for a task: >>> from celery import signature >>> signature('tasks.add', args=(2, 2), countdown=10) tasks.add(2, 2)
23. Call Signatures: Shortcuts Signatures are often nicknamed “subtasks”, because they are essentially tasks that execute tasks. >>> add.subtask((2, 2), countdown=10) tasks.add(2, 2) There is also a shortcut using star arguments. >>> add.s(2, 2, countdown=10) tasks.add(2, 2)
24. Signatures support the “Calling API” like regular tasks. >>> s = add.s(19, 23).delay().get() 42 Calling a Signature
25. Groups can be used to execute several tasks in parallel: >>> res = group(add.s(2, 2), add.s(4, 4)) >>> res.get() [4, 8] Groups
26. Chains feed the result from one subtask into the next one: >>> # (4 + 4) * 8 * 10 >>> res = chain(add.s(4, 4), mul.s(8), mul.s(10)) >>> res.get() 640 Chains
27. Chords are groups with a callback: >>> # sum(2+2, 3+3, 4+4) >>> c = chord(add.s(2, 2), add.s(3, 3), add.s(4, 4)) >>> res = c(sum.s()) >>> res.get() 18 Chords
28. Chunking lets you divide an iterable of work into pieces: >>> sig = add.chunks(zip(range(100), range(100)), 10) >>> res = sig() >>> sig.delay().get() [[0, 2, 4, 6, 8, 10, 12, 14, 16, 18], [20, 22, 24, 26, 28, 30, 32, 34, 36, 38], ... Chunks
29. For the following example, we’re using the following three tasks: Example: Combinations @app.task def add(x, y): return x + y @app.task def flatten(lists): return itertools.chain.from_iterable(lists) @app.task def sum_list(numbers): return sum(numbers)
30. Example: Combinations (1/4) The first signature returns 10 chunks of 10 add operations. >>> chunks = add.chunks(zip(range(100), range(100)), 10) We can convert these chunks to a celery group: >>> sig1 = chunks.group()
31. Example: Combinations (2/4) The first signature will return a list of 10 lists containing 10 numbers each. We want to flatten this to a single list containing all 100 numbers. >>> sig2 = flatten.s() Finally we want to sum all numbers in that list: >>> sig3 = sum_list.s()
32. Example: Combinations (3/4) We can now run these three signatures in a chain: >>> sig = chain(sig1, sig2, sig3) There’s also a shortcut syntax for this: >>> sig = sig1 | sig2 | sig3
33. Example: Combinations (4/4) The sig object is now still just a signature, a list of instructions on how to calculate the result. Nothing has been evaluated yet. Now let’s actually run those signatures and get the final result: >>> sig.delay().get() 9900
34. Preview: Dynamic Tasks The next version of Celery will support dynamic tasks – modifying a task in a chord or group at runtime. • replace(sig): Replace the current task with a new task inheriting the same task id. • add_to_chord(sig): Add a signature to the chord the current task is a member of.
35. Questions?
