Generating Code And Other Mischief With Swift Package Manager Plugins - 360iDev, Denver, CO, August 2022

It’s the build tooling step everyone hates: “Now, add a new Run Script Build Phase.” The Swift and Xcode teams have worked to try to make things at least a little bit better for things which need to happen at build time by adding Build Tool Plugins and Command Plugins to Swift Package manager.

In this talk, you’ll get a look at how to set these up to generate code and documentation, plus a look at some other silly things you can make it do.

Sample App: https://github.com/designatednerd/RadioactiveCat
Sample Plugin: https://github.com/designatednerd/DatedImageGenerator

Transcript

1. GENERATING CODE AND OTHER MISCHIEF WITH SWIFT PACKAGE MANAGER PLUGINS 360IDEV | DENVER, CO | AUGUST 2022 ELLEN SHAPIRO | @DESIGNATEDNERD | GUSTO.COM
6. ALCATRAZ
18. ! XCODE GHOST
19. ! XCODE GHOST
20. ! STRAWHORSE
23. !
25. XCODE SOURCE EXTENSIONS
26. REQUIRED HOST MAC APP
27. REQUIRED HOST MAC APP ▸ ! Can now be distributed easily on the Mac App store
28. REQUIRED HOST MAC APP ▸ ! Can now be distributed easily on the Mac App store ▸ " Sandboxing restrictions
29. REQUIRED HOST MAC APP ▸ ! Can now be distributed easily on the Mac App store ▸ " Sandboxing restrictions ▸ # Often winds up with an empty app
30. func perform(with invocation: XCSourceEditorCommandInvocation, completionHandler: @escaping (Error?) -> Void) { // Actual code of plugin }
32. ONLY SINGLE-FILE TEXT BUFFER ACCESS
33. ONLY SINGLE-FILE TEXT BUFFER ACCESS ▸ ! Does allow at least some sorting, linting, formatting
34. ONLY SINGLE-FILE TEXT BUFFER ACCESS ▸ ! Does allow at least some sorting, linting, formatting ▸ ☹ Only ever the current file
35. ONLY SINGLE-FILE TEXT BUFFER ACCESS ▸ ! Does allow at least some sorting, linting, formatting ▸ ☹ Only ever the current file ▸ # No access to the AST
36. ONLY SINGLE-FILE TEXT BUFFER ACCESS ▸ ! Does allow at least some sorting, linting, formatting ▸ ☹ Only ever the current file ▸ # No access to the AST ▸ $ No access to file or project structure
37. ONLY SINGLE-FILE TEXT BUFFER ACCESS ▸ ! Does allow at least some sorting, linting, formatting ▸ ☹ Only ever the current file ▸ # No access to the AST ▸ $ No access to file or project structure ▸ $ No user interface permitted
38. FURTHER INVOCATION LIMITATIONS
39. FURTHER INVOCATION LIMITATIONS ▸ ! Cannot run in background
40. FURTHER INVOCATION LIMITATIONS ▸ ! Cannot run in background ▸ " Must be actively invoked by the user
41. FURTHER INVOCATION LIMITATIONS ▸ ! Cannot run in background ▸ " Must be actively invoked by the user ▸ # No default key binding
47. SWIFT PACKAGE MANAGER ! PLUGINS
52. ✅ SWIFT 5.6
53. ✅ SWIFT 5.6 ! XCODE 14
54. 1. COMMAND PLUGINS 2. BUILD TOOL PLUGINS
55. COMMAND PLUGINS
56. CODE FROM "CREATE SWIFT PACKAGE PLUGINS" HTTPS://DEVELOPER.APPLE.COM/VIDEOS/PLAY/WWDC2022/110401/
57. COMMAND PLUGINS ▸ Can ask permission to write in the package directory
58. // Package.swift .plugin( name: "GenerateContributors", capability: .command( intent: .custom(verb: "regenerate-contributors-list", description: "Generates the CONTRIBUTORS.txt file based on Git logs"), permissions: [ .writeToPackageDirectory(reason: "This command write the new CONTRIBUTORS.txt to the source root.") ] )),
59. // Package.swift .plugin( name: "GenerateContributors", capability: .command( intent: .custom(verb: "regenerate-contributors-list", description: "Generates the CONTRIBUTORS.txt file based on Git logs"), permissions: [ .writeToPackageDirectory(reason: "This command write the new CONTRIBUTORS.txt to the source root.") ] )),
60. COMMAND PLUGINS ▸ Can ask permission to write in the package directory ▸ Can be invoked at the command line
61. // Get all plugins available on a particular package swift package plugin --list // Run a specific plugin, in this case GenerateContributors swift package regenerate-contributors-list
63. COMMAND PLUGINS ▸ Can ask permission to write in the package directory ▸ Can be invoked at the command line ▸ Can be invoked from a menu item in Xcode
69. COMMAND PLUGINS ▸ Can ask permission to write in the package directory ▸ Can be invoked at the command line ▸ Can be invoked from a menu item Xcode ▸ Either way, must be invoked separately from the build process
70. BUILD TOOL PLUGINS
71. BUILD TOOL PLUGINS RUN AUTOMATICALLY ON EVERY BUILD
72. BUILD TOOL PLUGINS (THE THING I REALLY WANT TO USE)
73. THE MORE COMPLICATED BUT LESS COMPLICATED WAY: EMBED A PACKAGE IN YOUR .XCODEPROJ
74. MORE COMPLICATED (YOU HAVE TO ADD A WHOLE SWIFT PACKAGE TO YOUR PROJECT)
75. LESS COMPLICATED (IT WORKS WAY MORE RELIABLY)
76. SAMPLE APP https://github.com/designatednerd/ RadioactiveCat
77. via https://energyeducation.ca/encyclopedia/Half_life
81. BUILD TOOL EASY MODE BRING IN SOMEONE ELSE'S PLUGIN
82. DO NIL DISTURB HTTPS://GITHUB.COM/ICANZILB/ DONILDISTURBPLUGIN
83. // Package.swift .dependencies: [ .package(url: "https://github.com/icanzilb/ DoNilDisturbPlugin.git", from: "0.0.5"), ]
84. // Package.swift .target( name: "Cats", dependencies: [ ], plugins: [ .plugin(name: "DoNilDisturbPlugin", package: "DoNilDisturbPlugin") ] ),
86. DO NOT BLINDLY CLICK TRUST & ENABLE ALL
92. BUILD TOOL HARD MODE: CREATE YOUR OWN PLUGIN
93. DON'T BUILD YOUR PLUGIN AND THE PACKAGE YOU'RE TESTING IT AGAINST IN THE SAME REPO
94. GITHUB.COM/DESIGNATEDNERD/ DATEDIMAGEGENERATOR
95. PLUGIN VS. EXECUTABLE
96. // File structure of the Swift Lib ! DatedImageGenerator ! Plugins ! DatedImageGenerator " DatedImageGenerator.swift ! Sources ! DatedImage " DatedImage.swift " ExifDateFormatter.swift ! DatedImageGeneratorExecutable " DatedImageGeneratorExecutable.swift ! Tests ! DatedImageGeneratorTests " DatedImageGeneratorExecutable.swift " Media.xcassets
97. // File structure of the Swift Lib ! DatedImageGenerator ! Plugins ! DatedImageGenerator " DatedImageGenerator.swift ! Sources ! DatedImage " DatedImage.swift " ExifDateFormatter.swift ! DatedImageGeneratorExecutable " DatedImageGeneratorExecutable.swift ! Tests ! DatedImageGeneratorTests " DatedImageGeneratorExecutable.swift " Media.xcassets
98. // File structure of the Swift Lib ! DatedImageGenerator ! Plugins ! DatedImageGenerator " DatedImageGenerator.swift ! Sources ! DatedImage " DatedImage.swift " ExifDateFormatter.swift ! DatedImageGeneratorExecutable " DatedImageGeneratorExecutable.swift ! Tests ! DatedImageGeneratorTests " DatedImageGeneratorExecutable.swift " Media.xcassets
99. // File structure of the Swift Lib ! DatedImageGenerator ! Plugins ! DatedImageGenerator " DatedImageGenerator.swift ! Sources ! DatedImage " DatedImage.swift " ExifDateFormatter.swift ! DatedImageGeneratorExecutable " DatedImageGeneratorExecutable.swift ! Tests ! DatedImageGeneratorTests " DatedImageGeneratorExecutable.swift " Media.xcassets
100. // File structure of the Swift Lib ! DatedImageGenerator ! Plugins ! DatedImageGenerator " DatedImageGenerator.swift ! Sources ! DatedImage // <-- Exported library used in executable and main app " DatedImage.swift " ExifDateFormatter.swift ! DatedImageGeneratorExecutable " DatedImageGeneratorExecutable.swift ! Tests ! DatedImageGeneratorTests " DatedImageGeneratorExecutable.swift " Media.xcassets
101. // File structure of the Swift Lib ! DatedImageGenerator ! Plugins ! DatedImageGenerator " DatedImageGenerator.swift ! Sources ! DatedImage // <-- Exported Framework used in executable and main app " DatedImage.swift " ExifDateFormatter.swift ! DatedImageGeneratorExecutable // <-- The thing that does all the work " DatedImageGeneratorExecutable.swift ! Tests ! DatedImageGeneratorTests " DatedImageGeneratorExecutable.swift " Media.xcassets
102. // File structure of the Swift Lib ! DatedImageGenerator ! Plugins ! DatedImageGenerator " DatedImageGenerator.swift ! Sources ! DatedImage " DatedImage.swift " ExifDateFormatter.swift ! DatedImageGeneratorExecutable " DatedImageGeneratorExecutable.swift ! Tests ! DatedImageGeneratorTests " DatedImageGeneratorExecutable.swift " Media.xcassets
103. // Plugins/DatedImageGenerator.swift @main struct DatedImageGenerator: BuildToolPlugin { func createBuildCommands(context: PluginContext, target: Target) async throws -> [Command] { // TODO: Create info for build command return [ .buildCommand( displayName: "Generate Dated Images", executable: try context.tool(named: "DatedImageGeneratorExecutable").path, // more to come here arguments: "TODO", outputFiles: ["TODO"] ) ] } }
104. WHAT'S IN THE EXECUTABLE?
105. // Sources/DatedImageGeneratorExecutable/ // DatedImageGeneratorExecutable.swift @main struct DatedImageGeneratorExecutable { static func main() throws { // How do we get information from the Plugin? } }
106. // Sources/DatedImageGeneratorExecutable/ // DatedImageGeneratorExecutable.swift @main struct DatedImageGeneratorExecutable { static func main() throws { // Grab the 2nd argument as a string ProcessInfo.processInfo.arguments[1] } }
107. // Sources/DatedImageGeneratorExecutable/ // DatedImageGeneratorExecutable.swift @main struct DatedImageGeneratorExecutable { static func main() throws { // Turn it into Data Data(ProcessInfo.processInfo.arguments[1].utf8)) } }
108. // Sources/DatedImageGeneratorExecutable/ // DatedImageGeneratorExecutable.swift @main struct DatedImageGeneratorExecutable { static func main() throws { // Decode it into a codable object! let invocation = try JSONDecoder() .decode(PluginInvocation.self, from: Data(ProcessInfo.processInfo.arguments[1].utf8)) } }
109. "I should just put the codable object in the executable and import it into the plugin"
113. // One copy of this in the plugin, one in the executable struct PluginInvocation: Codable { let catalogPaths: [String] let outputPath: String func encodedString() throws -> String { let data = try JSONEncoder().encode(self) return String(decoding: data, as: UTF8.self) } }
114. // One copy of this in the plugin, one in the executable // (or share with a common lib) struct PluginInvocation: Codable { let catalogPaths: [String] let outputPath: String func encodedString() throws -> String { let data = try JSONEncoder().encode(self) return String(decoding: data, as: UTF8.self) } }
115. // Plugins/DatedImageGenerator.swift @main struct DatedImageGenerator: BuildToolPlugin { func createBuildCommands(context: PluginContext, target: Target) async throws -> [Command] { guard let target = target as? SourceModuleTarget else { throw ImageGenError.notASourceModule } let assetCatalogPaths = target.sourceFiles(withSuffix: "xcassets") .compactMap { assetCatalog in return assetCatalog.path.string } let outputPath = context.pluginWorkDirectory .appending(["DatedImages.swift"]) let invocation = PluginInvocation(catalogPaths: assetCatalogPaths, outputPath: outputPath.string) return [ .buildCommand( displayName: "Generate Dated Images", executable: try context.tool(named: "DatedImageGeneratorExecutable").path, arguments: [try invocation.encodedString()], outputFiles: [outputPath] ) ] } }
116. // Plugins/DatedImageGenerator.swift @main struct DatedImageGenerator: BuildToolPlugin { func createBuildCommands(context: PluginContext, target: Target) async throws -> [Command] { guard let target = target as? SourceModuleTarget else { throw ImageGenError.notASourceModule } let assetCatalogPaths = target.sourceFiles(withSuffix: "xcassets") .compactMap { assetCatalog in return assetCatalog.path.string } let outputPath = context.pluginWorkDirectory .appending(["DatedImages.swift"]) let invocation = PluginInvocation(catalogPaths: assetCatalogPaths, outputPath: outputPath.string) return [ .buildCommand( displayName: "Generate Dated Images", executable: try context.tool(named: "DatedImageGeneratorExecutable").path, arguments: [try invocation.encodedString()], outputFiles: [outputPath] ) ] } }
117. ! TARGET (TECHNICALLY PACKAGEPLUGIN.TARGET)
118. // Plugins/DatedImageGenerator.swift @main struct DatedImageGenerator: BuildToolPlugin { func createBuildCommands(context: PluginContext, target: Target) async throws -> [Command] { guard let target = target as? SourceModuleTarget else { throw ImageGenError.notASourceModule } let assetCatalogPaths = target.sourceFiles(withSuffix: "xcassets") .compactMap { assetCatalog in return assetCatalog.path.string } let outputPath = context.pluginWorkDirectory .appending(["DatedImages.swift"]) let invocation = PluginInvocation(catalogPaths: assetCatalogPaths, outputPath: outputPath.string) return [ .buildCommand( displayName: "Generate Dated Images", executable: try context.tool(named: "DatedImageGeneratorExecutable").path, arguments: [try invocation.encodedString()], outputFiles: [outputPath] ) ] } }
119. ! PLUGIN CONTEXT (TECHNICALLY PACKAGEPLUGIN.PLUGINCONTEXT)
120. PLUGINWORKDIRECTORY IS YOUR SANDBOX
121. // Plugins/DatedImageGenerator.swift @main struct DatedImageGenerator: BuildToolPlugin { func createBuildCommands(context: PluginContext, target: Target) async throws -> [Command] { guard let target = target as? SourceModuleTarget else { throw ImageGenError.notASourceModule } let assetCatalogPaths = target.sourceFiles(withSuffix: "xcassets") .compactMap { assetCatalog in return assetCatalog.path.string } let outputPath = context.pluginWorkDirectory .appending(["DatedImages.swift"]) let invocation = PluginInvocation(catalogPaths: assetCatalogPaths, outputPath: outputPath.string) return [ .buildCommand( displayName: "Generate Dated Images", executable: try context.tool(named: "DatedImageGeneratorExecutable").path, arguments: [try invocation.encodedString()], outputFiles: [outputPath] ) ] } }
122. // Plugins/DatedImageGenerator.swift @main struct DatedImageGenerator: BuildToolPlugin { func createBuildCommands(context: PluginContext, target: Target) async throws -> [Command] { guard let target = target as? SourceModuleTarget else { throw ImageGenError.notASourceModule } let assetCatalogPaths = target.sourceFiles(withSuffix: "xcassets") .compactMap { assetCatalog in return assetCatalog.path.string } let outputPath = context.pluginWorkDirectory .appending(["DatedImages.swift"]) let invocation = PluginInvocation(catalogPaths: assetCatalogPaths, outputPath: outputPath.string) return [ .buildCommand( displayName: "Generate Dated Images", executable: try context.tool(named: "DatedImageGeneratorExecutable").path, arguments: [try invocation.encodedString()], outputFiles: [outputPath] ) ] } }
124. QUICK RECAP OF PLUGIN CREATION
125. QUICK RECAP OF PLUGIN CREATION ▸ Create a plugin in Plugins
126. QUICK RECAP OF PLUGIN CREATION ▸ Create a plugin in Plugins ▸ Create an executable it will call in Sources
127. QUICK RECAP OF PLUGIN CREATION ▸ Create a plugin in Plugins ▸ Create an executable it will call in Sources ▸ Use a codable object to pass data between them
128. QUICK RECAP OF PLUGIN CREATION ▸ Create a plugin in Plugins ▸ Create an executable it will call in Sources ▸ Use a codable object to pass data between them ▸ Note that the plugin depends on but cannot import the executable
129. ! BACK TO THE KITTAHS!
130. // In Cats/Package.swift dependencies: [ .package(url: "https://github.com/designatednerd/ DatedImageGenerator.git", from: "0.0.1"), .package(url: "https://github.com/icanzilb/ DoNilDisturbPlugin.git", from: "0.0.5"), ],
131. // In Cats/Package.swift .target( name: "Cats", dependencies: [ .product(name: "DatedImage", package: "DatedImageGenerator"), ], plugins: [ .plugin(name: "DatedImageGenerator", package: "DatedImageGenerator"), .plugin(name: "DoNilDisturbPlugin", package: "DoNilDisturbPlugin") ] ),
132. // In Cats/Package.swift .target( name: "Cats", dependencies: [ .product(name: "DatedImage", package: "DatedImageGenerator"), ], plugins: [ .plugin(name: "DatedImageGenerator", package: "DatedImageGenerator"), .plugin(name: "DoNilDisturbPlugin", package: "DoNilDisturbPlugin") ] ),
133. // In Cats/Package.swift .target( name: "Cats", dependencies: [ .product(name: "DatedImage", package: "DatedImageGenerator"), ], plugins: [ .plugin(name: "DatedImageGenerator", package: "DatedImageGenerator"), .plugin(name: "DoNilDisturbPlugin", package: "DoNilDisturbPlugin") ] ),
140. WHAT ABOUT RUNNING PLUGINS ON AN APP TARGET?
141. XCODE PROJECT PLUGIN
142. XCODE PROJECT PLUGIN (A KIND OF BUILD TOOL PLUGIN)
143. #if canImport(XcodeProjectPlugin) import XcodeProjectPlugin extension DatedImageGenerator: XcodeBuildToolPlugin { func createBuildCommands(context: XcodePluginContext, target: XcodeTarget) throws -> [Command] { let assetCatalogPaths = context.xcodeProject.filePaths .filter({ $0.string.hasSuffix("xcassets")}) .map { $0.string } // Rest of the code the same as in the main plugin } } #endif
144. #if canImport(XcodeProjectPlugin) import XcodeProjectPlugin extension DatedImageGenerator: XcodeBuildToolPlugin { func createBuildCommands(context: XcodePluginContext, target: XcodeTarget) throws -> [Command] { let assetCatalogPaths = context.xcodeProject.filePaths .filter({ $0.string.hasSuffix("xcassets")}) .map { $0.string } // Rest of the code the same as in the main plugin } } #endif
145. #if canImport(XcodeProjectPlugin) import XcodeProjectPlugin extension DatedImageGenerator: XcodeBuildToolPlugin { func createBuildCommands(context: XcodePluginContext, target: XcodeTarget) throws -> [Command] { let assetCatalogPaths = context.xcodeProject.filePaths .filter({ $0.string.hasSuffix("xcassets")}) .map { $0.string } // Rest of the code the same as in the main plugin } } #endif
146. #if canImport(XcodeProjectPlugin) import XcodeProjectPlugin extension DatedImageGenerator: XcodeBuildToolPlugin { func createBuildCommands(context: XcodePluginContext, target: XcodeTarget) throws -> [Command] { let assetCatalogPaths = context.xcodeProject.filePaths .filter({ $0.string.hasSuffix("xcassets")}) .map { $0.string } // Rest of the code the same as in the main plugin } } #endif
147. #if canImport(XcodeProjectPlugin) import XcodeProjectPlugin extension DatedImageGenerator: XcodeBuildToolPlugin { func createBuildCommands(context: XcodePluginContext, target: XcodeTarget) throws -> [Command] { let assetCatalogPaths = context.xcodeProject.filePaths .filter({ $0.string.hasSuffix("xcassets")}) .map { $0.string } // Rest of the code the same as in the main plugin } } #endif
154. SPM PLUGIN LIMITATIONS
155. SPM PLUGIN LIMITATIONS (that I've found so far)
156. SPM PLUGIN LIMITATIONS (that I've found so far) ▸ Still no UI for you
157. SPM PLUGIN LIMITATIONS (that I've found so far) ▸ Still no UI for you ▸ You can't even ask to use the network
158. SPM PLUGIN LIMITATIONS (that I've found so far) ▸ Still no UI for you ▸ You can't even ask to use the network ▸ You can't share data between plugins
159. SPM PLUGIN LIMITATIONS (that I've found so far) ▸ Still no UI for you ▸ You can't even ask to use the network ▸ You can't share data between plugins ▸ Can't do anything with build results
160. ! PLUGIN WISH LIST
161. PLUGIN WISH LIST ▸ File metadata
162. PLUGIN WISH LIST ▸ File metadata ▸ Ability to show UI in Xcode
163. OBLIGATORY SUMMARY SLIDE
164. OBLIGATORY SUMMARY SLIDE ▸ Alcatraz
165. OBLIGATORY SUMMARY SLIDE ▸ Alcatraz ! " Xcode 8 Extensions
166. OBLIGATORY SUMMARY SLIDE ▸ Alcatraz ! " Xcode 8 Extensions ▸ SPM Plugins to the rescue!
167. OBLIGATORY SUMMARY SLIDE ▸ Alcatraz ! " Xcode 8 Extensions ▸ SPM Plugins to the rescue! ▸ Command plugins: On demand, Build tool plugins: On every build
168. OBLIGATORY SUMMARY SLIDE ▸ Alcatraz ! " Xcode 8 Extensions ▸ SPM Plugins to the rescue! ▸ Command plugins: On demand, Build tool plugins: On every build ▸ Security: Be super-mindful of which plugins you use
169. OBLIGATORY SUMMARY SLIDE ▸ Alcatraz ! " Xcode 8 Extensions ▸ SPM Plugins to the rescue! ▸ Command plugins: On demand, Build tool plugins: On every build ▸ Security: Be super-mindful of which plugins you use ▸ Building plugins is a bit complicated, but also pretty fun
170. THANK YOU!
171. SWIFT-EVOLUTION LINKS! ▸ SE-0303: Extensible Build Tools github.com/apple/swift-evolution/ blob/main/proposals/0303-swiftpm-extensible-build-tools.md ▸ SE-0325: Additional Plugin APIs github.com/apple/swift-evolution/ blob/main/proposals/0325-swiftpm-additional-plugin-apis.md ▸ SE-0332: SPM Command Plugins github.com/apple/swift-evolution/ blob/main/proposals/0332-swiftpm-command-plugins.md
172. ! SLIGHTLY TERRIFYING LINKS! ▸ Xcode Ghost details: en.wikipedia.org/wiki/XcodeGhost ▸ Strawhorse leaked document: theintercept.com/document/ 2015/03/10/strawhorse-attacking-macos-ios-software- development-kit ▸ Strawhorse Context: theintercept.com/2015/03/10/ispy-cia- campaign-steal-apples-secrets/
173. ! PLUGIN LINKS! ▸ Do Nil Disturb: github.com/icanzilb/DoNilDisturbPlugin ▸ Swift SafeURL: github.com/baguio/SwiftSafeURL
