Dart & Henson - Better Android Intents

Presented at Andevcon SF 2016, DroidKaigi Tokyo 2017 and Andevcon Washington 2017

Transcript

1. BETTER ANDROID INTENTS
   DART & HENSON
   https://github.com/f2prateek/dart


   View Slide

2. ABOUT US
   Senior Android Dev @ Groupon

   ~20 years of Java coding
   OSS: Dart, TP, BoundBox, …
   STEPHANE NICOLAS
   DANIEL MOLINERO REGUERA
   Android Dev @ Groupon

   Turbulence Ninja
   OSS: Dart, TP.
   +stephane
   @D_Lemures


   View Slide

3. 5IF"OESPJE5FBNJT)JSJOH

   jobs.groupon.com/careers/


   View Slide

4. INTENTS & EXTRAS
   NAVIGATION LAYER
   DART: CONSUMING INTENTS
   ANNOTATIONS
   BINDING
   SETUP
   HENSON: CREATING INTENTS
   INTENT BUILDERS
   FLUENT API
   ANNOTATIONS
   SETUP
   CONCLUSION
   THE TALK


   View Slide

5. AN INTENT IS AN ABSTRACT DESCRIPTION OF
   AN OPERATION TO BE PERFORMED
   INTENTS & EXTRAS
   BROADCAST

   RECEIVER
   SERVICE
   ACTIVITY
   from developer.android.com/reference/android/content/Intent.html


   View Slide

6. AN INTENT IS AN ABSTRACT DESCRIPTION OF
   AN OPERATION TO BE PERFORMED
   INTENTS & EXTRAS
   ACTIVITY
   from developer.android.com/reference/android/content/Intent.html
   INTENT


   View Slide

7. EXTRAS CAN BE USED TO PROVIDE EXTENDED
   INFORMATION
   INTENTS & EXTRAS
   ACTIVITY
   from developer.android.com/reference/android/content/Intent.html
   INTENT
   EXTRAS


   View Slide

8. NAVIGATION LAYER
   ACTIVITY 1
   ACTIVITY 4
   ACTIVITY 2
   ALL INTENTS TOGETHER FORM
   THE NAVIGATION LAYER OF AN ANDROID APP
   ACTIVITY 3
   ACTIVITY 5
   ACTIVITY 6


   View Slide

9. NAVIGATION LAYER
   HOW TO ORGANIZE

   YOUR NAVIGATION LAYER ?


   View Slide

10. CONSUMING & CREATING INTENTS
    DEAL LIST

    ACTIVITY
    DEAL DETAIL

    ACTIVITY
    CREATING AN
    INTENT
    CONSUMING AN
    INTENT


    View Slide

11. View Slide

12. CONSUMING
    INTENTS


    View Slide

13. DART
    CONSUMING
    INTENTS


    View Slide

14. DART: CONSUMING INTENTS
    ACTIVITY
    String field1
    int field2
    boolean field3


    View Slide

15. DART: CONSUMING INTENTS
    ACTIVITY
    String field1
    int field2
    boolean field3
    INTENT


    View Slide

16. DART: CONSUMING INTENTS
    ACTIVITY
    String field1
    int field2
    boolean field3
    INTENT
    EXTRA 1 value 1
    EXTRA 2 value 2
    EXTRA 3 value 3
    EXTRAS


    View Slide

17. DART: CONSUMING INTENTS
    public class DealDetailActivity extends Activity {
    public static final String EXTRA_DEAL_ID = "EXTRA_DEAL_ID";
    public static final String EXTRA_SHOW_MAP = "EXTRA_SHOW_MAP";


    private String dealId;
    private boolean shouldShowMap;
    @Override
    public void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    dealId = getIntent().getStringExtra(EXTRA_DEAL_ID);
    shouldShowMap = getIntent().getBooleanExtra(EXTRA_SHOW_MAP, false);
    if (dealId == null) {
    throw new IllegalArgumentException("Deal Id is required");
    }
    ...
    }


    View Slide

18. public class DealDetailActivity extends Activity {
    public static final String EXTRA_DEAL_ID = "EXTRA_DEAL_ID";
    public static final String EXTRA_SHOW_MAP = "EXTRA_SHOW_MAP";


    private String dealId;
    private boolean shouldShowMap;
    @Override
    public void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    dealId = getIntent().getStringExtra(EXTRA_DEAL_ID);
    shouldShowMap = getIntent().getBooleanExtra(EXTRA_SHOW_MAP, false);
    if (dealId == null) {
    throw new IllegalArgumentException("Deal Id is required");
    }
    ...
    }
    DART: CONSUMING INTENTS


    View Slide

19. public class DealDetailActivity extends Activity {
    public static final String EXTRA_DEAL_ID = "EXTRA_DEAL_ID";
    public static final String EXTRA_SHOW_MAP = "EXTRA_SHOW_MAP";


    private String dealId;
    private boolean shouldShowMap;
    @Override
    public void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    dealId = getIntent().getStringExtra(EXTRA_DEAL_ID);
    shouldShowMap = getIntent().getBooleanExtra(EXTRA_SHOW_MAP, false);
    if (dealId == null) {
    throw new IllegalArgumentException("Deal Id is required");
    }
    ...
    }
    DART: CONSUMING INTENTS
    BOILERPLATE!!!


    View Slide

20. DART: ANNOTATIONS
    public class DealDetailActivity extends Activity {

    @InjectExtra String dealId;
    @InjectExtra @Nullable Boolean shouldShowMap;
    @Override
    public void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    Dart.inject(this);
    ...
    }
    }


    View Slide

21. DART: ANNOTATIONS
    DECLARE REQUIRED AND OPTIONAL FIELDS
    public class DealDetailActivity extends Activity {

    @InjectExtra String dealId;
    @InjectExtra @Nullable Boolean shouldShowMap;
    @Override
    public void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    Dart.inject(this);
    ...
    }
    }


    View Slide

22. DART: BINDING
    public class DealDetailActivity extends Activity {

    @InjectExtra String dealId;
    @InjectExtra @Nullable Boolean shouldShowMap;
    @Override
    public void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    Dart.inject(this);
    ...
    }
    }


    View Slide

23. DART: BINDING
    BIND INTENT EXTRAS TO ANNOTATED FIELDS
    public class DealDetailActivity extends Activity {

    @InjectExtra String dealId;
    @InjectExtra @Nullable Boolean shouldShowMap;
    @Override
    public void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    Dart.inject(this);
    ...
    }
    }


    View Slide

24. ACTIVITY MODEL
    String field1
    int field2
    boolean field3
    DART: BINDING A MODEL


    View Slide

25. ACTIVITY MODEL
    String field1
    int field2
    boolean field3
    DART: BINDING A MODEL
    SEPARATE EXTRAS AND ACTIVITIES


    View Slide

26. public class DealDetailModel {

    @InjectExtra String dealId;
    @InjectExtra @Nullable Boolean shouldShowMap;
    }
    MODEL:
    public class DealDetailActivity extends Activity {

    @Override
    public void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    Dart.inject(detailModelInstance, this);
    ...
    }
    ACTIVITY:
    DART: BINDING A MODEL


    View Slide

27. compile ‘com.f2prateek.dart:dart:2.0.1
    provided ‘com.f2prateek.dart:dart-processor:2.0.1
    GRADLE:

    com.f2prateek.dart
    dart
    2.0.1


    com.f2prateek.dart
    dart-processor
    2.0.1
    provided

    MAVEN:
    DART: SETUP


    View Slide

28. View Slide

29. CREATING
    INTENTS


    View Slide

30. HENSON
    CREATING
    INTENTS


    View Slide

31. public class CentralIntentFactory {
    public Intent newDealDetailActivityIntent(Context context,
    String dealId) {

    return new Intent(context, DealDetailActivity.class)
    .putExtra(EXTRA_DEAL_ID, dealId);

    }



    public Intent newDealDetailActivityIntent(Context context,

    String dealId,

    boolean showMap) {

    return new Intent(context, DealDetailActivity.class)

    .putExtra(EXTRA_DEAL_ID, dealId)

    .putExtra(EXTRA_SHOW_MAP, showMap);

    }

    ...

    }


    HENSON: CREATING INTENTS


    View Slide

32. public class CentralIntentFactory {
    public Intent newDealDetailActivityIntent(Context context,
    String dealId) {

    return new Intent(context, DealDetailActivity.class)
    .putExtra(EXTRA_DEAL_ID, dealId);

    }



    public Intent newDealDetailActivityIntent(Context context,

    String dealId,

    boolean showMap) {

    return new Intent(context, DealDetailActivity.class)

    .putExtra(EXTRA_DEAL_ID, dealId)

    .putExtra(EXTRA_SHOW_MAP, showMap);

    }

    ...

    }


    HENSON: CREATING INTENTS
    - MEYER’S OPEN/CLOSED PRINCIPLE
    - BIG BALL OF MUD


    View Slide

33. public class DealDetailActivity extends Activity {
    ...
    public static Intent getIntent(Context context,

    String dealId) {


    return new Intent(context, DealDetailActivity.class)

    .putExtra(EXTRA_DEAL_ID, dealId);

    }




    public static Intent getIntent(Context context,

    String dealId,

    boolean showMap) {


    return new Intent(context, DealDetailActivity.class)

    .putExtra(EXTRA_DEAL_ID, itemId)

    .putExtra(EXTRA_SHOW_MAP, showMap);

    }
    ...

    }


    HENSON: CREATING INTENTS


    View Slide

34. public class DealDetailActivity extends Activity {
    ...
    public static Intent getIntent(Context context,

    String dealId) {


    return new Intent(context, DealDetailActivity.class)

    .putExtra(EXTRA_DEAL_ID, dealId);

    }




    public static Intent getIntent(Context context,

    String dealId,

    boolean showMap) {


    return new Intent(context, DealDetailActivity.class)

    .putExtra(EXTRA_DEAL_ID, itemId)

    .putExtra(EXTRA_SHOW_MAP, showMap);

    }
    ...

    }


    HENSON: CREATING INTENTS
    BOILERPLATE!!!


    View Slide

35.

    HENSON: INTENT BUILDERS
    public class DealDetailActivity extends Activity {

    @InjectExtra String dealId;
    @InjectExtra @Nullable Boolean shouldShowMap;
    @Override
    public void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    Dart.inject(this);
    ...
    }
    }


    View Slide

36. DART & HENSON
    GENERATE THEM FOR YOU !


    HENSON: INTENT BUILDERS
    public class DealDetailActivity extends Activity {

    @InjectExtra String dealId;
    @InjectExtra @Nullable Boolean shouldShowMap;
    @Override
    public void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    Dart.inject(this);
    ...
    }
    }


    View Slide

37. public class DealDetailActivity$$IntentBuilder {

    private Intent intent;

    private Bundler bundler = Bundler.create();



    public DealDetailActivity$$IntentBuilder(Context context) {

    intent = new Intent(context, DealDetailActivity.class);

    }



    public DealDetailActivity$$IntentBuilder dealId(String dealId) {

    bundler.put("dealId", dealId);

    return this;

    }



    public DealDetailActivity$$IntentBuilder shouldShowMap(Boolean shouldShowMap) {

    bundler.put(“shouldShowMap", shouldShowMap);

    return this;

    }



    public Intent build() {

    intent.putExtras(bundler.get());

    return intent;

    }
    }


    HENSON: INTENT BUILDERS


    View Slide

38. public class DealDetailActivity$$IntentBuilder {

    private Intent intent;

    private Bundler bundler = Bundler.create();



    public DealDetailActivity$$IntentBuilder(Context context) {

    intent = new Intent(context, DealDetailActivity.class);

    }



    public DealDetailActivity$$IntentBuilder dealId(String dealId) {

    bundler.put("dealId", dealId);

    return this;

    }



    public DealDetailActivity$$IntentBuilder shouldShowMap(Boolean shouldShowMap) {

    bundler.put(“shouldShowMap", shouldShowMap);

    return this;

    }



    public Intent build() {

    intent.putExtras(bundler.get());

    return intent;

    }
    }


    HENSON: INTENT BUILDERS


    View Slide

39. public class DealDetailActivity$$IntentBuilder {

    private Intent intent;

    private Bundler bundler = Bundler.create();



    public DealDetailActivity$$IntentBuilder(Context context) {

    intent = new Intent(context, DealDetailActivity.class);

    }



    public DealDetailActivity$$IntentBuilder dealId(String dealId) {

    bundler.put("dealId", dealId);

    return this;

    }



    public DealDetailActivity$$IntentBuilder shouldShowMap(Boolean shouldShowMap) {

    bundler.put(“shouldShowMap", shouldShowMap);

    return this;

    }



    public Intent build() {

    intent.putExtras(bundler.get());

    return intent;

    }
    }


    HENSON: INTENT BUILDERS


    View Slide

40.

    HENSON: FLUENT API
    Intent intent = Henson.with(context)
    .gotoDealDetailActivity()
    .dealId(dealId)
    .shouldShowMap(true)
    .build();


    View Slide

41.

    HENSON: FLUENT API
    Intent intent = Henson.with(context)
    .gotoDealDetailActivity()
    .dealId(dealId)
    .shouldShowMap(true)
    .build();
    HENSON CLASS PROVIDES A FLUENT API
    TO ACCESS INTENT BUILDERS


    View Slide

42. HENSON: ANNOTATIONS
    @HensonNavigable
    public class SettingsActivity extends Activity {

    @Override
    public void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    ...
    }
    }


    View Slide

43. HENSON: ANNOTATIONS
    MAKE YOUR ACTIVITIES VISIBLE TO HENSON
    EVEN IF THEY DON'T USE DART ANNOTATIONS
    @HensonNavigable
    public class SettingsActivity extends Activity {

    @Override
    public void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    ...
    }
    }


    View Slide

44. public class DealDetailModel {

    @InjectExtra String dealId;
    @InjectExtra @Nullable Boolean shouldShowMap;
    }
    MODEL:
    @HensonNavigable(model = DealDetailModel.class)
    public class DealDetailActivity extends Activity {

    @Override
    public void onCreate(Bundle savedInstanceState) {
    super.onCreate(savedInstanceState);
    Dart.inject(detailModelInstance, this);
    ...
    }
    ACTIVITY:
    HENSON: ANNOTATIONS


    View Slide

45. compile ‘com.f2prateek.dart:henson:2.0.1
    provided ‘com.f2prateek.dart:henson-processor:2.0.1
    GRADLE:

    com.f2prateek.dart
    henson
    2.0.1


    com.f2prateek.dart
    henson-processor
    2.0.1
    provided

    MAVEN:
    HENSON: SETUP


    View Slide

46. CONCLUSION
    QUESTIONS ?
    COMMENTS ?


    View Slide

47. CONCLUSION
    QUESTIONS ?
    COMMENTS ?


    View Slide

48. BETTER ANDROID INTENTS
    DART & HENSON
    https://github.com/f2prateek/dart
    +stephane
    @D_Lemures


    View Slide
