From Ruby to Elixir

my talk at Sardines.rb (Lisbon Ruby meetup)

Transcript

1. from Ruby to Elixir


   View Slide

2. • why elixir?
   • historical context
   • quick intro
   • pipe operator
   • pattern-matching
   • processes
   • supervisors
   • phoenix
   • elixir in real life
   outline


   View Slide

3. • elixir
   • preemptive Erlang VM
   • yielding lightweight processes
   • no locks, no mutexes, etc.
   • ranch, cowboy
   • functional, immutable
   • ruby
   • MRI relies on GIL
   • OS processes, threads
   • locks, mutexes, etc.
   • WEBrick, unicorn, puma,
   passenger, etc.
   • OO, mutable
   why elixir?


   View Slide

4. historical context
   • Erlang (1986)
   • Ericsson (OSS 1998)
   • Ruby (1995)
   • Rails (2005)
   • F# (2005)
   • Clojure (2007)
   • Devise (2009)
   • Elixir (2009)


   View Slide

5. quick intro
   • integers
   • 2, 0xcafe, 0b100, 10_000
   • floats
   • 1.0, 3.1415, 6.02e23
   • lists
   • [1, 2, 3], [head|tail]
   • map
   • %{one: “un”, two: “deux”}
   • atom
   • :foo, :me@home, :elixir
   • tuple
   • {:ok, 11, ‘hi'}
   • keyword list
   • [a: :foo, b: :bar]
   • binary
   • <<104, 101, 108, 108, 111>>,
   “hello”


   View Slide

6. quick intro
   • functions
   • Enum.map/2, :erlang.localtime/0
   • examples
   • IO.puts(“Hello World”)
   • Map.get(%{one: “un”}, :one)
   • struct(User,
   %{fname: “John”, lname: “Doe”})
   # prints to stdout
   # returns “un”
   # returns a User struct
   # with first name “John”,
   # last name “Doe”


   View Slide

7. quick intro
   defmodule User do
   defstruct [:fname, :lname]
   def full_name(%User{fname: fname, lame: lname}) do
   “#{fname} #{lname}”
   end
   end
   $> user = %User{fname: “John”, lname: “Doe”}
   $> User.full_name(user)
   “John Doe”


   View Slide

8. pipe operator |>
   Enum.max(Enum.map(Enum.filter([1, 2, 3, 4, 5], fn x ->
   rem(x, 2) == 0 end), fn x-> x * 2 end))
   • find max of double the values


   View Slide

9. pipe operator |>
   Enum.max(
   Enum.map(
   Enum.filter(
   [1, 2, 3, 4, 5],
   fn x -> rem(x, 2) == 0 end
   ),
   fn x-> x * 2 end
   )
   )


   View Slide

10. pipe operator |>
    [1, 2, 3, 4, 5]
    |> Enum.filter(fn x -> rem(x, 2) == 0 end)
    |> Enum.map(fn x -> x * 2 end)
    |> Enum.max()
    # 8


    View Slide

11. pattern-matching
    def zero?(0), do: true
    def zero?(_), do: false
    zero?(0)
    zero?(3)
    zero?(“hello”)
    # true
    # false
    # false


    View Slide

12. pattern-matching
    def started_at_text(%Task{started_at: nil}), do: “Not started”
    def started_at_text(%Task{started_at: time} = task) do

    “Started task-#{task.id} @ #{DateTime.to_string(time)}”
    end
    def state(%Task{started_at: nil, closed_at: nil}), do: :waiting
    def state(%Task{started_at: nil}), do: :canceled
    def state(%Task{closed_at: nil}), do: :in_progress


    View Slide

13. processes
    process A process B


    View Slide

14. processes
    BEAM


    View Slide

15. processes
    BEAM
    2000 reductions each
    before yielding
    multiple schedulers
    ~1 per cpu


    View Slide

16. processes
    BEAM


    View Slide

17. processes
    BEAM


    View Slide

18. processes
    BEAM
    eu-west-1 us-east-1


    View Slide

19. supervisors
    BEAM


    View Slide

20. supervisors
    BEAM
    error


    View Slide

21. supervisors
    BEAM
    restart


    View Slide

22. one_for_one
    restart
    supervisors
    BEAM


    View Slide

23. one_for_all
    restart
    supervisors
    BEAM


    View Slide

24. phoenix


    View Slide

25. phoenix


    View Slide

26. phoenix
    Ruby Elixir
    Rack Plug
    Rails Phoenix
    ActiveRecord Ecto
    ERB EEx


    View Slide

27. elixir in real life
    • 1.5 billion page views per month
    • 200.000 concurrent users
    • resource intensive features
    • previously aggressive horizontal scaling
    • now 1/10th servers with low CPU usage


    View Slide

28. elixir in real life
    • 100.000 concurrent users
    • previously Java
    • now Erlang, Go and Elixir
    • 10.000s to 100.000s users per machine


    View Slide

29. elixir in real life
    • 11.000.000 concurrent users
    • 2.600.000 concurrent voice users
    • 220 Gbps
    • 120 Mpps


    View Slide

30. elixir in real life
    • media service handling millions of reqs/day
    • biometrics aggregator service handling
    100.000s connections per day
    • average of 6 Kubernetes pods
    • cpu limits of 600m
    • mem limits of 512Mi


    View Slide

31. the end
    thank you
    dnlserrano.dev
