This is the slide deck from a talk I gave about the StackStorm CI/CD pipeline.

https://www.youtube.com/watch?v=nVXVqWnEdtE

Patrick Hoolboom

May 07, 2015
Tweet

More Decks by Patrick Hoolboom

Other Decks in Technology

Transcript

  1. 1
    How StackStorm Builds & Runs
    StackStorm
    May 2015

    View Slide

  2. Actions
    Automations
    Infrastructure – Cloud – Applications – Tools – Processes
    {.}
    {.}
    Sensors
    Audit

    View Slide

  3. StackStorm Solution
    3
    Master
    Content Repo
    PLATFORM
    Web GUI CLI Chatops
    CLIENTS
    Sensor Plugins
    (inbound integrations)
    Action Plugins
    (outbound integrations)
    INTEGRATIONS
    .yml
    REST API Rules Engine Workflow Engine
    Audit…
    A
    M
    Q
    P
    m
    e
    s
    s
    a
    g
    e
    b
    u
    s
    A
    M
    Q
    P
    m
    e
    s
    s
    a
    g
    e
    b
    u
    s
    /
    /
    /
    /
    {*} IFTTT
    No N! issue
    No N! issue
    Loosely coupled; users
    abstract automation
    from integration
    Loosely coupled; users
    abstract automation
    from integration
    Workflow and rules
    enable simple scripts to
    be tied together like
    Legos. Automate &
    share pipelines.
    Workflow and rules
    enable simple scripts to
    be tied together like
    Legos. Automate &
    share pipelines.
    Polished – with GUI,
    ChatOps, CLI, RBAC,
    error handling, help &
    more
    Polished – with GUI,
    ChatOps, CLI, RBAC,
    error handling, help &
    more

    View Slide

  4. Why now?
    4
    IT does matter. A lot.
    Orchestration can deliver agility
    More change, more tools, DevOps
    = new requirements for automation

    View Slide

  5. What Problems Are We Solving?
    • Automated Testing (CI)
    – Integration testing on every commit to all supported
    versions
    • Packaging & Shipping (CD)
    – Distro specific packages on every successful build
    – Fully automated delivery to all repositories
    5

    View Slide

  6. Private and confidential

    View Slide

  7. View Slide

  8. How Is It Built?
    • GitHub Sensor
    – GitHub post commit hooks are received by a GitHub
    sensor
    • ActionChains
    – All workflows are written using the sequential
    workflow runner - ActionChain
    • ActionTriggers
    – Workflows are tied together using the trigger that is
    emitted on completion of an action execution.
    • Rules
    – Rules are used to enforce workflow execution
    preconditions
    8

    View Slide

  9. Other Technologies
    • StackStorm Datastore
    – Last build number, stable release branch
    • Consul
    – Service Discovery for build & packaging
    • AWS
    9

    View Slide

  10. 1. GitHub Commit
    10
    On each merge in to the monitored branches, both the unit tests, and the Mistral
    Integration Tests are fired.

    View Slide

  11. 2. Packaging for Staging
    11
    Successful unit tests fire off packaging of all components, including documentation,
    and ship to the staging environment.

    View Slide

  12. 3. Deploy to Staging
    12
    Packaging workflows will trigger upgrades on the staging hosts of the appropriate
    distro.

    View Slide

  13. 4. Smoke Test - Staging
    13
    On successful completion of the upgrade, basic smoke tests are ran.

    View Slide

  14. 5. End to End Test - Staging
    14
    Successful completion of the smoke tests, will trigger the full end to end testing suite.
    This includes all documented examples and deployment scripts.

    View Slide

  15. 6. Tag & Cut Release
    15
    Upon completion of end to end tests, the release is tagged and a new patch branch
    is created.

    View Slide

  16. 7. Package & Deploy
    16
    The release triggers the production packaging workflow. This workflow takes the
    blessed packages and delivers them to the production repositories.

    View Slide

  17. Why Build It Ourselves?
    • Eating Our Own Dog Food
    – Continuous validation of StackStorm as a CI/CD
    solution
    • The Ultimate Acceptance Testing
    • Bragging Rights
    17

    View Slide

  18. What's Next?
    • Containers
    – Unit Tests & Packaging Moved to Containers
    • ChatOps Improvements
    – Full Two Way ChatOps Integration
    18

    View Slide

  19. Want More Info?
    • St2 Continuous Delivery Integration Pack
    https://github.com/StackStorm/st2incubator/tree/master/packs/st2
    cd
    • IRC: Freenode #stackstorm
    [email protected]
    19

    View Slide

  20. Check Out Our new Meetup!
    Auto-Remediation and Event Driven Automation
    • http://www.meetup.com/Auto-Remediation-and-Event-Driven-Automation/
    • Thursday May 14, 2015 6:30pm
    • LinkedIn: 2029 Stierlin Ct, Mountain View, CA
    20

    View Slide

  21. Thank You
