Prometheus
Operator
A tale about
container
monitoring at
iFood
Volume I
by: Daniel Requena

View Slide

Index
Editor's Note ……………………………………………………….. 1
Foreword ...………………..…………...………………..………….. 2
Chapter I - Bare Metal Dungeons .……..….………… 3
Chapter II - Cloudy Mountains .………….……………. 4
Chapter III - The ignorance desert ..………….………. 5
Chapter IV - Container Harbor ..………….…………..… 6
Chapter V - The next adventure ………………………..7
References ..………………..…………...………………..………….9
About the author …………...………………..…………………..10

View Slide

Editor's Note
● This tale is based in facts.
● Characters and ﬁctional elements have been added for the
sake of a better storytelling.
● The main character is a chimera of iFood's SRE team for the
past 6 years or so.
● The only focus of this presentation is Monitoring.

View Slide

Foreword
This Adventure's slides are already available
https://speakerdeck.com/drequena/

View Slide

Chapter I
Bare Metal Dungeons

View Slide

Chapter I - Bare Metal Dungeons

View Slide

Class: Human
Race : Warrior
Level: 10
XP : 2 years
-------------
Int : #####
Str : ########
Dex : ###
STA : #
Tools:
. Linux (int)
. Networking (int)
. Bash (int)
. Pyrhon (bgn)
. Zabbix (bgn)

View Slide

Hello fellow Linus! I'm
ScrumMaster, the Bard!
Are you looking for a great
Monitoring adventure?
I heard that beyond the
dark forest, there is a
site called Bare Metal
Dungeons.
A place full of big
challenges: Racks Servers,
VMs, switches, etc...
A big reward in eXPerience
is promised to the hero who
answer to the call. Are you
interested?
Scrum Master,
the Bard
Linus, the
Sysadmin

View Slide

Hello my good friend!
A fare adventure you are
proposing to me.
I shall accept this
challenge rightway!
To the Bare Metal Dungeons
I SAY!
Accept my LinkedIn proﬁle
as a form of gratitude.
Thanks for the opportunity,
I hope to see you soon.
Good Bye!
Scrum Master,
the Bard
Linus, the
Sysadmin

View Slide


View Slide

The Bare Metal Dungeons landscape
● Physical servers
● Manual provisioned VMs
● Network devices
● Databases
● Web Servers
● Monolithic app
● Few users

View Slide

● Weapon of choice: Zabbix
○ Basic templates
○ Custom Templates
○ Bash scripts
○ Python integrations
○ E-mail alerts
○ ...

View Slide

● At the end...
○ More dynamic workloads
■ LLD
○ A lot of Custom Items
○ Some Web Scenarios (urg!)
○ Starting to use Chef
○ ...

View Slide

Class: Human
Race : Warrior
Level: 15
XP : 4 years
-------------
Int : ######
Str : ##########
Dex : ####
STA : #####
Tools:
.Linux (adv)
.Networking (int)
.Bash (adv)
.Pyrhon (int)
.Zabbix (int)
.Chef (bgn)
.AWS (bgn)

View Slide

Chapter II
Cloudy Mountains

View Slide

Chapter II - Cloudy Mountains
Hello again my dear friend
Linus!
Congrats on your success in
your last mission! I
believe you were looking
for vacations, am I right?
However, a new quest awaits
for you!
All applications and
systems are now moving to
the Cloudy Mountains.
Your mission is to support
the monitoring tasks after
the the brave DEV teams
break down the Monolithic
Dragon.
For that, A LOT of servers
will be created.
Scrum Master,
the Bard
Linus, the
Sysadmin

View Slide

Greetings my under occupied
friend!
A new quest you say! I must
accept rightway again.
So, the Monolithic Dragon
shall be broken down,
right?
And you said something
about the creation of a lot
of servers too.
Tell me, my slacker friend,
are you talking about how
many servers? 70?
Scrum Master,
the Bard
Linus, the
Sysadmin

View Slide

A little more.
Scrum Master,
the Bard
Linus, the
Sysadmin

View Slide

140 servers?
Scrum Master,
the Bard
Linus, the
Sysadmin

View Slide

A little more.
Scrum Master,
the Bard
Linus, the
Sysadmin

View Slide

Oh wow! More than 140? Are we
talking about 400 servers?
Scrum Master,
the Bard
Linus, the
Sysadmin

View Slide

There will be at least 1000
servers. Many dynamically
created by ASGs and others
created on AWS painel with no
previous notice.
Ow! And you shall monitor all
kinds of AWS componentes too.
Scrum Master,
the Bard
Linus, the
Sysadmin

View Slide

You know what? I'm starting
to reconsider our friendship
dude.
Scrum Master,
the Bard
Linus, the
Sysadmin

View Slide


View Slide

Cloudy Mountains landscape
● Migrate to Cloud: "Lift and shift".
○ Monolith at large scales
○ ASGs
○ HTTP routing
○ Big database
● Zabbix was still the only weapon of choice.
○ Dynamically registering hosts
○ Monitoring only infrastructure

View Slide

● The slow killing of the Monolithic Dragon.
○ More instances (asg)
○ SQS/SNS
○ More databases - ro/rw (asg)
○ Loadbalancers
○ Buckets
○ DynamoDB tables
○ Lambdas
○ Elastic Cache systems

View Slide

● Zabbix became complex and not the only weapon
○ Adding and removing hosts, LBs, SQS, etc...
○ API throttle
○ Ghost hosts and items
■ False alarms
○ Async process (SQS/SNS/Lambda)
● New weapons
○ CloudWatch
○ Lambdas

View Slide


View Slide

Class: Human
Race : Warrior
Level: 19
XP : 6 years
-------------
Int : ########
Str : ############
Dex : ######
STA : #######
Tools:
.Linux (adv)
.Networking (int)
.Bash (adv)
.Pyrhon (int)
.Zabbix (int)
.Chef (adv)
.AWS (adv)
.Terraform (adv)

View Slide

Chapter III
The ignorance desert

View Slide

Chapter III - The ignorance desert
Linus! My old friend! Long
time we don't see…
You know! I was wondering...
Scrum Master,
the Bard
Linus, the
Sysadmin

View Slide

Oh now WHAT?! Tell me WHAT
THE F*CK are you put me into
now!
Scrum Master,
the Bard
Linus, the
Sysadmin

View Slide

WOW! so aggressive.Calm
down.
Have you heard about the
Kubernetes feaver?
Apparently it is the NEW
silver bullet to all
problems.
All apps are now moving to
Kubernetes and no previous
monitoring solutions are
good to it.
Your quest is to monitor
Kubernetes itself and also
all apps inside it.
You must go fast to the
container harbor before the
ships starts to departure.
Scrum Master,
the Bard
Linus, the
Sysadmin

View Slide

IIRC, containers can be
created and destroyed in
seconds!
No tool that I'm aware of
can handle that kind of
elastic workload!
I must wander through the
desert of ignorance in
order to ﬁnd a suitable
tool for this situation.
Wish me luck! And the next
time we see each other,
just don't talk to me
anymore.
Scrum Master,
the Bard
Linus, the
Sysadmin

View Slide


View Slide

Prometheus
○ OpenSource
○ Lightweight
○ Simple Architecture
○ Pull based
○ "Agentless"
Alert Manager
○ Routing
○ Grouping
○ Deduplication
○ TSDB based (fast and small storage usage)
○ HTTP based
○ Powerful query language (PROMQL)
○ YAML ﬁle conﬁg
○ Service Discovery (*)
○ Notifying
○ Integrations

View Slide

Prometheus
tsdb
APP
kube_deployment_spec_replicas{deployment="coredns",endpoint="http",instance="100.108.141.184:8080",jo
b="kube-state-metrics",namespace="kube-system",pod="prometheus-operator-kube-state-metrics-78fb6c979-
nxrlc",service="prometheus-operator-kube-state-metrics"} 2
Prometheus
tsdb
APP
exporter
GET /metrics
GET /metrics
Get metrics
from app
somehow.
Reply in Prometheus
metrics standard

View Slide

Prometheus
tsdb
APP
Alert
Manager
Rules:
avg(metric) > 10
label: critical
Condition
Error!
Solved!
#Alerts
GET metrics
metric = 11
Store
Check
Result
route:
receiver: slack-general
group_by:
- job
routes:
- receiver:
slack-integration
match:
severity: critical
continue: true

View Slide

Consul
K8S
File
Prometheus
Prometheus
SD
- job_name: monitoring/myapp/0
scrape_interval: 30s
metrics_path: /metrics
kubernetes_sd_configs:
- role: endpoints
namespaces:
names:
- app
relabel_configs:
- source_labels:
[__meta_kubernetes_service_label_app]
separator: ;
regex: app
replacement: $1
action: keep
tsdb
AWS
DNS
App Endpoints:
- 100.101.30.1
- 100.101.30.2
- 100.101.30.3
- 100.101.30.4
app-pod1
app-pod2
app-pod3
app-pod4
GET /metrics
GET /metrics
GET /metrics
GET /metrics

View Slide


View Slide

The prometheus DIY problem
● Prometheus
● AlertManager
● Grafana
● K8s monitoring
○ Node Exporter
○ Kube state metrics
○ Internal components
■ API server
■ Etcd
■ CoreDNS
Custom apps
Grafana
Dashboards
Custom Alerts
Multiples
Prometheus
■ Kubelet
■ Controllers
■ Schedulers
■ KubeProxy
■ CNI
Custom Rules
AlertManager
Cluster
Defining
all
AS
CO
DE
Validation
Pipelines
Updates / Upgrades

View Slide

Operator Witch

View Slide

Operator Witch
Linus, the
Sysadmin
I can feel your despair my
young warrior. But fear
not! Cause I bring good
news to you.
I will teach you an old but
very powerful spell so you
can summon a complete
Prometheus stack.
With that your kubernetes
cluster shall be monitored
in a extensible and ﬂexible
way.
But be aware my dear
sysadmin! "What easy comes,
easy goes".

View Slide

Prometheus Operator

View Slide

Prometheus Operator ?
An operator is a pattern in which a software or even a platform is
configured, provisioned and managed using Kubernetes objects
(usually CRDs). That pattern gives flexibility and a single "language"
for kubernetes users and administrators to use.
Operators are normally composed by custom controllers that handle
defined CRDs and take actions against it, converging the managed
software state to the desired state just like a standard k8s object.
○ Operators examples:
■ Jenkins, Mongo, Mysql, Cassandra, Spark and many more...

View Slide

Prometheus Operator*
○ Prometheus Operator
○ Prometheus
○ AlertManager
○ Grafana
○ Node Exporter
○ Kube State Metrics
○ Prebaked Alerts
○ Cluster Dashboards
* Helm-chart
○ Kubernetes monitoring
■ API
■ Controllers
■ Schedulers
■ CoreDNS
■ CNI
■ Kubelet
■ KubeProxy

View Slide

Prometheus Operator
○ CRDs
■ Prometheus
■ AlerManager
■ PrometheusRule *
■ ServiceMonitor *
■ PodMonitor (iirc still in Beta)
Each CRD have its on API spec (see doc)

View Slide

Prometheus Operator
PrometheusRule and ServiceMonitor CRDs
- Brings ﬂexibility to monitor and alerting on any application (or
exporter) that can expose metrics using Prometheus standard, without
the SD syntax hell and the operational burden to validate, merge and
reload daemons.

View Slide

Prometheus Operator

View Slide

Prometheus Operator
○ AlertManager and Prometheus
■ Resources
■ Storage
■ Replicas
■ Retention
■ Namespace and object selectors
■ LogLevel
■ Docker image/tag (*)
■ And many more...

View Slide

[email protected]:~# helm install --namespace monitoring stable/prometheus-operator
Prometheus Operator (Installing)

View Slide

Operator Witch
Linus, the
Sysadmin
Oh! so wonderful!
An eternal debt to you I
have milady!
I didn't quite understand
your last verse, I must
admit.
But since the stack is all
set, who cares?
I must go now! thank you
very much!

View Slide

Class: Human
Race : Warrior
Level: 19
XP : 6 years
-------------
Int : ###########
Str : ###############
Dex : #########
STA : #########
COURAGE BOOST (#)
Tools:
.Linux (adv)
.Networking (int)
Bash (adv)
Pyrhon (int)
Zabbix (int)
.Chef (adv)
.AWS (adv)
.Terraform (adv)

View Slide

Chapter IV
Container Harbor

View Slide

Chapter IV - Container Harbor

View Slide

Container Harbor landscape
○ Dozens of kubernetes clusters (kops)
○ Prometheus Operator (helm)
■ Prometheus and Alertmanager
● Exposed by Ingress (web interfaces)
● 45 days of retention
● 500m CPU / 4G RAM
■ Slack as AlertManager Receiver
● Custom message templates
■ Grafana and Dashboards with Prometheus as DataSource
○ Jenkins as CI/CD system for apps

View Slide

Container Harbor - The happy Path
○ Install Prometheus Operator
○ Monitor entire cluster by default
○ Monitor internal Apps easily
○ Create custom Dashboards
○ Create custom alerts
○ "And Bob is your uncle!"

View Slide

Container Harbor - The happy Path

View Slide

Container Harbor - The REAL Path
○ Prometheus Targets:
■ ETCd not monitored ‍♂
■ Consequently not alarming.
Default ServiceMonitor from Prometheus Operator doesn't support
ETCd with TLS.
Solution:
Generate signed key and certiﬁcate based on K8s API and create a
secret on Prometheus Operator namespace and reference the ﬁles in
Chart values.

View Slide

Container Harbor - The actual Path
Snipped…. from values.yaml
kubeEtcd:
serviceMonitor :
caFile: /etc/prometheus/secrets/etcd-client/CA.crt
certFile: /etc/prometheus/secrets/etcd-client/CERT.crt
keyFile: /etc/prometheus/secrets/etcd-client/KEY.key
prometheus:
prometheusSpec :
secrets:
-

View Slide

○ Prometheus Targets:
■ KubeProxy no monitored
■ Consequently not alarming.
Kops listen KubeProxy metrics ports at 127.0.0.1 by default
Solution:
cluster.yaml (kops snipp) .
... .
kubeProxy: .
metricsBindAddress: 0.0.0.0 .
... .

View Slide

○ Prometheus and AlertManager
■ Both doesn't have Auth method to the Web-UI
■ Especially important to AlertManager
⚠
Solution:
Use a Auth solution over Ingress Layer.
- ldap-proxy (helm installed)
Grafana supports .toml ﬁle in order to auth on Ldap ❤

View Slide

○ Default Alarms uncalibrated.
○ Too many firings
■ ex: Pods CPU Throttling
○ "wrong" classifications.
■ ex: Pods restarting too many times (Warning level)
Solution:
Full Alarms check up.
Rebuild YAML file using jsonnet (good luck with that )
Substitute original alarms (service-monitors) with our calibrated ones.

View Slide

Container Harbor.

View Slide

Container Harbor.
● ServiceMonitor and PrometheusRule files
○ Per app on repositories
○ Later on our Helm Chart
● Custom Grafana Dashboards per app! ❤
○ configmap: labels -> grafana_dashboard: "1"
One "small" problem:
Some files were not appearing on our clusters. Syntax errors!
Linters from Prometheus Operator project (pipelines)
Solved in later Prometheus Operator version (admissionWebhook)

View Slide

Container Harbor.
Prometheus metrics became a thing!
● Lots of apps starting to expose them.
● Why not to expose them on ec2 apps?
○ Where store them?
○

Solution:
EC2 SD based on labels:
- PrometheusScrape: true

View Slide

Container Harbor.
Secret on Prometheus Operator's namespace.
name: prometheus-operator-prometheus-scrape-config
data: additional-scrape-configs.yaml:
- ec2_sd_configs: .
- endpoint: "" .
filters: .
- name: tag:PrometheusScrape .
values: .
- true .
… .
Reference on Prometheus object:
spec: .
additionalScrapeConfigs: .
key: additional-scrape-configs.yaml .
name: prometheus-operator-prometheus-scrape-config .

View Slide

Container Harbor.
Custom apps metrics, let's scale by it!
Solution:
Prometheus Adapter. (helm)
kubectl get APIService v1beta1.metrics.k8s.io ...
NAME SERVICE AVAILABLE ...
v1beta1.metrics.k8s.io kube-system/metrics-server True ...
v1beta1.custom.metrics.k8s.io kube-system/prometheus-adapter True
v1beta1.external.metrics.k8s.io kube-system/prometheus-adapter True

View Slide

Container Harbor.
apiVersion: autoscaling/v1beta1
kind: HorizontalPodAutoscaler
metadata:
name: my-app-hpa
spec:
scaleTargetRef:
apiVersion: apps/v1
kind: Deployment
name: my-app-to-scale
minReplicas: 1
maxReplicas: 10
metrics:
- type: custom
external:
metricName: Custom-metric-name
targetValue: 1500
Prometheus
tsdb
APP
GET /metrics
Prometheus
Adapter
Query metics
Prom metrics
Kubernetes
API
v1beta1.custom.metrics.k8s.io
v1beta1.external.metrics.k8s.io

View Slide

Container Harbor.
Scaling by external metrics, an example:
● Scaling by number of messages in SQS
● Tiamat
○ Collect queue stats and stores at prometheus.
○ Labels deﬁnes queue IDs
○ Plans to support
■ Kafka topics
■ ...

View Slide

Container Harbor.
apiVersion: autoscaling/v1beta1
kind: HorizontalPodAutoscaler
metadata:
name: my-app-hpa
spec:
scaleTargetRef:
apiVersion: apps/v1
kind: Deployment
name: my-app-to-scale
minReplicas: 1
maxReplicas: 10
metrics:
- type: custom
external:
metricName: My_queue_size
targetValue: 1500
Prometheus
tsdb
GET /metrics
Prometheus
Adapter
Query metics
Prom metrics
Kubernetes
API
v1beta1.external.metrics.k8s.io
Tiamat
My_queue_size: 2300

View Slide

Container Harbor.
● Many metrics (k8s and ec2 apps)
● Lots! lots! of Grafanas (datasource -> k8s prometheus)
● Gigantic queries!

View Slide

Container Harbor.
Solution:
Adjust Resources: Requests and Limits (CPU and Memory)
Use restrictive ﬂags.
- --query.max-samples=30000000
- --query.max-concurrency=4
- --query.timeout=1m (use carefully)
Prometheus object:
query:
maxConcurrency: 4
maxSamples: 30000000
timeout: 1m (use carefully)

View Slide

Container Harbor.
Solution (plus)
● Last unﬁnished query will be prompted on terminal (a clue at least)
● Since 2.16 Prometheus have a query log option
global: .
scrape_interval: 15s .
evaluation_interval: 15s .
query_log_file: /prometheus/query.log .

View Slide

Container Harbor.
● Scraped Metrics can also go wrong.
● Really wrong!
● Like knockout wrong

View Slide

Container Harbor.
Why? The cardinality hell.
Each unique set of labels in a metric is considered a new time series.
Highly mutable labels becomes a explosion of resource consumption
Solution:
Query and look for a big spike!
rate(prometheus_tsdb_head_series_created_total[_PERIOD_])
Fix metrics.
dns_query_count{deployment="myserver",endpoint="http",instance="100.108.141.184:8080",job="my_dns_app",nam
espace="dns",pod="dns-server-78fb6c979-nxrlc",query="assdfewr.onsite.com"} 234.03

View Slide

Container Harbor.
Even tuning, sometimes Prometheus explodes anyway
● Big queries for internal apps
● Cluster monitoring compromised
apiVersion:
monitoring.coreos.com/v1
kind: Prometheus
ruleNamespaceSelector:
matchExpressions:
- key: tribe
operator: NotIn
values:
- infra
serviceMonitorNamespaceSelector:
matchExpressions:
- key: tribe
operator: NotIn
values:
- infra
apiVersion:
monitoring.coreos.com/v1
kind: Prometheus
ruleNamespaceSelector:
matchExpressions:
- key: tribe
operator: NotIn
values:
- custom-apps
serviceMonitorNamespaceSelector:
matchExpressions:
- key: tribe
operator: NotIn
values:
- custom-apps

View Slide

Container Harbor.
● "Solution" (more of a mitigation…)
Prometheus
Infra
K8s
API
CoreDn
s
Infrastructure
Node groups
Prometheus
Apps
App2
App1
Other nodes
groups
... ...

View Slide

Container Harbor.
AlertManager
● Responsible to route alerts
● Single point of failure
● By default just 1 replica.
● Capable to create HA cluster.
Solution: (super easy)
AlertManager object (CRD)
Replicas: 3

View Slide

Container Harbor.
How about Prometheus HA?
● Prometheus does not create clusters
Prometheus
tsdb
APP-4
APP-3
APP-2
APP-1

View Slide

Container Harbor.
How about Prometheus HA?
● More replicas.
○ Duplicate metrics
○ Doesn't solve 100% problem
● Super easy to implement
api:monitoring.coreos.com/v1 .
kind: Prometheus .
metadata: .
name: Prometheus .
spec: .
Replicas: 2 .
… .
Prometheus
tsdb
APP-4
APP-3
APP-2
APP-1
Prometheus
tsdb

View Slide

Container Harbor.
● Solution:
○ Remote Write/Read
S3
External
Solution
Read/Write
Deduplication and
Long term storage S3
S3
S3
HA Storage
cluster
Fill Gaps
Prometheus
APP4
APP3
APP2
APP1
Prometheus ...

View Slide

Chapter V
The next adventure

View Slide

Unsolved problems yet...
● How to organize Federated prometheus
○ Number of grafanas
● Flexible alerting with AlertManager
○ Today ﬁxed channels and routes
○ Hard to create new ones
● Remote Read / Remote Write (Cortex / Thanos)
○ HA
○ Metrics Dedup
○ Long term persistence
Chapter V - The next adventure

View Slide

To be continued...

View Slide

References
● https://prometheus.io/
● https://github.com/coreos/prometheus-operator
● https://github.com/helm/charts/tree/master/stable/prometheus-operator
● https://www.youtube.com/watch?v=pRmnh8lgjsU
● https://kubernetes.io/docs/concepts/extend-kubernetes/operator/
● https://coreos.com/blog/introducing-operators.html
● https://operatorhub.io/
● https://github.com/tiagoapimenta/nginx-ldap-auth
● https://github.com/hugobcar/tiamat
● https://github.com/helm/charts/tree/master/stable/grafana
● https://github.com/DirectXMan12/k8s-prometheus-adapter
● https://cortexmetrics.io/
● https://www.youtube.com/watch?v=b_pEevMAC3I

View Slide

About the author
[email protected]
@Daniel_Requena
github.com/drequena
@daniel_requena
speakerdeck.com/drequena
linkedin.com/in/danielrequena/
Daniel Requena

View Slide

Prometheus Operator, a tale about container monitoring at iFood (volume I)

Prometheus Operator, a tale about container monitoring at iFood (volume I)

drequena

More Decks by drequena

Other Decks in Technology

Featured

Transcript
