Darko Grozdanovski - THE POWER OF EMM

Transcript

1. THE POWER OF EMM Darko Grozdanovski Solutions Architect DEPLOY ENTERPRISE-READY APPS FASTER
2. On the agenda today: • What is an EMM? • What is AppConfig? • Code an app with Managed Configuration • Overview of the deployment workflow • Create a managed configuration
3. What is an EMM? Enterprise mobility Management
4. What is an EMM? The infrastructure that enables organizations to run their enterprise apps, manage and secure the corporate data
5. Challenges in deploying to the enterprise
6. Developing for the end consumers • Deploying directly to the end users through Google Play
7. Traditional enterprise deployment • Distributing versions directly to organizations • Still used a lot for in-house apps
8. Traditional enterprise development lifecycle
9. Modern enterprise deployment • Always deploy using EMM and Google Play • Distribute using Managed Configurations
10. Modern enterprise development lifecycle
11. What is AppConfig? • The community’s mission is to streamline the adoption and deployment of mobile enterprise applications by providing a standard approach to app configuration and management, building upon the extensive app security and configuration frameworks available in the OS. https://appconfig.org
12. Benefits for Developers • EMM vendor neutral solution • Reduce need for proprietary SDK • Reduce need for App Wrapping
13. Benefits for Enterprises • Leverage existing EMM investments • Better native onboarding user experience • Greater selection of business apps
14. Members of AppConfig - EMM • 20+ EMM vendors are part of the community
15. Members of AppConfig - Apps • A huge ecosystem of apps that are part of the community • New ones are constantly added • In-house apps can also use it
16. When you DON‘T NEED to write code • Lock down a device into kiosk • Create an app VPN • Single Sign On with existing identity management providers • Disable screen capture • Disable copy/paste • Restrict input methods • Whitelist/Blacklist specific system apps
17. And many more options…
18. When you NEED to write code • Deliver managed app configurations
19. What are Android Managed Configurations
20. Android Managed Configuration
21. Android Managed Configuration
22. AppConfig - Managed Configuration • Create and manage application configurations directly the EMM admin console • A set of native Android API‘s enabling a deeper integration with an EMM system • Empowers the IT admin and eases app deployments
23. What can be configured?
24. Any combination of key value pairs that an app needs including dynamic user/device related properties
25. Device attributes • Make use of attributes that are normally not available for apps
26. User attributes • Receive and use data that identifies the enterprise user
27. Custom device or user attributes • Forward attributes from an Identity provider such as Active Directory • Manually define attributes and their values
28. Common configuration options • Username – typically full email address or just company domain for easier sign in • Server/Resource endpoint configurations • Crash reporting on/off • Device analytics on/off • On-device data retention policies • Prefered apps to interact with (for sending emails, opening PDF, viewing images)
29. Limitations and drawbacks of using Android managed configurations
30. Limitations and drawbacks • Testing the integration • Only works in Android Enterprise deployments • Requires Android 5.0 and up • Some API methods are available starting from Android 5.1 and 6.0 • Only primitive values can be delivered – No files/images etc…
31. How to get around some of these limitations • Provide reasonable defaults in case a managed configuration cannot be used • Know your audience – Ask the organization about the devices they are using, specifically their OS version • Host complex configurations/files/photos that the app needs and point to those with an identifier through configuration – Ex. https://mycdn.com/mobileiron/logo.png - where „mobileiron“ is the identifier to the resources for the specific organization.
32. How to implement “Managed Configurations” into an Android app
33. Add metadata to the application manifest <meta-data android:name="android.content.APP_RESTRICTIONS" android:resource="@xml/app_restrictions" />
34. Add XML file with app restrictions <?xml version="1.0" encoding="utf-8"?> <restrictions xmlns:android="http://schemas.android.com/apk/res/android" > <restriction android:key="string" android:title="string resource" android:restrictionType=["bool" | "string" | "integer" | "choice" | "multi-select" | "hidden" | "bundle" | "bundle_array"] android :description="string resource" android :entries="string-array resource" android :entryValues="string-array resource" android :defaultValue="reference" > <restriction …/> ... </restriction> <restriction …/> ... </restrictions> src/main/res/xml/app_restrictions.xml
35. Field Type - Boolean <restriction android:defaultValue="@bool/default_can_increment_number" android:description="@string/description_can_increment_number" android:key="can_increment_number" android:restrictionType="bool" android:title="@string/title_can_increment_number"/>
36. Field Type - String <restriction android:defaultValue="@string/default_welcome_text" android:description="@string/description_welcome_text" android:key="welcome_message" android:restrictionType="string" android:title="@string/title_welcome_text"/>
37. Field Type - Number <restriction android:defaultValue="@integer/default_number" android:description="@string/description_number" android:key="number" android:restrictionType="integer" android:title="@string/title_number"/> • Is validated in the admin UI • Empty value means 0 • Default value must be a number
38. Field Type - Choice <restriction android:defaultValue="@string/default_colors" android:description="@string/description_colors" android:entries="@array/entries_colors" android:entryValues="@array/entry_values_colors" android:key="colors" android:restrictionType="choice" android:title="@string/title_colors"/> • Entries and entryValues are mandatory
39. Field Type - Multi-select <restriction android:defaultValue="@array/default_user_role" android:description="@string/description_user_role" android:entries="@array/entries_user_role" android:entryValues="@array/entry_values_user_role" android:key="user_role" android:restrictionType="multi-select" android:title="@string/title_user_role"/> • Entries and entryValues are mandatory
40. Field Type Hidden <restriction android:defaultValue="@string/default_secret_code" android:description="@string/description_secret_code" android:key="secret_code" android:restrictionType="hidden" android:title="@string/title_secret_code"/> • Not shown to the admin in the UI • Use to provide a Read-only value • Must have a default set
41. Field Type – Bundle Array API Level 23 – Android 6.0 • Contains a subset of restrictions • Contains a bundle • Can dynamically add more items in the array from the Admin UI <restriction android:description="@string/description_bookmarks" android:title="@string/title_bookmarks" android:key="bookmark_list" android:restrictionType="bundle_array"> <restriction android:title="@string/title_bookmark" android:key="bookmark" android:restrictionType="bundle"> <restriction android:title="@string/title_bookmark_key" android:key="bookmark_name" android:restrictionType="string"/> <restriction android:title="@string/title_bookmark_value" android:key="bookmark_value" android:restrictionType="string"/> </restriction> </restriction>
42. Field Type – Bundle Array API Level 23 – Android 6.0
43. Read Configured values private fun stringValueInASingleMethod(key: String = "serverUrl"): String { val restrictionsManager = context.getSystemService(Context.RESTRICTIONS_SERVICE) as RestrictionsManager val entry = restrictionsManager.getManifestRestrictions(context.packageName).first { key == it.key } val applicationRestrictions = restrictionsManager.applicationRestrictions return if (applicationRestrictions.containsKey(key)) { applicationRestrictions.getString(key) } else { entry.selectedString } }
44. Register change receiver • It’s a broadcast receiver which needs to be registered in code • Delivers a notification when the restriction values are updated • Typical use is for kiosk apps, apps for task workers etc..
45. Register change receiver private var broadcastReceiver: BroadcastReceiver? = null public override fun onStart() { super.onStart() broadcastReceiver = object : BroadcastReceiver() { override fun onReceive(context: Context, intent: Intent) { // Fetch and use new values } } this.registerReceiver(broadcastReceiver, IntentFilter(Intent.ACTION_APPLICATION_RESTRICTIONS_CHANGED)) } public override fun onStop() { super.onStop() if (broadcastReceiver != null) { this.unregisterReceiver(broadcastReceiver) broadcastReceiver = null } }
46. Check if device is under management Check for an empty bundle. This means your application acts like it’s unmanaged. There is no configuration being delivered. The app is NOT managed by an EMM system, it has been installed by other means. fun isDeviceManaged(): Boolean = !restrictionsManager.applicationRestrictions.isEmpty
47. Check if device is configured properly Check for a bundle with a single key value pair with KEY_RESTRICTIONS_PENDING set to true. This means your application is being managed, but isn’t configured correctly. You should block this user from your app, and direct them to their IT administrator. API Level 22 – Android 5.1
48. Enable Android Enterprise in EMM
49. Enable Android Enterprise in EMM
50. Enable Android Enterprise in EMM • Use any Google Account (preferably create one that will only be used by the organization)
51. Enable Android Enterprise in EMM
52. Enable Android Enterprise in EMM
53. Enable Android Enterprise in EMM
54. Enable Android Enterprise in EMM
55. Enable Android Enterprise in EMM • This ID will be used by the developers inside google play later on
56. Suggestion – enroll into work profile for testing • Can test the interaction between work and private partitions of the device • Can more easily enable USB debugging and view logs • Easier to remove after done, no need to factory reset device
57. Developers release their app on Google Play
58. Release the app on Google Play
59. Release the app on Google Play • Release process on google Play is exactly the same as any normal app • Turn on Managed Google Play inside Pricing and Distribution to target organizations
60. Release the app on Google Play • App can be released privately only to specific organizations. It wont be visible on the public Google Play store in this case
61. Release the app on Google Play • Distribute the app to multiple organizations by adding their Google Enterprise ID to the list within Google Play
62. Hit the release button and wait! It takes a while…
63. EMM admin needs to approve the app, configure and distribute it
64. EMM Admin approves the app • Visit https://play.google.com/work/apps and approve the app
65. Import into the EMM system • The app is imported into the EMM
66. Create a managed configuration and push it to the devices
67. Create a managed configuration • Enter all the details and save the config • After saving the configuration will be published to the devices • It will be available immediately for any new app installations
68. Thank You! Questions? https://github.com/darko1002001/android-managed-configuration-sample https://github.com/googlesamples/android-AppRestrictionSchema https://appconfig.org Contact Info - Darko Grozdanovski dgrozdanovski@mobileiron.com linkedin.com/in/darko-grozdanovski
